Hans Grohe AXOR Montreux 16859 0 Series Instruction Manual

Citterio
39838XX0
Starck
10859XX0
Montreux
16859XX0
EN Installation/UserInstructions/Warranty
FR Instructionsdemontage/Moded'emploi/Garantie
ES Instruccionesdemontaje/Manejo/Garantía


English
Technical Information
Recommendedwaterpressure 15-75PSI
Max.waterpressure 145PSI
Flowrate .GPM
Holesizeinmountingsurface 1³⁄₁₆"
Max.depthofmountingsurface 1½"
Installation Considerations
Forbestresults,Hansgroherecommendsthat
thisunitbeinstalledbyalicensed,profes-
sionalplumber.
Pleasereadovertheseinstructionsthoroughly
beforebeginninginstallation.Makesurethat
youhavealltoolsandsuppliesneededto
completetheinstallation.
This faucet is for use with cold
water only. Do not connect it to
the hot water supply.
Thisfaucetrequiresa½"malenipple,extend-
ing½"outsidethesurfaceofthenishedwall.
Thewallmustbereinforcedatthemounting
point.
Keepthisbookletandthereceipt(orother
proofofdateandplaceofpurchase)for
thisproductinasafeplace.Thereceiptis
requiredshoulditbenecessarytorequest
warrantyparts.
•
•
•
•
•
10859XX0
39838XX0
16859XX0
25⁵⁄₁₆"
24¹¹⁄₁₆"
14⅛"
3½"
4⁹⁄₁₆"
2¾"
5¹¹⁄₁₆"
1⁹⁄₁₆"
6⁷⁄₁₆"
½"
NPT
26¹⁵⁄₁₆"
25"
14³⁄₁₆"
3⁹⁄₁₆"
2¾"
5⁹⁄₁₆"
½"
NPT
⅝"
4⅜"
26¹⁵⁄₁₆"
25"
14³⁄₁₆"
3⁹⁄₁₆"
2¾"
5⁹⁄₁₆"
½"
NPT
⅝"
4⅜"

3
Français Español
Données techniques
Pressiond’eaurecommandée 15-75PSI
Pressiond’eaumaximum 145PSI
Capaciténominale .GPM
Dimensiondutroudanslasurface 1³⁄₁₆po
 demontage
Profondeurmaximaledelasurface 1½po
 demontage
Datos tecnicos
Presiónrecomendadaenservicio 15-75PSI
Presiónenserviciomax. 145PSI
Caudalmáximo 1.5GPM
Tamañodeloricioenlasupercie 1³⁄₁₆"
 demontaje
Profundidadmáximadela 1½"
 superciedemontaje
À prendre en considération
pour l’installation
Pourdemeilleursrésultats,Hansgroherecom-
mandequeceproduitsoitinstalléparun
plombierprofessionnellicencié.
Veuillezlireattentivementcesinstructions
avantdeprocéderàl’installation.Assurez-
vousdedisposerdetouslesoutilsetdu
matérielnécessairespourl’installation.
Cerobinetrequiertunraccordmâleleté
NPTde½podontunepartiede½podoit
dépasserdelasurfacedumurni.
Installezlessupportsdemontantpourla
bridedexation.
Ce robinet est conçu uniquement
pour l’eau froide.
Conservezcelivretetlereçu(ouuneautre
preuvesurlaquellegurentladateetl’endroit
del’achat)pourceproduitdansunendroit
sûr.Lereçuestrequissivouscommandezdes
piècessousgarantie.
•
•
•
•
•
Consideraciones para la
instalación
Paraobtenermejoresresultados,lainsta-
lacióndebeestaracargodeunplomero
profesionalmatriculado.
Antesdecomenzarlainstalación,leaestas
instruccionesdetenidamente.Asegúresede
tenerlasherramientasylosinsumosnecesa-
riosparacompletarlainstalación.
EstegriforequiereunniplemachoNPTde
½”,queseextienda½”haciaafueradela
superciedelaparedterminada.
Instalelossoportesparaespárragosparala
bridademontaje.
Este grifo es para usar únicamente
con agua fría.
Mantengaestefolletoyelrecibo(uotro
comprobantedellugaryfechadecompra)
deesteproductoenlugarseguro.Elrecibo
serequiereencasodesernecesariosolicitar
piezasbajogarantía.
•
•
•
•
•

4
English
Roughing-in
Thisfaucetrequiresa½"NPTmalenipple,ex-
tending½"outsidethesurfaceofthenished
wall.
Installstudsupportsforthemountingange.
Installation
Positionthemountingangeoverthenipple.
Markthepositionsofthescrewholes.
Drillthescrewholes.
Do not drill into hidden
electrical or plumbing lines.
WrapthethreadsonthenipplewithTeon
tape.
Installtheange.
1
2
31

3
1


5
Français Español
Pièce intérieure
CerobinetrequiertunraccordmâleletéNPTde
½podontunepartiede½podoitdépasserde
lasurfacedumurni.
Installezlessupportsdemontantpourlabridede
xation.
Piezas interiores
EstegriforequiereunniplemachoNPTde½”,
queseextienda½”haciaafueradelasupercie
delaparedterminada.
Instalelossoportesparaespárragosparala
bridademontaje.
Installation
Placezlabridedexationsurleraccordleté.
Marquezlespositionsdestrousdevissage.
Percezlestrousdevissage.
Assurez-vous de ne pas percer
dans les câbles électriques ou con-
duits de plomberie dissimulés.
Enveloppezlesletssurleraccordletéavecdu
rubanTéon.
Installezlabride.
Instalación
Coloquelabridademontajesobreelniple.
Marquelasposicionesdelosoriciosparatornil-
los.
Perforelosoriciosparalostornillos.
No perfore las tuberías eléctricas
o de plomería escondidas.
EnvuelvalasroscasdelnipleconcintadeTeon.
Instalelabrida.

6
English
Installtheescutcheonontheange.
Installthefaucetonthemountingnipple.
Pushtheescutcheonoutoftheway.
Tightenthescrew.
Pushtheescutcheonagainstthewall.
Ifdesired,sealthewallaroundtheescutcheon
usingsiliconesealant.
Do not use petroleum based
putty.
silicone
ok!
4
5
6

7
Français Español
Installezl’écussonsurlabride.
Installezlerobinetsurleraccorddexation.
Déplacezl’écussonpourfairedel’espace.
Serrezlavis.
Poussezl’écussoncontrelemur.
Sinécessaire,scellezlemurautourdel’écussonà
l’aided’unagentd’étanchéitéàbasedesilicone.
N’utilisez pas de mastic à base de
pétrole.
Instalelosescudosenlabrida.
Instaleelgrifoenelnipledemontaje.
Saqueelescudo.
Aprieteeltornillo.
Presioneelescudocontralapared.
Silodesea,sellelaparedalrededordelescudo
conselladordesilicona.
No use masilla a base de petróleo.

8
English
Removetheaerator.
Turnonthewater.
Flushthefaucetandcheckforleaks.
Turnthewatero.
Change the handle (Optional
- Montreux only)
Removethescrewcover,screw,andhandle.
Installthenewhandle.
Installthehandlescrewandscrewcover.
7
1
2
3
1

9
Français Español
Retirezl’aérateur.
Ouvrezl’eau.
Rincezlerobinetetvériezs’ilyadesfuites.
Fermezl’eau.
Changement de poignée
(Étape optionnelle - Montreux
uniquement)
Retirezlecache-vis,lavisetlapoignée.
Installezlanouvellepoignée.
Installezlavisdepoignéeetlecache-vis.
Retireelaireador.
Abraelsuministrodeagua.
Laveelgrifoyveriqueparaasegurarsedeque
nohayapérdidas.
Cierreelsuministrodeagua.
Cambiar la manija (Opcional
- sólo para Montreux)
Retirelatapadeltornillo,eltornilloylamanija.
Instalelamanijanueva.
Instaleeltornillodelamanijaylatapadel
tornillo.

10
User Instructions / Instructions de service / Manejo
Caution: Risk of Injury
Thepotllermaybecomehotwhen
thearmispositionedaboveahot
stoveburner.
Alwayspushthepotllerawayfrom
theburnerafteruse.
Attention : Risque de
blessure
Lerobinetremplisseurpeutdevenir
chaudlorsquelebrasestplacé
au-dessusd’unbrûleurdecuisinière
activé.
Éloigneztoujourslerobinetremplis-
seurdubrûleuraprèsl’utilisation.
Precaución: Riesgo de
lesión
Elgrifoparacacerolaspuedecalen-
tarsecuandoelbrazosecolocaso-
breunquemadordecocinacaliente.
Siempreaparteelgrifoparacacero-
lasdelquemadorluegodeusarlo.

11
Cleaning Recommendation for Hansgrohe Products
Modernbathroomfaucets,kitchenmixersandshowersconsistofverydierentmaterialstocomplywiththeneedsof
themarketwithregardtodesignandfunctionality.Toavoiddamage,itisnecessarytoconsidercertaincriteriawhen
cleaning.
At the cleaning of the ttings and showers, in principle, it must be pointed out:
• Onlyusecleaningmaterialwhichisexplicitlyintendedforthistypeofapplication.
• Neverusecleaningmaterials,whichcontainhydrochloricacid,formicacid,chlorinepalelyeoraceticacid,as
theycauseconsiderabledamage.
• Phosphorusacidiccleanersareonlyconditionallyapplicable.
• Donotmixcleaningagents,unlessdirectedbythemanufacturer.
• Neverusecleaningmaterialsorapplianceswithanabrasiveeect,suchasunsuitablecleaningpowders,
spongepadsormicrobercloths.
• Alwaysfollowtheinstructionsonthecleaningagentpackagewithrespecttospeciedcleanerdosageand
contacttime.
• Thebuildingupofcalcicationshastoberemovedbycleaningregularly.
• Whenusingspraycleaners,sprayrstontoasoftclothorspongeneverdirectlyontotheproduct,asdrops
couldenteropeningsandgapsandcausedamage.
• Aftercleaning,rinsethoroughlywithcleanwatertoremoveanycleanerresidue.
• Theuseofsteamcleanersisnotpermitted.Thehightemperaturescandamagetheproducts.
Important
• Residuesofliquidsoaps,shampoosandshowerfoamscanalsocausedamage,sorinsewithcleanwaterafter
use.
• Thedamageofalreadydamagedsurfaceswilldeteriorateundertheeectofthecleansers.
• Components with damaged surfaces must be replaced, otherwise there is a risk of injury.
• Damage caused by improper treatment is not covered by our warranty.

1
Conseil de nettoyage pour les produits Hansgrohe
Denosjourslesanitairemoderne,larobinetterieetlesdouchettessecomposentdematériauxtrèsdiérentspour
satisfaireàlademandeconcernantledesignetlafonctionnalité.Pouréviterlesdétériorationsetlesréclamations,
aussibienpourl’utilisationquepourlenettoyageprochain,certainscritèresserontàprendreenconsidération.
A prendre en considération lors de l’entretien de la robinetterie et de douchettes:
• Ondoitseulementutiliserlesproduitsdenettoyagequisontformellementprévuspourcedomaine.
• Aucuncontactavecl’applicationdenettoyantscontenantdel’acidechlorhydrique,del’acideformiqueoude
l’acideacétiquequipeuventcauserdeconsidérablesdétériorations.
• Lesnettoyantsàbased’acidephosphorique,aussi,nesontpasàutilisersansréserves.
• Lemélangedenettoyantsengénéraln’estpasautorisé.
• L’utilisationdeproduitsdenettoyagerécurantsetdesustensilescommedesfrottoirs,desépongesàrécureret
destorchonsmicrobresestexclue.
• Lesconseilsd’entretiendesproducteursdenettoyantssontàsuivreobligatoirement.
• Lenettoyageestàfairecorrespondreavecledosage,letempsd’action,spéciqueàl’objetetàlanécessité.
• Ledépôtdecalcaireestévitéparunnettoyagerégulier.
• Pourlenettoyageavecproduitvaporiséliquide,enaucuncassurlarobinetterie,maisaucontraireaspergésur
lechion(torchon,éponge)eteectuercommecelalenettoyage,carlesaérosolspeuventpénétrerdansles
ouverturesetfentesdelarobinetterieetpeuventprovoquerdesdétériorations.
• Aprèslenettoyagerincezavecsusammentd’eauclairepouréliminerlesrestesdeproduitsattachés.
• L’utilisationd’appareildenettoyageàvapeurn’estpasautorisée,carlestempératuresimportantespeuvent
détériorerlesproduits.
Indications importantes
• Lesproduitspourlecorpscommelessavonsliquides,lesshampooingsoulesgelsdedouchepeuventcauser
desdétériorations.
• Iciaussiondoit:Aprèsl’utilisationrincersoigneusementlesrestesavecdel’eau.
Conseil de nettoyage
• Les deteriorations imputables à un mauvais entretien ne peuvent être pris en considération
par notre garantie.
• Parl’actiond’unnettoyantsurlesrevêtementsdéjàendommagéilseproduituneaggravationdes dégâts.desdégâts.

13
Recomendación de limpieza para los productos de Hansgrohe
Hoyendía,lasgriferíasdebañoydecocinaasícomoduchasmodernassecomponendematerialesmuydistintos
parasatisfacerlasexigenciasdelmercadorespectoaldiseñoylafuncionalidad.Paraevitardañosyreclamaciones
hayquetenerencuentaciertosaspectostantoenelusocomoensulimpieza.
Para el cuidado de las griferías y las duchas en principio hay que seguir lo siguiente:
• Usarsólodetergentesprevistosespecícamenteparaestecampodeaplicación.
• Noaplicardetergentesquecontenganácidoclorhídrico,fórmicooacéticoporquepuedencausardaños
importantes.
• Detergentesquecontienenácidofosfóricotampocopuedenseraplicadosilimitadamente.Porreglageneralno
sedebenmezclardetergentes.
• Tampocosedebenutilizarutensiliosabrasivos,comosonpolvosabrasivos,esponjasopañosdemicrobra.
• Setienenqueseguirsiemprelassugerenciasdeempleodelosfabricantesdelosdetergentes.
• Lalimpiezatienequeserrealizadasegúnladosicaciónyeltiempodeactuación,enfuncióndelobjetoy
ajustadaalasnecesidadesespecícasdelmismo.
• Graciasaunalimpiezaperiódicasepuedenevitarlosdepósitosdecal.
• Noconvienerociareldetergenteenningúncasosobrelagriferíasinosobrelostextilesyejecutarlalimpieza
así,porqueellíquidopuedeentrarenaperturasohendidurasdelagriferíaycausardaños.
• Despuésdelalimpiezahayqueaclararconsucienteaguaparaeliminarcompletamenteelrestode
detergente.
• Lautilizacióndelimpiadoresavapornoestápermitida,lasaltastemperaturaspuedendañarlosproductos.
Indicaciones importantes
• Losresiduosdeproductosdeaseocomojabónlíquido,champúsygeldeduchapuedendañartambiénlos
materiales.
• Porloquetambiénsedeberáprestaratenciónalosiguiente:aclararconabundanteaguadespuésdeluso.
• Conmaterialesyadañadoslaaccióndedetergentsincrementaráeldesgastedeestos.
• Los componentes con supercies dañadas deberán cambiarse, en otro caso se corre el
peligro de lesionarse.
• Losdañosqueresultendeunusoinadecuadonoestánincluidosennuestragarantía.

14
Limited Consumer Warranty
ThisproducthasbeenmanufacturedandtestedtothehighestqualitystandardsbyHansgrohe,Inc.(“Hansgrohe”).
ThiswarrantyislimitedtoHansgroheproductsthatarepurchasedbyaconsumerintheUnitedStatesorCanada
afterMarch1,1996,andinstalledineitherintheUnitedStatesorinCanada.
WHO IS COVERED BY THE WARRANTY
Thiswarrantyextendstotheoriginalpurchaseronly.Thiswarrantyisnon-transferable.
WHAT IS COVERED BY THE WARRANTY
ThewarrantycoversonlyyourHansgrohemanufacturedproduct.Hansgrohewarrantsthisproductagainstdefectsin
materialorworkmanshipasfollows:
Hansgrohewillreplaceatnochargeforpartsonlyor,atitsoption,replaceanyproductorpartoftheproductthat
provesdefectivebecauseofimproperworkmanshipand/ormaterial,undernormalinstallation,use,serviceand
maintenance.IfHansgroheisunabletoprovideareplacementandrepairisnotpracticalorcannotbemadein
timelyfashion,Hansgrohemayelecttorefundthepurchasepriceinexchangeforthereturnoftheproduct.
LENGTH OF WARRANTY
Replacementorrepairedpartsofproductswillbecoveredforthetermofthiswarranty,asstatedinthefollowing
twosentences.Ifyouareaconsumerwhopurchasedtheproductforuseprimarilyforpersonal,familyorhousehold
purposes,thiswarrantyextendsforaslongasyouowntheproductandthehomeinwhichtheproductisoriginally
installed.Ifyoupurchasedtheproductforuseprimarilyforanyotherpurpose,including,withoutlimitation,a
commercialpurpose,thiswarrantyextendsonly(i)for1year,withrespecttoHansgrohe&Commercialproducts,
and(ii)for5years,withrespecttoAxorproducts.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A.Conditions,malfunctionsordamagenotresultingfromdefectsinmaterialorworkmanship.
B.Conditions,malfunctionsordamageresultingfrom(1)normalwearandtear,improperinstallation,improper
maintenance,misuse,abuse,negligence,accidentoralteration;()theuseofabrasiveorcausticcleaningagents
or“no-rinse”cleaningproducts,ortheuseoftheproductinanymannercontrarytotheproductinstructions;or(3)
conditionsinthehomesuchasexcessivewaterpressureorcorrosion.
C.Laborandotherexpensesfordisconnection,deinstallation,orreturnoftheproductforwarrantyservice
(includingbutnotlimitedtoproperpackagingandshippingcosts),orforinstallationorreinstallationofthe
product.
D.Accessories,connectedmaterialsandproducts,orrelatedproductsnotmanufacturedbyHansgrohe.
E.AnyHansgroheorAxorproductsoldfordisplaypurposes.
F.RubbedBronzenishissubjecttoa3-yearlimitedwarranty.ChromeandallPVDnishesarecoveredbythe
limitedlifetimewarranty.
 G.HansgroheWaterFiltrationSystemissubjecttoa1-yearlimitedwarranty.Warrantydoesnotinclude
replacementlters.
TO OBTAIN WARRANTY PARTS OR INFORMATION
ContactyourHansgroheretailer,orcontactTechnicalServiceat:
Hansgrohe,Inc.
149BluegrassLakesParkway
Alpharetta,GA30004
Toll-free800-334-0455
Inrequestingwarrantyservice,youwillneedtoprovide:
1.Thesalesreceiptorotherevidenceofthedateandplaceofpurchase.
.Adescriptionoftheproblem.
3.Deliveryoftheproductorthedefectivepart,postageprepaidandcarefullypackedandinsured,to:
Hansgrohe,Inc.
149BluegrassLakesParkway
Alpharetta,GA30004
Toll-free800-334-0455

15
Whenwarrantyserviceiscompleted,anyrepairedorreplacementproductorpartwillbereturnedtoyoupostage
prepaid.
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE
PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER.
HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY
OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT. HANSGROHE SHALL
NOT BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, ARISING OUT OF BREACH OF THIS WARRANTY OR ANY IMPLIED
WARRANTY (INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY).
SomeStatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages,sotheabovelimitation
orexclusionmaynotapplytoyou.Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights
thatvaryfromstatetostate.
TO THE EXTENT PERMITTED BY LAW, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE EXPRESS
WARRANTY.
Somestatesdonotallowlimitationsonhowlonganimpliedwarrantymaylast,sotheabovelimitationsmaynot
applytoyou.Youmayberequiredbylawtogiveusareasonableopportunitytocorrectorcureanyfailureto
complybeforeyoucanbringanyactionincourtagainstusundertheMagnuson-MossWarrantyAct.
PRODUCT INSTRUCTIONS AND QUESTIONS
Uponpurchaseorpriortoinstallation,pleasecarefullyinspectyourHansgroheproductforanydamageorvisible
defect.Priortoinstalling,alwayscarefullystudytheenclosedinstructionsontheproperinstallationandthecareand
maintenanceofthisproduct.Ifyouhavequestionsatanytimeabouttheuse,installationorperformanceofyour
Hansgroheproduct,orthiswarranty,pleasewriteusorcallustoll-freeat800-334-0455.

Hansgrohe,Inc.•1490BluegrassLakesParkway•Alpharetta,GA30004
Tel.800-334-0455•Fax770-360-9887
www.hansgrohe-usa.com
US-InstallationInstructions•PartNo.•Revised11/010
