Hans Grohe Metris Select 320 1jet Series Manual

ZH 用户手册/组装说明 2
EN Instructions for use / Assembly instructions 3
Lesezeichen
中文 2
English 3
Metris Select 320 1jet
14883007

2
中文
安装 (参见第页4)
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
冷热水管间过大的压力差必须予以平衡。
安装提示
• 安装前必须检查产品是否受到运输损害。安装后将不认可运输损害或
表面损伤。
• 管道和阀门必须根据通用标准进行安装、冲洗和检查。
• 请遵守当地国家现行的安装规定。
• 首次调试时和维护作业之后，管接头中的空气可能产生噪音。大约使
用管接头15次后噪音消失。
技术参数
工作压强： 最大1MPa
推荐工作压强： 0,1-0,5MPa
测试压强： 1,6MPa
(1MPa=10bar=147PSI)
热水温度： 最大60°C
热力消毒:70°C/4分钟
• 该产品专为饮用水设计！
• 自动防止回流
符号说明
请勿使用含有乙酸的硅胶！
调节 (参见第页6)
热水温度调节。如果使用即热式喷头，则不建议安装热水阀门。
保养 (参见第页9)
单向阀必须在符合国家或当地的法律的情况下按照EN806-5定期检查(至
少一年一次)。
大小 (参见第页8)
流量示意图 (参见第页8)
备用零件 (参见第页10)
清洗 (参见第页7)
操作 (参见第页6)
• 汉斯格雅建议，清晨或在水流长时间停滞后，前半升水不作饮用水使
用。
• 通过手柄打开阀门时出水口可能流出少量水。
• 抬起把手打开龙头，并调节需要的水温。通过位于正面出水口的调节
钮可以暂时停止水流。长时间不使用时，例如夜晚或房屋空置，则必
须将把手完全关闭。
问题 原因 补救
没有水 - 回流截止阀杵杆(A)未安装 - 安装杵杆(A)(参见第页32/36)
龙头不灵活 - 阀芯损坏，结垢 - 更换阀芯
龙头滴水 - 阀芯损坏 - 更换阀芯
水从龙头出水嘴流出 - O形环损坏 - 更换O形环
水从螺纹底座中流出 - 连接软管没有完全旋入基体 - 用手拧紧连接软管
- 连接软管的O形环损坏 - 更换O形环
热水温度过低 - 温度限制器设置错误 - 设置温度限制器
更换龙头后，在打开可调龙头时流量减少 - 安装了错误的可调龙头 - 更换可调龙头(#98463000)
调节按钮不好用 - 调节按钮脏污 - 清洁调节按钮，给O形环23x1,5上油
(参见第页10)

3
English
Assembly (see page 4)
Safety Notes
Gloves should be worn during installation to prevent crushing and cutting
injuries.
The hot and cold supplies must be of equal pressures.
Installation Instructions
• Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
• The pipes and the fixture must be installed, flushed and tested as per the
applicable standards.
• The plumbing codes applicable in the respective countries must be observed.
• During initial start-up and after servicing, air in the fittings can cause noise. After
switching the jet on and off about 15 times, the noise will stop.
Technical Data
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C / 4 min
• The product is exclusively designed for drinking water!
• Safety against backflow
Symbol description
Do not use silicone containing acetic acid!
Adjustment (see page 6)
To adjust the hot water limiter. Using a hot water limiter in combination with a
continuous flow water heater is not recommended.
Maintenance (see page 9)
The check valves must be checked regularly according to EN 806-5 in accord-
ance with national or regional regulations (at least once a year).
Dimensions (see page 8)
Flow diagram (see page 8)
Spare parts (see page 10)
Cleaning (see page 7)
Operation (see page 6)
• Hansgrohe recommends not to use as drinking water the first half liter of water
drawn in the morning or after a prolonged period of non-use.
• Minor leaking may occur briefly at the spout when opening the fitting via the
lever.
• Use the lever to open the tap and set the desired temperature. The water flow
can be paused by pressing the Select button on the face side of the spout.
When the tap is not used for a longer period of time, f.e. when retiring at night
or leaving the house, it must be closed completely by means of the lever.
Fault Cause Remedy
No water - No plunger (A) for the backflow preventer was
installed
- Install plunger (A) (see page 32 / 36)
Mixer stiff - Cartridge defective, calcified - Exchange cartridge
Mixer dripping - Cartridge defective - Exchange cartridge
Water escaping in area of swivel spout - O-ring defective - Exchange O-ring
Water escaping at the threaded base - connection hoses not completely screwed into basic
body
- Tighten connection hoses by hand
- O-ring at the connection hose defective. - Exchange O-ring
Hot water temperature too low - Hot water limiter incorrectly set - Set hot water limiter
Low flow with Select valve after valve replacement - Improper Select valve installed - Replace Select valve (#98463000)
Select button stiff - Select button soiled - Clean Select button and grease 23x1,5 O-ring
(see page 10)

4
(3 Nm)
max. 35 mm
max. 60 mm
1a 21b
150°
110°
6a
6b
TX20
4 5a
5b
SW 24 mm
(4 Nm)
1.
SW 10 mm
SW 19 mm
(4Nm)
2.
3.
1.
2.
3
!
75°
75°
55°
95°
55°
95°
360°
150°
1
5
0
°
TX20
(2 Nm)
(A)
6a
MontageMontage

5
> 2 min
2.
1.
3.
1.
2.
!
!
360°
55°
55°
35°
75°
75°
35°
SW 22 mm
110°
1
1
0
°
TX20
(2 Nm)
SW 22 mm
(2 Nm)
7 8 9
10
6b
Montage

0,3 MPa
60 °C 10 °C
6
+
+
21 3 4
5 6 7
4.
3.
1.
2.
3.
1.
2.
6 x
36°C
38°C
43°C
50°C
55°C
60°C
17 x
4 mm
4 mm
(5 Nm)
4 mm
4 mm
关 / close
开 / open 热 / hot
冷 / cold
开 / open
关 / close
Justierung / Bedienung

7
English
Cleaning Recommendation for Hansgrohe Products
Today, modern sanitary and kitchen tapware, showers, accessories, washstands,
tubs and radiators consist of very different materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider cer
tain criteria when
cleaning.
With regard to caring for the Hansgrohe products, the fol-
lowing must in principle be heeded:
• Only use cleaning material which is explicitly provided for this type of applica-
tion.
• Never use cleaning materials, which contain hydrochloric acid, formic acid,
chlorine pale lye or acetic acid, as they cause considerable damage.
• Phosphorus acidic cleaners are only conditionally applicable.
• Mixing cleaning agents is not permitted, generally.
• Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
• The instructions of the cleaning agent manufacturers have to be followed
absolutely.
• Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
• The building up of calcifications has to be removed by cleaning regulary.
• When using spray cleaners, spray the cleaning solution onto a soft cloth or
sponge, never directly onto the Hansgrohe products, as the atomised spray
could enter openings and gaps in the Hansgrohe products and cause damage.
• After cleaning rinse thoroughly with clean water to remove any cleaner residue.
• The use of steam cleaners is not permitted. The high temperatures can damage
the products.
Important
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
Components with damaged surfaces must be exchanged,
otherwise there could be an injury danger.
Damage caused by improper treatment will not be covered by our guarantee.
Warranty
Hansgrohe guarantees to the consumer that this product is free of production faults.
If evertheless any defect is detected within 5 years from date of purchase, Hans-
grohe will remedy this defect free of charge. You will find the conditions and details
of this guarantee at www.hansgrohe-int.com/guarantee. Please contact your
contracting party to claim your rights under this guarantee. This guarantee does not
affect the customer‘s rights under the respective national legislation.
QuickClean
The QuickClean cleaning function only needs a small manual rub over to remove
the lime scale from the spray channels.
•
•
•
•
•
•
•
•
•
•
•
Hansgr
ohe
Hansgrohe
w
ww.hansgrohe-int.com/guarantee
Q
uickClean
QuickClean
QUICK
CLEAN
Reinigung

8
223
13°
307
257
365
183
163
110
157
Ø 34
max. 60
183
835
G 3/8
208
79
57
121
365
G 3/8
G 1/2
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
Metris Select 320 1jet
14883007
Metris Select 320 1jet
14883007
Maße / Durchflussdiagramm

9
SW 10 mm SW 19 mm
12 3
SW 10 mm
SW 19 mm
(4 Nm)
1.
2.
Wartung

10
98462000 92287000
(23x1,5)
92289000
95140000
97523000
96456000
95291000
95372000
97548000
92481000
(11x3)
92961000
92730000
95008000
97209000 98455000
96338000
95049000
98189000
(14x2,5)
97558000
92646000
98368000
98193000
(32x2)
95498000
92288007
A
98486000
(110° / 150°)
Armaturenfett
Grease
䀵滑油
93395000
(G⅜ / G½)
Metris Select 320 1jet
14883007
Serviceteile

11

Hansgrohe · Auestraße 5 – 9 · D-77761 Schiltach · Telefon [phone] · Telefax +49 (0) 7836/511440
E-Mail: [email protected] · Internet: www.hansgrohe.com
07/2021 9.02485.52
