Hans Grohe Swing C 04053 0 Series Installation guide

Swing C
04053xx0
Swing C
04054xx0
Swing C
04055xx0
Solaris E
04056xx0
Installation Instructions / Warranty

2
Technical Information
Recommended operating pressure 45 - 80 psi
Recommended hot water temp. 120°- 140° F*
Flow rate 2.2 gpm
Hole sizes
Valves 1 1/4"
Transfer valve 1 1/4"
Pull rod 3/8" min.
Requires 1/2" supply hoses -- not included.
*Please know and follow all applicable local codes when setting the
temperature on the water heater.
Installation Considerations
• For best results, Hansgrohe recom-
mends installation by a licensed profes-
sional plumber.
• The hot and cold supplies should be
flushed thoroughly prior to installation
of this faucet.
• This valve is for use on vertical spray
bidets only. It is not suitable for use on
other fixtures.
• The transfer valve has an integral
vacuum breaker.
Vertical Spray Bidet Mixer
Swing C
04053xx0 Cross handles
04054xx0 Scroll handles
04055xx0 Lever handles
04055xx0
04054xx004053xx0
Solaris E
04056xx0
04056xx0

3
Install the spray assembly
Position the spray and sealing washer in the hole in the
bidet.
Install the washer and mounting nut.
Connect the spray hose to the spray.
Do not to twist or kink the hose.
Install the transfer valve
Install the y-connector and seal on the bottom of the
transfer valve. Screw the connecting hoses to the
y-connector.
Screw the elbow connector to the outlet port on the side
of the transfer valve. The arrow on the elbow connector
indicates the direction of the water flow. It should point
downward.
Screw the spray hose to the elbow connector.
Push the transfer valve, nylon washer, and one of the
china seals (tapered side up) through the transfer valve
hole in the bidet.
Install the second china seal, tapered side down.
Thread the valve mounting nut to the top of the transfer
valve as far as it will go. The valve mounting nut should
rest on the mounting surface.
Make sure that the transfer valve stands straight.
Overtightening the nut may result in
damage to the bidet.
1
2
3
1
2
3
1
2

4
Install the pop-up guide assembly
Remove the nut, metal washer, and sealing washer from
the pop-up guide assembly.
Position the pop-up guide and sealing washer on the
proper hole on the bidet.
Install the metal washer and nut.
Install the valves – 04056xx0 only
Remove the valve mounting nuts from the valves.
Push the valves up into the holes. Install the mounting nuts
on the valves.
Tighten the tensioning screws.
Overtightening the screws may re-
sult in damage to the bidet.
Overtightening the nut may result in
damage to the bidet.
4
5
6
1
2
12

5
Install the valves – all other models
Remove the mounting plates and stop rings from the
valves.
Push the valve up through the hole. Slide the stop ring
onto the valve. Install the mounting plate. The stop ring
will stop it at the proper height.
Rest the mounting plate on the mounting surface.
Tighten the nut against the underside of the mounting
surface. Tighten the tensioning screws.
Connect the connecting hoses to the valve
outlets – all models
Hold the hose steady with one wrench while tightening
the hose nut with a second wrench.
Do not twist or kink the hose.
Install the handles – Model 04056xx0
only
Place the handles over the valve mounting nuts. Tighten
the handles by rotating the escutcheons clockwise.
Overtightening the nut or screws
may result in damage to the bidet.
Install the hot and cold supply lines (not included) on the
valve inlets.
7
8
9
1
2

6
Install the handles – all other models
Install the deco rings on the handles.
Hold the lever or cross part of the handle in the desired
“off” position with one hand. With the other hand, turn
the bell part of the handle clockwise, so
that it threads down over the valve stem.
Install the transfer valve trim
Screw the sleeve down onto the transfer valve.
Push the handle over the stem and secure it with the
screw.
Line up the locator tab on the screw cover with the notch
in the handle. Press the screw cover down firmly.
10
11
1
2

7
Installation / Installation / Instalación
1 2
3 4
5 6

8
User Instructions
on off
cold hot
Note: Water will continue to flow from
the rim wash while the vertical spray
runs. This is normal and does not indi-
cate a product defect.

9
1 valve set 88503000
2 mounting kit 88511000
3 hot cartridge 94009000
4 cold cartridge 94008000
5 transfer valve 88632000
6 sleeve 88635xx0
7 transfer valve handle 88636xx0
8 hot/cold connection hose 88631000
9 spray hose 88630000
10 pull rod 88634xxX
11 aerator 88633xx0
12 deco ring 88600xx0
13 valve set 97960000
14 lever handle 88612xx0
15 cross handle 88614xx0
16 scroll handle, cold 88613xx0
scroll handle, hot 88642xx0
17 Solaris E handle 95244xx0
Replacement Parts
xx = color
00 = chrome
62 = oil rub bronze
82 = brushed nickel
83 = polished nickel
1
2
3
4
5
6
7
8
910
11
12
5
8
9
10
11
3
4
13
6
717
14 15 16

10
Cleaning Recommendation for Hansgrohe Products
Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the
needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take
proper care of it.
For best results:
• Prevent the buildup of mineral scale and /or soap residue by cleaning your Hansgrohe product(s) when
needed.
• Select a cleaning agent specifically intended for the type of product.
• Do not use these types of cleaners as they will cause damage to your Hansgrohe product:
 Any cleaning agent containing hydrochloric acid, formic acid, lye, or acetic acid.
 Abrasive cleaning powders, pads, or brushes.
 Steam cleaners.
 “No rinse” cleaning agents.
• Always follow the instructions provided by the manufacturer of the cleaning agent.
• Do not mix cleaning agents, unless directed by the manufacturer.
• Do not spray cleaners directly onto the product as drops could enter openings and gaps and cause damage.
When using spray cleaners, spray the cleaner onto a soft cloth or sponge.
• Always rinse your Hansgrohe product thoroughly with clear water and polish dry with a soft cloth after
cleaning.
Important
• Residue from soaps and shampoos can cause damage. Rinse the product with clean water after each use.
• Residue from basin/tub/tile cleaner can cause damage to faucets and fittings. Immediately rinse any
overspray from the Hansgrohe product.
• Damage to the product caused by improper care or the use of improper cleaning agents is
not covered by the warranty.
• If a component of the product is damaged, replace it, as there is risk of injury.

11
Limited Consumer Warranty
This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”).
This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after
March 1, 1996, and installed in either in the United States or in Canada.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original purchaser only. This warranty is non-transferable.
WHAT IS COVERED BY THE WARRANTY
The warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in
material or workmanship as follows:
Hansgrohe will replace at no charge for parts only or, at its option, replace any product or part of the product
that proves defective because of improper workmanship and/or material, under normal installation, use, service
and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be made
in timely fashion, Hansgrohe may elect to refund the purchase price in exchange for the return of the product.
LENGTH OF WARRANTY
Replacement or repaired parts of products will be covered for the term of this warranty, as stated in the following two
sentences. If you are a consumer who purchased the product for use primarily for personal, family or household purposes,
this warranty extends for as long as you own the product and the home in which the product is originally installed. If
you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose,
this warranty extends only (i) for 1 year, with respect to Hansgrohe & Commercial products, and (ii) for 5 years, with
respect to Axor products.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions or damage resulting from (1) normal wear and tear, improper installation, improper
maintenance, misuse, abuse, negligence, accident or alteration; (2) the use of abrasive or caustic cleaning agents
or “no-rinse” cleaning products, or the use of the product in any manner contrary to the product instructions; or
(3) conditions in the home such as excessive water pressure or corrosion.
C.Labor and other expenses for disconnection, deinstallation, or return of the product for warranty service
(including but not limited to proper packaging and shipping costs), or for installation or reinstallation of the product.
D. Accessories, connected materials and products, or related products not manufactured by Hansgrohe.
E. Any Hansgrohe or Axor product sold for display purposes.
F. Rubbed Bronze finish is subject to a 3-year limited warranty. Chrome and all PVD finishes are covered by the
limited lifetime warranty.
G. Hansgrohe Water Filtration System is subject to a 1-year limited warranty. Warranty does not include
replacement filters.
TO OBTAIN WARRANTY PARTS OR INFORMATION
Contact your Hansgrohe retailer, or contact Technical Service at:
Hansgrohe, Inc.
1492 Bluegrass Lakes Parkway
Alpharetta, GA 30004
Toll-free 800-334-0455
In requesting warranty service, you will need to provide:
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to:
Hansgrohe, Inc.
1492 Bluegrass Lakes Parkway
Alpharetta, GA 30004
Toll-free 800-334-0455
When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid.

Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004
Tel. [phone] • Fax [phone]
www.hansgrohe-usa.com
US - Installation Instructions • Part No. 90566301-03 • Revised 9/2013
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS
PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE
NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR
LIABILITY IN CONNECTION WITH THIS PRODUCT. HANSGROHE SHALL NOT BE LIABLE TO PURCHASER
OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ARISING
OUT OF BREACH OF THIS WARRANTY OR ANY IMPLIED WARRANTY (INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY).
Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation
or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights
that vary from state to state.
TO THE EXTENT PERMITTED BY LAW, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE EXPRESS WARRANTY.
Some states do not allow limitations on how long an implied warranty may last, so the above limitations may not apply
to you. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before
you can bring any action in court against us under the Magnuson-Moss Warranty Act.
PRODUCT INSTRUCTIONS AND QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any damage or visible defect.
Prior to installing, always carefully study the enclosed instructions on the proper installation and the care and maintenance
of this product. If you have questions at any time about the use, installation or performance of your Hansgrohe product,
or this warranty, please write us or call us toll-free at 800-334-0455.
