Harbor Freight Tools luminarEVERYDAY 59249 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 23b
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 59249
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
To reduce the risk of FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
1. Use only insulated staples or
plastic ties to secure cords.
2. Route and secure cords so that they
will not be pinched or damaged when
the cabinet is pushed to the wall;
3. Position the portable cabinet light with respect to
the cabinet so the lamp replacement markings
are able to be read during relamping;
4. Not intended for recessed installation
in ceilings, or soffits; and
5. The National Electrical Code (NEC) does not permit
cords to be concealed where damage to insulation
may go unnoticed. To prevent fire danger, do not
run cord behind walls, ceilings, soffits, or cabinets
where it may be inaccessible for examination.
Cords should be visually examined periodically and
immediately replaced when any damage is noted.
6. Install only according to these instructions.
Improper installation can create hazards.
7. Avoid electric shock. Keep plugs and receptacles
dry. Use only on GFCI-protected circuits.
8. Not suitable for damp locations.
9. Wear ANSI-approved goggles and heavy-
duty work gloves during installation.
10. Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
11. Do not operate the Light in explosive atmospheres,
such as in the presence of flammable liquids,
gases or dust. The Light generates sparks
which may ignite the dust or fumes.
12. Do not abuse the Power Cord. Never use the Cord
for unplugging the Light. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
13. Maintain the Light. Check for breakage of
parts and any other condition that may affect
the Light’s operation. If damaged, have it
repaired before use. Many accidents are
caused by poorly maintained items.
14. Maintain labels and nameplates on the
Light. These carry important safety
information. If unreadable or missing, contact
Harbor Freight Tools for a replacement.
15. This product is not a toy. Keep it
out of reach of children.
16. Do not install directly over a heat source (stove, etc.).
17. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
18. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.

Page 3For technical questions, please call 1-888-866-5797.Item 59249
IMPORTANT SAFETY INSTRUCTIONS
CAUTION! This portable luminaire has a polarized plug (one blade is wider than the other) as a
feature to reduce the risk of electric shock. This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Never use with an extension cord unless plug can be fully inserted. Do not alter the
plug. TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT
SAVE THESE INSTRUCTIONS.
Symbology
Double Insulated
VAC Volts Alternating Current
AAmperes
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover ventilation ducts.
Keep flammable objects away.
WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.

Page 4 For technical questions, please call 1-888-866-5797. Item 59249
Specifications
Electrical Rating 120 VAC / 60Hz / 6W / 0.055A
Lumens 450
CCT Selectable 2700k, 3000k, 4000k
Linkable Lights 30 Units Maximum
Linking Cable Length 21"
Power Cord Length 5 ft.
Mounting Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
Surface Mounting
WARNING! TO PREVENT SERIOUS INJURY:
Verify that installation surface has no hidden
utility lines before drilling or driving Screws.
Note: The maximum distance to the receptacle
is determined by the length of cord provided.
1. Position the Light where it will be
mounted, mark Screw hole locations at
each keyhole on the Light ends.
Mark Screw holes
2. Remove the Light and drive the 2 mounting
Screws into the marked positions. Leave
Screw heads protruding approximately
1/8" beyond the mounting surface.
1/8 inch
Protrusion
3. Align large ends of keyholes on Light
with Screws on mounting surface.
4. Slide Light towards small ends of keyholes to secure.
5. Connect no more than thirty Under Cabinet
Lights together by plugging Linkable
Power Cables into power receptacles.
Linkable
Power Cable
Power Cord
6. Plug power cord into 120VAC grounded receptacle.

Page 5For technical questions, please call 1-888-866-5797.Item 59249
Operation
1. The Light has a 4-way Power Switch;
• Off
• 2700k Warm White
• 3000k Soft White
• 4000k Bright White
2. Turn on Power Switch(es) to the desired selection.
3. Turn off the Power Switch(es) when
finished using the Light(s).
Maintenance
Procedures not specifically explained in this manual must
be performed only by a qualified technician
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Unplug the Light from its electrical outlet before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM LIGHT FAILURE:
Do not use damaged equipment. If damage is noted, have the problem corrected before further use.
1. BEFORE EACH USE, inspect the general
condition of the Under Cabinet Light. Check for:
• loose hardware
• misalignment or binding of moving parts
• damaged cord/electrical wiring
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. PERIODICALLY, clean the Diffuser Cover with
nonabrasive glass cleaner and a clean cloth.
WARNING! TO PREVENT SERIOUS INJURY: If
the supply cord of this light is damaged, it must be
replaced only by a qualified service technician.

Page 6 For technical questions, please call 1-888-866-5797. Item 59249
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175463777 when ordering parts.

Page 7For technical questions, please call 1-888-866-5797.Item 59249
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
