Harman Kardon AVR 3650 User manual

7.1-channel, 110-watt audio/video receiver with HDMI®v.1.4a for 3-D, Deep Color and Audio Return Channel
AVR 3650
Specifications
Harman Kardon AVR 3650
If you’re looking for an AVR packed with next-generation
technology, look no further than the Harman Kardon
AVR 3650. The AVR 3650 has an impressive list of
features that take home entertainment to the next level.
With HDMI®v.1.4a with 3-D and all the latest Dolby®and
DTS®audio modes, the AVR 3650 lets you experience
a new dimension in TV viewing (when combined with a
3-D TV) – while also giving you the benefit of the
Harman Kardon brand’s own Logic 7®processing, which
helps create a 360-degree soundstage through 7.1
channels of surround sound and has network connectivity
for Internet radio and music file streaming from a home
network. And just know: This AVR does far more than
just movies and soundtracks. Revel in the fact that you
can now play music in any room of the house using the
receiver’s multiroom audio functionality. And with six HDMI
inputs (including one on the front panel), extensive video
and audio connectivity, and the ability to connect with
The Bridge IIIP for iPod/iPhone playback, the AVR 3650
solidifies itself as a versatile receiver that accommodates
every entertainment whim with grace, style and ease.
Highlights
HDMI v.1.4a with 3-D, Deep Color and Audio Return Channel
Powers an entire 7.1-channel surround-sound system
110 watts of power per channel
Network connectivity to access a world of music and
entertainment via the Web
Dolby Volume
Dolby TrueHD and DTS-HD Master Audio™decoding
Logic 7 processing
The Bridge IIIP connectivity
Internet radio and home network connectivity for
audio-file streaming
EzSet/EQ™technology
Music playback from USB
Multizone functionality
Surround-sound decoding
Six HDMI inputs
Extensive audio connectivity
Color-coded binding-post speaker connectors
Multi-device programmable remote
FM stereo/FM/AM tuner
SIRIUS Satellite Radio®-ready

HARMAN Consumer, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA www.harmankardon.com
© 2011 HARMAN International Industries, Incorporated. All rights reserved.
Harman Kardon and Logic 7 are trademarks of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. EzSet/EQ is a trademark of HARMAN
International Industries, Incorporated. Control4 is a registered trademark of Control4 Corporation. Dolby and Pro Logic are registered trademarks of Dolby Laboratories. DTS is a registered
trademark of DTS, Inc. DTS-HD Master Audio is a trademark of DTS, Inc. HDMI is a registered trademark of HDMI Licensing LLC. iPod and iPhone are trademarks of Apple Inc., registered in the
U.S. and other countries. iPod/iPhone not included. SIRIUS Satellite Radio is a registered mark of SIRIUS XM Radio Inc. SIRIUS Connect is a trademark of SIRIUS XM Radio Inc.
Features, specifications and appearance are subject to change without notice
7.1-channel, 110-watt audio/video receiver with HDMI®v.1.4a for 3-D, Deep Color and Audio Return Channel
Key Features
Power/Technology
■Powers a 7.1-channel surround-sound system
■ 110 watts of power per channel
■ High instantaneous-current capability (HCC), ultrawide-bandwidth
amplifier design for accurate, dynamic sound and emotion
■ HDMI v.1.4a with 3-D for playing 3-D TV or 3-D movies
■HDMI Audio Return Channel and Deep Color
■Dolby Volume maintains the same volume level – no matter
what program or channel you’re watching
■Dolby TrueHD and DTS-HD Master Audio decoding for high-
resolution sound that matches high-resolution video
■Logic 7 processing turns conventional stereo sources into
incredible 7.1-channel surround sound
■FM/AM radio with 30 station presets
■Internet radio and home network connectivity for audio-file
streaming
■EzSet/EQ capability automatically adjusts individual speaker
volume levels, delay and equalization
■Multizone functionality allows you to play music in other zones
using the dedicated Zone 2 IR remote control
■Dolby Pro Logic®IIz surround-sound decoding for a more
in-depth surround-sound experience
■Decoding for all varieties of Dolby Digital and DTS soundtracks
■Lip-sync adjustment delays the audio signal to match the
video signal
■Screen-saver function prevents image burn-in on CRT and
plasma displays
Connectivity
■Network connectivity allows for streaming media files from
your home network and Internet radio stations via a broadband
connection
■Assignable SBL and SBR amplifier channels for flexibility during
configuration
■ Works with The Bridge IIIP (optional) to play entertainment from
your iPod or iPhone device
■ Six HDMI inputs for extensive video connectivity
■ Two component and two composite video inputs
■Four digital audio inputs and three analog audio inputs
■Front-panel USB port plays music from memory sticks
■ Zone 2 line output expands your system into an additional room
■Subwoofer pre-out allows for connection to a powered subwoofer
■Color-coded binding-post speaker connectors for secure
connections
■ Headphone jack with HARMAN Headphone surround mode for
stereo headphones
■ Remote (IR) in/out connections
■ Upgradeable firmware via USB port
■ Detachable IEC power cord
■ SIRIUS Satellite Radio-ready capability
Ease of Use
■ Graphical user interface (GUI) for easy system set up
■Multi-device programmable remote to control your entire
audio/video system
■Two-line dot-matrix information display lets you adjust the unit
without turning on the TV – and is great when listening to music
■Control4®-certified technology allows the receiver to be used
with a centralized home integration and control system
Key Specifications
Audio Section
■Stereo mode continuous average power: 110 watts/channel,
20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms
■Multichannel power: 110 watts/channel, 20Hz – 20kHz,
<0.07% THD, two channels driven @ 8 ohms
■Bandwidth @ 1W (+0dB/–3dB): 10Hz – 130kHz
■Input sensitivity/impedance (line-in): 200mV/47k ohms
■Signal-to-noise ratio (IHF-A): 100dB
■Adjacent channel separation – Dolby Pro Logic I/II: 40dB,
Dolby Digital: 55dB, DTS: 55dB
■High instantaneous-current capability (HCC): ±45 amps
■Transient intermodulation distortion (TIM): immeasurable
■Slew rate: 40V/μsec
FM Tuner Section
■Frequency range: 87.5MHz – 108.0MHz
■Usable sensitivity (IHF): 1.3μV/13.2dBf
■Signal-to-noise ratio (mono/stereo): 70dB/68dB
■Distortion (mono/stereo): 0.2%/0.3%
■Stereo separation: 40dB @ 1kHz
■Selectivity (±400kHz): 70dB
■Image rejection: 80dB
■IF rejection: 90dB
AM Tuner Section
■Frequency range: 522kHz – 1710kHz
■Signal-to-noise ratio: 45dB
■Usable sensitivity (loop): 500μV
■Distortion (1kHz): 50%, mod 0.8%
■Selectivity (±10kHz): 30dB
Video Section
■Television format: NTSC
■Input level/impedance: 1Vp-p/75 ohms
■Output level/impedance: 1Vp-p/75 ohms
■Video frequency response (composite video): 10Hz – 8MHz (–3dB)
■HDMI v.1.4a with 3-D, Audio Return Channel and Deep Color
General
■Power requirement: AC 120V/60Hz
■Power consumption: 120W idle; 1405W maximum
(seven channels driven)
■Dimensions (H x W x D): 440mm x 165mm x 435mm
(17-5/16" x 6-1/2" x 17-1/8")
■Weight: 19.95 kg (44 lb)
AVR 3650
