HART HPRL01 User manual

HPRL01 20V
Rotary Tool
Outil rotatif
Herramienta rotatoria
OPERATOR’S MANUAL
General Power Tool Safety Warnings 2-3
Rotary Tool Safety Warnings 3-5
Symbols 6
Features 6
 Assembly 7
 Operation 7-10
 Maintenance 10
 Illustrations 11-13
 Parts/Service
 Backpage
MANUEL D’UTILISATION
 Avertissementsdesécuritégénérales 2-3
 relativesauxoutilsélectriques
 Avertissementsdesécuritérelatifs 3-6
outil rotatif
Symboles 6
Caractéristiques7
 Assemblage 7
 Utilisation 7-10
 Entretien 10
 Illustrations 11-13
 Commandedepiècesetdépannage
 Pagearrière
MANUAL DEL OPERADOR
Advertenciasdeseguridadpara 2-3
 herramientaseléctrica
 Advertenciasdeseguridadde 3-6
rotatoria
 Símbolos 6-7
Características 7
 Armado 7
 Funcionamiento 7-10
 Mantenimiento 10
 Illustraciones 11-13
 Pedidosdepiezasyservicio
 Pág.posterior
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
WARNING: To reduce the risk of
injury, the user must read and understand the
operator’s manual before using this product.
CE LIVRET D’INSTRUCTIONS CONTIENT DES
CONSIGNES DE SÉCURITÉ IMPORTANTES.
VEUILLEZ LE LIRE ET LE CONSERVER POUR
TOUTE RÉFÉRENCE FUTURE.
AVERTISSEMENT : Pour
réduire les risques de blessures, l’utilisateur
doit lire et veiller à bien comprendre le manuel
d’utilisation avant d’employer ce produit.
ESTE FOLLETO DE INSTRUCCIONES CONTIENE
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LÉALO Y CONSÉRVELO PARA REFERENCIA
FUTURA.
ADVERTENCIA: Para reducir
el riesgo de lesiones, el usuario debe leer y
comprender el manual del operador antes de
usar este producto.

2 – English
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failuretofollowallinstructionslistedbelowmayresult
inelectricshock,fireand/orseriousinjury.
Save all warnings and instructions for future refer-
ence. Theterm“powertool”inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless)powertool.
WORK AREA SAFETY
Keep work area clean and well lit. Clutteredordark
areasinviteaccidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust.Powertoolscreatesparkswhichmayignitethe
dustorfumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodifiedplugsand
matchingoutletswillreduceriskofelectricshock.
Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators.
Thereisanincreasedriskofelectricshockifyourbody
isearthedorgrounded.
Do not expose power tools to rain or wet conditions. Water
enteringapowertoolwillincreasetheriskofelectricshock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
orentangledcordsincreasetheriskofelectricshock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Useofacord
suitableforoutdoorusereducestheriskofelectricshock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply.UseofaGFCIreducestherisk
of electric shock.
Use this product only with batteries and chargers listed
in tool/appliance/battery pack/charger correlation
supplement 995000850.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of
drugs, alcohol or medication.Amomentofinattention
whileoperatingpowertoolsmayresultinseriouspersonal
injury.
Use personal protective equipment. Always wear eye
protection.Protectiveequipmentsuchasdustmask,non-
skidsafetyshoes,hardhat,orhearingprotectionusedfor
appropriateconditionswillreducepersonalinjuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carryingpowertools with yourfingeron the switchor
energizingpowertoolsthathavetheswitchoninvites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. Awrenchorakeyleftattachedtoa
rotatingpartofthepowertoolmayresultinpersonalinjury.
Do not overreach. Keep proper footing and balance at
all times. Thisenablesbettercontrolofthepowertoolin
unexpectedsituations.
Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Looseclothes,jewelryorlonghaircanbecaught
inmovingparts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Useof dustcollection
canreducedust-relatedhazards.
Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. A careless action can cause severe
injurywithinafractionofasecond.
Do not wear loose clothing or jewelry. Contain long hair.
Looseclothes,jewelry,orlonghaircanbedrawnintoairvents.
Do not use on a ladder or unstable support. Stable
footingonasolidsurfaceenablesbettercontrolofthe
powertoolinunexpectedsituations.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool
for your application. Thecorrectpowertoolwilldothe
jobbetterandsaferattherateforwhichitwasdesigned.
Do not use the power tool if the switch does not turn
it on and off.Anypowertoolthatcannotbecontrolled
withtheswitchisdangerousandmustberepaired.
Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Suchpreventive
safetymeasuresreducetheriskofstartingthepowertool
accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
toolsaredangerousinthehandsofuntrainedusers.
GENERAL POWER TOOL SAFETY WARNINGS

3 – English
SAFETY WARNINGS COMMON FOR GRINDING,
SANDING, WIRE BRUSHING, POLISHING, CARVING
OR ABRASIVE CUTTING-OFF OPERATIONS
This power tool is intended to function as a grinder,
sander, wire brush, polisher, carving or cut-off tool.
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failuretofollowallinstructionslistedbelowmayresult
inelectricshock,fireand/orseriousinjury.
Do not use accessories which are not specifically
designed and recommended by the tool manufacturer.
Just because the accessory can be attached to your
powertool,itdoesnotassuresafeoperation.
The rated speed of the accessories must be at least
equal to the maximum speed marked on the power
tool. Accessoriesrunningfasterthantheirratedspeed
canbreakandflyapart.
The outside diameter and the thickness of your
accessory must be within the capacity rating of your
power tool. Incorrectlysizedaccessoriescannot be
adequatelycontrolled.
The arbour size of wheels, sanding drums or any other
accessory must properly fit the spindle or collet of the
power tool. Accessoriesthatdonotmatchthemounting
hardwareofthepowertoolwillrunoutofbalance,vibrate
excessivelyandmaycauselossofcontrol.
Mandrel mounted wheels, sanding drums, cutters or
other accessories must be fully inserted into the collet
or chuck. Ifthemandrelisinsufficientlyheldand/orthe
overhangofthewheelistoolong,themountedwheel
maybecomelooseandbeejectedathighvelocity.
Do not use a damaged accessory. Before each use
inspect the accessory such as abrasive wheels for
chips and cracks, sanding drum for cracks, tear or
excess wear, wire brush for loose or cracked wires.
If power tool or accessory is dropped, inspect for
damage or install an undamaged accessory. After
inspecting and installing an accessory, position
yourself and bystanders away from the plane of
the rotating accessory and run the power tool at
maximum no-load speed for one minute.Damaged
accessorieswillnormallybreakapartduringthistesttime.
GENERAL POWER TOOL SAFETY WARNINGS
ROTARY TOOL SAFETY WARNINGS
Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Manyaccidentsarecaused
bypoorlymaintainedpowertools.
Keep cutting tools sharp and clean. Properlymaintained
cuttingtoolswithsharpcuttingedgesarelesslikelyto
bindandareeasiertocontrol.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Useofthepowertoolforoperationsdifferent
fromthoseintendedcouldresultinahazardoussituation.
Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slipperyhandlesandgrasping
surfacesdonotallowforsafehandlingandcontrolofthe
toolinunexpectedsituations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. Achargerthatissuitablefor one type
ofbatterypackmaycreateariskoffirewhenusedwith
anotherbatterypack.
Use power tools only with specifically designated
battery packs. Useofanyotherbatterypacksmaycreate
ariskofinjuryandfire.
When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquidejectedfromthe
battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictablebehaviorresultinginfire,explosion,orrisk
ofinjury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposuretofireortemperature
above265°Fmaycauseexplosion.
Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specified in the instructions. Chargingimproperlyorat
temperaturesoutsidethespecifiedrangemaydamage
thebatteryandincreasetheriskoffire.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
willensurethatthesafetyofthepowertoolismaintained.
Never service damaged battery packs. Serviceofbattery
packsshouldonlybeperformedbythemanufactureror
authorizedserviceproviders.

4 – English
ROTARY TOOL SAFETY WARNINGS
Wear personal protective equipment. Depending on
application, use face shield, safety goggles or safety
glasses. As appropriate, wear dust mask, hearing
protectors, gloves and workshop apron capable of
stopping small abrasive or workpiece fragments.
Theeyeprotectionmustbecapableofstoppingflying
debrisgeneratedbyvariousoperations.Thedustmaskor
respiratormustbecapableoffiltratingparticlesgenerated
byyouroperation.Prolongedexposuretohighintensity
noise may cause hearing loss.
Keep bystanders a safe distance away from work area.
Anyone entering the work area must wear personal
protective equipment.Fragmentsofworkpieceorofa
brokenaccessorymayflyawayandcauseinjurybeyond
immediateareaofoperation.
Hold power tool by insulated gripping surfaces only,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessorycontactinga“live”wiremaymakeexposed
metalpartsofthepowertool“live”andcouldgivethe
operatoranelectricshock.
Always hold the tool firmly in your hand(s) during
the start-up. Thereactiontorqueofthemotor,as it
acceleratestofullspeed,cancausethetooltotwist.
Use clamps to support workpiece whenever practical.
Never hold a small workpiece in one hand and the
tool in the other hand while in use. Clampingasmall
workpieceallowsyoutouseyourhand(s)tocontrolthe
tool.Roundmaterialsuchasdowelrods,pipesortubing
haveatendencytorollwhilebeingcut,andmaycause
thebittobindorjumptowardyou.
Position the cord clear of the spinning accessory. If
youlosecontrol,thecordmaybecutorsnaggedandyour
handorarmmaybepulledintothespinningaccessory.
Never lay the power tool down until the accessory
has come to a complete stop. Thespinningaccessory
maygrabthesurfaceandpullthepowertooloutofyour
control.
After changing the bits or making any adjustments,
make sure the collet nut, chuck or any other
adjustment devices are securely tightened. Loose
adjustmentdevicescanunexpectedlyshift,causingloss
of control, loose rotating components will be violently
thrown.
Do not run the power tool while carrying it at your side.
Accidental contact with the spinning accessory could
snagyourclothing,pullingtheaccessoryintoyourbody.
Regularly clean the power tool’s air vents. The motor’s
fanwilldrawthedustinsidethehousingandexcessive
accumulationofpowderedmetalmay causeelectrical
hazards.
Do not operate the power tool near flammable
materials.Sparkscouldignitethesematerials.
Do not use accessories that require liquid coolants.
Usingwaterorotherliquidcoolantsmayresultin
electrocution or shock.
KICKBACK AND RELATED WARNINGS
Kickbackisasuddenreactiontoapinchedorsnagged
rotatingwheel,sandingband,brushoranyotheraccessory.
Pinchingorsnaggingcausesrapidstallingoftherotating
accessorywhichinturncausestheuncontrolledpowertool
tobeforcedinthedirectionoppositeoftheaccessory’s
rotation.
Forexample,ifanabrasivewheelissnaggedorpinched
bytheworkpiece,theedgeofthewheelthatisentering
intothepinchpointcandigintothesurfaceofthematerial
causing the wheel to climb out or kick out. The wheel may
eitherjumptowardorawayfromtheoperator,dependingon
directionofthewheel’smovementatthepointofpinching.
Abrasivewheelsmayalsobreakundertheseconditions.
Kickbackistheresultofpowertoolmisuseand/orincorrect
operatingproceduresorconditionsandcanbeavoidedby
takingproperprecautionsasgivenbelow.
Maintain a firm grip on the power tool and position
your body and arm to allow you to resist kickback
forces. The operator can control torque reactions or
kickbackforces,ifproperprecautionsaretaken.
Use special care when working corners, sharp edges,
etc. Avoid bouncing and snagging the accessory.
Corners,sharpedgesorbouncinghaveatendencyto
snagtherotatingaccessoryandcauselossofcontrolor
kickback.
Do not attach a toothed saw blade. Suchbladescreate
frequentkickbackandlossofcontrol.
Always feed the bit into the material in the same
direction as the cutting edge is exiting from the
material (which is the same direction as the chips are
thrown). Feedingthetoolinthewrongdirectioncauses
thecuttingedgeofthebittoclimboutoftheworkand
pullthetoolinthedirectionofthisfeed.
When using rotary files, cut-off wheels, high-speed
cutters or tungsten carbide cutters, always have the
work securely clamped. These wheels will grab if they
becomeslightlycantedinthegroove,andcankickback.
When a cut-off wheel grabs, the wheel itself usually
breaks.Whenarotaryfile,high-speedcutterortungsten
carbidecuttergrabs,itmayjumpfromthegrooveand
youcouldlosecontrolofthetool.
SAFETY WARNINGS SPECIFIC FOR
GRINDING AND ABRASIVE CUTTING-OFF
OPERATIONS:
Use only wheel types that are recommended for your
power tool and only for recommended applications. For
example: do not grind with the side of a cut-off wheel.
Abrasivecut-offwheelsareintendedforperipheralgrinding,
sideforcesappliedtothesewheelsmaycausethem to
shatter.

5 – English
ROTARY TOOL SAFETY WARNINGS
For threaded abrasive cones and plugs use only
undamaged wheel mandrels with an unrelieved
shoulder flange that are of correct size and length.
Propermandrelswillreducethepossibilityofbreakage.
Do not “jam” a cut-off wheel or apply excessive
pressure. Do not attempt to make an excessive depth
of cut. Overstressingthewheelincreasestheloadingand
susceptibilitytotwistingorsnaggingofthewheelinthe
cutandthepossibilityofkickbackorwheelbreakage.
Do not position your hand in line with and behind the
rotating wheel. Whenthewheel,atthepointofoperation,
ismovingawayfromyourhand,thepossiblekickback
maypropelthespinningwheelandthepowertooldirectly
at you.
When wheel is pinched, snagged or when interrupting
a cut for any reason, switch off the power tool and
hold the power tool motionless until the wheel comes
to a complete stop. Never attempt to remove the cut-
off wheel from the cut while the wheel is in motion
otherwise kickback may occur. Investigateandtake
correctiveactiontoeliminatethecauseofwheelpinching
or snagging.
Do not restart the cutting operation in the workpiece.
Let the wheel reach full speed and carefully re-enter
the cut. Thewheelmaybind,walkuporkickbackifthe
powertoolisrestartedintheworkpiece.
Support panels or any oversized workpiece to minimize
the risk of wheel pinching and kickback. Largeworkpieces
tendtosagundertheirownweight.Supportsmustbeplaced
undertheworkpiecenearthelineofcutandneartheedge
oftheworkpieceonbothsidesofthewheel.
Use extra caution when making a “pocket cut” into
existing walls or other blind areas. Theprotrudingwheel
maycutgasorwaterpipes,electricalwiringorobjectsthat
can cause kickback.
SAFETY WARNINGS SPECIFIC FOR WIRE
BRUSHING OPERATIONS:
Be aware that wire bristles are thrown by the brush
even during ordinary operation. Do not overstress the
wires by applying excessive load to the brush. The wire
bristlescaneasilypenetratelightclothingand/orskin.
Allow brushes to run at operating speed for at least
one minute before using them. During this time no
one is to stand in front or in line with the brush. Loose
bristlesorwireswillbedischargedduringtherun-intime.
Direct the discharge of the spinning wire brush away
from you. Smallparticlesandtinywirefragmentsmaybe
dischargedathighvelocityduringtheuseofthesebrushes
andmaybecomeimbeddedinyourskin.
ADDITIONAL SAFETY RULES
Always use proper guard with grinding wheel.Aguard
protectsoperatorfrombrokenwheelfragments.
Know your power tool. Read operator’s manual
carefully. Learn its applications and limitations, as well
as the specific potential hazards related to this tool.
Followingthisrulewillreducetheriskofelectricshock,
fire,orseriousinjury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1.Followingthisrulewillreduce
theriskofseriouspersonalinjury.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Followingthisrulewillreducetherisk
ofseriouspersonalinjury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reducetheriskofseriouspersonalinjury.
Check damaged parts. Before further use of the tool, a
guard or other part that is damaged should be carefully
checked to determine that it will operate properly and
perform its intended function. Check for alignment
of moving parts, binding of moving parts, breakage
of parts, mounting, and any other conditions that
may affect its operation. A guard or other part that is
damaged should be properly repaired or replaced by an
authorized service center. Followingthisrulewillreduce
theriskofshock,fire,orseriousinjury.
Inspect for and remove all nails from lumber before
using this tool. Followingthisrulewillreducetheriskof
seriouspersonalinjury.
Do not grind or sand heat flammable materials.Sparks
fromthewheelcouldignitethesematerials.
This product is not intended for use as a dental drill or
in human or veterinary medical applications. Serious
injurymayresult.
When using steel screws, cut-off wheels, high speed
cutters, or tungsten carbide cutters, always have the
work securely clamped. Never attempt to hold the work
with one hand while using any of these accessories.
Save these instructions. Refertothemfrequentlyanduse
themtoinstructotherswhomayusethisproduct.Ifyou
loansomeonethisproduct,loanthemtheseinstructions
also.

6 – English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicatesapotentialpersonalinjuryhazard.
Read
Operator’s
Manual
Toreducetheriskofinjury,usermustreadandunderstandoperator’smanualbefore
usingthisproduct.
Eye Protection AlwaysweareyeprotectionwithsideshieldsmarkedtocomplywithANSIZ87.1.
Wet
Conditions
Alert
Donotexposetorainoruseindamplocations.
Long Hair Failuretokeeplonghairawayfromtheairinletcouldresultinpersonalinjury.
Recycle
Symbols
Thisproductuseslithium-ion(Li-ion)batteries.Local,stateorfederallawsmayprohibit
disposalofbatteriesinordinarytrash.Consultyourlocalwasteauthorityforinformation
regardingavailablerecyclingand/ordisposaloptions.
VVolts Voltage
min Minutes Time
Direct Current Typeoracharacteristicofcurrent
nRated Speed Maximumrotationalspeed
.../min Per Minute Revolutions,strokes,surfacespeed,orbitsetc.,perminute
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicatesanimminentlyhazardoussituation,which,ifnotavoided,willresultindeathor
seriousinjury.
WARNING: Indicatesapotentiallyhazardoussituation,which,ifnotavoided,couldresultindeath
orseriousinjury.
CAUTION: Indicatesapotentiallyhazardoussituation,which,ifnotavoided,mayresultinminoror
moderateinjury.
NOTICE: (WithoutSafetyAlertSymbol)Indicatesimportantinformationnotrelatedto aninjury
hazard,suchasasituationthatmayresultinpropertydamage.
FEATURES
PRODUCT SPECIFICATIONS
Collet ................................................................................................................................................................1/8in.Universal
RatedSpeed .......................................................................................................................................5,000-34,000/min(RPM)

7 – English
UNPACKING
Thisproductrequiresassembly.
 Carefullyremovethetoolandanyaccessoriesfromthe
box.Allitemslistedinthe Includes section must be
includedatthetimeofpurchase.
WARNING:
Items in this Assembly section are not assembled to
theproductbythemanufacturerandrequirecustomer
installation. Use of a product that may have been
improperlyassembledcouldresultinseriouspersonal
injury.
 If any parts are damaged or missing, please call
1-800-776-5191forassistance.
WARNING:
Ifanypartsaredamagedormissingdonotoperatethis
productuntilthepartsarereplaced.Useofthisproduct
withdamagedormissingpartscouldresultinserious
personalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesorattachmentsnotrecommendedforuse
withthisproduct.Anysuchalterationormodificationis
misuseandcouldresultinahazardousconditionleading
topossibleseriouspersonalinjury.
ASSEMBLY
OPERATION
WARNING:
Donotallowfamiliaritywiththisproducttomakeyou
careless.Rememberthatacarelessfractionofasecond
issufficienttoinflictseriousinjury.
WARNING:
Always remove battery pack from the tool when you
are assembling parts, making adjustments, cleaning,
orwhennotinuse.Removingbatterypackwillprevent
accidental starting that could cause serious personal
injury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesandotherpossible
seriousinjuries.
WARNING:
Do not use any attachments or accessories not
recommendedbythemanufacturerofthisproduct.The
useofattachmentsoraccessoriesnotrecommended
canresultinseriouspersonalinjury.
WARNING:
Battery products are always in operating condition.
Therefore,theswitchshouldalwaysbelockedwhennot
inuseorcarryingatyourside.
APPLICATIONS
Youmayusethisproductforthepurposeslistedbelow:
Cutting
Sanding
Polishingandbuffing
Engraving
Drilling
CONNECTING THE PEN HOLDER AND FLEX
SHAFT TO THE ROTARY TOOL CONSOLE
See Figure 1, page 11.
 Slidetheflangeonthepenholderintotheopeningon
thesideoftherotarytoolconsoleuntilitisfullyseated.
NOTE: Oncefullyseated,thetabontheflangewillsnap
intothehousing,preventingthepenholderfrombeing
removed.
 Placethecollaroftheflexshaftontothethreadedoutlet
on the rotary tool console.
 Turnthecollarclockwiseandtightensecurely.
NOTICE:
Whenassemblingtheflexshaftontothethreadedoutlet,
make sure the collar of the flex shaft can be turned
smoothly.Ifyoufeelresistance,stopanduntightenthe
collar.Rotateoneofthehexagonshaftsorthreadthe
outlet45˚beforetryingagain.Forcingthecollarontothe
threadedoutletcandamagethetool.

8 – English
OPERATION
INSTALLING/REMOVING BATTERY PACK
See Figure 2, page 11.
TurnswitchtotheOFFposition.
Insertthebatterypackintothebatteryportasshown.
Makesurethelatchonthebatterypacksnapsintoplace
andthebatterypackissecuredintheproductbefore
beginningoperation.
Depressthelatchandpulltoreleaseandremovethe
batterypack.
For complete charging instructions, see the operator’s
manualsforyourbatterypackandcharger.
KEY HOLE HANGER
To mount the rotary tool console, use the key hole hang-
ingfeature.Screwsshouldbeinstalledsothatthecenter
distanceis4in.
TURNING THE ROTARY TOOL ON/OFF
See Figure 3, page 11.
To turn the tool ON:movetheON/OFFswitchtotheON
position.
To turn the tool OFF:movetheON/OFFswitchtothe
OFFposition.
INSTALLING/REMOVING ACCESSORIES
See Figures 4 - 6, page 12.
NOTICE:
Topreventdamagetothespindleorspindlelock,always
allowmotortocometoacompletestopbeforeengaging
thespindlelock.
To install:
 Slidethe accessorystorageboxforfrequentlyusedbits
intothegarageontheleftorhingedsideofthetool.
 Removethebatterypack.
Slidethespindlelockleverforwardandrotatetheshaftby
handuntilthespindlelockengagestheshaft,preventing
further rotation.
Withthespindlelockengaged,usethecolletwrenchto
loosen the collet nut, if necessary.
Insert the shank of the accessory into the collet until the
shankbottomsout,thenpullitout1/16in.toallowfor
expansionwhentheaccessorygetshot.
Withthespindlelockengaged,tightenthecolletnutwith
theprovidedwrenchuntiltheaccessoryshankisgripped
bythecollet.Avoidexcesstighteningofthecolletnut.
To remove:
 Withdrawthe accessorystoragebox.
 Removethebatterypack.
Withthespindlelockengaged,loosenthecolletnutwith
theprovidedwrench.
Removetheaccessory.
DANGER:
If you are changing an accessory immediately after
use, be careful not to touch the collet, collet nut, or the
accessorywithyourhandsorfingers.Youwillgetburned
becauseoftheheatbuild-upfromcutting.Alwaysuse
thewrenchprovided.
USING MANDRELS
See Figures 7 - 8, pages 12 - 13.
Themostcommontypesofmandreltousewiththistool
includethestandardmandrelwhich is used with cut-off
discs,grindingwheels,emerywheels,andcut-offwheels.
Screwmandrelsareusedwithpolishingwheelsandpolish-
ingdrums.Drummandrelsareusedwithsandingdrums.
To install:
 Removethebatterypack.
Installthemandrel.
If using the standard mandrel:
Pressandholdthespindlelock.
Inserttheslotendoftheprovidedwrenchintotheslot
ontopofthemandrelandunscrew.
Removemandrelscrewandwasher.
Placedesiredaccessoryovermandrelshaftand align
accessoryholewithmandrelhole.
Insertmandrelscrewwithwasherthroughtheaccessory
andmandrelshaftholes.
NOTE:Themandrelwashershouldbeplacedbetween
themandrelscrewandtheaccessory.
Tightenusingprovidedwrench.
If using the screw mandrel:
Aligndesiredaccessoryholewithmandrelscrewhead.
Screwaccessoryontomandrelbytwistingclockwiseuntil
secure.
If using the drum mandrel:
Alignappropriatesizedsandingdrumovermandreland
pushdowntocompletelycoverdrumendofmandrel.
NOTE:Ifnecessary,tightenthescrewonthedrum
mandrelheadtoexpandthedrumandsecurelyholdthe
sandingdruminplace.
BALANCING ACCESSORIES
Forprecisionwork,itisimportantthatallaccessoriesbe
properlybalanced.Tobalanceanaccessory,slightlyloosen
thecolletnutandgivetheaccessoryorcolleta1/4in.turn.
Youshouldbeabletotellbythesoundandfeeliftheacces-
soryisrunninginbalance.Continueadjustinginthisfashion
untilthebestbalanceisachieved.Replaceaccessoriesif
theybecomedamagedorunbalanced.

9 – English
SELECTING THE RIGHT SPEED
See Figure 9, page 13.
Therotarytoolhasaspeedrangeof5,000-34,000RPM.To
selecttherightspeedforeachjob,useapracticepieceof
material.Varyspeedtofindthebestspeedfortheaccessory
youareusingandthejobtobedone.
Usethespeedcontroldialtosetthebestspeedforthejob.
Whenthedialissettothemaximumsetting,approximately
34,000RPMisachieved.
Refer to the Speed Dial Settingstabletodeterminethe
properspeedbasedonthematerialbeingworkedandthe
typeofaccessorybeingused.
SLOWER SPEEDS
Certainmaterials,someplasticsforexample,requirearela-
tivelyslowspeedbecausethefrictionofthetoolgenerates
heatandcausestheplastictomeltathighspeed.
Slowspeeds(15,000RPMorless)areusuallybestfor
polishingoperationsusingthepolishingaccessories.They
mayalsobebestforworkingondelicateprojects,delicate
woodcarving,andfragilemodelparts.
Higherspeedsarebetterforcarving,cutting,andshaping
wood.
Hardwoods,metals,andglassrequirehighspeedoperation.
Drillingshouldalsobedoneathighspeeds.
Todeterminetheoptimumoperationalspeedfordifferent
materialsandaccessories,refertotheSpeed Dial Settings
table.Lookthistableoverandbecomefamiliarwithit.
Thebestwaytodeterminethecorrectspeedforworkon
anymaterialistopracticeforafewminutesonapieceof
scrap,evenafterreferringtothetable. You can quickly
learnthataslowerorfasterspeedismoreeffectivejustby
observingwhathappenswhenyoumakeapassortwoat
differentspeeds.
Whenworkingwithascrappieceofplastic,startataslow
rateofspeedandincreasethespeeduntil you observe
whethertheplasticismeltingatthepointofcontact;reduce
thespeedslightlytogetoptimumworkingspeedwithout
meltingtheworkpiece.
NOTE:
Plasticandmaterialsthatcouldmeltatlowtemperatures
shouldbecutatlowspeeds.
Softwoodshouldbecutathighspeed.
Aluminum,tin,andcopper,lead,andzincalloysmaybe
cutatanyspeed,dependingonthetypeofcuttingbeing
done.Useparaffinorothersuitablelubricantonthecutter
topreventthecutmaterialfromadheringtothecutter
teeth.
OPERATION
OPERATING THE ROTARY TOOL
See Figure 10, page 13.
Learning to use the rotary tool:
Holdthepeninyourhandandgetusedtoitsweight,
balance,andthetaperofthehousing.Thistaperpermits
thepentobegraspedlikeapencil.
Examinetherotarytoolaccessoriescarefully.Damaged
accessoriescanflyapartastheycomeuptospeedand
shouldnotbeused.Theuseofdamagedaccessories
canresultinseriouspersonalinjury.
Practiceonscrapmaterialsfirsttoseehowthetool
operates.Keepinmindthattheworkisdonebythespeed
ofthetoolandbytheaccessoryinthecollet.Youshould
notleanonorpushthetoolintothework.
Itisbesttomakeaseriesofpasseswiththetoolrather
thanattempttodoalltheworkinonepass.Tomakeacut,
passthetoolbackandforthovertheworklikeyouwoulda
smallpaintbrush.Cutalittlematerialoneachpassuntilyou
reachthedesireddepth.Formostwork,agentletouchis
best;youwillhavegreatercontrol,makefewererrors,and
get the most efficient work out of the accessory.
Forthebestcontrolinclosework,gripthetoollikeapencil
betweenyourthumbandforefinger.
A“handgrip”methodofholdingthetoolisusedforopera-
tionssuchasgrindingaflatsurfaceorusingcut-offdiscs.
To operate the rotary tool:
 Secureallworkin a viseorclamptoa workbench to
preventitfrommovingunderthetool.
 Holdthetoolinfrontandawayfromyou,keepingthetool
accessoryclearoftheworkpiece.
 Turnonthetoolandletthemotorandaccessorybuild
uptofullspeed.
 Lowerthetoolgraduallyuntiltheaccessorycontactsthe
workpiece.
 Movethetoolcontinuouslyatasteady,consistentpace.
 Usejustenoughpressuretokeepthetoolfromchattering
or bouncing.
NOTE: Heavypressurewilldecreasethetool’sspeedand
putastrainonthemotor.The weight of the tool alone is
adequateformostjobs.
Lift the toolawayfromtheworkpiecebeforeturningoff
the tool.

10 – English
OPERATION
MAINTENANCE
NOTE: ILLUSTRATIONS START ON PAGE 11
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.
GENERAL MAINTENANCE
Avoidusingsolventswhencleaningplasticparts.Most
plasticsaresusceptibletodamagefromvarioustypesof
commercialsolventsandmaybedamagedbytheiruse.Use
cleanclothstoremovedirt,dust,oil,grease,etc.
WARNING:
Donotatanytimeletbrakefluids,gasoline,petroleum-
basedproducts,penetratingoils,etc.,comeincontact
withplasticparts.Chemicalscandamage,weakenor
destroyplastic whichcouldresultinseriouspersonal
injury.
WARNING:
Whenservicing, useonlyidenticalreplacementparts.
Useofanyotherpartscouldcreateahazardorcause
productdamage.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesresultinginpossible
seriousinjury.
WARNING:
To avoid serious personal injury, always remove the
battery pack from the product when cleaning or
performinganymaintenance.
SPEED DIAL SETTINGS
Type of Accessory Application Speed (x 1000)
AluminumOxide
GrindingBits Grindingnails/screws 32
Fiberglass Cut-off
Wheel Cutbolts,screws,nails,thinwood 30
SandingDrums Sandingwhitepine 30
Felt Polishing Wheels Polishing steel, aluminum, brass, stone, ceramic, glass 12-15
Drill Bit Drillingholesintowood 32
Wire Brush Brushing metal 15
EngravingBit Engravingsoftmetals Highspeedsforwoods,
slowspeedsformetals
High-speedCutter Shapingcurvedsurfaces 20-33
ConicalGrinding
Stone Grindingmetaledges 32
