Lifestyle Solutions Cottage Series User manual

Slats Box
13 pcs Slats
2 pcs Bed Side Rails
1 pc Slat Support
4 pcs Leg Support
1 pc Head Board
Parts And Fittings packing Detail
M4 x 32mm Screw - 26pcs
(Packed in Separate Box)
1 pc Foot Board
A complete assembled view of
Conventional Bed
Hardware Pack In Slats Box
Box # 3
Box # 2
Box #1
Bed Assembly Instructions
Cottage Bed
Page 1 of 2
M4 Allen Key
- 1 pc
Barrel Nut - 4 pcs
Washer- 8 pcs.
Hardware packing in Box #1
M5 Allen Key - 1pc
Bolt M8 x 20mm - 8 pcs
Bolt M6 x 70mm - 4 pcs
The Fusion Of Function And Comfort With Style
LIFESTYLE SOLUTIONS

Bed Assembly Instructions
COTTAGE BED
Page 2 of 2
The Fusion Of Function And Comfort With Style
Step 1/Diagram 1
Fix both side rails to the Head Board and Foot Board as shown in
diagram 1 with the 20mm bolts and washers.
Step 2/Diagram 2
Spread out all the slats on to the slat support.
Further secure the pre-drilled slats to the
slats support and support legs with 4nos
M6 x 70mm bolt as shown in diagram 2.
Step 3/Diagram 3
Finally, place both ends of the
assembled slats in the bed frame
resting on both sides of the
side rails and screw them in
place with the 32mm screws
provided as shown in diagram 3.
Foot board
Slat
Head board
Side Rail
4nos M6 x 70mm bolt
fastened to 4nos
pre-drilled slats
Diagram 2
Head Board & Foot Board Leg
Washer
Pre-drilled
Slat
Slat
Support
M5 Allen Key
Side Rail Metal Bracket
Support Leg
Barrel Nut
M6x70mm Bolts
M8 x 20mm
Bolt
Threaded Hole
Diagram 1
Model shown for assembly instructions only
Screw
Fasten screws to all slats
on side rail
Diagram 3

The Fusion Of Function And Comfort With Style
Cottage Series
Fixing of Drawer Knobs
Step 1
Remove drawer knobs as shown
Step 2
Refix knobs on outside as shown
The drawer knobs are fixed inside the drawers to reduce
transportation related damages.
you'll need to remove and fix it onto the correct orientation.
Drawer Knobs
Bolt

COTTAGE SERIES 7 Drawer Dresser
Assembly Instructions
Step #1
Remove Drawer Knobs as shown
Step #2
Refix knobs on the outside as
shown. Bolt
Drawer Knobs
Shelf Panel
Adjustable Pin
Slide Shelf Panel into
position as shown
Step #3 The Fusion of Function and Comfort with Style
LIFESTYLE SOLUTIONS
Shelf Panel is placed beneath
the Dresser together with the
Mirror Brace

COTTAGE SERIES MIRROR FRAME
Assembly Instructions Parts
Hardwares
Fixing Mirror Frame onto the Casegood
Wood Screw - 12 pcs.
Mirror Frame
Mirror Brace
Mirror Frame
Wood Screw
7Drawer Dresser
This side up sticker
Mirror Brace
This side up sticker
Please make sure the groove is below the
table top when assemble the Mirror Frame
Groove
The Fusion Of Function And Comfort With Style
LIFESTYLE SOLUTIONS
Mirror Brace is packed in
the 7 Drawer Dresser Box

COTTAGE SERIES TV ARMOIRE
Fixing of Wooden Door Knobs.
The Door knobs are fixed inside the Doors to reduce Transportation
related damages.
You'll need to remove and fix it onto correct orientation.
Bolt
Pull string
to open the door
The Fusion of Function and Comfort with Style
LIFESTYLE SOLUTIONS
Step #1
Remove Dood Knob as Shown
Step #2
Refix Knobs on the outside As Shown
Door Knob
Screw Driver

Page 2
Screw driver
Hinge Screw
The Fusion Of Function And Comfort With Style
LIFESTYLE SOLUTIONS
Due to 'settling' and 'transportation', there is a chance
that you may have to adjust the doors of
the armoire. You may loosen
the screws on the door hinges
(as shown) and adjust the doors
and retighten the screws.
Please note that this adjustment
may not be required.
Optional Step
If you want to convert your TV Armoire to
a wardrobe, please place the wooden rod
into the bracket attached to the Side panel.
Wooden rod clothing hanger
Wooden rod bracket
