Form No. FDW Spec Sheet
FLAV-R-FRESH®
IMPULSE DISPLAY CABINETS
Models FDW-1, FDW-1X, FDW-2, FDW-2X
Hatco has a profitable way to create
impulse foo sales with the small
Flav-R-Fresh Hol ing an Display
Cabinet. Controlle moisturize heat lets
you isplay an hol hot foo s longer
using minimum counter space.
FLEXIBILITY
The Hatco Flav-R-Fresh has separate
heat an humi ity controls to keep crisp
foo s crisp an moist foo s moist, not
just for minutes but for hours. It hol s
everything from hot pretzels to 15"
(381 mm) pizzas, croissants to bagels,
an even hot ogs an meat pies.
Electrical components, controls, an
water reservoir are locate at the top
for easy access. A temperature monitor
in icates the cabinet temperature. A re
light in icates a low water level an a
green light shows the humi ity cycle.
Mo els with two oors are available for
pass-through convenience an a variety
of merchan ising racks help enhance
foo appeal.
The Hatco Flav-R-Fresh is i eal for
restaurants, pizzerias, convenience
stores, concession stan s, snack bars,
an kiosks.
QUALITY
The following features assure the finest
performance for years to come:
• The stainless steel isplay cabinet
features tempere glass si es an
oor for full-view isplay.
• Shatter-resistant incan escent
light enhances foo appeal while
safe-guar ing foo pro ucts from
bulb breakage.
• A large single oor provi es fast
access to foo racks.
• Foo ecals an merchan ising signs
are available to help promote pro uct.
METAL SHEATHED AIR HEATING ELEMENTS
GUARANTEED AGAINST BURNOUT AND BREAKAGE
FOR TWO YEARS.
Mo el FDW-1 with
rotating 4-tier rack an
accessory ecals an pans
Mo el FDW-1X with
stationary 4-shelf
multi-purpose rack
ANSI/NSF 4
Custom Foo Decals & Merchan ising Signs
Designe to attract attention an
stimulate sales, Flav-R-Fresh offers
eye-catching foo ecals (specify
Pizza, Chicken, Pretzel, or Biscuits/
Croissants). Or choose optional
PIZZA or PRETZEL isplay signs
in bright re with yellow letters.
Printe in U.S.A.
September 2007

ITEM#
SPECIFICATIONS
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-Mail: [e-mail]
Form No. FDW Spec Sheet
191⁄2"(495 mm)
Models FDW-2 & -2X only
207⁄8"(530 mm)
SIDE VIEW
271⁄2"
(699 mm)

FRONT VIEW
18" (457 mm)
PRODUCT SPECS
Impulse Display Cabinet
The humi ity controlle Impulse Display Cabinet shall be
a Flav-R-Fresh®Mo el ....rate at ....volts an ....watts, as
manufacture by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
With 24/7 parts an service assistance (U.S. an Cana a only),
the cabinet shall have .... oor(s), tempere glass si es,
stationary rack (or revolving isplay), an incan escent isplay
light. It shall inclu e a water reservoir, humi ity selector switch,
temperature selector ial, on-off switch, an in icating lights.
A 6' (1829 mm) cor with plug shall be attache .
Accessories shall inclu e merchan ising racks, isplay sign(s),
an foo graphic ecals.
OPTIONS (NOT FOR RETROFIT)
❑Designer Colors: Warm Re , Black, Gray Granite,
White Granite, Navy Blue, Hunter Green
❑Self-Closing Doors
ACCESSORIES
❑ 4-Tier Circle Rack (Requires motorless rack coupling
on -X mo els)
❑ 4-Shelf Multi-Purpose Rack (Each shelf 135/8"W x 125/8"D
(346 x 321 mm))
❑ 4-Shelf Angle Rack (Each shelf 14"W x 141/2"D
(356 x 368 mm))
❑ 3-Tier Pretzel Tree (Requires motorless rack coupling
on -X mo els)
❑ Motorless Rack Coupling (For -X mo els only)
❑ 14" (356 mm) Diameter Pizza Pan
❑ 15" (381 mm) Diameter Pizza Pan
❑ Half-size Sheet Pan 18" x 13" (457 x 330 mm)
❑ 4" (102 mm) A justable Legs
❑ Merchan ising Signs (3 per set)
Pizza
Pretzel
❑Custom Foo Decals (3 per set)
Pizza, Chicken, Pretzel, or Croissants/Biscuits
*Mo els FDW-1 an FDW-2 inclu e rack motor. Mo els with “X” esignator o not have
revolving isplay an are NOT available for retrofit.
†Pretzel Rack available in lieu of Circle Rack.
▲
Accommo ates half-size sheet pans.
Display Rack Selection
3-Tier Pretzel Tree
Mo el FDW3TPT
Rack Opening:
513⁄16" (148 mm)
4-Shelf Angle Rack
Mo el FDW4SAR
Rack Opening:
33⁄4" (95 mm)
4-Shelf Multi-Purpose Rack*
Mo el FDW4SMP
Rack Opening:
31⁄2" (89 mm)
4-Tier Circle Rack
Mo el FDW4TCR
Rack Opening:
31⁄4" (83 mm)
Maximum
15" (381 mm)
iameter pans
DIMENSIONS
FDW-1, FDW-1X: 18"W x 191⁄2"D x 271⁄2"H
(457 x 495 x 699 mm).
FDW-2, FDW-2X: 18"W x 207⁄8"D x 271⁄2"H
(457 x 530 x 699 mm).
Cabinet Opening: 151⁄2"W x 191⁄4"H
(394 x 489 mm).
VOLTAGE
120 volts, 60 Hz, 1470 watts, 12.3 amps (uses
NEMA 5-15P, NEMA 5-20P – Cana a).
Export voltages available.
CORD LOCATION
Facing controls, un erneath left corner.
PLUG CONFIGURATIONS
Mo el* Type Rack Style Shipping Weight
FDW-1 1 Door Circle Rack†with Rack Motor 80 lbs. (36 kg)
FDW-1X 1 Door Multi-Purpose Rack 82 lbs. (37 kg)
without Rack Motor
FDW-2 2 Doors Circle Rack†with Rack Motor 86 lbs. (39 kg)
FDW-2X▲2 Doors Multi-Purpose Rack 88 lbs. (40 kg)
without Rack Motor
CEE 7/ 7 Schuko
NEMA 5-20PNEMA 5-15P
BS-1363
FLAV-R-FRESH®
IMPULSE DISPLAY CABINETS
Models FDW-1, FDW-1X, FDW-2, FDW-2X
* Accommo ates half-size sheet pans (Not inclu e ).
WATER QUALITY REQUIREMENTS
Water supply in excess of 3.0 grains of har ness per gallon (GPG) (.75 grains
of har ness per liter) must be treate an softene before being use . Water
containing over 3.0 GPG (.75 GPL) will ecrease the efficiency an re uce
the operating life of the unit.
Note: Product failure caused by liming or sediment buildup is not covered
under warranty.
