Hathaway NG2237BL User manual

NG2237BL
Ver. 0118
HOOPS DUAL ELECTRONIC
BASKETBALL GAME
ASSEMBLY INSTRUCTIONS
Please Do Not Hesitate to
Contact Our Consumer Hotline
at 800-759-0977
with Any Questions That May
Arise During Assembly or
Use of This Product!

THANK YOU!
Thank you for purchasing this product. We work around the clock and around the globe to ensure
that our products maintain the highest possible quality. However, in the rare case of issues during
assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate
assistance before contacting your retailer. Please read the warranty information at the back of these
assembly instructions for further details.
2
CARE AND USE
1. This product is intended for INDOOR use only.
2. Do NOT drag the game when moving it, as this will damage the legs.
ASSEMBLY TIPS
1. Find a clean, level surface to begin the assembly of your game. We recommend that two adults
work together to assemble this game. You may want to carefully cut or tear the four corners of the box
so that the bottom of the box can be used as your work surface.
2. Remove all of the contents from box and verify that you have all of the parts shown on the Parts
Identifier before you begin assembly. Note: Some parts may be pre-installed or pre-assembled.
3. Some figures or drawings may not look exactly like product.
4. When installing parts that have more than one screw or bolt, hand tighten all screws or bolts
in place before final tightening with screwdriver or wrench.
5. Electric screwdrivers may be helpful during assembly; however, please set a low torque and use
extreme caution because screws may be stripped or overtightened, resulting in damaged parts, if the
electric screwdriver’s torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETYINSTRUCTIONS CAREFULLY.
CHOKE HAZARD - THIS ITEM MAY CONTAIN SMALL BALLS AND PARTS
NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.

3
HOOPS DUAL ELECTRONIC BASKETBALL - NG2237BL
Parts List
3
HOME VISITOR
TIME
910 11 12
13 14 15 16
Switch Sensor Control Box with Wire
Electronic Scorer
2 3 4
x2 x2 x1 x1
6 7 85
x2 x2 x1
x1 x2 x1 x1
x6
x2
x1
x2
Rim
18 19 20
Inflation Pump with Needle
Rim Support Plate
x1
x1
21
Backboard
x1
M6 Washer
22
x64
23
M6 x 20mm Bolt
24
x16
25
M6 x 41mm Bolt
x8
M6 x 50mm Bolt
26
x4
M6 x 68mm Bolt
27
x2
M6 Nut
28
x32
29
M3 5 x 10mm Screw
x4
Electronic Scorer Face Plate
30
x1
Basketball
31
Wrench
32
x1
17
x2
x2
Rear Top Leg Rear Middle Leg Rear Bottom Leg - Left Rear Bottom Leg - Right
1NGP56201
NGP6034
NGP56222
NGP2122
NGP56251
NGP56221
NGP56271
NGP56211
NGP56272
NGP56261
NGP56302
NGP56291
NGP2217
NGP56301
NGP5644
NGP56231
NGP5637
NGP6038
NGP6037
NGP56361 NGP56421*NGP56421*
NGP56421* NGP56421*
NGP56421*
NGP56421*
NGP6042 NGP56421*NGP56431**
Back Arm Middle Arm Center Top Leg Center Middle Leg - Right
Center Middle Leg - Left Base Front Arm - Right Front Arm - Left
x2 x1
NGP56331 NGP56321
Cross Brace Lean Bar
M6 x 45mm Bolt
x2
NGP56421*
Hinge ONLY
NGP56311
Hinge ONLY
NGP56312
*Items included in Hardware Pack, NGP56421
**Item included with Electronic Scorer, NGP2122
01/18 For replacement parts please call 800-759-0977.

4
For replacement parts please call 800-759-0977.
33 34 35
Net Power Adapter
A1
x2 x1
A3
Power Tools
-Set Low Torque
High Torque
over tightened
X2
Strong Adults Needed No Children in
Assembly Area
Keep away from pets Do not use or keep product
outdoors. For indoor use only.
No wet/humid conditions.
TOOLS REQUIRED
• Wrench - Included
• Allen Wrench - Included
Electric Screwdrivers may be helpful during assembly;
however, please set a low torque and use extreme caution.
CAUTION!
*Items included in Hardware Pack, NGP56421
x1
NGP56421*
Hex Wrench
Parts List (Cont.)
A2
NGP56411
NGP5637
36
Ball Return Net
x1
NGP56351 37
HOOPS DUAL ELECTRONIC BASKETBALL - NG2237BL
Plastic Pole Insert Foot Pad
x2 x4
x2
Pre-installed
Lock Pin
Pre-installed
Pre-installed
Spring Lock
x12
Pre-installed
01/18

5
THANK YOU!ASSEMBLY INSTRUCTIONS
FIG. 1
FIG. 2
X 1
X 1
X 1
X 1
X 1
X 1

THANK YOU!
6
ASSEMBLY INSTRUCTIONS (CONT.)
FIG. 3 NOTE: Hand tighten all bolts in place, then
tightening with wrench once fully assembled.
FIG. 4
X 2
X 8
X 2
X 2
X 4
X 2
X 2
X 4
X 2
X 2

ASSEMBLY INSTRUCTIONS (CONT.)
7
FIG. 5
FIG. 6
X 2
X 2
X 1
X 8
X 2
X 2
X 4
Bolt goes
through
top hole of 6
Bolt goes
through
top hole of 6

X 1
X 1
X 1
ASSEMBLY INSTRUCTIONS (CONT.)
8
FIG. 7

X 2
X 2
X 2
X 1
X 32
X 16
X 16
X 1
X 4
X 1
X 2
ASSEMBLY INSTRUCTIONS (CONT.)
9
FIG. 8
FIG. 9
Attaching Net, 35

X1
X 4
X 2
X 2
X 1
1. Disengage Lean Bar (14) and slip end
through elastic straps and pocket at bottom
of Ball Return (34), then reattach to
Front Arms (11&12)
2. Slip Cross Brace (13) on inside of Ball
Return (34) and attach to Lean Bar (14)
on each end using hardware as shown 3. Wrap top Velcro straps on Ball Return (34)
around Lean Bar (14) on both side and secure
to other end of strap with Velcro
THANK YOU!
10
ASSEMBLY INSTRUCTIONS (CONT.)
FIG. 10

NOTE: Control Box Wire must
be plugged into Electronic
Scorer and Controller turned
on, along with Electronic
Scorer, for Scorer to work.
Scorer will NOT work until
this is done.
X 1
X 8
X 4
X 4
X 2
ASSEMBLY INSTRUCTIONS (CONT.)
11
Sensor Wire
Sensor Wire
Electronic Scorer
Control Wire
FIG. 12A
ON / OFF
Control Wire
Control
Wire
Holders
VISITOR
HOME
POWER
SUPPLY
CONTROL
WIRE
1. Slip elastic strap
over top leg (1) 2. Secure elastic strap
over bolt (26) end sticking
out on back
When net is OPEN, pin goes in front hole.
NOTE: Pin fits tight, so you may need to
jiggle frame slightly to get holes to line up.
FIG. 11
FIG. 12

Game can be folded when not in use to
save space. Make sure lock pins are fully
engaged in up or down position.
Please be cautious when doing this
as to not pinch fingers or hand in hinge.
Always make sure lock pins are
disengaged before folding net.
Failing to do so will damage game.
When net is CLOSED, pin goes in top hole.
NOTE: Lock pin chain should be attached
to back top hole.
ASSEMBLY INSTRUCTIONS (CONT.)
12
FIG. 13

13
ON / OFF
CONTROL
WIRE /
CONTROL
CABLE
VISITOR
ELECTRONIC SCORER OPERATION
Use Enclosed Power Adapter or
Install Batteries:
Using a screwdriver, unscrew lid and open the
battery box. Insert 3 “AA” batteries ( not included)
in the order of polarity as shown on the inside
cover. Close the cover and tighten screw.
Turn the power ON using the ON/OFF switch.
Reminders:
• DO NOT insert batteries if using Power Adapter.
• Batteries must be installed according to the
correct polarization (+ and -) requirement.
• Please clean the battery contacts, and also those
of the device, prior to battery installation.
• If the game will not be used for a long period of time,
we recommend that the batteries should be removed.
ASSEMBLY INSTRUCTIONS (CONT.)
WARNING:
!
1) Requires 3 “AA” batteries (not included).
2) Do not mix old and new batteries.
3) Do not mix alkaline, standard (carbon zinc), or
rechangeable (nickel-cadmium) batteries.
ON/OFF PLAY
SELECT
UP
SELECT
DOWN
SOUND PAUSE RESET
CONTROL PANEL
CONTROL BOX OPERATION
Press "ON/OFF" to activate the scorer.
Scoreboard "HOME" shows "01" (pre- set game 1).
Press "SELECT UP and DOWN" to select a game.
Press "PLAY" to enter selected game mode.
Press "SOUND" to switch sound ON/OFF while playing.
Press "PAUSE" to pause or start time counting.
Press and hold the button "ON/OFF" 3 seconds to turn off scorer.
Press and hold the button "RESET" 3 seconds to reset the games.
NOTE: If no shot is made or no button is pressed in 15 mins,
scorer will be turned off automatically.
HOME
POWER
SUPPLY

1. Beat the Clock
Press "PLAY" to enter game 1.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
Press "UP/Down" to select playing time, 30/45/60 seconds.
Press "PLAY" to begin the game.
Scoreboard "HOME" shows Player 1, 3;
Scoreboard "VISITOR" shows Player 2, 4.
All shots worth 2 points until last 10 seconds, then each
score counts 3 points. Countdown 5 seconds to next
player's turn when one player finishes game. Player with
most points scored wins ( LED will flash on player with
higher score).
Press "PLAY" to restart this game.
2. 3 Point Beat the Clock
Press "PLAY" to enter game 2.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
Press "UP/Down" to select playing time, 30/45/60 seconds.
Press "PLAY" to begin the game.
Scoreboard "HOME" shows Player 1, 3;
Scoreboard "VISITOR" shows Player 2, 4.
All shots made count 3. Countdown 5 seconds to next
player's turn when one player finishes game. Player with
most points scored wins ( LED will flash on player with
higher score).
Press "PLAY" to restart this game.
3. Battle Back
Press "PLAY" to enter game 3.
Press "UP/Down" to select multiple players (P2/P4).
Press "PLAY" to begin the game.
Shot made in "HOME" frame, +2 points scored display on
"HOME" board and -2 points for "VISITOR".
Shot made in "VISITOR" frame, +2 points scored display
on "VISITOR" board and -2 points for "HOME".
Once a player scores 10 points they win and game
is finished.
Press "PLAY" to restart this game.
4. Horse
Press "PLAY" to enter game 4.
Press "UP/Down" to select multiple players (P2/P3/P4).
CHOOSE FROM 8 DIFFERENT GAME OPTIONS
14
Press "PLAY" after the number of players is selected.
Player has to make a shot in 2 seconds.
First player is allowed to shoot at any hoop (HOME or
VISITOR). If first player scores in 2 seconds, no letter is
given. Game continues for next player. Scoreboard will
display "next player (P2P3/P4)" and LED will flash twice
in a second. After flash, next player has to duplicate the
shot in the same hoop selected by first player.
If player can't score in 2 seconds, player receives the first
letter "H" which will display on scoreaboard. Game remains
for the same player untill the player scores. If player keeps
missing, player receives "O" followed by "R", "S", "E".
After the letter "E" is given, the player is out.
The first player to spell "horse" is out. Play continues until
last player to spell “horse” wins.
Press "PLAY" to restart this game.
5. Check Point
Press "PLAY" to enter game 5.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
"HOME" displays "player", "VISITOR" displays "24" points,
pre-set 40 seconds playing time.
Points scored will display on scoreboard "HOME".
Before time is out, once 24/52/68/86 points is scored,
playing time increases 10/20/10/20 seconds respectively.
Countdown 5 seconds to next player's turn when one
player finishes game.
Player with most points scored wins ( LED will flash on
player with higher score).
Game is finished when a player scores 98 points.
Press "PLAY" to restart this game.
6. Around the World
Use tape to mark shooting lines.
Press "PLAY" to enter game 6.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
"HOME" scoreboard displays Player 1/2/3/4, "VISITOR"
displays points scored.
Once score reaches 10 points or time reaches 99 seconds,
5 second countdown, until next player’s turn, when one
player finishes game.
Player who finishes the game first wins (LED will flash
on winner).
Press "PLAY" to restart this game.

7. Left and Right Shoot
Press "PLAY" to enter game 7.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
Press "UP/Down" to select playing time, 30/45/60 seconds.
Press "PLAY" to begin the game.
Scoreboard "HOME" displays Player,
"VISITOR" displays points
Make a shot in "HOME" frame when LED is flasing on
"HOME", 2 points scored display on “HOME”.
Make a shot in "VISITOR" frame when LED is flasing on
"VISITOR", 2 points scored display on “VISITOR”.
5 second countdown, until next player’s turn, when one
player finishes game.
Player with most points scored wins ( LED will flash on
player with higher score).
Press "PLAY" to restart this game.
8. One on One
Press "PLAY" to enter game 8.
Press "UP/Down" to select single/multiple players
(P1/P2/P3/P4).
Press "PLAY" after the number of players is selected.
Press "UP/Down" to select playing time, 30/45/60 seconds.
Press "PLAY" to begin the game.
Scoreboard "HOME" displays Players 1 and 3,
"VISITOR" displays Players 2 and 4.
All shots worth 2 points until last 10 seconds, then each
score counts 3 points. Countdown 5 seconds to next
player's turn when one player finishes game. Player with
most points scored wins ( LED will flash on player with
higher score).
Press "PLAY" to restart this game.
CHOOSE FROM 8 DIFFERENT GAME OPTIONS
15

180-DAY LIMITED WARRANTY
16
This product is warranted to the original purchaser to be free from defects in material or workmanship
for a period of 180 days from the date of the original retail purchase.
This warranty does not cover defects or damage due to improper installation, alteration, accident or
any other event beyond the control of the manufacturer. Defects or damage resulting from misuse,
abuse or negligence will void this warranty. This warranty does not cover scratching or damage that
may result from normal usage.
This product is not intended for institutional or commercial use; the manufacturer does not assume
any liability for such use. Institutional or commercial use will void this warranty.
This warranty is nontransferable and is expressly limited to the repair or replacement of the defective
product. During the warranty period, the manufacturer shall repair or replace defective parts at no
cost tothe purchaser. Shipping charges and insurance are not covered and are the responsibility of
the purchaser. Labor charges and related expenses for removal, installation or replacement of the
product or components are not covered under this warranty.
The manufacturer reserves the right to make substitutions to warranty claims if parts are unavailable
or obsolete.
The manufacturer shall not be liable for loss of use of the product or other consequential or incidental
costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of
injury resulting from the use of this product.
This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of
. Neither the manufac-
turer nor any of its representatives assumes any other liability in connection with this product.
All warranty claims must be made through the retailer where the product was originally
purchased. A purchase receipt or other proof of date of purchase will be required to process
all warranty claims. The model number and part numbers found within the assembly
instructions will be required when submitting any parts requests or warranty claims.
For further warranty information or inquiries, please call 800-759-0977

NG2237BL
Ver. 0118
JEU DE BASKET-BALL
ÉLECTRONIQUE HOOPS DUAL
INSTRUCTIONS D’ASSEMBLAGE
Contactez notre
service à la clientèle au
800-759-0977
avec des questions sur le montage
ou l'utilisation de ce produit.

2
MERCI!
Merci d’avoir acheté notre produit. Nous travaillons 24 heures sur 24, partout dans le monde, à garantir
que nos produits sont de la meilleure qualité possible. Toutefois, dans les rares cas de problèmes lors
du montage ou de l'utilisation de ce produit, se il vous plaît communiquer avec notre service à la clientèle
au 800-759-0977 pour une aide immédiate avant de contacter votre revendeur. Pour obtenir de plus amples
renseignements, veuillez lire l'information relative à la garantie au verso de ce guide d’instructions.
ENTRETIEN ET USAGE
1. Ce produit doit être utilisé À L’INTÉRIEUR seulement.
2. NE JAMAIS déplacer le jeu en la traînant, cela pourrait endommager les pieds.
INSTRUCTIONS D’ASSEMBLAGE
1. Trouver une surface propre et plane, pour commencer le montage de votre table de jeu. La table
s’assemble à l’envers pour être ensuite retournée sur ses pieds, une fois l’assemblage complété.
Cette table est lourde et nécessite au moins deux adultes forts pour la soulever et la retourner.
2. Retirez le contenu de la boîte, avant de commencer l’assemblage, assurez-vous d’avoir toutes
les pièces telles que listées et illustrées au tableau d’identification. Avis : certaines pièces sont
préassemblées ou préinstallées.
3. Certaines illustrations ou dessins peuvent ne pas ressembler au produit que vous avez acheté.
4. Quand vous fixez en place une pièce avec plus d’une vis ou écrou, veuillez, en premier, les
visser à la main et terminer la fixation avec un tournevis ou une clé.
5. Un tournevis électrique peut être utile lors de l’assemblage, mais veuillez le régler à basse torque
et l’utiliser avec prudence; si la torque est trop élevée, la vis peut se défaire ou être trop serrée.
AVERTISSEMENTS!
LIRE TOUTES LES INSTRUCTIONS D’ASSEMBLAGE ET LES CONSIGNES DE SÉCURITÉ ATTENTIVEMENT.
RISQUE D’ÉTOUFFEMENT – CERTAINS ÉLÉMENTS DU PRODUIT CONTIENNENT
DE PETITES PIÈCES - NE CONVIENT PAS À UN ENFANT DE MOINS DE TROIS ANS.
IMPORTANT! VEUILLEZ LIRE, EN ENTIER, TOUTES LES
INSTRUCTIONS AVANT D’ASSEMBLER VOTRE PRODUIT.

3
JEU DE BASKET-BALL ÉLECTRONIQUE - NG2237BL
liste des pièces
3
HOME VISITOR
TIME
910 11 12
13 14 15 16
Interrupteur Le boîtier de commande avec fil
Marqueur électronique
2 3 4
x2 x2 x1 x1
6 7 85
x2 x2 x1
x1 x2 x1 x1
x6
x2
x1
x2
Panier
18 19 20
Pompe à air avec aiguille
Panneau de support pour panier
x1
x1
21
Panneau arrière
x1
Rondelle 6 mm
22
x64
23
Boulon 6 mm x 20mm
24
x16
25
Boulon 6 mm x 41mm
x8
Boulon 6 mm x 50mm
26
x4
Boulon 6 mm x 68mm
27
x2
Écrou M6
28
x32
29
Vis M3 5 x 10mm
x4
Tableau électronique
30
x1
Ballon de basket
31
Clé anglaise
32
x1
17
x2
x2
Tube l arrière supérieur Tube arrière centre Tube arrière inférieur - gauche Tube arrière inférieur - droite
1NGP56201
NGP6034
NGP56222
NGP2122
NGP56251
NGP56221
NGP56271
NGP56211
NGP56272
NGP56261
NGP56302
NGP56291
NGP2217
NGP56301
NGP5644
NGP56231
NGP5637
NGP6038
NGP6037
NGP56361 NGP56421*NGP56421*
NGP56421* NGP56421*
NGP56421*
NGP56421*
NGP6042 NGP56421*NGP56431**
Tube d’assemblage Tube centre Tube centre supérieur Tube centre centre - droite
Tube centre centre - gauche Base Tube avant - droite Tube avant - gauche
x2 x1
NGP56331 NGP56321
Tube de support Tube u de pente
Boulon 6 mm x 45mm
x2
NGP56421*
Charnière
SEULEMENT
NGP56311
Charnière
SEULEMENT
NGP56312
*Pièces incluses dans le sac de quincaillerie NGP56421
**Article inclus avec marqueur électronique, NGP2122
01/18 Pour commander les pièces de remplacement,
veuillez téléphoner au 1 800 759-0977

4
33 34 35
Panier Adaptateur secteur
A1
x2 x1
A3
X2
Outils requis
• Clé - incluse
• Clé hexagonale - incluse
x1
NGP56421*
Clé hexagonale
liste des pièces (suite)
A2
NGP56411
NGP5637
36
Filet de retour de ballon
x1
NGP56351 37
JEU DE BASKET-BALL ÉLECTRONIQUE - NG2237BL
Plastique Pôle Insertion Patin de pied
x2 x4
x2
Pre-installed
Attache de sécurité
Pre-installed
Pre-installed
Attache à ressort
x12
Pre-installed
*Pièces incluses dans le sac de quincaillerie NGP56421
Pour commander les pièces de remplacement,
veuillez téléphoner au 1 800 759-0977
Outils électriques –
régler à basse vitesse
Haute vitesse –
trop serré
Deux adultes sont requis
pour la manipulation Ne pas laisser un enfant dans la zone d’assemblage
L’utilisation d’un tournevis électrique peut être utile pendant
l’assemblage; toutefois, réglez-le à une basse vitesse et
soyez extrêmement prudent.
AVERTISSEMENT!
Tenir loin des animaux Ne pas l’utiliser ou
l’entreposer à l’extérieur.
Pour usage à l’intérieur seulement.
Éviter les endroits
mouillés et humides.
01/18
