Hathaway Ventura BG50352 User manual

BG50352
Please Do Not Hesitate to
Contact Our Consumer Hotline
at 800-759-0977
with Any Questions That May
Arise During Assembly or
Use of This Product!
Ver. 02/20
VENTURA 55-IN. FOOSBALL TABLE
WITH ELECTRIC DART BOARD
ASSEMBLY INSTRUCTIONS

2
THANK YOU!
Thank you for purchasing this product. We work around the clock and around the globe to ensure
that our products maintain the highest possible quality. However, in the rare case of issues during
assembly or use of this product, please contact our Consumer Hotline at 800-759-0977for immediate
assistance before contacting your retailer. Please read the warranty information at the back of these
assembly instructions for further details.
CARE AND USE
ASSEMBLY TIPS
1. Find a clean, level surface to begin the assembly of your game table. We recommend that two adults
work together to assemble this game. You may want to carefully cut or tear the four corners of the box
so that the bottom of the box can be used as your work surface.
2. Remove all of the contents from box and verify that you have all of the parts shown on the Parts
List before you begin assembly. Note: Some parts may be pre-installed or pre-assembled.
3. Some figures or drawings may not look exactly like product.
4. When installing parts that have more than one screw orbolt, hand tighten all screws orbolts
in place before final tightening with screwdriver orwrench.
5. Electric screwdrivers may be helpful during assembly; however, please set a low torque and use
extreme caution because screws may be stripped or overtightened, resulting in damaged parts, if the
electric screwdriver’s torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY.
CHOKE HAZARD - THIS ITEM MAYCONTAIN SMALL BALLS AND PARTS
NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
1. This product is intended for INDOOR use ONLY.
2. Do NOT sit on table, or drag table when moving, as this will damage the legs. Do NOT lift table by rods.
4. Keep table covered when not in use. Remove dust on play surface and cabinet with vacuum or wipe
with a clean, soft cloth.
5. Occasionally wipe the rods with a clean, soft cloth and make sure the players are tight.
6. Do NOT spin rods too aggressively, as this may cause damage. We recommend the use of 100%
silicon to periodically lubricate the bushings, but from the outside of the table so you don’t drip on playfield.

3
Parts List
VENTURA 55-IN. FOOSBALL TABLE - BG50352
2/20 For replacement parts please call 800-759-0977.
Illustrations Not to Scale
PARTS
12 3 4 5 6 7 NGP7490
17
X13
ROD WASHER
X13
BLUE PLAYER
HARDWARE PACK - NGP7625
11 X6 21 X26 22 X26 27 X8
28 X8 29 X16
X4
X2
END PANEL
13
X3
1/4” x 720mm
SUPPORT ROD
NGP7500
NGP7505
X16
ROD BUMPER
X8
ROD HANDLE ROD END CAP
1/4” NUT M4 x 28 mm BOLT M4 NUT
31
X16
20
X3
LEFT LEG
12
18A
LEG PANEL B
NGP7501
X2
SIDE PANEL
89
X1
PLAYFIELD
10
X2
GOAL BOX
15 NGP7506
X2
RIGHT LEG
16
18B 19 NGP7504
BALL ENTRY CUP
SUPPORT BRACE
LEG PANEL A
RED PLAYER
1/4” x 1-1/2” BOLT 1/4” WASHER
5/16” WASHER
5/16” x 2-5/8” BOLT
X20
NGP7600 NGP7796 NGP7614 NGP7617
NGP7620
NGP7619
NGP7618
NGP7621
NGP7616
NGP7615
NGP7622
NGP7623 NGP7624
NGP7499
33 X8
34 X6
ALLEN WRENCH
F3.5 x 45 mm
SCREW
NGP7626
LEG LEVELER
14 X2
X4 X2
X8
X16
X2
X1
X2
32
NGP5102
X2
SOCCER BALL
3 PLAYER ROD
2 PLAYER ROD
SLIDE SCORER
2423 NGP7507
25 26
X2 X2
X2 X4
5 PLAYER ROD
30
T3.5 x 25 mm
SCREW
T3.5 x 45 mm
SCREW
T3.5 x 12 mm
SCREW

4
ASSEMBLY INSTRUCTIONS
1.
2.

5
ASSEMBLY INSTRUCTIONS (CONT.)
4.
3.

6
ASSEMBLY INSTRUCTIONS (CONT.)
5.
6.

NOTE: Two adults are required to turn table upright. Turn over using main table body only, NOT legs,
and place on all four feet on ground at same time.
AWAY HOME
7
ASSEMBLY INSTRUCTIONS (CONT.)
7.
Insert rod end part way through
one side panel, then place rest of
parts needed on each rod, in order
shown, before inserting through
other side panel.

NOTE: Handle (19) attaches to rod end with
hole and Rod End Cap (20) goes on opposite
end. Each team should face the opposite
goal and all be the same color.
See diagram for rod and player positions.
8
ASSEMBLY INSTRUCTIONS (CONT.)
8.
9.

9
180-DAY LIMITED WARRANTY
This product is warranted to the original purchaser to be free from defects in material or workmanship
for a period of 180 days from the date of the original retail purchase.
This warranty does not cover defects or damage due to improper installation, alteration, accident or
any other event beyond the control of the manufacturer. Defects or damage resulting from misuse,
abuse or negligence will void this warranty. This warranty does not cover scratching or damage that
may result from normal usage.
This product is not intended for institutional or commercial use; the manufacturer does not assume
any liability for such use. Institutional or commercial use will void this warranty.
This warranty is nontransferable and is expressly limited to the repair or replacement of the defective
product. During the warranty period, the manufacturer shall repair or replace defective parts at no
cost tothe purchaser. Shipping charges and insurance are not covered and are the responsibility of
the purchaser. Labor charges and related expenses for removal, installation or replacement of the
product or components are not covered under this warranty.
The manufacturer reserves the right to make substitutions to warranty claims if parts are unavailable
or obsolete.
The manufacturer shall not be liable for loss of use of the product or other consequential or incidental
costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of
injury resulting from the use of this product.
This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of
. Neither the manufac-
turer nor any of its representatives assumes any other liability in connection with this product.
All warranty claims must be made through the retailer where the product was originally
purchased. A purchase receipt or other proof of date of purchase will be required to process
all warranty claims. The model number and part numbers found within the assembly
instructions will be required when submitting any parts requests or warranty claims.
For further warranty information or inquiries, please call 800-759-0977
