Havis DS-PAN-1200 Series User manual

Owner’s Manual
Havis Docking Station
For Panasonic Toughbook 33 Tablet
DS-PAN-1200 Series
DS-PAN-1201
DS-PAN-1201-2
DS-PAN-1202
DS-PAN-1202-2
DS-PAN-1203
DS-PAN-1204
DS-PAN-1204-2
DS-PAN-1205
DS-PAN-1205-2
DS-PAN-1206
DS-PAN-1200-SERIES_OMN_4-18
Havis, Inc.
75 Jacksonville Road
Warminster, PA 18974

Before Beginning
Havis is pleased to provide this Owner’s Manual to aid in the proper installation and use of the
DS-PAN-1200 Series Docking Station for the Panasonic Toughbook 33 Tablet.
For questions regarding the set-up of your DS-PAN-1200 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional product support and information.
This Owner’s Manual applies to the following Part Numbers:
DS-PAN-1201
DS-PAN-1201-2
DS-PAN-1202
DS-PAN-1202-2
DS-PAN-1203
DS-PAN-1204
DS-PAN-1204-2
DS-PAN-1205
DS-PAN-1205-2
DS-PAN-1206
•NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE AIRBAG DEPLOYMENT ZONE.
•DO NOT USE COMPUTER WHILE DRIVING.
•NE JAMAIS RANGER OU INSTALLER LA STATION D'ACCUEIL DIRECTEMENT DANS LA ZONE DE DÉPLOIEMENT DES COUSSINS
GONFLABLES D'UN VÉHICULE.
•NE PAS UTILISER L’ORDINATEUR EN CONDUISANT.
•READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
•DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE, STEAM, DUST, ETC. ARE
PRESENT
•DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR UNDOCKING WITH YOUR
COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES CAN CAUSE PERMANENT DAMAGE.
•FOR THE DS-PAN-1201, DS-PAN-1201-2, DS-PAN-1202, DS-PAN-1202-2, DS-PAN-1204, DS-PAN-1204-2, DS-PAN-1205, &
DS-PAN-1205-2 DOCKING STATIONS: DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product requires a
certified, automotive grade, Panasonic approved 120W power source rated for a continuous, regulated 15.6VDC output
(Havis Part Number LPS-103 or equivalent). Failure to comply with this requirement will cause product damage that is
NOT repairable and is NOT covered under warranty.
•FOR THE DS-PAN-1203 & DS-PAN-1206 DOCKING STATIONS: DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE:
The Panasonic Toughbook 33 requires a certified, Panasonic approved power source rated for a continuous, regulated
15.6VDC output. Failure to comply with this requirement will cause product damage that is NOT repairable and is NOT
covered under warranty.
•LIRE ATTENTIVEMENT TOUTES LES INSTRUCTIONS AVANT DE COMMENCER L'INSTALLATION.
•NE PAS ENTREPOSER, INSTALLER OU UTILISER LA STATION D'ACCUEIL DANS UN ENDROIT OÙ DE L'EAU, DE L'HUMIDITÉ, DE LA
VAPEUR,DE LA POUSSIÈRE, ETC. SONT PRÉSENTES
•NE CONNECTEZ OU DÉCONNECTEZ PAS VOTRE ORDINATEUR S'IL N'EST PAS ÉTEINT. LA MISE EN MARCHE OU L'ARRÊT DE VOTRE
ORDINATEUR EN MODE MARCHE, VEILLE, HIBERNATION OU SOMMEIL PEUT CAUSER DES DOMMAGES PERMANENTS.
•POUR LES STATIONS D'ACCUEIL DS-PAN-1201, DS-PAN-1201-2, DS-PAN-1202, DS-PAN-1202-2, DS-PAN-1204, DS-PAN-1204-2,
DS-PAN-1205, & DS-PAN-1205-2 NE PAS CONNECTER DIRECTEMENT ÀLA SOURCE DE TENSION DU VÉHICULE : Ce produit
nécessite une source d'alimentation de 120 W certifiée de qualité automobile approuvée par Panasonic et conçue pour une
sortie continue et régulée de 15,6 VDC (numéro de pièce Havis LPS-103 ou équivalent). Le non-respect de cette exigence
entraînera des dommages au produit qui ne sont PAS réparables et qui ne sont PAS couverts par la garantie.
•POUR LES STATIONS D'ACCUEIL DS-PAN-1203 ET DS-PAN-1206 : NE PAS CONNECTER DIRECTEMENT ÀLA SOURCE DE TENSION
DU VÉHICULE : Le Toughbook 33 de Panasonic nécessite une source d'alimentation certifiée et approuvée par Panasonic pour
une sortie continue et régulée de 15,6 VDC. Le non-respect de cette exigence entraînera des dommages au produit qui ne sont
PAS réparables et qui ne sont PAS couverts par la garantie.
•FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY (DS-PAN-1202, DS-PAN-1202-2,
DS-PAN-1205, DS-PAN-1205-2, & DS-PAN-1206) REFER TO THE SUPPLIED LIND POWER SUPPLY REFERENCE
GUIDE.
•WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN 0°C to 50°C (32°F to 122°F).
PLEASE REFER TO PANASONIC TOUGHBOOK 33 OWNER’S MANUAL FOR MORE INFORMATION.

Before Beginning
Precautions/Précautions
•Do not place metal objects or containers of liquid on top of the Docking Station
•If a malfunction occurs, immediately unplug the Power Supply and remove the laptop
•Use only the specified Power Supply (Part # LPS-103) with this Docking Station
•Do not connect cables into ports other than what they are specified for
•Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F) for a long period of time
•Ne placez pas d'objets métalliques ou de contenants avec des liquides sur la station d'accueil
•En cas de dysfonctionnement, débranchez immédiatement l'alimentation électrique et retirez l'ordinateur portable
•Utilisez uniquement l'alimentation électrique spécifiée (partie # LPS-103) avec cette station d'accueil
•Ne pas connecter les câbles dans des ports autres que ceux spécifiés
•Ne laissez pas la station d'accueil dans un environnement àtempératur élevée (plus de 85°C, 185°F) pendant une longue période
Specifications
Power Supply Input 15.6V DC-In
Dimensions 11.83” (30.00 cm) H x 12.88” (32.70 cm) W x 3.50” (8.89 cm) D
Weight 3.08 lbs. (1.40 kg)
Operating Environment -10°C to 50°C (14°F to 122°F)
Storage Environment -20°C to 60°C (-4° F to 140°F)
EC DECLARATION OF CONFORMITY in accordance with EN 50498
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Panasonic Toughbook 33 Tablet Only
Model: DS-PAN-120X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
Automotive EMC Directive EN 50498:2010, Electromagnetic compatibility (EMC) -
2004/108/EC: Product family standard for aftermarket electronic equipment in vehicles
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the Automotive EMC Directive 2004/108/EC, Annex I, 6.5, 6.6, 6.8, and 6.9. This product requires the
use of a recommended e-Marked automotive power supply when used within vehicles.
Warminster, PA, USA December 20, 2017 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modifications to the model DS-PAN-120X not expressly
approved by Havis, Inc. could void the user's authority to operate this equipment.

Parts Included
Latch Hook
Alignment Posts
Barrel Lock
Docking Connector
Ground Pins (x2)
Docking Station
Power Cable Stain Relief
Strain Relief Points
Mounting Holes
VESA 75, and
RAM 2.25” Ball
(3-hole 120°pattern)
Ports

Parts Included (continued)
Hardware Kit (HWK-0031)
This Hardware Kit includes:
1. Zip Ties (4)
2. Keys (2)
3. M4 x 0.7 x 20mm long Pan Head Screws (5)
4. Split Lock Washers (5)
5. Washers, M4 (5)
Tools required for installation:
• #2 Phillips (For M4 Pan Head Screws)

Antenna Identification
DS-PAN-1201-2, DS-PAN-1202-2, DS-PAN-1204-2, DS-PAN-1205-2
• HAVIS ANTENNA A
• HAVIS ANTENNA B
Antenna Connectors (TNC) Tablet Interface
Toughbook 33 Tablet




B
B
B
A
A
A

Port Replication Capability
Rearward Facing Ports
DS-PAN-1201, DS-PAN-1201-2, DS-PAN-1202, DS-PAN-1202-2
Rearward Facing Ports
DS-PAN-1204, DS-PAN-1204-2, DS-PAN-1205, DS-PAN-1205-2
Forward Facing Ports
DS-PAN-1201/1201-2/1202/1202-2/1204/1204-2/1205/1205-2
External Antenna Switch
DISABLED / ENABLED
Ethernet
RJ45 (x2)
USB 2.0 (x2)
USB 3.0 (x2)
Serial Antenna (TNC)
Optional: Part IDs
DS-PAN-1201-2
DS-PAN-1202-2
Power Input
External Antenna Switch
DISABLED / ENABLED
Ethernet
RJ45 (x2)
USB 2.0 (x2)
USB 3.0 (x2)
Serial Antenna (TNC)
Optional: Part IDs
DS-PAN-1204-2
DS-PAN-1205-2
Power Input VGAHDMI
USB 2.0 (x2)

Installation
1) Align Docking Station mounting holes with the hole pattern on mounting device. Using the
four (4) M4 0.7 x 20mm Pan Head Screws (Hardware Kit Item 3), four (4) Washers, M4
(Hardware Kit Item 4), and four (4) Lock Washers, M4 (Hardware Kit Item 5), secure the
Docking Station to device. Torque screws to 20 in-lbs (2.3Nm) ±10%
A) Havis Desktop Stand installation (sold separately, Part # DS-DA-218).
B) In-Vehicle mounting system installation (not included).
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4
Desktop Stand
(VESA 75 mm)
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4

Cable Management
1) Tip the Docking Station to a position that is comfortable to work with.
2) Install all cables that are necessary for computing needs.
3) Use Zip Ties (Hardware Kit Item 1) and the Strain Relief Points to secure cables and reduce risk of
accidental disconnects.
4) Create a service loop with cables to ensure that no tension is on the connectors and to enable
intended motion.
5) Tie off cables onto a stationary part of the mounting system.
4
5
This loop must be large enough to allow
full range of expected rotation and
extension without stressing connections.
Collect cables to secure to the
mounting system.
(Note: mounting system not included)

Operation - Docking
1) Docking Station must be unlatched before docking your tablet. Push down on the Barrel Lock button
and release slowly.
DO NOT FORCE TABLET ONTO DOCKING STATION. IF THERE IS RESISTANCE, CHECK ALIGNMENT OF TABLET ON DOCKING STATION.
NE PAS FORCER L'ORDINATEUR PORTABLE SUR LA STATION D'ACCUEIL. S'IL Y A DE LA RÉSISTANCE, VÉRIFIER L'ALIGNEMENT DE
L'ORDINATEUR PORTABLE SUR LA STATION D'ACCUEIL
.
NOTE: Ensure a proper connection by aligning the tablet’s
Alignment Sockets with the Docking Station’s Alignment Posts
Alignment Posts on the
DS-PAN-1200 Series Docking Station
Alignment Sockets on the bottom of
Panasonic Toughbook 33 Tablet
Latched Unlatched

Operation - Docking (continued)
2) Hold tablet in landscape orientation, with bottom mounted docking connector angled toward Docking
Station. Lower tablet into the bottom of the Docking Station.
3) Pivot tablet so it sits flush in the Docking Station and hold while depressing the Latch Handle to secure
tablet in place. You will hear an audible click when Latch Hook is fully engaged.
4) For theft deterrence, secure tablet by locking Docking Station with supplied key (Hardware Kit Item 2).

Operation - Undocking
1) If previously locked, unlock Docking Station using supplied key.
2) Secure tablet to avoid inadvertent ejection from Docking Station. Push down on the Barrel Lock button
and release quickly taking care not to obstruct the travel of the Latch Hook. If the Latch Hook does not
extend fully to its unlatched position, lift up lightly on the front of the Latch Hook to fully release.
3) Once unlatched grab both sides of tablet, rock the top forward and carefully lift out of Docking Station,
top end first.

Related Products
Havis offers a wide variety of accessory products specifically for use with your Docking Station.
For more information or to order, please visit www.havis.com.
LPS-103
120W Power Supply
External in-vehicle power supply and cable for Panasonic
Tougbook 33 with cigarette lighter adaptor.
LPS-211
Power Supply Mounting Bracket
Mount a power supply directly to your Universal Cradle with this
versatile bracket.
DS-DA-103
Stylus Holder
Secure a wide array of styluses to your Docking Station.
DS-DA-306
Replacement Power Supply Output Cable
Replacement yellow tip output cable for the LPS-103 power
supply for DS-PAN-1200 Series Docking Stations.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations for use in
the home or office.
DS-DA-502
Replacement Keys
Set of two (2) replacement keys for DS-PAN-1200 Series
Docking Stations.
