Havis DS-GTC-7X0 Series User manual

Owner’s Manual
Havis Docking Station
For Getac Z710 & ZX70 Rugged Tablets
www.havis.com
1-800-524-9900
DS-GTC-711
DS-GTC-711-2
DS-GTC-703
DS-GTC-703-2
DS-GTC-714
DS-GTC-714-2
DS-GTC-715
DS-GTC-715-2
DS-GTC-716
DS-GTC-716-2
DS-GTC-7X0 Series

DS-GTC-711
DS-GTC-711-2
DS-GTC-703
DS-GTC-703-2
DS-GTC-714
DS-GTC-714-2
DS-GTC-715
DS-GTC-715-2
DS-GTC-716
DS-GTC-716-2
Before Beginning (Original Instructions)
2
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-GTC-7X0 Series Docking Station for
the Getac Z710 & ZX70 Rugged Tablets.
For questions regarding the set-up of your DS-GTC-7X0 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
• DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE,
STEAM, DUST, ETC. ARE PRESENT
• DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR
UNDOCKING WITH YOUR COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES
CAN CAUSE PERMANENT DAMAGE.
• FOR THE DS-GTC-711, DS-GTC-711-2, DS-GTC-714, DS-GTC-714-2, DS-GTC-715,
DS-GTC-715-2 DOCKINGS STATIONS: DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE
source rated for a continuous, regulated 12DC output (Havis Part Number LPS-164 or
equivalent). Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
• FOR DS-GTC-703, DS-GTC-703-2, DS-GTC-706, DS-GTC-706-2 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Getac Z710/ZX70 tablet
output. Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY
REFER TO THE SUPPLIED GETAC POWER SUPPLY REFERENCE GUIDE.
• WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN
0°C to 50°C (32°F to 122°F).
PLEASE REFER TO GETAC Z710/ZX70 OWNER’S MANUAL FOR MORE INFORMATION.

Table of Contents
3
Parts Included
Port Replication Capability
Installation
Cable Management
Operation - Docking
Operation - Undocking
3
4
5
5
6
7
8
10
• Donot place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the tablet
(Part # LPS-164)with this Tablet
• Donot leave theDocking Station in ahigh temperature environment (greater than 70°C, 158°F)
for along period of time
Precautions
Power Supply Input 12.0 V DC-In
Dimensions 8.7” ( 22.1 cm) H x 9.2” ( 23.4 cm ) W x 2.9” ( 7.4 cm ) D
Weight 1.5 lbs ( 0.68 kg )
Operating Environment -20° C to 50° C ( -4° F to 122°F )
Storage Environment -40° C to 70° C ( -40° F to 158° F )
FCC 47CFR, Part 15 compliance:
to the model DS-GTC-7XX not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
EC DECLARATION OF CONFORMITY
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Product name: Tablet Docking Station
Model: DS-GTC-7XX, where ‘x’ may be any alphanumeric character and which describes product options.
(Object of Declaration) May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following directives, standards, or other normative documents:
EMC Directive 2014/30/EU EN 55022::2010/AC:2011
EN 55024:2010
RoHS Directive 2011/65/EU EN 50581:2012
The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the
Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
Supplementary Information:
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation.
Signed for and on behalf of Havis, Inc.:
Warminster, PA, USA June 10, 2014 Bruce Jonik, Director of Engineering , Havis, Inc.

4
Hardware Kit
Docking Station
Parts Included
(Optional, Part #s
DS-GTC-711-2/713-2/
714-2/715-2/716-2)
(DS-GTC-711/711-2)
(DS-GTC-714/714-2)
(DS-GTC-715/715-2)

5
Port Replication Capability
(DS-GTC-711-2, DS-GTC-712-2, DS-GTC-703-2, DS-GTC-714-2, DS-GTC-715-2)
In reference to the GETAC Z710 & ZX70 Antenna connections
Full Port Replication (JAE Connector Only)
(DS-GTC-711, DS-GTC-711-2)
Antenna Connectors (SMA)
(Optional - DS-GTC-711-2)
Power InputHDMISpeakerUSB 2.0
(x2)
SerialEthernet
(RJ45)
Lite Port Replication (POGO Connector Only)
(DS-GTC-714, DS-GTC-714-2)
Power InputSpeakerUSB 2.0
(x2)
SerialEthernet
(RJ45)
Antenna Connectors (SMA)
(Optional - DS-GTC-714-2)
Power Only Port Replication (POGO Connector Only)
(DS-GTC-715, DS-GTC-715-2)
Power InputSpeaker Antenna Connectors (SMA)
(Optional - DS-GTC-715-2)
Antenna Connectors (SMA) Tablet Interface
ANT. A ANT. B
Z710 WWAN GPS
ZX70 WWAN GPS

6
Installation
1) Align Docking Station mounting holes with the holes on VESA 75mm
hole pattern device. Using the four (4) M4 x 0.7x12mm Pan Head Screws
(Hardware Kit Item 3), four (4) Washers, M4 (Hardware Kit Item 4), and four (4)
Lock Washers, M4 (Hardware Kit Item 5), secure the Docking Station to device.
Torque screws to 20 in-lbs (2.3Nm) ± 10%.
A) Havis Desktop Stand installation (sold seperately, Part # DS-DA-218).
B) In-Vehicle mounting system installation.
Desktop Stand
(VESA 75 mm)
M4 x 0.7x12mm
Pan Head Screws
Lock Washer, M4
Washer, M4
Washer, M4
M4 x 0.7x12mm
Pan Head Screws
Lock Washer, M4

www.havis.com • 1-800-524-9900 7
This loop must be large enough
to allow full range of expected
rotation and extension without
stressing connections.
Collect cables and secure
to the mounting system.
(Note: Mounting system not included)
Cable Management
1) Tip the Docking Station to a position that is comfortable to work with.
2) Connect all cables that are necessary for computing needs.
3) Use Zip Ties (Hardware Kit Item 1) to strain relieve cables. Strain Relief Points
are located on the bottom and sides of Docking Station and should be used
to anchor each cable.
4) Create a service loop with cables to ensure that no tension is on the
connectors and to enable intended motion.
5) Tie off cables onto a stationary part of the mounting system.
Use as many zip ties as
necessary to secure cables.

8
Operation - Docking
1) Ensure Docking Station is unlatched by lifting Latch Handle.
DO NOT FORCE TABLET ONTO DOCKING STATION.IF THERE IS RESISTANCE,
CHECK ALIGNMENT OF TABLETON DOCKING STATION.
NOTE: Ensure a proper connection by aligning the tablet’s
Alignment Sockets with the Docking Station’s Alignment Posts
Alignment Posts
DS-GTC-7X0 Series Docking Station
Alignment Sockets
Bottom of Getac Z710 Rugged Tablet

Latch Tab will engage
in front of your tablet
9
Operation - Docking
2) Hold tablet in landscape orientation, and guide into the Docking Station.
Next, lower tablet into the bottom of the Docking Station, while ensuring
that the alignment sockets are aligned with the Docking Station’s
Alignment Posts.
3) When tablet is properly seated in the Docking Station, lower the Latch
Handle to secure tablet in place.
If there is excessive force while
lowering the Latch Handle, check
orientation and position of tablet

10
Operation - Docking (continued)
Operation - Undocking
1) If previously locked, unlock Docking Station using supplied key.
2) While holding tablet with one hand, lift the Latch Handle on the top
of Docking Station.
3) Once unlatched grab both sides of tablet, carefully lift tablet up and out
of Docking Station.
4) For theft deterrence, secure tablet by locking Docking Station with
supplied key (Hardware Kit Item 2).

www.havis.com • 1-800-524-9900 11
Related Products
with the DS-GTC-7X0 Series Docking Station. For more information or
to order, please visit www.havis.com.
LPS-164
40W Getac Power Supply for DS-GTC-710 Docking Stations
External in-vehicle power supply and cable for Getac Z710/ZX70
Rugged Tablets with cigarette lighter adaptor.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations
for use in the home or office.
DS-DA-503
Replacement Keys
Set of two (2) replacement keys for DS-GTC-700
Series Docking Stations.
DS-DA-801
Screen Blanking Solution
Powered by Blank-it, USB dongle manages In-vehicle
computer displays and prevents driver distraction.
LPS-213
Accessory Bracket for Panel Mounting LPS-164 Power Supply
Replacement bracket for panel mounting a Getac power supply
