Hawking CS140 User manual

CS140
The Ideal SOHO KVM Switch
Solution
§Excellent for Small Office and Home Office
§Compatible with most Operating Systems
§Compatible with most keyboards, monitors
and mice
§Free Technical Support
Control 4 Computers with a Single
Keyboard, Monitor and Mouse
Control four PCs or Servers with one Keyboard,
Monitor and Mouse using the Hawking CS140
KVM Switch. Installation is effortless. There is no
software to configure no repetitive installation
routines and compatibility issues are non-
existent. It works with any hardware platform
and with all operating systems.
The CS140 saves space and money by reducing
the number of peripherals and accessories
needed in your work environment. It also
eliminates the inconvenience of having to move
between 4 computers. The CS140 is the perfect
solution for Small Office and Home Office
environments needing cost effective ways to
control multiple PCs.
The Benefits of USB KVM Switch
•4Computers Share a singlePS2 Keyboard,
PS2 Mouse and Monitor.
•Easy to install and use, No software required.
Use standard PS2/VGA cables connect all
the computers.
•Easy to operate, computer selection viapush
button switch and Hot Key.
•Wall-Mountable for Space Saving.
•Saves time, space, power, and equipment
costs.

Package Contents:
§One four port Mini KVM Switch
§Easy to follow users manual
Systems Requirement:
Console
•One VGA, SVGA or Multisync Monitor, which
meets the minimum resolution, required of
both systems in the installation.
•One standard two button PS/2 Mouse
•One PS/2 style Keyboard or AT style
Keyboard with adapter.
Computer
•One VGA, SVGA or Multisync card.
•Either a 6-pin mini-DIN (PS/2 style) or DB-9
(serial) mouse port. Either a 6-pin mini-DIN
(PS/2 style) keyboard port with +5V DC on pin
4 and ground on pin 3 or 5-pin DIN (AT style)
keyboard port with +5V DC on pin 5 and
ground on pin 4.
System Support:
Microsoft Windows 95/98/ME/NT/2000
Netware, Linux and More
Ready, Connect & Go!
It's easy to install, it's easy to use! Everyone can
do it.
Step 1 Connect Keyboard, Mouse and Monitor
Plug the Keyboard & mouse and monitor into the
console port connectors of the CS140
Step 2: Connect Computers
Plug PC PS2/VGA ports into the CS140 using
PS2/VGA Cables
Step3 –You can use two easy ways to control
your CS140.
Copyright Hawking Technologies, Inc. 2001. All rights
reserved. All trademarks herein are the property of their
respective owners. Product specification subjects to change
without notice.
Application Note:
Features Benefits
Compact, Mini KVM
Switch Save Time, Space, Power and Equipment
Cost
Compatible with most
Operation Systems Works with Windows 95/98/ME/NT/2000,
NetWare
Compatible with most
standard keyboards,
monitors and two
button mouse
Works with AT, PS/2
keyboard, Microsoft
standard two button
mouse
Hot Key and Push
Button Selection Easy switching using keyboard or push button
Number, caps, scroll
lock key settings are
recalled
Hassle free -you don't
have to worry about
keyboard settings
Specification:
§Power: No Power required
§Accessing PC Number: 4
§PC Selections: keyboard/button
§Keyboard Emulation: PS/2 & AT
§Mouse Emulation: PS/2 & Serial
§LEDs: 4 port status
§VGA Resolution (MAX): 1920x1440
§Scan Interval: 3 seconds
§Console Connectors
oKeyboard: 6-pin mini-Din (F)
oMouse: 6-pin mini-Din (F)
oMonitor: HDB-15 VGA (F)
§PC Connectors
oKeyboard: (4) 6-pin mini-Din
(F)
oMouse: (4) 6-pin mini-Din (F)
oMonitor: (4) HDB-15 VGA (M)
§Enclosure: Plastic
§Weight: 8 oz
§Dimensions (LxWxH): 6 5/8” x 3 3/8” x 1 1/8”
Ordering Information:
CS102U 2-Port USB KVM Switch with Cable
CS142 2-Port PS2 KVM Switch with Cable
CS140 4-Port PS2 KVM Mini Switch
CS144A 4-Port PS2 KVM Switch
CS148 8-Port OSD Rack Mount KVM Switch
CL106P 6ft Premium PS2 KVM Cable
CL110P 10ft Premium PS2 KVM Cable
CL106A 6ft Premium AT/Series KVM Cable
2X001 Foot Switch
2X004 Rack Mount Kit
