10/17 Model 7433FP Page 1 of 4
NO. OOO2076521 (0)
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 7433FP
Eye/Face Wash
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2080048(17)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any goods,
or part thereof, which shall appear to the Company upon inspection to be of defective
material or not of first class workmanship, provided that claim is made in writing to Haws
within a reasonable period after receipt of the product. Where claims for defects are made,
the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS
will not be liable for the cost of repairs, alterations or replacements, or for any expense
connected therewith made by the owner or his agents, except upon written authority from
HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer agrees
that Haws has made no other warranties either expressed or implied in addition to those
above stated, except that of title with respect to any of the products or equipment sold
hereunder and that HAWS shall not be liable for general, special, or consequential damages
claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

10/17 Model 7433FP Page 2 of 4
LOCATION OF UNIT: The Model 7433FP Emergency Eye/Face Wash should be
installed in close proximity to potential accident areas. It should be clearly identified
free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1/2" NPT with 30-90 psi (2-
6 ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1/2" NPT. Waste outlet is 1-1/4"
NPT.
MAINTENANCE: In freezing conditions, wipe eye/face wash head and dust cover
dry after each use to prevent unwanted ice build up.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2.
Insufficient water flow.
2.
a.
Verify minimum 30 psi flowing supply
line pressure.
b.
Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and adapter.
Disassemble adapter to gain access
and clean rubber flow control.
3.
Eye/face wash streams do not
meet desired eye level.
3.
Possible blocked flow control, see
above solution. Possible non-leveled
eye/face wash assembly.
4.
Water does not drain properly.
4.
Check the main waste line of your
building to see if it does handle the
capacity required for the entire
drainage system.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
SP80 BRACKET
SP170
TEST TAG
9095
EYEWASH DUST COVERS
SP175
EYEWASH SIGN
SP11FC
EYEWASH
HEADS
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
CLF
02/24/93
17
0002080048
7433FP EYEWASH
FREEZE RESISTANT
1:1
11
FV 11/23/17
VWC
3 of 4
PARTS BREAKDOWN
5175
2017
VWC
SP402
VALVE ASSEMBLY
SP90 BOWL

206mm
8-1/8"
076mm
FLOOR LINE
OPEN POSITION
3-1/2"
89mm
5/16"
76mm
3"
14-5/8"
371mm
1-1/4" NPT
WALL (NOT SUPPLIED)
SLEEVE CAST INTO
1/2" NPT
WASTE LINE
OPEN POSITION
(NOT SUPPLIED)
1-1/4" IPS
OUTLET
SUPPLY
POSITION
CLOSED
8-1/2"
216mm
346mm
13-5/8" (MAX WALL THICKNESS)
WALL
12"
305 mm
2-5/16"
59mm
5-5/8"
143mm
1/4" IPS PIPE
SLOPE 5° MIN.
FOR DRAINAGE
ROD
5/8"
CLOSED
POSITION
SELF-
DRAINING
VALVE
NOTES:
1. TO COMPLY WITH ANSI Z358.1-2014 FOR EMERGENCY EYEWASH OR EYE/FACE WASH:
EYEWASH OR EYE/FACE WASH SHALL BE POSITIONED SUCH THAT FLUSHING FLUID FLOW PATTERN IS NOT LESS THAN 33"
(838 mm) AND NO GREATER THAN 53" (1346 mm) FROM SURFACE ON WHICH USER STANDS, AND 6.0" (153 mm) MINIMUM FROM
WALL OR NEAREST OBSTRUCTION.
2 HEIGHT IS DETERMINED BY WATER FLOW PATTERN HEIGHT SHOWN, WHICH IN TURN, IS DEPENDENT ON IN-LINE SUPPLY
PRESSURE.
3 VALVE IS SELF-DRAINING. THIS PERMITS STANDING WATER TO DRAIN AFTER EACH USE PREVENTING FREEZE-UPS. PROPER
PROVISIONS MUST BE MADE FOR DRAINAGE.
4. WHEN INSTALLING THIS UNIT, LOCAL , STATE, OR FEDERAL CODES SHOULD BE ADHERED TO FOR INSTALLATION DIMENSIONS
(LOCATIONS), WASTE AND SUPPLY REQUIREMENTS OTHER THAN SHOWN.
5. DIMENSIONS MAY VARY BY ± 1/2 [13].
6-7/8"
175mm
2-3/4"
70mm
Ø
3X
MOUNTING
HOLES
(MOUNTING
HARDWARE
NOT SUPPLIED)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
TRF
05/16/91
17
0002080048.D
7433FP EYEWASH
FREEZE RESISTANT
1:1
11
FV 11/23/17
VWC
4 of 4
INSTALLATION
5175
2017
VWC
33"-53"
838mm-1346mm
FLOW PATTERN
(SUPPLIED)
(1-3/4")
O.D.
3
2
HEATED AREA
