Haws 8309WC User manual

10/17 Model 8309WC Page 1 of 5
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
No. 2067461(21)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged
by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing to
Haws within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection.
HAWS will not be liable for the cost of repairs, alterations or replacements, or for any
expens
e connected therewith made by the owner or his agents, except upon written
authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by
defective materials or poor workmanship, except for replacements, as provided above.
Buyer agrees that Haws has made no other warranties either expressed or implied in
addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL, PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
Model 8309WC Barrier Free
Shower & Eye/Face Wash
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS

10/17 Model 8309WC Page 2 of 5
LOCATION OF UNIT: The Model 8309WC Barrier Free Emergency Shower should
be installed in close proximity to potential accident areas. It should be clearly
identified, free
from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1-1/4” IPS with 30-90 psi
(2-6 ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet
recommended.
PLUMBING CONNECTIONS: Inlet supply is 1-1/4” IPS. Waste outlet is 1-1/4” IPS.
INSTALLATION PROCEDURE
Refer to Installation drawing for parts list to insure all required parts are included. Use
pipe joint sealant PST #565 (clarification. Check Loctite) on all connections.
STEP 1: Prepare the emergency shower foundation by using the floor flange
assembly as a template. Locate the three holes for the 3/8-16 UNC x 6"
anchor bolts (not supplied). They should extend 1" above the floor level.
STEP 2: Once the concrete foundation is ready (dry), assemble the floor flange
assembly to the anchor bolts; then securely fasten with 3/8-16 UNC Hex
Nuts and 3/8" washers (not supplied). Seal and tighten floor flange and tee
making certain the waste tee is facing the proper location and the foot
control holes are facing side to side.
STEP 3: Assemble nipple (1-1/4” x 19”) to the floor flange assembly and tighten
with a pipe wrench.
STEP 4: Assemble the eyewash loop assembly to the 19” nipple from step three.
Connect the pipe wrench to the galvanized nipple between the two tees to
avoid damage.
STEP 5: Assemble in the following order:
Attach nipple (1-1/4” x 28-3/4”) and tee (1-1/4”) onto the loop assembly.
Attach nipple (1-1/4” x 25”) onto the tee.
Attach tee (1-1/4” x 1-/14” x 1”) onto nipple.
Attach valve assembly onto tee.
Assemble the street elbow (1”) onto nipple (1” x 21”).
Attach nipple onto valve.
STEP 6: Assemble showerhead onto street elbow (1”).
STEP 7: Assemble the sign onto the unit. Use the strap, screws, washers and nuts
provided, to mount the sign onto the upright. The sign should be
positioned for maximum visibility.
STEP 8: Insert the galvanized plug into the optional supply line tee that is not used.
Before connecting the supply water line to the emergency shower, FLUSH
THE LINE THOROUGHLY.

10/17 Model 8309WC Page 3 of 5
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2.
Insufficient water flow, shower
and eyewash.
2.
Verify minimum 30 psi (2 ATM) flowing
supply line pressure.
3.
Insufficient water flow on
eyewash, however, shower is
sufficient.
3a.
Verify minimum 30 psi (2 ATM) flowing
supply line pressure.
b.
Probable clogging of flow control due to
inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble the head.
Clean flow control and reassemble
head. See SP65 Installation Drawing for
details.
c.
Remove cap located on L – Strainer
using a 3/8” allen wrench to access and
clean filter screen.
4.
Eyewash or face wash streams
do not meet desired eye level or
are not balanced.
4a.
Possible blocked flow control see above
solution. (Possible non-leveled eyewash
assembly.)
5.
Insufficient water flow at the
showerhead, however, eyewash
is sufficient.
5a.
Probable clogging of flow control inside
shower head. Unscrew shower head off
of elbow and clean rubber flow control.
6.
Water does not drain properly.
6a.
Check your drain system for debris.
Check the main waste line of your
building to see if it does handle the
capacity required for the entire drainage
system.
7.
Water leak between joints or
fittings.
7a.
Tighten loose connections. If leak
persists, the application of hot water will
sometimes reseat improperly applied
joint compound. After 30 minutes wait
and retest, a persistent leak will
necessitate reassembly and additional
sealant.
For more information on Haws Products, please see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

10
12
FLOOR FLANGE
REPAIR KIT
PULL ROD, 44"
TEST TAG
STRIPE TAPE
L-STRAINER
EYE/FACE WASH ASSY
VALVE ASSEMBLY
SHOWER VALVE ASSY
2BOWL
SHOWER HEAD
SHOWER SIGN
7
11
10
9
8
6
5
3
4
1
7
2
3
9
8
4
5
PARTS BREAKDOWN
11
SP65 EYE/FACE WASH ASSEMBLY
1
SP65
SP90
SP225
SP829
-
SP178
SP75
SP202
SP185
SP170
SP509
VRKEWSTR
6
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
P
A
GE
DATE
DATE
ECN:
REVISED PER
CHKD
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
DO 7/30/96
21
0002067461
8309WC BARRIER-FREE
SHOWER AND EYE/FACE WASH
1:6
11
FV 11/23/17
.
VWC
4OF5
PARTS BREAKDOWN
5241 VWC
12

28-3/4"
171mm
6-3/4"
FLOOR
LINE
STRAINER
327mm
12-7/8"
18-5/8"
473mm
1-1/4" IPS
WASTE
1575mm
62"
19" NIPPLE
1-1/4" IPS
NIPPLE
SUPPLY
730mm
28-3/4"
Ø229mm
MOUNTING
30°
B.C.
Ø203mm
3X
Ø8"
Ø3/8"
Ø10mm
Ø9"
24" NIPPLE
TOP VIEW
686mm
27" MIN
914mm
36" MAX
1181mm
46-1/2"
32mm
1-1/4"
31"
787mm
4
3
3
3
DETAIL
33"-53"
838mm-1364mm
FLOW PATTERN
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
D O 07/96
21
0002067461.D
8309WC BARRIER-FREE SHOWER
AND EYE/FACE WASH
1:18
11
FV 11/23/17
.
VWC
5 OF 5
INSTALLATION
5241
2017
VWC
NOTES:
1. WHEN INSTALLING THIS UNIT, LOCAL , STATE, OR FEDERAL CODES SHOULD BE ADHERED TO FOR INSTALLATION DIMENSIONS
(LOCATIONS), WASTE AND SUPPLY REQUIREMENTS OTHER THAN SHOWN.
2. TO COMPLY WITH ANSI Z358.1-2014 FOR EMERGENCY EYEWASH OR EYE/FACE WASH:
- EYEWASH OR EYE/FACE WASH SHALL BE POSITIONED SUCH THAT FLUSHING FLUID PATTERN IS NOT LESS THAN 33" (838mm) AND
NO GREATER THAN 53" (1346mm) FROM SURFACE ON WHICH USER STANDS; AND 6.0" (153mm) MINIMUM FROM WALL OR NEAREST
OBSTRUCTION.
- SHOWER SHALL BE POSITIONED SUCH THAT SHOWER HEAD IS NOT LESS THAN 82" (2083mm) AND NO GREATER THAN 96" (2438mm)
FROM SURFACE ON WHICH USER STANDS.
- SHOWER SPRAY PATTERN SHALL HAVE A MINIMUM DIAMETER OF 20" (508mm) AT 60" (1524mm) ABOVE SURFACE ON WHICH USER
STANDS. CENTER OF SPRAY PATTERN SHALL BE LOCATED AT LEAST 16" (406mm) FROM ANY OBSTRUCTION.
3 THESE DIMENSIONS MUST BE MAINTAINED TO MEET WHEELCHAIR ACCESSIBILITY REQUIREMENTS AND STILL COMPLY WITH ANSI
REQUIREMENTS STATED ABOVE.
4 DO NOT USE REGULAR PIPE SEALANT, IF NECESSARY, USE DOW CORNING 832 SEALANT. PLACING 5 SMALL BEADS ON THE MALE
5. DIMENSIONS MAY VARY BY ±1/2" (13 mm).
82"-96"
2083mm-2438mm
