Haws 8901RFK Axion Guide

•
HAWS AG
•
Bachweg 3
•
CH-3401 Burgdorf
•
Switzerland
•
www.haws.ch
HAWS Corporation •P.O.Box 2070 •1455 Kleppe Lane •Sparks,Nevada 89431/USA www.hawsco.com
HAWS DRINKING FAUCET COMPANY
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
NOTE TO INSTALLER: please leave this information with the maintenance departement.
THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2")
2,4m
1 1/4" G
Supply
52
28
TÜV tested
8901RFK Axion
2080192/1
SCALE 1:10
8901RFK Axion
Jeannine Ruf 28.10.2011
1/5
No.
Eye/Face Wash & Body Spray
Model
Free acces to the eye/facewash & body spray 8901RFK Axion must be guaranteed at all times.
The operator is responsible for the observance of this requirement.
81
105
86
230

•
HAWS AG
•
Bachweg 3
•
CH-3401 Burgdorf
•
Switzerland
•
www.haws.ch
HAWS Corporation •P.O.Box 2070 •1455 Kleppe Lane •Sparks,Nevada 89431/USA www.hawsco.com
HAWS DRINKING FAUCET COMPANY
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
Check the main shutoff valve.
Problem
Check the line pressure. This should be at least 2BAR /1.
30PSI (dynamic).
Blocked flow, possibly due to the conduit not being2.
correctly flushed out. Dismantle the spray element, and
clean the rubber flow-regulator.
TROUBLESHOOTING
Repair-checklist
1. No flow
2. Insufficient flow of water
2080192/1
8901RFK Axion
Jeannine Ruf 28.10.2011
2/5
No. Model 8901RFK Axion
Eye/Face Wash & Body Spray
Shower location: The eye/facewash & body spray 8901RFK Axion must be installed in the vicinity
of potential danger zones. It must be highly visible and easily accessible.
Connection conduit: You are recommended to use a 1/2" G conduit, capable of withstanding
pressures of 2 - 6BAR (30 - 90PSI). The use of an inlet filter designed to prevent the entry of
suspended particles and other impurities is also recommended.
Water quality: Eye/facewash & body spray require a supply of drinking water conforming to European
standards or their equivalents in other countries.
Water temperature: The required water temperature should be determined by the user. The accepted
ideal range is 15 - 35°C / 60 - 95°F (but please ensure conformity with local regulations).
Volum flow: A minimum flow rate of 6 litres / 1,6 US gallons per minute must be maintained. The
eye/facewash & body spray must be capable of delivering this amount of water for at least 15 minutes.
Connection to plumbing system: The inlet consists of a 1 1/4" G male-threaded conduit.
Regular inspection:
The eye/facewsh & body spray 8901RFK Axion should be inspected at weekly intervals.
The inspection tag should be dated and signed after each check.
