Hay 5F User manual

– INSTRUCTION MANUAL –
DESIGN BY STEFAN DIEZ
TABLE GROUP 4
5F, 5G, 6F, 6G, 7B, 7C, 7D, 7E, 8F, 8G, 12F, 12G
NEW ORDER

 TABLE OF CONTENTS 
TABLES
TABLE OVERVIEW
PARTS OVERVIEW
TABLE ASSEMBLY INSTRUCTIONS
CONNECTORS
TABLE WALL CONNECTOR INSTRUCTIONS
FRONT SHELF CONNECTOR INSTRUCTIONS
END SHELF CONNECTOR INSTRUCTIONS
END TRAY CONNECTOR INSTRUCTIONS
CABLE MANAGEMENT
CABLE TRAY INSTRUCTIONS
CABLE CLIP INSTRUCTIONS
CABLE GUIDE INSTRUCTIONS
PLUG SOCKET
WALL MOUNTING GUIDELINE
CARE AND MAINTENANCE
5
67
821
2225
2629
3033
3436
3739
4041
4243
4447
48
49

4

 TABLE OVERVIEW 
  
TABLE

5F
  
TABLE

7B 
 
TABLE

7C 
 
TABLE

7D
  
TABLE

7E 
 
TABLE

8F
  
TABLE

12F
  
TABLE

8G
  
TABLE

12G
  
TABLE

5G 
 
TABLE

6F 
 
TABLE

6G
150x75
150x150 150x150 150x150
150x150 200x100
200x75
200x100
200x75
150x75 150x100 150x100
5
It is important to start by identifying your table model to ensure you follow
the correct assembly instructions.

TABLE
PART
x4 x4 x4 x1-
-
-
-
-
- -
-
- -
-
-
- -
-
-
-
-
-
-
-
-
-
-
-
-
x1
x1
x1
x1
x1
x1x2
x2
x2
x2
x2
x2
x2
x2
x2
x2
x2
x2
x1
x1 x1
x1 x1
x1 x1
x1 x1 x1
x1 x1
x1 x1
x1 x1
x1 x1
x1 x1
x1 x1 x1
x1 x1
x4 x4 x4
x4 x4 x4
x4 x4 x4
x4 x4 x4x4
x4 x4 x4
x4 x4 x4
x4 x4 x4
x4 x4 x4
x4 x4 x4
x4 x4 x4x4
x4 x4 x4

ACorner knot*

BFrame profile

CLeg*

DTabletop

ESupport bar

FExtra
support bar

GTray

HSingle profile

LCable covers
 PARTS 



TABLE

5F



TABLE

5G



TABLE

6F



TABLE

6G



TABLE

7B



TABLE

7C



TABLE

7D



TABLE

7E
*Depending on your configuration your table may or may not have four legs/corner knots.



TABLE

8F



TABLE

12F



TABLE

8G



TABLE

12G
6

 PARTS 
x1
x1 x1
x1-
-
- -
-
- -
-
-
x1 x1
x1
x1 x1
x1-
-
-
-
-
-
-
-
- -
-
- -
-
-
x1 x1
x1
x1
x1
x1
x1
x1 x1
x1
x1 x1
x1
x1
x1 x1x1x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x2 x2
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1
x1 x1x1

MCable covers

OFootrest**

3 Supportbar
Extra
support bar

2

4 Frame

5 Tabletop

11 Tray divider

13 High table**

6 Legs
BAG

3
BAG

2
BAG

4
BAG

5
BAG

11
BAG

13
BAG

6
**Only for high tables with footrest
7

88
SB
(SUPPORT BAR)
ESB
(EXTRA SUPPORT BAR)
The small dotted markings on the table frame should align with the marks
indicated on the support bar/extra support bar connector.
The markings on the table frame are not numbered, but counting outwards
from the central mark (0) will guide you to the correct position for your
support bar.
0 1 45 6123 2 3456
SB
SB
ESB
ESB
 INFORMATION ON SUPPORT BARS 
The tables in this manual use extra support bars (ESB) to reinforce their construction.
You will find information below on how to mount them and find their correct position.

99
6 5 4 3 2 1 0 1 2 3 4 5 6
0 1 45 6123 2 3456
TABLE
POSITION
FRAME PROFILE 150 CM
  
TABLE

7B
  
TABLE

7D
  
TABLE

7C
  
TABLE

7E
0
0
11 22 3
1
3
1
44
  
TABLE

6F
  
TABLE

8F
  
TABLE

5F
  
TABLE

12F
  
TABLE

5G
  
TABLE

12G
  
TABLE

6G
  
TABLE

8G
FRAME PROFILE 100 CM
FRAME PROFILE 75 CM
TABLE
TABLE
POSITION
POSITION
011
 SUPPORT BAR POSITIONS 
0
22
3 3 44 1
1

10
  
3A x2
BAG

3
1.
Insert the brackets
  
3A into the two shortest table frame profiles

B. Then mount the
extra support bar connectors
  
2D and support bar connector delivered in support
bar  Eon both frame profiles and fasten them with screws
  
3C using tool 
 
3B .
Make sure to find the correct position on page 11, before tigthening screws.
BAG

2
  
3B x1
  
3C x4
  
2D x2
FIND THE CORRECT
POSITION IN THE
OVERVIEW ON PAGE 11
FIND THE CORRECT
POSITION IN THE
OVERVIEW ON PAGE 11
Connector is
delivered with
the support
bar

E
9
9
x2

11
2.
Insert the corner knots

A into the two table frame profiles from step 1.
Then connect them with the other two profiles

B to close the frame.
Place the supportbars

Eand  Fin between.

12
3.
Secure the frame with screws
  
4B using tool
  
4A in each corner.
  
4B x32
  
4A x1
BAG

4

13
  
3C x4
  
3B x1
x2
BAG

3
4.
Fasten the support bar

Eand extra support bar  F with screws
  
3A using tool 
 
3B .

14
Mount the legs

C to the footrest  O with screws 
 
13A using tool 
 
13B
Start by loosely tightening all the screws before tightening them all completely.
5.
ONLY FOR HIGH TABLES 5F, 5G, 6F, 6G, 8F, 8G, 12F AND 12G
WITH FOOTREST
BAG

13
  
13A x1
  
13B x8

15
6.
Connect the legs

C by threading them onto the tap of the corner knot.
Secure with screws
  
6B using tool
  
6A .
  
6B x4
  
6A x1
BAG

6

16
Mount the profile connectors
  
11A with screws 
 
11B in the table top  Dwith
holes in the corners.
7.
ONLY FOR TABLES 7D AND 7E
  
11B x4
  
11A x4
BAG

11

17
8.
Mount the tabletops

D by inserting it into one of the short ends.
Then slowly lower the tabletop into place.

18
9.
Fasten the table top

D with the clips
  
5B from underneath. Distrubute the clips evenly.
Secure them with screws
  
5C using tool
  
5A .
  
5C x10
  
5A x1
  
5B x10
BAG

5
x1

19
10.
Place cable covers

Lor  Mdepeding on your table model.
If the floor is uneven and the table is unstable, adjust the hight of the feet until the
table is stable.

20
11.
ONLY FOR TABLES 7D AND 7E
Mount profiles

Hand tray  G .
