Hay EIFFEL SHELF User manual

– INSTRUCTION MANUAL –
DESIGN BY DEPPING & JØRGENSEN
EIFFEL SHELF

 PARTS 

A Shelf x1

B Shelf x1

G Upright x20

I Screw x20
M5x25

K Allen key x1

C Shelf x1

D Shelf x1

E Shelf x1

F Shelf x1

H Screw x40
5Mx12

J Screw x4

Protect the shelves from scratches and other damage while assembling.

1.
Mount 4 x

G parts onto the

A part using the

H and

K parts.
NOTICE
Make sure to use the correct
screws. The correct screws for
this step are the short screws
M5x12 (

H parts)

2.
Mount the

B part onto the 4 x

G parts using the

I and

K parts.

3.
Mount 4 x

G parts onto the

B part using the

H and

K parts.
NOTICE
Make sure to use the correct
screws. The correct screws for
this step are the short screws
M5x12 (

H parts)

4.
Repeat the last two steps for the

C ,

D ,

E and

F parts.

5.
Mount the

J parts onto the

F part.

6.
Turn the shelf over (two people are recommended).

7.
Done!

 CARE & MAINTENANCE 
Our Care & Maintenance offers guidance for optimal
maintenance of your HAY product. It includes advice
and instructions on cleaning and caring for specific
materials to prolong the life of your furniture.
Please find our Care & Maintenance
guide by scanning the QR code
You can find more relevant information on
Eiffel Shelf by scanning the QR code
You can also find the same information here
hay.dk/downloads
