hayneedle Glider and Ottoman DAS005-1 User manual

For assistance with assembly, please contact
Hayneedle Customer Care Center
1-888-880-4884
1/7
ITEM NAME: HOOP BACK GLIDER ROCKER AND OTTOMAN SET
SKU: DAS
005-1 / DAS005-2

* Please check that all parts and hardware are included before beginning assembly.
* Save all packing materials until assembly is complete to avoid accidentally discarding smaller
parts or hardware.
* Read through the preparation and assembly instructions in full before beginning assembly.
* Please use CAUTION AND CARE WHEN LIFTING the product to avoid personal injury and (or)
damage to the product.
* The following additional tools are required for assembly:
* For ease of assembly, two adults are recommended.
* Assembly time: Approxmiately 20 minutes.
BASE (A) Qty:1 BACK REST (B) Qty:1 SEAT CUSHION (C ) Qty:1
BACK CUSHION (D) Qty:1 ARM CUSHIONS ( E) Qty:2 LEFT ARM (FL) Qty:1
RIGHT ARM (FR) Qty:1 OTTOMAN (G) Qty:1
PRE-ASSEMBLY PREPARATION:
THIS PACKAGE MAY CONTAIN SMALL ITEMS WHICH SHOULD BE KEPT AWAY FROM CHILDREN
* Phillips head screwdriver
PANEL AND FITTINGS IDENTIFICATION
2/7
20-3/4"
22-1/4"
27-1/8"
21-1/2"
21-3/4"
24-1/2"
28-1/2"
23-1/4"
13-1/2"
15-1/4"
19-3/4"
11-3/8"
3"
19-3/4"
11-3/8"
15-1/2"
20-1/2"

1 2 3
BOLT Qty: 2 BOLT Qty: 2 BOLT Qty: 4
4 5 6
SPRING WASHER Qty: 8
BARREL NUT
Qty: 6 ALLEN KEY Qty: 1
STRUCTURAL DIAGRAM
4MM
Ø1/4" X 1/2"
HARDWARE LIST
Ø1/4" X 1-1/2"
Ø1/4" X 1-3/4"
Ø1/4" X 2"
Distributedby:JardineEnterpriseLtd.
P.O.Box83-66
Taipei,Taiwan
NOTE:
1.Useglue(10)wheninsertingwooddowels(5),wipeanyexcessglue.
2.Afterassemblyiscompleted,allow8hoursforgluetodrybeforeusing.
3/7
B
A
FR
FL
EE
G

STEP 1:
STEP-BY-STEP ASSEMBLY:
Attach the back frame (B) to the base (A) with bolts (1) and spring washers (4). Use Allen Key
(6) to tighten the bolts.
NOTE : Do not fully tighten the bolts. Leaving the bolts loose will facilitate assembly in the
following step.
Distributedby:JardineEnterpriseLtd.
P.O.Box83-66
Taipei,Taiwan
NOTE:
1.Useglue(10)wheninsertingwooddowels(5),wipeanyexcessglue.
2.Afterassemblyiscompleted,allow8hoursforgluetodrybeforeusing.
4/7

STEP 2:
Repeat the above step to attach left arm assembly (FL) to back frame (B) and base (A).
STEP-BY-STEP ASSEMBLY:
NOTE : Do not tighten the bolts until all bolts have been installed. Once all bolts have been
installed, fully tighten all bolts installed in previous steps.
Insert barrel nuts (5) in right arm assembly as shown in Detail (A).
Attach the right arm assembly (FR) to back frame (B) with bolt (2) and spring washer (4). Use
Allen key (6) to install bolt (2).
Insert barrel nuts (5) right arm assembly as shown in Detail (B).
Attach right arm assembly (FR) to base (A) using bolts (3) and spring washers (4) as shown. Use
Allen key (6) to install bolts (3).
Distributedby:JardineEnterpriseLtd.
P.O.Box83-66
Taipei,Taiwan
NOTE:
1.Useglue(10)wheninsertingwooddowels(5),wipeanyexcessglue.
2.Afterassemblyiscompleted,allow8hoursforgluetodrybeforeusing.
5/7
Bolts (3) must go through the
holes underneath base (A).
Bolt (2) must go through the
hole on the side of back rest (B).
DETAIL A
DETAIL B
NOTE- Barrel nuts (5) must be inserted so that the bolts can pass through them. If barrel nuts
(5) are not inserted properly, use a Phillips head screwdriver (not included) to rotate them.

STEP 3:
Attach the arm cushions (E) to the armrests by buttoning the buttons along with the interior
seat and on the sides.
Place the seat cushion (C) onto the base (A).
Attach the back cushion (D) to the back frame (B).
STEP-BY-STEP ASSEMBLY:
Distributedby:JardineEnterpriseLtd.
P.O.Box83-66
Taipei,Taiwan
NOTE:
1.Useglue(10)wheninsertingwooddowels(5),wipeanyexcessglue.
2.Afterassemblyiscompleted,allow8hoursforgluetodrybeforeusing.
E
E
6/7
A
B
