Heal-Tech QuickShifter easy Instructions and recipes

QuickShifter easy
Supplementary Manual
Honda CB650F ABS 2014-2018 (iQSE-1 + QSH-P2T)
www.healtech-electronics.com 1/3
Secure the bike on a stand.
Remove the seat.
Remove the side fairings.
Locate the ignition coil connectors on the
right side under the side fairing.

QuickShifter easy
Supplementary Manual
Honda CB650F ABS 2014-2018 (iQSE-1 + QSH-P2T)
www.healtech-electronics.com 2/3
Take off the Black terminal from the coil.
Connect the Black terminal to the QSH
Red wire terminal.
Connect the QSH Green terminal to this
coil terminal.
Splice the QSH White wire to the
Green/Blue wire of the coil by using the
supplied red wire tap connector.
Take off the Black terminal from the
other ignition coil.
Connect the QSH Green terminal to the
empty ignition coil terminal.
Isolate the unused Black terminal with
tape.

QuickShifter easy
Supplementary Manual
Honda CB650F ABS 2014-2018 (iQSE-1 + QSH-P2T)
www.healtech-electronics.com 3/3
Connect the QSH Black wire terminal to
the battery negative terminal.
Mount the QSE sensor.
(Place the sensor in the rod as shown.
Tighten the nut by hand fully and then by a
1/4 turn using a wrench but maximum to
about 6 Nm.)
Typical position for the QuickShifter easy.
Secure the unit properly.
