Healthy Choice AF605 User manual

CAUTION: TO AVOID DAMAGE TO YOUR BENCH TOP AND SPLASH
BACK, DO NOT PLACE THE AIR FRYER DIRECTLY ON BENCH TOP.
HOUSEHOLD USE ONLY
Carefully read all instructions before use and save for future reference.
Model: AF605 | Batch: PR4703
6L DIGITAL AIR FRYER
with viewing window

IMPORTANT SAFEGUARDS
PLEASE READ AND SAVE THIS INSTRUCTION MANUAL
FOR FUTURE REFERENCE
When using the appliance, basic safety precautions should be followed,
including:
1. Remove and safely discard any packaging material and labels before
using this product for the rst time. Ensure children and babies do not
play with plastic bags or any packaging materials.
2. Before use, check that your local voltage corresponds with the
specications shown on the appliance nameplate located under the
appliance.
3. Always operate the appliance on a horizontal surface that is level,
stable and non-combustible. Do not operate the appliance on or near
combustible materials such as tablecloths or curtains.
4. Do not place the appliance on or near a hot gas or electric burner, or
in a heated oven.
5. Never connect this appliance to an external timer or a separate
remote-control system.
CAUTION: TO AVOID DAMAGE TO YOUR BENCHTOP AND SPLASH
BACK, DO NOT PLACE THE AIR FRYER DIRECTLY ON BENCHTOP.
Please use air fryer on heat-proof material and on a dry, level and even
surface. Leave a minimum distance of 20cm from walls and other heat-
sensitive materials.
Do not place the appliance against a wall or against other appliances.
Hot air up to 160 Degrees expels through the rear vent of the appliance.
Leave at least 20cm clearance around the entire appliance, including
directly above it.
Additional care should be taken when placing appliances on benchtop
surfaces or near splashbacks where such materials (acrylics, timber, stone
etc.) do not have high heat-resistant properties.

6. Never use this appliance with an extension cord or power board.
Ensure it is plugged into a dedicated power point and without any other
appliances on the same outlet.
7. Do not turn on the power until the appliance and parts are in place as
required.
8. To protect against electric shock, do not immerse the cord, plug, or
appliance in water or any other liquid. Do not expose the appliance to
dripping or splashing and ensure that no objects lled with liquids such
as vases are placed on the appliance. Do not put any water or other
liquid into the main housing of the appliance through the vents. Do not
rinse it under the tap.
9. Do not touch the appliance, power cord or power plug with wet
hands.
10. Unplug from the outlet when not in use and before cleaning. Allow
the appliance to cool down before putting on or taking off the parts, and
before cleaning.
11. The appliance does not contain any serviceable parts inside. Do
not attempt to open and repair the appliance yourself. All components
should only be serviced by a qualied technician.
12. Do not use the appliance if the plug, power cable or unit itself are
damaged. If the power cord is damaged, you must have it replaced at a
service centre by qualied persons in order to avoid a hazard.
13. Do not use the appliance for anything other than the intended use. It
is for household use only. It is not to be used outdoors or for commercial
purposes.
14. Close supervision is necessary when the appliance is used near
children. Keep the appliance and power cord out of reach of children
when it is in operation or during the cooling process.
15. This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, ofces and other working environments;
- farmhouses;
- by clients in hotels, motels and other residential-type environments;
- bed and breakfast type environments.
16. Extreme caution must be used when moving an air fryer containing
hot food.

17. Leave enough open space from other objects while in use. Do not
block air intakes or exhausts.
18. Do not place the appliance against a wall or against other
appliances. Leave at least 20 centimetres of free space on the back and
sides and above the appliance. Do not place anything on top of the
appliance.
19. When the appliance is in operation, hot air is released through the
air outlet vent. Keep your hands and face at a safe distance from the air
outlet vent.
20. Do not touch the hot surfaces. The appliance’s outer surfaces may
become hot during use. The rotisserie basket and rotisserie fork set will be
hot. Wear oven mitts or use the rotisserie remover tool to remove them.
Wear oven mitts when handling the crisper trays and drip tray.
21. Do not cover the appliance while in use.
22. Do not let the cord hang over the edge of the table or counter.
23. Do not unplug the appliance by pulling on the cord.
24. This appliance can be used by children 8 years and above and
people with a physical, sensory or mental impairment, or people without
knowledge or experience if they are supervised or given prior instructions
concerning the use of the appliance by someone responsible for their
safety. Children must be supervised to ensure that they do not play with
the appliance.
25. Do not leave the appliance operating while unattended.
26. The appliance may emit light smoke during its rst use. It is not
defective, and the smoke will burn off within a few minutes.
27. Should the appliance emit black smoke, unplug it immediately. Wait
for the smoke to stop before removing the contents inside.
28. To prevent the food from contacting the inner upper wall and heating
element, do not overll the rotisserie fork or crisper trays.
29. Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance and its cord
out of reach of children younger than 8 years.

1. Control panel
2. Viewing window
3. Housing body
4. Basket
5. Grill Insert
6. Front panel of the basket
7. Basket handle
8. Bottom cover
9. Air outlet
10. Electrical cord
Technical Parameters
Voltage 220-240V~ 50/60Hz
Power 1500 Watts
Capacity 6 Litre
Adjustable temperature 80°C - 200°C
Timer 1 - 60 min

1. Remove all packaging and promotional materials.
2. Thoroughly clean the basket and grill insert with hot soapy water.
3. Wipe the inside and outside of the appliance with a soft moist cloth.
This is an oil-free fryer that works on hot air, do not ll the basket with oil
or frying fat.
Note: When your air fryer is heated for the rst time, it may emit slight
smoke or odour. This is normal with many brand-new appliances. This
does not affect the safety of your appliance.
1. Place the appliance on a stable, horizontal, and even surface. Do not
place the appliance on a non-heat-resistant surface.
2. Place the grill insert in the basket. Do not ll the basket with oil or any
other liquid. Do not put anything on top of the appliance, the airow will
be disrupted and affect the hot air frying result.
Before rst use
Preparing for use

USING THE APPLIANCE
1. Connect the plug to an earthed wall socket.
2. Carefully pull the basket out of the air fryer.
3. Put the ingredients in the basket.
4. Slide the basket back into the air fryer.
Never use the basket without the grill insert in it.
Caution: Do not touch the basket during and after use, as it gets very hot.
Only hold the basket by the handle.
5. Determine the required preparation time for the ingredient (see section
‘Settings’ in this manual).

6. Some ingredients require shaking halfway through the preparation
time (see section “Settings” in this manual). To shake the ingredients, pull
the basket out of the appliance by the handle and shake it. Then slide it
back into the air fryer.
Tip: If you set the timer to half the preparation time, you hear the timer
buzzer when you need to shake the ingredients. However, this means
that you must set the timer again for the remaining preparation time after
shaking.
7. When you hear the timer buzzer, the set preparation time has elapsed.
Pull the basket out of the appliance.
8. Check if the food is ready. If it isn’t ready yet, simply slide the basket
back into the appliance and set the timer to a few extra minutes.
9. To remove ingredients (e.g. fries), pull the basket out of the air fryer
and place it on a trivet. Do not turn the basket upside down, as any
excess oil that has collected on the bottom will leak onto the ingredients.
The basket and the food are hot. Depending on the type of ingredients in
the air fryer, steam may escape from the cooking basket.
10. Empty the basket into a bowl or onto a plate.
11. When a batch of ingredients is ready, the air fryer is instantly ready
to cook another batch.

CONTROL PANEL INSTRUCTIONS
Power Key
When Power Key is pressed once, the display illuminates and shows the
default cooking time of the rst pre-set menu option. The icon indicating
the menu option will ash.
Function Key
Press the Function Key to switch between the pre-programmed menu
options (going from left to right). After selecting the desired cooking
mode press start or wait 5 seconds for the automatic start.

Temperature/Timer Key
The temperature and time can be adjusted using the Temperature/Timer
key according to personal preferences and tastes. The corresponding -
and + keys can be used to increase/decrease the temperature and time.
The temperature increases or decreases by 5°C and the time increases or
decreases by 1 minute.
Delay Time Key
To delay air frying, simply press the Delay Time key. You can customize
the delay time for up to 24 hours.
You can press the Start/Cancel key to cancel the operation at any time.
The machine will initiate cooling fans for 30 seconds.
Once cooking is complete or if no functions are selected within 1 minute,
the air fryer will automatically enter standby mode. To exit standby
mode, simply press the Start/Cancel key.

SETTINGS
The settings table will help you select the best cooking option for the
ingredients.
Note: Keep in mind that these settings are an indication only. As
ingredients differ in origin, size, shape as well as brand, we cannot
guarantee the best setting for your ingredients.
Do not pull out the basket to shake/check on food for an extended
period of time. Try to be as brief as possible to not disturb the cooking
process.
Tips
• Smaller ingredients usually require a slightly shorter cooking time
than larger ingredients.
• A larger amount of ingredients only requires a slightly longer cooking
time, and a smaller amount of ingredients only requires a slightly
shorter cooking time.
• Shaking smaller ingredients halfway through the preparation time
optimizes the result and can help prevent unevenly fried ingredients.
• Add some oil to fresh potatoes for a crispy result. Fry your ingredients
in the air fryer within a few minutes after you added the oil.
• Snacks that can be prepared in an oven can also be prepared in the
air fryer.
• Use pre-made dough to prepare lled snacks quickly and easily. Pre-
made dough also requires a shorter cooking time than homemade
dough.
• Place a baking tin or oven dish in the air fryer basket if you want
to bake a cake or quiche or if you want to fry fragile ingredients or
lled ingredients.

180°C
190°C
190°C
180°C
180°C
190°C
190°C
170°C
180°C
200°C
150°C
190°C
20min
10min
13min
10min
10min
38min
20min
10min
13min
20min
14min
10min

Unplug the appliance and allow it to cool down completely before
handling, cleaning or storing.
Wash all accessories in warm soapy water after every use.
Note: the basket and the grill insert are dishwasher safe.
The inside of the air fryer can be cleaned with hot water, a mild
detergent and a non-abrasive sponge. Wipe the outer housing body with
a soft, damp cloth. Do not use detergents or cleaners on the outside of
the appliance. If necessary, remove the excess food residue on the upper
screen with a soft brush.
CLEANING AND MAINTENANCE
Tip: If food is stuck to the grill insert or the bottom of the basket, ll the
basket with hot water and some washing-up liquid. Put the grill insert in
the basket and let them soak for approximately 10 minutes.
STORING
PROPER DISPOSAL
Allow the appliance to cool down completely before storing it. Store the
appliance in an upright position in a dry location. Do not place any
heavy items on top of the appliance during storage as this may result in
possible damage to the appliance.
Once the appliance reaches the end of its life cycle, do not throw it
away. Hand it in at an ofcial recycling collection point.

TROUBLESHOOTING
Problem
The air fryer does not
work.
The ingredients are not
cooked properly.
The ingredients are
fried unevenly in the
air fryer.
Fried snacks are not
crispy when they come
out of the air fryer.
I cannot slide the
basket into the
appliance properly.
White smoke comes
out of the appliance.
Fresh fries are fried
unevenly in the air
fryer or are not crispy.
Possible cause
The appliance is not plugged in.
You have not set the timer.
The amount of ingredients in the
basket is too big.
The set temperature is too low.
The preparation time is too short.
Certain types of ingredients need
to be shaken halfway through the
preparation time.
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
There are too many in-gredients in
the basket.
The basket is not placed in the pot
correctly.
You are preparing greasy
ingredients.
The pot still contains grease
residues from previous use.
You did not use the right potato
type.
You did not rinse the potato sticks
properly before you fried them.
The crispiness of the fries depends
on the amount of oil
and water in the fries.
Solution
Plug in the air fryer.
Set the timer key
Put smaller batches of ingredients
in the basket. Smaller batches are
fried more evenly.
Increase the temperature.
Increase cooking time.
Shake the ingredients halfway
through the cooking time.
Use oven-ready snacks or lightly
brush some oil onto the snacks for
a crispier result.
Do not ll the basket beyond the
MAX indicator.
Push the basket into the pot until
you hear a click.
Greasy ingredients cause a large
amount of oil to leak into the
basket which then produces white
smoke. This doesn’t affect the
appliance or the end result.
White smoke is caused by grease
heating up in the basket. Make
sure you clean the basket properly
after each use.
Use fresh potatoes and make sure
they stay rm during frying.
Rinse the potato sticks properly to
remove starch from the outside of
the sticks.
Make sure you dry the potato
sticks properly before you add the
oil. Cut the potato sticks smaller
for a crispier result.

www.lenoxx.com.au
1300 666 848
LenoxxElectronics LenoxxElectronics @LenoxxAustralia
