Hearth & Home Technologies • STONEKIT Stone Placement Installation Manual • 4099-976 Rev. B • 03/21
Stone Placement Instructions
Model: STONEKIT
WARNING: Turn o󰀨 appliance and allow to cool com-
pletely before beginning installation. DO NOT use this
optional kit with any other internal hearth option such
as logs.
Kit Contents:
• Eighteen(18)ceramicberstones
NOTE —Donothandlestoneswithyourbarehands.Always
wear gloves to prevent skin irritation from stone material.
After handling the stones, wash your hands with soap and
watertoremoveanytracesofbers.
Figure 1 – Stone Placement for AVFL42N(P)IP-BU and AVFL42N(P)IP-RB
NOTE:Priortoplacingthestonesyoumustrstinstallthe
deectionglassandcrushedglassmedia. For properair
deectionglassandcrushedglassmediaplacementplease
refer to the Owner’s and Installation Manuals for the partic-
ularAVFLorLANAIappliancethatthiskitisbeingusedfor.
1. Beginbyplacing stones randomlyonthe hearth area
outsideoftheburner.Nostoneshouldbeplacedonor
infrontofthepilotarea.
2. Lightthe applianceand lookfor anycontact between
ameandstones.Ifcontactismade,movethestones
fromtheamearea.SeeFigure1,2or3.
Forusewiththefollowingmodels:AVFL42N(P)IP-RB,AVFL42N(P)IP-BU,AVFL48N(P)IP,AVFLST48N(P)IP,
AVFL60N(P)IP-B,ODLANAIG-48,ODLANAIGST-48,ODLANAIG-60
Air deflection glass
Burner surface. DO NOT place stones in the unshaded area.
Example of stone accessory placement

Hearth & Home Technologies • STONEKIT Stone Placement Installation Manual • 4099-976 Rev. B • 03/21
Figure 2 – Stone Placement for AVFL48N(P)IP, AVFL48N(P)IP, ODLANAIG-48 and ODLANAIGST-48
Air deflection glass
Burner surface. DO NOT place stones in the unshaded area.
Example of stone accessory placement
Figure 3 – Stone Placement for AVFL60N(P)IP-B and ODLANAIG-60
Air deflection glass
Burner surface. DO NOT place stones in the unshaded area.
Example of stone accessory placement
