Heat & Glo SL-750TRS-IPI-D User manual

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 1
Models:
SL-750TRS-IPI-D
SL-550TRS-IPI-D
SL-350TRS-C
• Do not store or use gasoline or other Àam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas suppli-
er’s instructions.
- If you cannot reach your gas supplier, call
the ¿re department.
• Installation and service must be performed
byaquali¿edinstaller,serviceagency,orthe
gas supplier.
WARNING: If the information in
these instructions is not followed ex-
actly, a ¿re or explosion may result
causing property damage, personal
injury, or death.
This appliance has been supplied with an integral barrier
to prevent direct contact with the ¿xed glass panel. Do
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
WARNING
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other
combustibles away.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
Owner’s Manual
Installation and Operation
DO NOT DISCARD THIS MANUAL
CAUTION
ThisappliancemaybeinstalledasanOEMinstallationinmanu-
facturedhome(USAonly)ormobilehomeandmustbeinstalled
inaccordancewiththemanufacturer’sinstructionsandtheman-
ufacturedhomeconstructionandsafetystandard, Title24 CFR,
Part 3280 or Standard for Installation in Mobile Homes, CAN/
CSA Z240MH.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
Installation and service of this appliance should be
performed by quali¿ed personnel. Hearth & Home
Technologiessuggests NFI certi¿ed or factory-trained
professionals, or technicians supervised by an NFI
certi¿ed professional.
Leave this manual with
party responsible for
use and operation.
•••
DO NOT
DISCARD
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber
or gas ¿tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Important operating
and maintenance
instructions included.
Read, understand and follow
these instructions for safe
installation and operation.

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
2
Congratulations
Listing Label Information/Location
Model Name:___________________________________________ Date purchased/installed:__________________
Serial Number:__________________________________________ Location on appliance: ____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
Congratulations on selecting a Heat & Glo gas appliance
—an elegant and clean alternative to wood burning
appliances. The Heat & Glo gas appliance you have
selected is designed to provide the utmost in safety,
reliability, and ef¿ciency.
As the owner of a new appliance, you’ll want to read and
carefully follow all of the instructions contained in this
Owner’s Manual. Pay special attention to all Cautions and
Warnings.
This Owner’s Manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this Owner’s Manual, unless
noted otherwise, applies to all models and gas control
systems.
Your new Heat & Glo gas appliance will give you years of
durable use and trouble-free enjoyment. Welcome to the
Heat & Glo family of appliance products!
Read this manual before installing or operating this appliance.
Please retain this owner’s manual for future reference.
We recommend that you record the following
pertinent information about your appliance.
Gas and Electric
Information
Model Number
Serial Number
Type of Gas
The model information regarding your speci¿c appliance can be found on
the rating plate usually located in the control area of the appliance.
Homeowner Reference Information
Hearth & Home Technologies, Inc.
20802 Kensington Blvd., Lakeville, Mn 55044

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 3
Î
- Table of Contents -
Î= Contains updated information.
Section 1: Listing and Code Approvals
A. Appliance Certi¿cation................................... 4
B. Glass Speci¿cations...................................... 4
C. BTU Speci¿cations........................................ 4
D. High Altitude Installations .............................. 4
E. Non-Combustible Materials Speci¿cation...... 4
F. Combustible Materials Speci¿cation.............. 4
G. Requirements for the Commonwealth
of Massachusetts........................................... 5
Section 2: Getting Started
A. Design and Installation Considerations......... 6
B. Tools and Supplies Needed........................... 6
C. Inspect Appliance and Components.............. 6
Section 3: Framing and Clearances
A. Selecting Appliance Location......................... 7
B. Constructing the Appliance Chase ................8
C. Clearances .................................................... 8
D. Mantel Projections......................................... 9
Section 4: Termination Locations
A.Vent Termination Minimum Clearances....... 10
Section 5: Vent Information and Diagrams
A. Vent Table Key............................................. 12
B. Use of Elbows..............................................12
C. Measuring Standards .................................. 12
D. Use of Flex Vent..........................................13
E. Vent Diagrams............................................. 14
Section 6: Vent Clearances and Framing
A. Pipe Clearances to Combustibles............... 24
B. Wall Penetration Framing............................ 24
C. Vertical Penetration Framing.......................25
Section 7: Appliance Preparation
A. Top Vent....................................................... 26
B. Rear Vent..................................................... 27
C. Securing and Leveling the Appliance.......... 28
Section 8: Installing Vent Pipe
A. Assembly of Vent Sections for DVP Pipes .. 29
B. Disassembly of Vent Sections..................... 31
C. Installing Heat Shield and
Horizontal Termination Cap ........................ 33
D. Installing Roof Flashing and Vertical
Termination Cap .......................................... 35
Section 9: Gas Information
A. Fuel Conversions...................................... 37
B. Gas Pressures.......................................... 37
C. Gas Connection........................................ 37
Section 10: Electrical Information
A. Recommendation for Wire........................39
B. Connecting to the Appliance..................... 39
C. Standing Pilot Ignition System Wiring....... 39
D. Intelli¿re Ignition System Wiring.................40
E. Junction Box Installation...........................41
F. Wall Switch Installation for Fan................. 41
Section 11: Finishing
A. Mantel Projections .................................... 42
B.Facing Material ......................................... 42
Section 12: Appliance Setup
A. Remove Shipping Materials...................... 43
B. Clean the Appliance.................................. 43
C. Accessories .............................................. 43
D. Ember and Lava Rock Placement............ 43
E. Install Refractory....................................... 44
F. Positioning the Logs ................................. 45
G. Glass Assembly ........................................ 51
H. Grilles and Trim......................................... 51
I. Air Shutter Setting......................................51
Section 13: Operating Instructions
A. Before Lighting Appliance......................... 52
B. Lighting Appliance..................................... 53
C. After Appliance is Lit.................................55
D. Frequently Asked Questions..................... 55
Section 14: Troubleshooting
A. Standing Pilot Ignition System..................56
B. Intelli¿re Ignition System........................... 58
Section 15: Maintaining and Servicing Appliance........... 60
Section 16: Reference Materials
A. Appliance Dimension Diagrams................ 62
B. Vent Components Diagrams..................... 65
C. Service Parts ............................................ 70
D. Warranty ................................................... 78
E. Contact Information .................................. 79
Î

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
4
Listing and Code Approvals
C. BTU Speci¿cations
1
MODELS: SL-750TRS-IPI-D,SL-550TRS-IPI-D,
SL-350TRS-C
LABORATORY: Underwriters Laboratories, Inc. (UL)
TYPE: Direct Vent Gas Appliance Heater
STANDARD: ANSI Z21.88-2002 • CSA2.33-M02 • UL307B
A. Appliance Certi¿cation
B. Glass Speci¿cations
Hearth&HomeTechnologiesappliancesmanufacturedwith
tempered glass may be installed in hazardous locations
such as bathtub enclosures as de¿ned by the Consumer
Product Safety Commission (CPSC). The tempered glass
has been tested and certi¿ed to the requirements of ANSI
Z97.1and CPSC16 CFR1202 (Safety GlazingCerti¿cation
Council SGCC# 1595 and 1597.ArchitecturalTesting, Inc.
Reports 02-31919.01 and 02-31917.01).
This statement is in compliance with CPSC 16 CFR
Section 1201.5 “Certi¿cation and labeling requirements”
which refers to 15 U.S. Code (USC) 2063 stating “…Such
certi¿cate shall accompany the product or shall otherwise
be furnished to any distributor or retailer to whom the
product is delivered.”
Some local building codes require the use of tempered
glass with permanent marking in such locations. Glass
meeting this requirement is available from the factory.
Please contact your dealer or distributor to order.
NOTE: Thisinstallationmustconform with local codes. In the
absence of local codes you must comply with the National
Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A.
and the CAN/CGA B149 Installation Codes in Canada.
NOTINTENDEDFORUSE AS APRIMARYHEATSOURCE.
Thisapplianceistestedandapproved as either supplemental
room heat or as a decorative appliance. It should not be fac-
tored as primary heat in residential heating calculations. D. High Altitude Installations
U.L.Listed gasappliances aretested andapproved without
requiring changes for elevations from 0 to 2000 feet in the
U.S.A. and Canada.
When installing this appliance at an elevation above 2000
feet, it may be necessary to decrease the input rating by
changing the existing burner ori¿ce to a smaller size. Input
rate should be reduced by 4% for each 1000 feet above
a 2000 foot elevation in the U.S.A., or 10% for elevations
between 2000 and 4500 feet in Canada. If the heating
value of the gas has been reduced, these rules do not
apply. To identify the proper ori¿ce size, check with the
local gas utility.
If installing this appliance at an elevation above 4500 feet
(in Canada), check with local authorities.
Do NOT use this appliance if any part has been under water.
Immediately call a quali¿ed service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
This product is listed to ANSI standards for “Vented Gas
Appliance Heaters” and applicable sections of “Gas Burn-
ing Heating Appliances for Manufactured Homes and
RecreationalVehicles”,and “Gas FiredAppliances for Use
at High Altitudes”.
Heat & Glo Quality Systems
registered by SGS ICS
E. Non-Combustible Materials Speci¿cation
Material which will not ignite and burn. Such materials are
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
Materials that are reported as passing ASTM E 136,
Standard Test Method for Behavior of Materials in a
Vertical Tube Furnace at 750oC, shall be considered
non-combustible materials.
F. Combustible Materials Speci¿cation
Materialsmadeoforsurfacedwithwood,compressedpaper,
plant ¿bers, plastics, or other material that can ignite and
burn, whether Àame proofed or not, or whether plastered or
unplastered shall be considered combustible materials.
WARNING
Models
U.S. (0-2000 ft.) or
Canada (2000-4500 ft.)
Maximum
Input
BTU/h
Minimum
Input
BTU/h
Ori¿ce
Size
(DMS)
SL-750TRS-IPI-D (NG) U.S. 30,000 20,500 #36
Canada 27,000 18,450 #37
SL-750TRS-IPI-D (LP) U.S. 27,000 15,800 #52
Canada 24,300 14,220 #53
SL-550TRS-IPI-D (NG) U.S. 27,000 17,000 #38
Canada 24,300 15,300 #39
SL-550TRS-IPI-D (LP) U.S. 25,000 14,000 #53
Canada 22,500 12,500 #54
SL-350TRS-C (NG) U.S. 22,500 15,750 #43
Canada 20,250 14,175 #44

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 5
For all side wall horizontally vented gas fueled equipment
installed in every dwelling, building or structure used in
whole or in part for residential purposes, including those
owned or operated by the Commonwealth and where
the side wall exhaust vent termination is less than seven
(7) feet above ¿nished grade in the area of the venting,
includingbut notlimited todecksandporches,thefollowing
requirements shall be satis¿ed:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented
gas fueled equipment, the installing plumber or gas¿tter
shall observe that a hard wired carbon monoxide detector
with an alarm and battery back-up is installed on the
Àoor level where the gas equipment is to be installed. In
addition, the installing plumber or gas¿tter shall observe
that a battery operated or hard wired carbon monoxide
detector with an alarm is installed on each additional level
of the dwelling, building or structure served by the side
wallhorizontalvented gasfueledequipment. It shallbethe
responsibility of the property owner to secure the services
of quali¿ed licensed professionals for the installation of
hard wired carbon monoxide detectors.
Inthe eventthat theside wallhorizontally ventedgasfueled
equipmentisinstalled in a crawlspaceor an attic, thehard
wired carbon monoxide detector with alarm and battery
back-up may be installed on the next adjacent Àoor level.
In the event that the requirements of this subdivision can
not be met at the time of completion of installation, the
ownershallhave a periodofthirty (30) daystocomply with
the above requirements; provided, however, that during
said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Eachcarbon monoxide detectoras required inaccordance
with the above provisions shall comply with NFPA720 and
be ANSI/UL 2034 listed and IAS certi¿ed.
Signage
Ametal or plastic identi¿cation plate shall be permanently
mounted to the exterior of the building at a minimum
height of eight (8) feet above grade directly in line with
the exhaust vent terminal for the horizontally vented gas
fueled heating appliance or equipment. The sign shall
read, in print size no less than one-half (1/2) inch in size,
“GAS VENT DIRECTLY BELOW. KEEP CLEAR OFALL
OBSTRUCTIONS”.
Inspection
Thestate or localgasinspector oftheside wallhorizontally
vented gas fueled equipment shall not approve the
installationunless, uponinspection,theinspectorobserves
carbon monoxide detectors and signage installed in
accordance with the provisions of 248 CMR 5.08(2)(a)1
through 4.
Exemptions
The following equipment is exempt from 248 CMR
5.08(2)(a)1 through 4:
• Theequipmentlisted in Chapter10entitled “Equipment
Not Required To Be Vented” in the most current edition
of NFPA54 as adopted by the Board; and
• Product Approved side wall horizontally vented gas
fueled equipment installed in a room or structure
separate from the dwelling, building or structure used
in whole or in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equipment Venting System Provided
When the manufacturer of Product Approved side wall
horizontally vented gas equipment provides a venting
system design or venting system components with the
equipment, the instructions provided by the manufacturer
for installation of the equipment and the venting system
shall include:
• Detailed instructions for the installation of the venting
system design or the venting system components; and
• A complete parts list for the venting system design or
venting system.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall
horizontallyventedgas fueledequipmentdoes not provide
the parts for venting the Àue gases, but identi¿es “special
venting systems”, the following requirements shall be
satis¿ed by the manufacturer:
• The referenced “special venting system” instructions
shallbeincluded withtheappliance or equipmentinstal-
lation instructions; and
• The“special ventingsystems” shallbe ProductApproved
bythe Board,and theinstructionsforthatsystemshallin-
clude a parts list and detailed installation instructions.
A copy of all installation instructions for all Product Ap-
provedside wall horizontallyventedgas fueledequipment,
all venting instructions, all parts lists for venting instruc-
tions, and/or all venting design instructions shall remain
with the appliance or equipment at the completion of the
installation.
See Gas Connection section for additional Common-
wealth of Massachusetts requirements.
G. Requirements for the Commonwealth of
Massachusetts
NOTE: The following requirements reference various
Massachusetts and national codes not contained in
this document.

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
6
A. Design and Installation Considerations
Hearth & Home Technologies direct vent gas appliances
are designed to operate with all combustion air siphoned
from outside of the building and all exhaust gases ex-
pelled to the outside. No additional outside air source is
required.
Getting Started
C. Inspect Appliance and Components
2
When planning an appliance installation, it’s necessary to
determine the following information before installing:
• Where the appliance is to be installed.
• The vent system con¿guration to be used.
• Gas supply piping.
• Electrical wiring.
• Framing and ¿nishing details.
• Whether optional accessories—devices such as a fan,
wall switch, or remote control—are desired.
B. Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Reciprocating saw Framing material
Pliers Hi temp caulking material
Hammer Gloves
Phillips screwdriver Framing square
Flat blade screwdriver Electric drill and bits (1/4 in.)
Plumb line Safety glasses
Level 1/2 - 3/4 inch length, #6 or #8 Self-drilling screws
Manometer Voltmeter
Tape measure Noncorrosive leak check solution
One 1/4 inch female connection (for optional fan).
• Carefully remove the appliance and components from
the packaging.
• Theventsystemcomponentsandtrimdoors areshipped
in separate packages.
• The gas logs may be packaged separately and must
be ¿eld installed.
• Report to your dealer any parts damaged in shipment,
particularly the condition of the glass.
• Read all of the instructions before starting the in-
stallation. Follow these instructions carefully dur-
ing the installation to ensure maximum safety and
bene¿t.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, ¿re of¿cials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
CAUTION
Keep appliance dry.
• Mold or rust may cause odors.
• Water may damage controls.
WARNING
Inspect appliance and components for
damage. Damaged parts may impair safe
operation.
WARNING
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report damaged parts to dealer.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
• Installation and use of any damaged
appliance or vent system component.
WARNING
• Modi¿cation of the appliance or vent system.
• Installation other than as instructed by Hearth & Home
Technologies.
• Improper positioning of the gas logs or the glass door.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
Any such action may cause a ¿re hazard.

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 7
HB
G
F
E
D
C
A
I
3Framing and Clearances
NOTE:
•Illustrations reÀect typical installations and are FOR
DESIGN PURPOSES ONLY.
•Illustrations/diagrams are not drawn to scale.
•Actual installation may vary due to individual design
preference.
WARNING
Fire Risk
Provide adequate clearance:
• Around air openings
• To combustibles
• For service access
Locate appliance away from traf¿c areas.
A. Selecting Appliance Location
Whenselecting alocationfor yourapplianceit isimportant to
consider the required clearances to walls (see Figure 3.1).
Figure 3.1 Appliance Locations
NOTE: For actual appliance dimensions refer to Sec-
tion 16.
In addition to these framing dimensions, also reference the following sections:
• Clearances and Mantel Projections (Section 3.C and 3.D)
• Vent Clearances and Framing (Section 6).
AB C D EFG H I
SL-750TRS-IPI-D Inches 45 42 63-3/4 See Section
D for Alcove
Installation
1 1/2 52 73-1/4 16-1/4
Millimeters 1143 1067 1619 25 13 1321 1861 413
SL-550TRS-IPI-D Inches 41-1/2 37 58-3/4 1 1/2 48-1/2 68-1/4 16-1/4
Millimeters 1054 940 1492 25 13 1232 1734 413
SL-350TRS-C Inches 39-3/8 34 55-5/8 1 1/2 46-3/8 65-1/8 16-1/4
Millimeters 1000 864 1413 25 13 1178 1654 413

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
8
Fire Risk.
•Construct chase to all clearance
speci¿cations in manual.
•Locate and install appliance to all
clearance speci¿cations in manual
WARNING
B. Constructing the Appliance Chase
A chase is a vertical boxlike structure built to enclose the
gasappliance and/oritsvent system.Vertical ventsthatrun
on the outside of a building may be, but are not required to
be, installed inside a chase.
Construction of the chase may vary with the type of building.
These instructions are not substitutes for the requirements
of local building codes. Local building codes MUST be
checked.
Chasesshouldbe constructed in themannerof all outside
walls of the home to prevent cold air drafting problems.
The chase should not break the outside building envelope
in any manner.
Walls, ceiling, base plate and cantilever Àoor of the chase
shouldbe insulated.Vaporand airin¿ltrationbarriers should
beinstalled inthe chaseas perregional codesfor therest of
the home.Additionally, in regions where cold air in¿ltration
may be an issue, the inside surfaces may be sheetrocked
and taped for maximum air tightness.
To furtherprevent drafts,the wallshield andceiling ¿restops
shouldbe caulkedwith hightemperature caulkto sealgaps.
Gas line holes and other openings should be caulked with
C. Clearances
Figure 3.2 Clearances to Combustibles
Fire Risk.
Odor Risk.
•Install appliance on hard metal or wood
surfaces extending full width and depth of
appliance.
•Do NOT install appliance directly on
carpeting, vinyl, tile or any combustible
material other than wood.
WARNING
high temp caulk or stuffed with unfaced insulation. If the
appliance is being installed on a cement slab, a layer of
plywood may be placed underneath to prevent conducting
cold up into the room.
C
B
D
A
E
H
I
F
FROM TOP
OF HOOD
TO CEILING
G
J
Models
ABCDEFGHIJ
DVP PIPE SL PIPE Rough
Opening
(Height)
DVP PIPE SL PIPE Rough
Opening
(Width)
Clearance
to Ceiling Non-Combustible
Floor Combustible Flooring Behind Appliance Sides of Appliance Front of Appliance
Rough
Opening
(Width)
Rough
Opening
(Width)
Rough
Opening
(Depth)
Rough
Opening
(Depth)
SL-750TRS-IPI-D Inches 10 8-5/8 38-1/4 27-1/2 16-1/4 42 31 0 0 1/2 1/2 36
Millimeters 254 219 971 699 413 1067 787 0 0 13 13 915
SL-550TRS-IPI-D Inches 10 8-5/8 33 27-1/2 16-1/4 37 31 0 0 1/2 1/2 36
Millimeters 254 219 838 699 413 940 787 0 0 13 13 915
SL-350TRS-C Inches 10 8-5/8 31 27-1/2 16-1/4 34 31 0 0 1/2 1/2 36
Millimeters 254 219 787 699 413 864 787 0 0 13 13 915

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 9
A
Top View
INTERIOR WALL
FIREPLACE
OPENING
B
MANTEL LEG OR WALL PROJECTIONS
D. Mantel Projections
Figure 3.3 Clearances to Mantels or other
Combustibles above Appliance
Figure 3.4 Clearances to Mantel Legs or Wall Projections
(Acceptable on both sides of opening.)
2” 4" 5” 6” 7” 8” 9”
2" 3" 4"5"
12"
11"
10"
9"
8"
7"
6"
TOP FRONT EDGE
OF FIREPLACE
3”
11”12”
10”
31”
CEILING
1” 1”
If Aminimum is ____, then Bmaximum is_____.
AInches 345678
Millimeters 76 102 127 152 178 203
BInches 12345
f
Millimeters 25 51 76 102 127 f

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
10
A. Vent Termination Minimum Clearances
Fire Risk.
Explosion Risk.
Maintain vent clearance to combustibles as
speci¿ed.
WARNING
• Do not pack air space with insulation or
other materials.
Failure to keep insulation or other materials
away from vent pipe may cause ¿re.
Roof Pitch H (Min.) Ft.
Flat to 6/12...........................................................1.0*
Over 6/12 to 7/12.................................................1.25*
Over 7/12 to 8/12.................................................1.5*
Over 8/12 to 9/12.................................................2.0*
Over 9/12 to 10/12...............................................2.5
Over 10/12 to 11/12.............................................3.25
Over 11/12 to 12/12.............................................4.0
Over 12/12 to 14/12.............................................5.0
Over 14/12 to 16/12.............................................6.0
Over 16/12 to 18/12.............................................7.0
Over 18/12 to 20/12.............................................7.5
Over 20/12 to 21/12.............................................8.0
Figure 4.1
Figure 4.2 Minimum Height from Roof to
Lowest Discharge Opening
Termination Locations
4
Measure horizontal clearances from this surface.
Measure vertical clearances from this surface.
Figure 4.3 Multiple Vertical Termination
Figure 4.2 speci¿es minimum vent heights for various
pitched roofs.
(See Figure 4.4 for speci¿c clearances)
* 3 foot minimum in snow regions
HORIZONTAL
OVERHANG
VERTICAL
WALL
GAS DIRECT VENT
TERMINATION CAP
12
X
ROOF PITCH
IS X/ 12
LOWEST
DISCHARGE
OPENING
2 FT.
MIN.
20 INCHES MIN.
H (MIN.) - MINIMUM HEIGHT FROM ROOF
TO LOWEST DISCHARGE OPENING
C
A
GAS
TERMINATION
B
GAS, WOOD OR FUEL
OIL TERMINATION
Gas
Termination Wood & Fuel Oil Termination Comments
A6 in. 20 in. min. Horizontal distance between terminations
B20 in. 24 in. min. Distance to perpendicular wall
C18 in. 18 in. Vertical distance between terminations

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 11
V= VENT TERMINAL X= AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED
Figure 4.4 Minimum Clearances for Termination
A = 12 inches...............clearancesabovegrade,veranda,
porch, deck or balcony
B = 12 inches...............clearances to window or door
thatmay be opened, ortoperma-
nently closed window. (Glass)
D* = 18 inches...............vertical clearance to unventilated
sof¿torto ventilated sof¿t located
above the terminal
*30 inches..............for vinyl clad sof¿ts and below
electrical service
F = 9 inches................clearance to outside corner
G = 6 inches.................clearance to inside corner
H = 3 ft. (Canada)........not to be installed above a gas
meter/regulator assembly within 3
feet (90cm) horizontally from the
center-line of the regulator
I = 3 ft. .......................clearancetogasserviceregulator
vent outlet
J = 9 inches (U.S.A.)
12 inches (Canada) clearance to non-mechanical
air supply inlet to building or the
combustion air inlet to any other
appliance
K = 3 ft. (U.S.A.)
6 ft. (Canada)...........clearance to a mechanical (pow-
ered) air supply inlet
L** = 7 ft...........................clearance above paved
sidewalk or a paved driveway
located on public property
M*** = 18 inches.................clearance under veranda, porch,
deck, balcony or overhang
42 inches ................vinyl
CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS SUGGESTED THAT A VINYL PROTECTOR KIT BE INSTALLED.
** aventshall notterminate directlyabovea sidewalkor paveddriveway
whichislocated betweentwosingle familydwellingsand servesboth
dwellings.
*** only permitted if veranda, porch, deck or balcony is fully open on a
minimum of 2 sides beneath the Àoor, or meets Note 2.
NOTE 1: On private property where termination is less than 7 feet above
a sidewalk, driveway, deck, porch, veranda or balcony, use of a listed cap
shield is suggested. (See vents components page)
NOTE 2: Termination in an alcove space (spaces open only on one side
and with an overhang) are permitted with the dimensions speci¿ed for
vinyl or non-vinyl siding and sof¿ts. 1. There must be 3 feet minimum
between termination caps. 2. All mechanical air intakes within 10 feet
of a termination cap must be a minimum of 3 feet below the termination
cap. 3. All gravity air intakes within 3 feet of a termination cap must be a
minimum of 1 foot below the termination cap.
(See Note 1)
(See Note 1)
(See Note 2)
NOTE 3: Local codes or regulations may require different
clearances.
NOTE 4: Termination caps may be hot. Consider their proximity to
doors or other traf¿c areas.
NOTE 5: Location of the vent termination must not interfere with
access to the electrical service.
WARNING: In the U.S: Ventsystemtermination isNOT permitted in
screenedporches.Youmustfollow sidewall,overhang and ground
clearances as stated in the instructions.
In Canada: Vent system termination is NOT permitted in screened
porches. Vent system termination is permitted in porch areas with
two or more sides open. You must follow all side walls, overhang
and ground clearances as stated in the instructions.
Hearth & Home Technologies assumes no responsibility for the
improper performance of the appliance when the venting system
does not meet these requirements.
QMIN = # termination caps x 3 RMAX = (2 / # termination caps) x QACTUAL
N = 6 inches ..................non-vinyl sidewalls
12 inches ................vinyl sidewalls
P = 8 ft.
Alcove Applications
S = 6 inches...................clearance from sides of elec-
trical service
T = 12 inches..................clearance above electrical
service
(See Note 5)
(See Note 5)
Electrical
Service
V
S
VS
V
T
D*
V
MN
P
R
Q
QMIN RMAX
1 cap 3 feet 2 x Q ACTUAL
2 caps 6 feet 1 x Q ACTUAL
3 caps 9 feet 2/3 x Q ACTUAL
4 caps 12 feet 1/2 x Q ACTUAL

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
12
5Vent Information and Diagrams
Fire Hazard.
Explosion Risk.
Asphyxiation Risk.
Do NOT connect this gas appliance to a
chimney Àue serving a separate solid-fuel or
gas burning appliance.
• Vent this appliance directly outside.
• Use separate vent system for this appliance.
May impair safe operation of this appliance or
other appliances connected to the Àue.
WARNING
CAUTION
ALL vent con¿guration speci¿cations MUST be followed.
• This product is tested and listed to these
speci¿cations.
• Appliance performance will suffer if speci¿cations are
not followed.
B. Use of Elbows
Diagonal runs have both vertical and horizontal vent as-
pects when calculating the effects. Use the rise for the
vertical aspect and the run for the horizontal aspect (see
Figure 5.1).
Two450elbowsmay be usedinplace ofone900elbow.On
450runs, one foot of diagonal is equal to 8.5 inches hori-
zontal run and 8.5 inches vertical run. A length of straight
pipe is allowed between two 450elbows (see Figure 5.1).
Figure 5.1
A. Vent Table Key
The abbreviations listed in this vent table key are used in
the vent diagrams.
C. Measuring Standards
Vertical and horizontal measurements listed in the vent
diagrams were made using the following standards.
1. Pipemeasurementsareshown usingthe effectivelength
of pipe (see Figure 5.2).
2. Measurementsaremadefromthe applianceouter wrap,
not from the standoffs.
3. Horizontal terminations are measured to the outside
mountingsurface (Àangeof terminationcap) (seeFigure
4.1).
4. Vertical terminationsare measuredto bottomof termina-
tion cap.
5. Horizontal pipe installed level with no rise.
Figure 5.2 DVP Pipe Effective Length
Effective
Height/Length
DVP4 4
DVP6 6
DVP12 12
DVP24 24
DVP36 36
DVP48 48
DVP6A 3 to 6
DVP12A 3 to 12
DVP12MI 3 to 12
DVP24MI 3 to 24
Length/
Inches
Pipe
Symbol Description
V1First section (closest to appliance of vertical length
V2Second section of vertical length
H1First section (closest to appliance) of horizontal length
H2Second section of horizontal length
Horizontal
V
ertical
8-1/2 in.
8-1/2 in.
12 in.

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 13
3in.CLEARANCE TERMINATION
CAP
FLEX-VENT
1in.
CLEARANCE
D. Use of Flex Vent
The Àex vent must be supported with
the spacing between support intervals
notexceeding 4 feet,with no morethan
½ inch sag between supports.
A support is required at each change
in venting direction, and in any location
where it is necessary to maintain the
necessary clearance to combustibles.
A simple “up and out” installation
(Figure 5.3) requires only enough
support to maintain the necessary
clearance to combustibles. However,
the vent attachment point and the
¿restop location are considered to be
supports.
Figure 5.3

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
14
Figure 5.4
E. Vent Diagrams
Fire Risk. Explosion Risk.
Do NOT pack insulation or other combustibles between ceiling ¿restops.
• ALWAYS maintain speci¿ed clearances around venting and ¿restop systems.
• Install wall shield and ceiling ¿restops as speci¿ed.
Failure to keep insulation or other material away from vent pipe may cause ¿re.
WARNING
1. Top Vent - Horizontal Termination Venting
V Minimum H1Maximum
SL-350TRS SL-550, SL-750TRS-D
90° Elbow 1.5 ft. 457 mm 1 ft. 305 mm
0.5 ft. 152
mm 2 ft. 610 mm 2 ft. 610 mm
1.5 ft. 457
mm 3 ft. 914 mm 3 ft. 914 mm
2.5 ft. 762
mm 5 ft. 1.5 m 5 ft. 1.5 m
3.5 ft. 1.1 m 7 ft. 2.1 m 7 ft. 2.1 m
4.5 ft. 1.4 m 15 ft. 4.6 m 15 ft. 4.6 m
H Maximum= 15 ft. (4.6 m)
V + H Maximum= 40 ft. (12.2 m)
H1
V1
Note: Use SL-D Series
components only.
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
One Elbow (Natural Gas) One Elbow (Propane)
V Minimum H1Maximum
90° Elbow Not Allowed
0.5 ft. 305 mm 1 ft. 305 mm
1.5 ft. 610 mm 3 ft. 914 mm
2.5 ft. 914 mm 5 ft. 1.5 m
3.5 ft. 1.1 m 7 ft. 2.1 m
4.5 ft. 1.4 m 15 ft. 4.6 m
H Maximum= 15 ft. (4.6 m)
V + H Maximum = 40 ft. (12.2 m)

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 15
H2
H1
V1
Figure 5.5
Two Elbows
Note: Use SL-D Series
components only.
NOTE: There MUST be a 25%
reduction in total H when using
Àex vent except when using the
simple up and out installation
(see Figure 5.3).
V Minimum H1Maximum
SL-350TRS, SL-550TRS-D,
SL-750TRS-D
90° Elbow NOTALLOWED
0.5 ft. 152 mm 1 ft. 305 mm
1.5 ft. 457 mm 2 ft. 610 mm
2.5 ft. 762 mm 4 ft. 1.2 m
3.5 ft. 1.1 m 6 ft 1.8 m
4.5 ft. 1.4 m 14 ft. 4.3 m
H + H1 Maximum= 14 ft. (4.3 m)
V + H + H1 Maximum= 40 ft. (12.2 m)
Propane
V Minimum H1Maximum
90° Elbow Not Allowed
1 ft. 305 mm 1 ft. 305 mm
1.5 ft. 457 mm 2 ft. 610 mm
2.5 ft. 762 mm 4 ft. 1.2 m
3.5 ft. 1.1 m 6 ft. 1.8 m
4.5 ft. 1.4 m 14 ft. 4.2 m
H Maximum= 14 ft. (4.3 m)
V + H Maximum = 40 ft. (12.2 m)
Natural Gas

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
16
Figure 5.6
1. Top Vent - Horizontal Termination - (continued)
Three Elbows
H2
V2
H1
V1
V1Minimum
Model: SL-350TRS-C Models: SL-550TRS-IPI-D, SL-
750TRS-IPI-D
H1Maximum H1+ H2Maximum H1Maximum H1+ H2Maximum
Elbow only 1.5 ft. 457 mm 2 ft. 610 mm 1 ft. 305mm 2 ft. 610 mm
.5 ft. 152 mm 2 ft. 610 mm 4 ft. 1.2 m 2 ft. 610 mm 4 ft. 1.2 m
1.5 ft. 457 mm 3 ft. 914 mm 6 ft. 1.8 m 3 ft. 914 mm 6 ft. 1.8 m
2.5 ft. 762 mm 5 ft. 1.5 m 10 ft 3.0 m 5 ft. 1.5 m 10 ft. 3.0 m
3.5 ft. 1.1 m 7 ft. 2.1 m 14 ft. 4.3 m 7 ft. 2.1 m 14 ft. 4.3 m
4.5 ft. 1.4 m 14 ft. 4.3 m 14 ft. 4.3 m 14 ft. 4.3 m 14 ft. 4.3 m
V1+ H1+ V2+ H2Maximum=40 ft. (12.2 m)
Note: Use SL-D Series
components only.
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
Natural Gas
Propane
V1Minimum
ALL MODELS
H1Maximum H1+ H2Maximum
Elbow only Not Allowed Not Allowed
0.5 ft. 152 mm 1 ft. 305
mm 2ft. 610 mm
1.5 ft. 457 mm 3 ft. 914
mm 6 ft. 1.8 m
2.5 ft. 762 mm 5 ft. 1.5 m 10 ft 3.0 m
3.5 ft. 1.1 m 7 ft. 2.1 m 14 ft. 4.3 m
4.5 ft. 1.4 m 14 ft. 4.3 m 14 ft. 4.3 m
V1+ H1+ V2+ H2Maximum=40 ft. (12.2 m)

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 17
2. Top Vent - Vertical Termination
No Elbow
Figure 5.7
NOTE: If installing a vertical vent/
termination off the top of the appli-
ance, the optional vertical termina-
tion bafÀe should be used.
CAP
V1
V1= 44 ft. Max. (13.4 m)
Note: Use SL-D Series
components only. BafÀe Instruction
1. Install the bafÀe over the center of the exhaust outlet in
the ¿rebox (see Figure 5.8).
2. Center the exhaust opening in the open end of the
bafÀe, and secure through the slots on the bafÀe with
the 2-1/4 in. self tapping screws provided.
BafÀes are recommended for these vertically terminated
productswhichhave excessive draft. BafÀes compensate
for high draft, restore visual Àame height, and limit exces-
sive cooling resulting from too much secondary air. Refer
to the allowable vent con¿gurations in the model speci¿c
installer’s guide for recommended use of this bafÀe.
BAFFLE
VIEW FROM
UNDERNEATH
SIDE VIEW
FIREBOX
BACK
EXHAUST
FIREBOX
BACK
BAFFLE
FRONT
OF UNIT

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
18
Figure 5.8
Two 90° Elbows
V2
H1
V1
Note: Use SL-D Series
components only.
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
V1 Minimum
HMaximum
All Models
90° Elbow NOTALLOWED
.5 ft 152 mm 1 ft. 305 mm
1 ft 305 mm 2 ft. 610 mm
2 ft 610 mm 4 ft. 1.2 m
3 ft 914 m 6 ft. 1.8 m
4 ft 1.2 m 8 ft. 2.4 m
5 ft. 1.5 m 15 ft 4.6 m
H Maximum= 15 ft. (4.6 m)
V1 + V2 + HMaximum= 40 ft (12.2 m)
V1 Minimum
H1 Maximum H1 Maximum V2V1 + V2 Minimum
SL-350TRS SL-550TRS-D, SL-750TRS-D * *
90° Elbow 1.5 ft. 457 mm 1 ft. 305 mm * *
.5 ft 152 mm 2 ft 610 mm 2 ft. 610 mm * *
1 ft 305 mm 2.5 ft 762 mm 2.5 ft. 762 mm * *
2 ft 610 mm 4 ft 1.2 m 4 ft. 1.2 m * *
3 ft 914 m 6 ft 1.8 m 6 ft. 1.8 m * *
4 ft 1.2 m 8 ft 2.4 m 8 ft. 2.4 m * *
5 ft. 1.5 m 15 ft 4.6 m 15 ft 4.6 m * *
H Maximum= 15 ft. (4.6 m)
V1 + V2 + HMaximum= 40 ft (12.2 m)
*No speci¿c restrictions on this value EXCEPT V1 + V2 + H cannot exceed 40 ft (12.2 m)
Propane
Natural Gas

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL350TRS-C • InD • 2065-985 Rev. o • 3/07 19
Figure 5.9
2. Top Vent - Vertical Termination - (continued)
Three 90° Elbows
H2
V
2
H1
V1
ALL MODELS
V1 H
1+ H2 Maximum V2V1 + V2 Minimum
90° Elbow 0 0 1.5ft 457 mm 1.5ft 457 mm
.5 ft 152 mm 1 ft 305 mm * * * *
1.5 ft 457 mm 2 ft 610 mm * * * *
2.5ft 762 mm 4 ft 1.2 m * * * *
3.5ft 1.1 m 6 ft 1.8 m * * * *
4.5 ft 1.4 m 14 ft. 4.3 m * * * *
HMaximum= 14 ft (4.3m)
*No speci¿c restrictions on this value EXCEPT V1+ V2+ H1+ H2
CANNOT exceed 40 ft. (12.2 m).
Note: Use SL-D Series
components only.
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
ALL MODELS
V1 H
1+ H2 Maximum V2V1 + V2 Minimum
90° Elbow NOTALLOWED
.5 ft 152 mm 0 ft 0 mm * * * *
1.5 ft 457 mm 2 ft 610 mm * * * *
2.5ft 762 mm 4 ft 1.2 m * * * *
3.5ft 1.1 m 6 ft 1.8 m * * * *
4.5 ft 1.4 m 14 ft. 4.3 m * * * *
HMaximum= 14 ft (4.3m)
V1+ V2+ H Maximum= 40 ft. (12.2 m)
Natural Gas
Propane

Heat & Glo • SL-750TRS-IPI-D, SL-550TRS-IPI-D, SL-350TRS-C • InD • 2065-985 Rev. o • 3/07
20
V1
H1
V3
V2
H2
2. Top Vent - Vertical Termination - (continued)
Four 90 ° Elbows
Figure 5.17
V1H1V2H2V3
1.5 ft. 457 mm 4 ft. 1.2 m 4 ft. 1.2 m 4 ft. 1.2 m 3.5 ft. 1.0 m
V1 + V2 + V3 + H1 + H2 Maximum= 40 ft. (12.2 m)
Natural Gas and Propane
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
Note: Use SL-D Series
components only.
V1
H1
V3
V2
H2
2. Top Vent - Vertical Termination - (continued)
Four 90 ° Elbows
Figure 5.17
V1H1V2H2V3
1.5 ft. 457 mm 4 ft. 1.2 m 4 ft. 1.2 m 4 ft. 1.2 m 3.5 ft. 1.0 m
V1 + V2 + V3 + H1 + H2 Maximum= 40 ft. (12.2 m)
Natural Gas and Propane
NOTE: There MUST be a
25% reduction in total H
when using Àex vent except
when using the simple up
and out installation (see
Figure 5.3).
Note: Use SL-D Series
components only.
