Heat Storm HS-1500-WALL-R User manual

1500W | IN-WALL SMART HEATER
HS-1500-WALL-R

3. Then place screws into wood studs into
the wall as shown below
Heater is prewired for an outlet and cord can be cut for direct
wire application
DISCLAIMER - Recommened professional installation by a
certified electrician

What you do
single touch
Combo
touch with -
Combo
touch with +
single touch
single touch
single touch
3 sec long touch
single touch
single touch
3 sec long touch
single touch
5 sec long touch
Turns heater ON/OFF
Increase temperature 1
degree.
Alternate between F° and C°
Decrease temperature 1
degree.
Alternate between F° and C°
Change working mode from
Low-Auto-High
Toggle fan only/heat mode
Set delay on/off timer
Toggle sound ON/OFF
Turn ON/OFF Child Lock
Turns dislplay OFF
Enable Wifi Discovery Mode
Red - on
White - off
White - all the
time
White - all the
time
Red - high
Green -low
White - auto
White - no timer
set
Green - timer set
for off
Red - Timer is set
for On
Red - Child lock
is on
Blue - Connected
to wifi
fast blink blue -
discovery mode
slow blink blue -
AP discovery mode
What heater will do Color Status
icon
SELECTING CELSIUS AND FAHRENHEIT
By pressing the"+" and"-" icons at the same time, you can set
the heater to function and display in Celsius or Fahrenheit.
NOTE: Switching between Celsius and Fahrenheit can only be
performed using touch screen on heater, and is not available
using the remote control.
SETTING THE TEMPERATURE
When pressing either the"+" or"-" icons the display will enter
into temperature setting mode. The heater will indicate that
it is in this mode when the numbers begin to blink. Pressing
the"+" or"-" icons will change the thermostat by l °F or l0° C.
-The default set temperature of the heater is 70 °F or 27 °C.
-After 5 seconds without control input the display will exit
temperature setting mode and show the current ambient
temperature.
NOTE: After the heater function or power is shutoff the blower
will continue to run for several minutes to cool the internal
components.
CHILD LOCK FEATURE
Press the Lock/Soundless icon for 3 seconds to engage child
lock.
When the child lock is on, no changes can be made to the
settings until the child lock is turned off.
To turn off child lock - Press the Lock/Soundless icon for 3
seconds to disable child lock.
FACTORY RESET
Power off heater and allow time for elements to cool. Unplug
and plug in heater. Within 3 minutes of plugging in heater,
Fan
Timer
Child Lock
WIFI

press and hold On/Off icon for 10 seconds. This will reset heater
to factory settings.
THERMOSTAT CALIBRATION
Thermostat readings can vary based on the environment. If
desired, the thermostat on the heater can be manually calibrat
ed to match central HVAC system.
NOTE: Thermostat calibration can only be performed using the
Control Panel on the heater and is not available using the
remote control.
NOTE: Typically Heat Storm Infrared Heater thermostats are
more accurate than home central thermostats. Changing your
Heat Storm Infrared Heater to match your central system may
reduce its efficiency.
NOTE: You may have to attempt thermostat calibration several
times to make your heater thermostat match your HVAC
system.
1. Press the Thermostat Calibration on the bottom of the APP
control panel to begin calibration.
2. Use the"+" and/or"-" buttons to adjust the thermostat.
3. Press Confirm the heater will exit thermostat calibration.
FAN ONLY MODE
Press the Fan icon for 3 seconds to toggle between fan
only/heat mode.
Fan modes – single touch Fan icon to change working mode
from Low-Auto-High.
WARNING: ANY REQUIRED SERVICE AND MAINTENANCE
SHOULD ONLY BE PERFORMED BY AN AUTHORIZED SERVICE
REPRESENTATIVE.
Watch video tutorials at heatstorm.com

You can watch video tutorials at heatstorm.com, or scan below
Check for desired temperature.

If the smell persists for more than a couple of hours, call
customer service at 435-752-6611.
(435-752-6611)
Why does the Blower Fan keep running after I have turned
off the unit?
The Blower Fan will continue to run until the heat chamber has
cooled down. After a few minutes the fan will shut off automati-
cally. This ensures that the heating elements are cooled properly
increasing the longevity of your heater.
Can the heating elements be replaced?
Yes. Contact an authorized repair center, generally, this is the
store where you purchased your heater. If you ordered the heater
online or have had the heater for longer than one year, contact
customer service (435-752-6611) to order replacement elements.
My cord is getting very hot, especially at the plug. Is that
normal?
No. Most likely the problem is the connection from the wall
wiring to the outlet is faulty and is causing the outlet and plug to
overheat. Also, make sure there are not too many appliances
plugged into outlets on a single circuit. This problem is quite
common in older homes. If the problems persist consult a quali-
fied electrician.
The heater's airflow seems to have diminished?
Make sure the air inlet is not blocked.
Once I initially plug the unit in and turn it on, how long will
it take to heat my room?
Generally, it takes about a half hour. Please remember that with
any type of heating process there are many variables; size of the
room, how well the room is insulated, how many doors/windows,
how much bare concrete (which acts as a heat sink with any type
of heating), the opening and closing of an exterior door, etc.
Heating performance will vary in every environment.

Can I use the heater to heat multiple rooms at the same
time?
Yes. Keep in mind the heating will vary based on how open your
floor plan is and the sizes of the rooms involved. Please be advised
this heater is good for 700-1000 square feet of supplemental
heating.
My Heater never seems to reach the set temperature, it
just keeps running.
There are several possible causes. Make sure the filters are clean. If
the room is drafty or poorly insulated the thermostat sensor may
be taking an inaccurate reading. Make sure to keep doors closed
so that the heater can heat the room. Also, ensure that the heater
is plugged into an interior wall and is not below a window. Often,
when a heater is below a window the cool air from the window is
causing an inaccurate temperature reading. If none of the above
assist with the problem, your heater may be too small for the
room. This heater can heat 700-1000 square feet of supplemental
heating and approximately 150-300 square feet of primary heat-
ing. The square footage amounts will vary depending on how well
insulated your home is.
My home is not insulated very well, will this heater help
me?
Yes, but keep in mind that rooms with little insulation will not
retain the heat as efficiently and may result in your heater running
longer or more often.
Can I use the heater if I have vaulted or cathedral ceilings?
Yes, but it may take longer to heat the room initially. Once the
room has reached the desired temperature it will cycle on and off
accordingly.
Will I be able to use the heater in a basement or garage?
Yes, if the basement is finished with drywall insulation and carpet.
Other¬wise, we recommend you use our Heat Storm Outdoor
Infrared Heaters for this heating need. For more information visit
heatstorm.com or contact customer service at 435-752-6611
Can I use more than one heater at a time?
Yes, but make sure they are not on the same electrical circuit.
Each heater and appliance should be on its own circuit. If you are
on the fence about having 2 heaters in a room, we recom-
No, we do not recommned using an extension cord, surge
protector, or power strip.
-If heater in unplugged while in working mode, the fan will blow
again when plugged in.
-When heater is unplugged in standby mode the fan will not start
when plugged in.
-If the heater didn’t finished it cool down procedure when it was
unplugged, the fan will blow immediately when the heater is turned
on by on/off icon.
