Heat Storm SIGNATURE Series User manual

1
SIGNATURE
S eries
INSTALLATION GUIDE
Thank you and congratulations on your purchase of your Heat Storm TM
Signature Series Radiant Glass Heater.
This heater has been designed with care for you.

2
Contents
I.Safety Instructions ………………………………………………………………3
II. Heater Installation ………………………………………………………………6
Wall Mounting Instructions……………………………………………………7
Operation Instructions ………………………………………………………..11
Connecting Smart Phone to Heater (Wi-Fi) ……………………………….12
III.Technical Specifications ……………………………………………………..14
IV. Limited Warranty ……………………………………………………………..16

3
I. Safety Instructions
PLEASE READTHIS MANUAL BEFORE OPERATING.
WARNING:
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED, AN ELECTRIC SHOCK OR FIRE MAY
RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
-Use extreme caution when operating heater near children.
-Use extreme caution when leaving the heater unattended.
-Do not operate if the heater malfunctions. Disconnect power and have heater
inspected by an electrician before re-using.
-Do not use outdoors unless proper coverings and precautions are used. Do not
mount in location that could get wet. (ie: in a covered patio).
-Switchheaterswitchto"OFF"positionbeforeunpluggingcordfromwall.
-Do not use heaters in area where gas, paint, flammable vapors or liquids are used or
stored.
-Any other use not recommended by the manufacturer may cause fire, electric
shock, orinjury to persons.
TO REDUCE THE RISK OF FIRE, DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THE HEATER
-Theinstallationmustbe protectedby a25or 30 mAdifferentialcircuit-
breaker (NFC15-100 electrical safety standard). The power supply outage must be of omnipolar
type (phase and neutral cut-off).
-The SIGNATURE heatermustbeconnected tothe power supply (120V AC
60Hz) byanelectricalcircuitprotectedby an overcurrentcircuitbreaker10Aplaced in an
electrical distribution board.
If the power cable is damaged, it must be replaced by a qualified electrician (cable type
SJOOW 14/2).
-The system complies with current standards (see technical data).
The SIGNATURE heater is suitable for indoor use and can be suitable for outside use if all
precautions are taken to prevent the heater from getting wet.

4
Your SIGNATURE Series glass heater is IP 44 rated. This means that for a
bathroom installation, your heater can be located in the following area: Volume 2.
protection index IP44: zones 2 and more
Theheatershouldnot be placed directly belowa power outlet.
Test the control unit before installation and ensure that no hot spots develop.
Only use the SIGNATURE Series heater for the recommended applications andwith
the SIGNATURE Series accessories offered (towel bars).
Do not attempt todisassemble theunit as this willvoid the warranty.
Plug protected by 30mA RCD

5
This device is not intended for use by persons (including children) with reduced
physical, sensory or mental capacities, unless they have been helped by a person
responsible for their safety. The SIGNATURE Series heater is a certified device for
its performance and safety.
PRECAUTIONS FOR USE
The SIGNATURE Series is made of glass, handle it with care.
The SIGNATURE Series heater must not be used if the glass panels are damaged
or the radiator has impact marks.
The SIGNATURE Series is a radiant heater: do not install any obstacle within 20in
of its emitting surface.
The SIGNATURE Series provides directional heat, and needs to be installed where
you would like supplemental heat.
Do not cover the control unit or glass face to ensure radiation efficiency, and avoid
accidental overheating.
Turn off the SIGNATURE Series heater and wait for it to cool downprior to
cleaning with asoft, dampcloth.
The radiant surface can reach 80°C (176°F). Respect a minimum distance of
8’’ between the SIGNATURE Series heater surface and any object.
The SIGNATURE Series is hot when in use. Do not touch.

6
II. Installation
The SIGNATURE Series heater is composed of:
• A tempered glass decorative surface,
• An aluminum heating film (patented),
• A mounting system for vertical or horizontal position
• Towel bars can be added before fixing to the wall.
This will turn your SIGNATURE Series heater
into a towel dryer, ideal for your bathroom.
(Accessories sold separately)
Suggested Tools for Assembly Included Hardware
BEFORE MOUNTING –Determine desired heater location on wall. Allow 3”
space between heater edges and other obstacles. Use level to ensure heater will be
level when installed.

  
 

7
   
      
 
 
STEP 1
STEP 2

8




 
STEP 3
STEP 4

9
 
 
 
STEP 5

10

    

 


STEP 6
ENJOY!
Securing Bolt

11
OPERATING INSTRUCTIONS
• Electrical connection
A 15 AMP, 120 Volt, 60 Hz circuit with a properly
grounded outlet is required.
Ideally, the heater will be on a dedicated circuitas
other appliances on the same circuit may causethe
circuit breaker to trip or the fuse to blow whenthe
heater is in operation.
CAUTION: Do not exceed the current rating of the
outlet. Always plug heaters directly into a wall
outlet/receptacle.
Clean the SIGNATURE Series glass heater with a
soft, damp cloth before heating.
Switch on using the switch located on the side of the
control unit.

12
CONNECTING SMART PHONE TO SIGNATURE SERIES HEATER (Wi-Fi)
Download the Smart Life –Smart Living
App
Add device, select Heater (Wi-Fi), and connect on smart phone.

13
When connected, the control unit will show an illuminated Wi-Fi symbol and heat
symbol. The heat light will be blue (turned off)
When the heater is turned on (on the app), the heat symbol will change color to
red.
Adjust settings on the Smart Life App.
Enjoy!
For assistance call 435-752-6611, or email us at [e-mail]

14
III.Technical Specifications
Voltage: ~120V/AC (60Hz)
Maximal Intensity per radiator: 5A
Protection Class: II
Protection Index: IP44
Indicated power per room: 54W/10 sq ft
Conformity: UL499 & UL2021
SIGNATURE SERIES GLASS HEATERS RANGE:
Power
Width
Length
Weight
Square footage estimate
500W
16’’
48’’
23,3lb
110 sq ft
750W
16’’
72’’
39,7lb
160 sq ft
750W
24’’
48’’
34,4lb
160 sq ft
1100W
24’’
72’’
50,7lb
215 sq ft
Please read and be sure your electrical installation can support the
heater
SIGNATURE Series 16’’ x 72’’ :
THERMAL POWER
Nominal Thermal Power
P nom
750
W
Minimal Thermal Power ( indicative)
P min
675
W
SIGNATURE Series 16’’ x 48’’ :
THERMAL POWER
Nominal Thermal Power
P nom
500
W
Minimal Thermal Power (indicative)
P min
450
W
Maximal Thermal Power (constant)
P max
525
W
AUXILIARY ELECTRICAL CONSUMPTION
At nominal thermal power
C el
500
W/h
At minimal thermal power
C el min
450
W/h
Power off
C el veil
0.5
W/h

15
Maximal Thermal Power (constant)
P max
787.5
W
AUXILIARY ELECTRICAL CONSUMPTION
At nominal thermal power
C el
750
W/h
At minimal thermal power
C el min
675
W/h
Power off
C el veil
0.5
W/h
SIGNATURE Series 24’’ x 48’’ :
THERMAL POWER
Nominal Thermal Power
P nom
750
W
Minimal Thermal Power ( indicative)
P min
675
W
Maximal Thermal Power (constant)
P max
787.5
W
AUXILIARY ELECTRICAL CONSUMPTION
At nominal thermal power
C el
750
W/h
At minimal thermal power
C el min
675
W/h
Power off
C el veil
0.5
W/h
SIGNATURE Series 24’’ x 48’’ :
THERMAL POWER
Nominal Thermal Power
P nom
1200
W
Minimal Thermal Power ( indicative)
P min
1080
W
Maximal Thermal Power (constant)
P max
1260
W
AUXILIARY ELECTRICAL CONSUMPTION
At nominal thermal power
C el
1200
W/h
At minimal thermal power
C el min
1080
W/h
Power off
C el veil
0.5
W/h
WARNING:
If your heater is damaged, do not attempt to repair it yourself.
Contact EnergyWise Solutions for assistance at 435-752-6611, or
[e-mail]

16
IV. Limited Warranty
• 1-year limited warranty.
• The warranty period starts from the date of purchase on the invoice or receipt.
• This warranty applies in addition to all standard laws.
LIMITED WARRANTY CONDITIONS
Any request for warranty is subject to compliance with the following terms and
conditions:
• Warranty is valid only for domestic use in a dry location.
• Warranty covers manufacturing defects.
Warranty does not extend to:
• damage resulting from abuse, misuse, accidents or natural disasters, damages
resulting from other unusual circumstances in connection with residential
applications.
• Damage resultingfrom impropermaintenance and cleaning, overload,ordueto
moisture.
• Incorrect Installation.
• Damage caused by third parties. (transport or assembly)
• EnergyWise Solutions reserves the right to inspect damage on site in order to verify
the conformity of the warranty terms and conditions.
• Ifa defect covered by this warranty isfound, the manufacturer will repair orreplace the
product. Customers are responsible for shipping on warranty returns after 30days.
