MULTI-FUNCTION TOOL
Thank you for choosing Heinner!
SAFETY INSTRUCTIONS
WARNING! ALWAYS WEAR EYE, FACE AND EAR PROTECTION!
When operating the tool
Check that the switch is in the 'OFF' position before connecting to the power supply. Switch to
'OFF' immediately after completion of the task. Keep the mains cable away from any moving
parts or accessories. Never cover the ventilation slots in the tool.
Electrical safety
The electric motor has been designed for one voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Using an extension lead
Always use an approved extension lead suitable for the power input of this tool. Before use,
inspect the extension lead for signs of damage, wear and ageing. Replace the extension lead if
damaged or defective. When using an extension lead on a reel, always unwind the lead
completely. Use of an extension lead not suitable for the power input of the tool or which is
damaged or defective may result in a risk of fire and electric shock.
Caring for the environment
Power tools that are no longer usable should not be disposed of with household waste but in an
environmentally friendly way. Please recycle where facilities exist. Check with your local council
authority for recycling advice. Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the environment. Please recycle
packaging where facilities exist. Check with your local council authority for recycling advice.
General Power Tool Safety Warnings
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term “power tool" in all of the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well it.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust.
c) Keep children and bystanders away while operating a power tool.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators.
c) Do not expose power tools to rain or wet conditions.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts.

MULTI-FUNCTION TOOL
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication.
b) Use personal protective equipment. Always wear eye protection.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool.
d) Remove any adjusting key or wrench before turning the power tool on.
e) Do not overreach. Keep proper footing and balance at all times.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away
from moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
b) Do not use the power tool if the switch does not turn it on and off.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tools operation. If damaged, have the power
tool repaired before use.
f) Keep cutting tools sharp and clean.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions and
in the manner intended- for the particular type of power tool, taking into account the working
conditions and the work to be performed.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
ADDITIONAL SAFETY INSTRUCTIONS
Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord.
Cutting accessory contacting a "live" wire may make exposed metal parts of the power tool "live'
and could give the operator an electric shock.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety.

MULTI-FUNCTION TOOL
SPECIFICATIONS
Motor size: 300W
Input: 230~50Hz
No load speed: 10000-22000/min
Orbit angle: 3.5 degree
Sanding pad size: 90x90x90mm
Variable speed: YES
USING YOUR MULTI FUNCTION TOOL
WARNING!
Be sure to disconnect the rotary tool from the power supply before fitting or removing accessory
bits.
Your Multi-Function Tool has been designed for sanding and cutting and many additional
applications.
This tool is intended for use in a DIY (Do It Yourself) context or for hobbyist purposes. It is not
built for continuous daily use in a trade or professional capacity.
Before first using
Take the machine and all accessories out of the package. Check the machine, loose parts and
accessories for transport damage. Keep the package far away children to prevent danger
happening.
Before using this machine, pull the other plug out of the socket.
Attaching Your Accessory
1. Choose the desired angle required for your application.
2. Position the perforated holes on the accessory over the locating pins on the accessory/ drive
spindle of the multi-function head
3. Ensure the accessory is sitting flat against the face of the accessory drive spindle.
4. Place the accessory fixing washer in alignment with the inner hole of the accessory drive
spindle.
5. Insert the locking bolt through the accessory fixing washer and into the accessory drive spindle
of the Multi-Function Tool. Hand tighten only.
Removing Your Accessory
1. Loosen the locking bolt by rotating the Allen key in an anti-clockwise direction
2. Remove the locking bolt and the accessory fixing washer from the Multi-Function Tool.
Remove the accessory.
3. To re-attach an accessory, follow the instructions on "Attaching your accessory".
Change of sanding paper
The sanding pad is a hook and loop base plate covered with Velcro material. The sanding paper
can be easily attached or removed from the Velcro fastening system.
1. Align the sanding paper to the sanding pad and press firmly to hold in place. The holes in the
sanding paper lines up with the holes on the sanding pad.

MULTI-FUNCTION TOOL
2. To remove or change the sanding paper carefully peel off the sanding paper from one of the
triangle ends.
On/off switch
Operating the On/Off Switch
1. To turn the Multi-function Tool on, push the switch to "O"
position.
2. To tum the Multi-function Tool off push the switch to the "I"
position.
Adjusting the Variable Speed
Note: In various applications you will need to select the correct speed.
1. When the Multi-Function Tool power is turned on, select the "speed" by scrolling the variable
speed. The higher the number on the variable speed dial the faster the oscillation frequency of
the Multi-Function Tool.
2. Recommended oscillation frequency for applications:
•High oscillation frequency
Sanding, sawing, rasping, and polishing stone and Metal (rasping and polishing accessories not
supplied)
•Low oscillation frequency
Polishing varnishes (polishing accessories not supplied)
Choosing the Correct Sanding Paper
Sanding paper is rated according to the number marked on the rear of the sanding paper. The
higher the number, the smaller and less coarse the particles are on the sanding paper. The lower
the number, the larger and coarser the particles are on the sanding paper, this will provide a
more aggressive sanding action. Coarse grit is used for removing paint and sanding down rough
surfaces. Medium grit is used for sanding down plain timber. Fine grit is used to give a smooth
finish to bare wood. Extra fine grit is used for polishing or sanding between coats of paint.
If there are still marks on your work after sanding, try stepping back to a coarser grade of sanding
paper and sanding the marks out. Then recommence with the original choice of grit, or try using
a finer (higher numbered) piece of sanding paper to eliminate the unwanted marks and finish
the job.
Note: Try not to apply excessive pressure when using the Multi-Function Tool as a sander.
Excessive pressure with sanding paper can lead to swirl marks or "ring" impressions on your
workpiece.
Sanding
In sanding mode, the Multi-Function Tool can be used on materials such as wood, plastic and
painted surfaces. Caution: Ensure the Multi-Function Tool is not placed on the work piece.
Note: Ensure you have the correct sanding paper for your application. Always test on a scrap
work piece before using on your work piece
1. Slide the on/off switch forward to the "O" position.
2. Select the desired oscillation frequency speed on the variable speed dial and wait until the
motor reaches its maximum speed.
3. Place the Multi-Function Tool on your work piece, ensuring the whole area of the sanding pad
is in contact with the work surface.
4. Allow the Multi-Function Tool to do the work and do not apply heavy pressure on the Multi-
Function Tool. Heavy pressure will not increase the removal of material but may wear your
sanding paper faster.
5. If sanding corners in hard to reach areas use the tip or triangle edge of the sanding pad.

MULTI-FUNCTION TOOL
Note: Sanding pad must be kept flat on work piece.
Do not tilt the sanding base and use the edge of the sanding paper. This may cause damage to
the sanding pad, reducing its ability to hold your sanding paper.
Sawing- Square Blade
CAUTION: Clamp your workpiece securely if possible and ensure the Multi-Function Tool is not
placed on the workpiece before commencing your work.
Note: Ensure your blades are not blunt or damaged in any way before commencing your
application.
1. In sawing mode, the Multi-Function Tool can be used on wood, plastics.
2. Slide the on/off switch forward to the "O” position.
3. Select the desired oscillation frequency speed on the variable speed dial and wait until the
motor reaches its maximum speed
4. If plunging use a slight pendulum motion, to allow sufficient chip or debris removal.
Note: If using the Multi-Function Tool for plunge cuts. Only use this application on soft materials
such as wood, gypsum plaster boards. Also check if there are no nails or screws in the workpiece
before cutting.
MAINTENANCE
•Keep the ventilation slots of the Multi-Function Tool clean at all times, if possible, prevent
foreign matter from entering the vents.
•After each use, blow air through the Multi-Function Tool housing to ensure it is free from all
dust particles which may build up. Buildup of dust particles may cause the Multi-Function Tool
to overheat and fail.
•If the enclosure of the Multi-Function Tool requires cleaning do not use solvents but a moist
soft cloth only. Never let any liquid get inside the Tool; never immerse any part of the Multi-
Function Tool into a liquid.
Carbon brushes
When the carbon brushes wear out the Multi-Function Tool will spark and/or stop. Discontinue
use as soon as this happens. They should be replaced prior to recommencing use of the Multi-
Function Tool. Carbon brushes are a wearing component of the tool therefore not covered
under warranty. Continuing to use the Multi-Function Tool when carbon brushes need to be
replaced may cause permanent damage to the Multi-Function Tool. Carbon brushes will wear
out after many uses but when the carbon brushes need to be replaced take the tool to an
electrician or a power tool repairer for a replacement. Always replace both carbon brushes at
the same time.
WARNING!
The following actions will result in the warranty being void:
•Professional, Industrial or high frequency use.
•If the tool has been operated on a supply voltage other than that specified on the tool.
•If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or
alterations.
•Failure to perform maintenance as set out within the instruction manual.
•If the tool is disassembled or tampered with in any way.
RECYCLING
Electrical and electronic equipment waste (DEEE) might contain dangerous materials which
can have a negative impact on the environment and human health if not collected separately.

MULTI-FUNCTION TOOL
This item is in conformity with the European Directive EU DEEE (2012/19/EU) and is marked
with an electronic and electrical waste logo graphically represented in the image below.
This icon shows that DEEE should not be collected with household waste but
separately.
We recommend you to consider the following:
- Materials and components used when manufacturing this item are high quality materials
which can be reused and recycled;
- Do not throw away the item with household waste at the end of life;
-Take the item to a collecting point where it will be collected for free;
-Please contact the local authorities for details on the collecting centers.
Conformity with the RoHS Directive: the item you purchased is in conformity with the EU
Directive RoHS (2011/65/UE). It does not contain materials listed as harmful or prohibited in
the Directive.
Thank you for helping us protect the environment and our health!
Manufactured for
Network One Distribution
Marcel Iancu St., no. 3-5, Bucharest, 020757
2018
