HEINZMANN
Engine & Turbine Management
Safety Systems
Triton OMD
Oil Mist Detection System
CAN Protocol

The appropriate manuals must be thoroughly studied before instal-
lation, initial start-up and maintenance.
All instructions pertaining to the system and safety must be followed in
full. Non-observance of the instructions may lead to injury to persons
and/or material damage.
HEINZMANN shall not be held liable for any damage caused through
non-observance of instructions.
Independent tests and inspections are of particular importance for all
applications in which a malfunction could result in injury to persons or
material damage.
All examples and data, as well as all other information in this manual
are there solelyfor the purpose of instruction and they may not be used
for special application without the operator running independent tests
and inspections beforehand.
HEINZMANN does not guarantee, neither expressly nor tacitly, that
the examples, data or other information in this manual is free from er-
ror, complies with industrial standards or fulfils the requirements of any
special application.
To avoid any injury to persons and damage to systems, the follow-
ing monitoring and protective systems must be provided:
−Thermal overload protection
−Overspeed protection independent of the rpm controller
HEINZMANN shall not be held liable for any damage caused through
missing or insufficiently rated overspeed protection.
The following must also be provided for ship propulsion:
−Second power supply for the engine control system
If the governor is used for propulsion, a second power supply has to be
provided to the engine control system if the governor can't keep its po-
sition after power failure.
The following must also be provided for alternator systems:
−Overcurrent protection
−Protection against faulty synchronisation for excessively-large fre-
quency, voltage or phase difference
−Directional contactor
The reasons for overspeeding may be:
−Failure of positioning device, control unit or its auxiliary devices
−Linkage sluggishness and jamming

The following must be observed before an installation:
−Always disconnect the electrical mains supply before any interven-
tions to the system.
−Only use cable screening and mains supply connections that corre-
spond with the European Union EMC Directive
−Check the function of all installed protection and monitoring systems
Please observe the following for electronically controlled injection
(MVC):
−For common rail systems each injector line must be equipped with a
separate mechanical flow-rate limiter
−For unit pump (PLD) and pump-injector unit (PDE) systems, the
fuel enable is first made possible by the solenoid valve’s control
plunger motion. This means that in the event of the control plunger
sticking, the fuel supply to the injection valve is stopped.
As soon as the positioning device receives power, it can actuate the
controller output shaft automatically at any given time. The range of the
controller shaft or control linkage must therefore be secured against un-
authorised access.
HEINZMANN expressly rejects any implied guarantee pertaining to
any marketability or suitability for a special purpose, including in the
event that HEINZMANN was notified of such a special purpose or the
manual contains a reference to such a special purpose.
HEINZMANN shall not be held liable for any indirect and direct dam-
age nor for any incidental and consequential damage that results from
application of any of the examples, data or miscellaneous information
as given in this manual.
HEINZMANN shall not provide any guarantee for the design and
planning of the overall technical system. This is a matter of the operator
its planners and its specialist engineers. They are also responsible for
checking whether the performances of our devices match the intended
purpose. The operator is also responsible for a correct initial start-up of
the overall system.
