Hellenbrand HVN Series User manual

1
Manufacturers of Pre-Engineered and Custom Designed
Water Treatment Systems for Commercial and Industrial Applications
Hellenbrand, Inc.
404 Moravian Valley Road • Waunakee, WI 53597
www.hellenbrand.com • [email protected]
HVN Series
Apartment Buildings
Boiler Water Treatment
Car Washes
Commercial Buildings
Condominiums
Factories
Hospitals
Laundries
Mobile Home Parks
Motels and Hotels
Nursing and Rest Homes
Ofce Buildings
Restaurants
Schools

2
Pre-Engineered Products
Standard System Designs
• 20” – 72” diameter
• Hardness removal capacities up to 3,000,000 grains per tank.
• Flow rates up to 780 gpm.
• PLC, electronic or electro-mechanical control options.
• Single, twin and multiple tank system designs.
HVN Softener System Designs
System Designs Single Twin Tri-Plex Four-Plex
Time Clock X X X X
Variable Reserve X X X X
Parallel, Individual Meters X X X
Demand Recall X X X
Alternating, One Meter X
Alternating, Individual Meters X X X
HVN Series Softeners

3
HVN Series Softeners
Custom Systems
Equipment Options:
• Finish painted, epoxy lined and primed, epoxy exterior
or galvanized steel vessels.
• Non-Code or ASME code vessels.
• 100 psig w.p., 125 psig w.p. or 150 psig w.p.
• Cast iron or noryl® Y-Pattern diaphragm or cast iron
buttery valves.
• Galvanized, PVC, copper, stainless steel, or black
carbon steel-face piping.
• Various metering design options.
• Skid mounting (full interconnecting piping and
pre-wired) on multiple tank systems.
• A wide variety of operational modes and control
options.
• Brine reclaim.
• Reclaim of regeneration water for re-use elsewhere.
Job Site Assistance and/or Supervision Options:
• Oversee media loading.
• Oversee installation.
• Start-up.
• Owner training.

4
Hellenbrand, Inc.
404 Moravian Valley Rd
Waunakee, WI 53597
www.hellenbrand.com Updated 1/21/09
MODEL NO. EXCHANGE CAPACITY QTY RECOMMENDED SERVICE FLOW FLOW FLOW MAX FLOW PSID MINERAL BWF BRINE MAKER DATA
HVN- MAXIMUM MINIMUM CONTINUOUS PEAK GPM GPM GPM @ MAX RATED TANK SIZE RATE SALT SIZE
grains grains cu.ft. GPM PSI-D GPM PSI-D @15 PSID @25 PSID RATED CAP FLOW inches gpm lbs max min inches
150-1 150,000 100,000 5 22 12 32 23 25 33 30 21 20 x 54 10.0 450 75 30 24 x 40
150-1 1/4 150,000 100,000 5 30 9 50 19 42 59 30 9 20 x 54 10.0 450 75 30 24 x 40
150-1 1/2 150,000 100,000 5 30 7 50 16 48 67 30 7 20 x 54 10.0 450 75 30 24 x 40
150-2 150,000 100,000 5 30 5 50 11 64 91 30 5 20 x 54 10.0 450 75 30 24 x 40
210-1 1/4 210,000 140,000 7 37 10 56 20 47 64 42 13 24 x 54 15.0 610 105 42 24 x 54
210-1 1/2 210,000 140,000 7 42 10 70 22 55 76 42 10 24 x 54 15.0 610 105 42 24 x 54
210-2 210,000 140,000 7 42 6 70 12 81 114 42 6 24 x 54 15.0 610 105 42 24 x 54
210-2 1/2 210,000 140,000 7 42 5 70 10 95 135 42 5 24 x 54 15.0 610 105 42 24 x 54
300-1 1/2 300,000 200,000 10 51 11 76 22 61 82 60 15 30 x 54 20.0 850 150 60 30 x 48
300-2 300,000 200,000 10 60 7 100 15 100 138 60 7 30 x 54 20.0 850 150 60 30 x 48
300-2 1/2 300,000 200,000 10 60 5 100 10 128 179 60 5 30 x 54 20.0 850 150 60 30 x 48
300-3 300,000 200,000 10 60 4 100 8 150 213 60 4 30 x 54 20.0 850 150 60 30 x 48
450-1 1/2 450,000 300,000 15 51 12 76 23 58 79 90 31 30 x 60 20.0 950 225 90 30 x 60
450-2 450,000 300,000 15 84 13 126 24 92 131 90 14 30 x 60 20.0 950 225 90 30 x 60
450-2 1/2 450,000 300,000 15 90 11 150 22 116 167 90 11 30 x 60 20.0 950 225 90 30 x 60
450-3 450,000 300,000 15 90 9 150 17 134 196 90 9 30 x 60 20.0 950 225 90 30 x 60
600-1 1/2 600,000 400,000 20 51 11 76 22 61 83 120 47 36 x 60 30.0 1250 300 120 39 x 48
600-2 600,000 400,000 20 84 11 126 20 104 144 120 19 36 x 60 30.0 1250 300 120 39 x 48
600-2 1/2 600,000 400,000 20 119 12 179 22 139 197 120 12 36 x 60 30.0 1250 300 120 39 x 48
600-3 600,000 400,000 20 120 9 200 18 172 249 120 9 36 x 60 30.0 1250 300 120 39 x 48
750-2 750,000 500,000 25 84 12 126 21 100 141 150 28 36 x 72 30.0 1630 375 150 39 x 60
750-2 1/2 750,000 500,000 25 119 13 179 23 132 190 150 18 36 x 72 30.0 1630 375 150 39 x 60
750-3 750,000 500,000 25 150 14 250 27 161 237 150 14 36 x 72 30.0 1630 375 150 39 x 60
900-2 900,000 600,000 30 84 10 126 19 110 151 180 33 42 x 60 45.0 1840 450 180 42 x 60
900-2 1/2 900,000 600,000 30 119 10 179 19 153 214 180 19 42 x 60 45.0 1840 450 180 42 x 60
900-3 900,000 600,000 30 180 13 277 24 199 286 180 13 42 x 60 45.0 1840 450 180 42 x 60
LBS SALT/REGEN
HVN Softener Model Specifications
Steel Tank - Diaghragm Valve Nest
HVN Softener Model Specications
Steel Tank - Diaghragm Valve Nest – 150,000 - 900,000 Grain Units
Steel Tank - Diaphragm Valve Nest
MODEL NO. EXCHANGE CAPACITY QUANTITY SERVICE FLOW RATES MINERAL IN/OUT BWF BRINE MAKER DATA SHIPPING
HVN- MAXIMUM MINIMUM OF RESIN CONTINUOUS PEAK TANK SIZE PIPE SIZE RATE SALT LBS SALT/REGEN SIZE WEIGHT
AUTOMATI
C
grains grains cu.ft. GPM PSI-D GPM PSI-D inches inches gpm lbs max min inches lbs
1200-2 1/2 1,200,000 800,000 40 150 15 200 25 48 X 72 2-1/2" 60 2200 600 240 50 X 60 5850
1200-3 1,200,000 800,000 40 215 15 303 25 48 X 72 3" 60 2200 600 240 50 X 60 5900
1200-4 1,200,000 800,000 40 310 15 445 25 48 X 72 4" 60 2200 600 240 50 X 60 6000
1500-2 1/2 1,500,000 1,000,000 50 170 15 220 25 54 X 72 2-1/2" 70 4000 700 300 60 X 64 7200
1500-3 1,500,000 1,000,000 50 225 15 307 25 54 X 72 3" 70 4000 700 300 60 X 64 7050
1500-4 1,500,000 1,000,000 50 340 15 495 25 54 X 72 4" 70 4000 700 300 60 X 64 7300
1950-2 1/2 1,950,000 1,300,000 65 170 14 220 24 60 X 72 2-1/2" 90 4800 975 390 72 X 54 8450
1950-3 1,950,000 1,300,000 65 235 15 325 25 60 X 72 3" 90 4800 975 390 72 X 54 8500
1950-4 1,950,000 1,300,000 65 445 15 650 25 60 X 72 4" 90 4800 975 390 72 X 54 8600
2400-2 1/2 2,400,000 1,600,000 80 170 13 220 23 66 X 72 2-1/2" 110 5800 1200 480 72 X 64 10450
2400-3 2,400,000 1,600,000 80 245 15 340 25 66 X 72 3" 110 5800 1200 480 72 X 64 10500
2400-4 2,400,000 1,600,000 80 480 15 690 25 66 X 72 4" 110 5800 1200 480 72 X 64 10600
2400-6 2,400,000 1,600,000 80 515 15 750 25 66 X 72 6" 110 5800 1200 480 72 X 64 10900
3000-2 1/2 3,000,000 2,000,000 100 170 12 220 22 72 X 72 2-1/2" 130 7500 1500 600 90 X54 12850
3000-3 3,000,000 2,000,000 100 255 15 355 25 72 X 72 3" 130 7500 1500 600 90 X54 12900
3000-4 3,000,000 2,000,000 100 500 15 720 25 72 X 72 4" 130 7500 1500 600 90 X54 13000
3000-6 3,000,000 2,000,000 100 540 15 780 25 72 X 72 6" 130 7500 1500 600 90 X54 13300
HVN Softener Model Specifications
HVN Softener Model Specications
Steel Tank - Diaghragm Valve Nest – 1.2 - 3 Million Grain Units
Product improvement designs are subject to change without notice.
Refer to Hellenbrand Bulletin 2050 “Flow Rates and Soft Water Quality (Hardness Leakage) if your application requires that levels of hardness leakage do not exceed “x” .
