hentech HT008C-P-T User manual

Instruction Manual for LED Underwater Light HT008C-P-T
Manufacturer: Hentech Technology Development Co., LTD
Add: Xinmin Industrial Zone, Longzhou Road, Lunjiao Town, Shunde District,
Foshan City, Guangdong Province, China 528308
Telephone: [phone]
Fax: [phone]
Website: http://www.hentech.ca
IMPORTANT: This manual includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer, as well as the user,
must read these instructions before beginning installation and start-up.
Technical Specification
Standard input voltage: 12V AC/DC (Range: 12~18VAC or DC)
Standard input watt:
RGB White
18W 23W 30W
33W 21W 26W 33W 36W
Use life: 60,000 hours
16 programs with Synchronization capability
Dimensions:

Chart of parts
The parts marked with * are not included and needs to buy separately.
The parts marked with ** are not included.
The below drawing shows how to connect the cable from the lamp to the power source.
Tips: The LED bulb is fitting to PAR56 niches and can be used to replace the PAR56. Refer to
the below picture.

Maintenance & Replacement
There is no maintenance required for this lamp ¨ it is designed to be used only once, meaning
that replacement is necessary if it becomes defective (repairing is impossible). Before any
handling, ensure that there is NO voltage supplied to the lamp. To replace, unfasten the lamp
from the bracket. Ensure the new lamp is of the same model and characteristics as the one
being replaced.
If thecable pipes you use has inner diameter 26mm or more, you can use theretrofit connector
to connect the cable easily. Simply crimp both connections with the splice connectors, slide the
cable sleeve over the connection and hand tighten the gland nuts.Then hide the retrofit
connector in the pipe. The retrofit connector is ordered separately.
Start-up
?The lamp should only operate underwater whilesecured to the vertical walls of the pool. Never
switch on the lamp if it is not underwater.
?In case of colored lamps, 16 pre-programmed effects and combinations may be selected using
the on/off switch of your pool lights. Just switch off and switch on within 2 seconds.
?If the light is powered off for more than 20 seconds, it will keep the latest program when it is
turned on again.
?To achieve synchronization, confirm all lamps are installed correctly on the same switch, after
they are powered off for more than 20 seconds, switch on and switch off continuously three
times, and then finally turn them on again. They will all go to program 5. Now you can select a
program for them by switch off and on within 8 seconds.
?Alternatively, we recommend using our optional controller (with in-built safety transformer)
which comes with (a) remote control for easy operation and (b) auxiliary connection of 24V for
operation of any other electrical item.
Safety Warnings
The persons who are in charge of installation should have the required qualifications for this type
of work.
?Avoid making contact with the electric voltage.
?Comply with the current standards regarding accident prevention.
?IEC 364-7-702 standards must be observed: WIRING IN BUILDINGS, SPECIAL WIRING,
SWIMMING POOLS.
?Replacement must be performed with the lamp disconnected from the electric power system.
?Do not handle any electrical components with wet feet.
Warranty
The manufacturer warrants this resin filled LED underwater lights against defects in materials
and workmanship for a period of three years from the date of purchase. This warranty does not
cover the fixture becoming damaged due to misuse, accidental damaged, improper handling
and/or installation and specifically excludes liability for direct, incidental or consequential
damages. Defects in materials and workmanship are exclusive of the following:
?The light with less than 400 normal LED has 3 dead LED or less.
?The light with more than 400 normal LED has 6 dead LED or less.
?The light has small air bulbs inside the resin on the front side with a size of 9 mm2or less, and
the number of the air bulbs is 3 or less.
?The light has small air bulbs inside the resin on the back side.
