hentech HT028C-T User manual

Instruction Manual for HT028C-T LED Underwater Light
Manufacturer: Hentech Technology Development Co., LTD
Add: Xinmin Industrial Zone, Longzhou Road, Lunjiao Town, Shunde District,
Foshan City, Guangdong Province, China 528308
Telephone: [phone]
Fax: [phone]
Website: http://www.hentech.ca
IMPORTANT: This manual includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer, as well as the user,
must read these instructions before beginning installation and start-up.
Technical Specification
Standard input voltage: 12V AC/DC (Range: 12~18V AC or DC)
Standard input watt:
RGB / White
6W / 7W
Use life: 60,000 hours
16 programs with Synchronization capability
Dimensions:

Packing Contents
The following items are included inside the box:
Lamp Assembly x 1
Plastic Nut x 1
Rubber Ring x 3
Instruction & Use
This is a high technology electronic controlled light based on LED¡s in three colors: red, green
and blue. These three base colors together can produce many other colors to create the perfect
atmosphere in the pool. Any of the 16 pre-programmed effects can be selected with the on/off
switch of your pool lights. The LED¡s can also be warm white only or natural white only. The
LED¡s are driven by constant current. The technology of True PWM is adopted on the lights.
High temperature protection makes the LED¡s be protected while the internal temperature
reaches a high level. All these technologies guarantee long working life of the LED lamps. The
lights must be used / operated while fully submerged underwater only.
?This lamp is designed to be fixed in new pools and/or pools with existing surface mounted
lamps that need replacement.
?This lamp is designed to be used only once. Should it become defective, repair is impossible,
and replacement is necessary.
?The manufacturer is not responsible in any circumstances for assembly, installation or start-up
of any electric components which have been inserted or handled at locations other than its
own premises.
16 Programs of RGB LED Bulbs
1. White: sun white
2. Red: one color red
3. Green: one color green
4. Blue: one color blue
5. Green-blue: fixed color green/blue
6. Red-green: fixed color red/green
7. Blue-red: fixed color blue-red
8. Evening sea: slow animation red/blue
9. Evening rivers: slow animation red/green
10. Riviera: slow animation green/blue
11. White: neutral white
12. Rainbow: slow animation blue/red/green
13. River of colors: program 12, followed by program 15
14. Disco: fast animation
15. Four seasons: slow animation in red/blue/green/violet
16. Party: fast animation
Installation
All lamps should be placed on the wall of the pool below the water surface, in areas that are
easily accessible from the upper edge of the pool.
?All lamps should be installed on the same transformer and switch.
?The lights can be installed for both concrete pools and fiberglass pools.
?The lights fit into standard 1.5¡¡wall fittings of swimming pools.
?The lamp is supplied with cable of 2m, 4m, 6m, 10m, 16m or 20m according to the need of the
user, making it possible to install multiple lamps connected to a single junction box.
The light can befixed on concrete or stone wall pools, thin wall pools, fiberglass wall pools,
metal wall pools, or wooden wall pools with liner.
It can be threaded into the 1.5¡¡female-thread wall fitting or conduit/pipe

The below drawing shows how to connect the cable from the lamp to the power source.
Maintenance & Replacement
There is no maintenance required for this lamp ¨ it is designed to be used only once, meaning
that replacement is necessary if it becomes defective (repairing is impossible). Before any
handling, ensure that there is NO voltage supplied to the lamp. The light is designed to be
replace without cutting any cable. To replace, unfasten the lamp from the wall fittings, unfasten
the nut and disconnect the wire. Then connect the wire to a new lamp and fasten the new lamp
with the nut, and then fasten the light back to the wall fittings. Ensure the new lamp is of the
same model and characteristics as the one being replaced.
Start-up
?The lamp should only operate underwater whilesecured to the vertical walls of the pool. Never
switch on the lamp if it is not underwater.
?In case of colored lamps, 16 pre-programmed effects and combinations may be selected using
the on/off switch of your pool lights. Just switch off and switch on within 2 seconds.
?If the light is powered off for more than 20 seconds, it will keep the latest program when it is
turned on again.
?To achieve synchronization, confirm all lamps are installed correctly on the same switch, after
they are powered off for more than 20 seconds, switch on and switch off continuously three
times, and then finally turn them on again. They will all go to program 5. Now you can select a
program for them by switch off and on within 8 seconds.
?Alternatively, we recommend using our optional controller (with in-built safety transformer)
which comes with (a) remote control for easy operation and (b) auxiliary connection of 24V for
operation of any other electrical item.

Safety Warnings
The persons who are in charge of installation should have the required qualifications for this type
of work.
?Avoid making contact with the electric voltage.
?Comply with the current standards regarding accident prevention.
?IEC 364-7-702 standards must be observed: WIRING IN BUILDINGS, SPECIAL WIRING,
SWIMMING POOLS.
?Replacement must be performed with the lamp disconnected from the electric power system.
?Do not handle any electrical components with wet feet.
Warranty
The manufacturer warrants this LED underwater lights against defects in materials and
workmanship for a period of one year from the date of purchase. This warranty does not cover
the fixture becoming damaged due to misuse, accidental damaged, improper handling and/or
installation and specifically excludes liability for direct, incidental or consequential damages.
