HERO Euro Lite Series User manual

Hero Medical Euro Lite Seat Walker User Manual
Hero Medical Euro Lite Seat Walker
User Manual

Hero Medical Euro Lite Seat Walker User Manual
1
No part of this user manual may be copied, distributed, reproduced, duplicated, scanned or stored whether

Independent Living Specialists Pty Ltd. Independent Living Specialists does not accept responsibility for any
changes, errors or omissions. All information is subject to change without prior notice and products may vary
from that of the actual images depicted.
Section Title Page
1Introduction 2
2 Safety & Precautions 3
3Features 4
4 4
5Instructions For Use 5
6Labelling Information 8
7 Product Care & Maintenance 9
8 Recycle & Disposal 9
9Warranty 10
Contents

Hero Medical Euro Lite Seat Walker User ManualHero Medical Euro Lite Seat Walker User Manual
Introduction
32
Weight Capacity
The maximum safety weight limit for the seat walker is 130kg and must not be exceeded.
If the maximum safety weight limit is exceeded, this can increase the risk of damage to the seat
walker and/or risk of serious injury to the user and others.
User Safety
To ensure user safety, it is highly recommended that the below safety checks are completed
prior to each use of the seat walker:
• Brakes are functional
• Castors do not show signs of wear and tear
• Backrest, seat, hand grip, storage bag and other removable parts are properly attached to
the seat walker
Note: Failure to complete the above safety checks may result in seat walker malfunction and
has the potential to cause injury to the user and others.
Exposure to Weather
Avoid exposure to hot or cold temperatures for extended periods of time, as it can cause parts
of the seat walker to become very hot or cold. This can result in an increased risk of damage to
the seat walker and/or risk of injury to the user and others.
Uneven Terrain
Operating the seat walker on uneven terrain increases the risk of the seat walker tipping over.
Only operate on even and solid surfaces.
Intended Use

please apply brakes and ensure it is on even ground.
Safety & Precautions 2
1
S322126 Seat Walker - Euro Lite Aluminium Low Hero Medical 130kg SWL
S310066 Seat Walker - Euro Lite Aluminium Standard Hero Medical 130kg SWL
S310834 Seat Walker - Euro Lite Aluminium Tall Hero Medical 130kg SWL
S322125 Seat Walker - Euro Lite Carbon Fibre (5kg Frame Weight) Low Hero Medical 130kg SWL
S310067 Seat Walker - Euro Lite Carbon Fibre (5kg Frame Weight) Standard Hero Medical 130kg SWL
S310835 Seat Walker - Euro Lite Carbon Fibre (5kg Frame Weight) Tall Hero Medical 130kg SWL

Hero Medical Euro Lite Seat Walker User ManualHero Medical Euro Lite Seat Walker User Manual
54
Instructions for Use 5
Features
3
Specications
4
Lightweight
Storage bag with carry handles
Ergonomic, height-adjustable handles
Folds easily for transportation and compact storage
Large front castors for easy maneuvering and stability
Name Aluminium
Low
Carbon
Fibre
Low
Aluminium
Standard
Carbon
Fibre
Standard
Aluminium
Tall
Carbon
Fibre Tall
SKU S322126 S322125 S310066 S310067 S310834 S310835
Frame material Aluminium Carbon
Fibre Aluminium Carbon Fibre Aluminium Carbon Fibre
Size Low Low Standard Standard Tall Tall
Frame weight 6.4kg 5.2kg 6.6kg 5.3kg 6.8kg 5.4kg
Gross weight 7.8kg 6.6kg 8kg 6.7kg 8.2kg 6.8kg
Seat height (seat to floor) 50cm 50cm 57cm 57cm 63cm 63cm
Overall height (floor to handles) 66-84cm 66-84cm 73-90cm 73-90cm 77-96cm 77-96cm
Seat width 45cm 45cm 45cm 45cm 45cm 45cm
Outer width (including rear castors) 59cm 60.5cm 59cm 60.5cm 59cm 60.5cm
Front castor size 9” 9” 9” 9” 9” 9”
Rear castor size 9” 9” 9” 9” 9” 9”
Safe work load (SWL) 130kg 130kg 130kg 130kg 130kg 130kg
Handle
Handbrake
Release Lever for Handle
Storage
Bag Clip
Rear Castor
Backrest
Seat
Safety Clip
Storage Bag
Front Castor

Hero Medical Euro Lite Seat Walker User ManualHero Medical Euro Lite Seat Walker User Manual
76
Unfolding the Seat Walker
·Unclip the safety clip located above the storage bag.
·Pull the handles apart until the frame is half open.
·Place hands flat on the top of the seat and push downwards to fully unfold the seat walker.
Adjusting the Handle Height
·Pull the white clip to unlock the handle.
·Pull or push the handles to reach
desired height.
Attaching and Removing the
Storage Bag
·Push the clips of the storage bag onto the
pole located at the front end of the seat.
·Pull the clips to remove the storage bag.
Using the Brakes
The seat walker features handbrakes with an integrated locking function to provide optimal
control and safety for the user.
·To apply the brakes when in motion, pull the handbrake lever towards the handle and
release to disengage brakes.
·To lock the brakes when the seat walker is parked, push the handbrake lever down until it
locks. To release the brakes, pull the handbrake lever towards the handle.
·To adjust the tension of the brakes, tighten or loosen the tension adjustment nut (located
at the end of the brake cable above the rear wheels). Adjusting the tensions of the brakes
ensures the safe operation of the brakes when in use.
Folding the Seat Walker
·Pull the strap located in the middle of the seat upwards to unlock the frame.
·Push both of the handles inwards to fully collapse the seat walker.
·Clip the black safety clip onto the seat frame to lock the folded seat walker in place.

Hero Medical Euro Lite Seat Walker User ManualHero Medical Euro Lite Seat Walker User Manual
98
Product Care & Maintenance
Recycle & Disposal
7
8
Labelling Information
6
• It is recommended that the seat walker is inspected every 3 months for signs of wear and
tear of the castors, seat or backrest.
• If there are visible signs of wear and tear, please contact your authorised dealer for
replacement parts.
• Please ensure the brakes are tested prior to each use.
• If exposed to water or moisture, promptly dry the seat walker to prevent corrosion of the
frame.
• 
• All replacement parts as well as after-sales support and repair services are available
through Hero Medical dealers.
Please follow the local government rules in regards to proper recycling and disposal. It should
always be done through an authorised agent or licensed place of disposal. Please review the
list of seat walker parts and packaging materials to ensure they are recycled or disposed of
correctly.
• 
• Seat & Backrest: vinyl & nylon
• Castors and handgrips: polyurethane
• Packaging: cardboard box and plastic
a. Product Label

product label includes the following information:
• Name and address of the company
• Name and code for the product
• Safe Working Load (SWL)
• Serial number of the product (which includes the date of manufacture and the batch
serial number)
b. Usage Label

usage label includes the following information:
• Overall seat walker width is 59cm
• Suitable for outdoor and indoor use
• Safe Working Load of accessories bag
is 5kg
• Overall seat walker width is 60.5cm
• Suitable for outdoor and indoor use
• Safe Working Load of accessories bag
is 5kg
Label for aluminium product variations:
S322126, S310066 & S310834
Label for carbon bre product variations:
S322125, S310067 & S310835

Hero Medical Euro Lite Seat Walker User Manual
10
Warranty
9
The Hero Medical Euro Lite seat walker comes with 12 months warranty from the date of
purchase on structural integrity.
• During the warranty period any parts that have become defective due to faulty

dealer of where the product was purchased.
• The warranty excludes castors, components and parts that are subject to reasonable wear
and tear.
• 
• 
• 
purchased should be contacted immediately.

Independent Living Specialists
Unit 1, 12 Mars Road
Lane Cove West NSW 2066
1300 008 267 | ilsau.com.au
©2023 HERO MEDICAL. INDEPENDENT LIVING SPECIALISTS

