HERO GLAMOUR PROGRAMMED FI User manual

PREFACE
Thank you for selecting a Hero MotoCorp GLAMOUR PROGRAMMED FI. We wish
you many miles of continued riding pleasure in the years ahead.
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve
environment compatibility, comply with all applicable legislation including environment
legislation and strengthen the green supply chain.
Your motorcycle is conforming to latest (Bharat stage-III norms) regulation for emission,
safety & noise levels. We are also using non asbestos brake shoes / pads and engine
gaskets which are environment friendly in nature.
This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp GLAMOUR PROGRAMMED FI. Please take time to read it
carefully. As with any fine machine, proper care and maintenance are essential for
trouble-free operation and optimum performance.
Let us make this world a safer, healthier and more environment friendly place.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.

NOTE
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION
AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE
ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR
GUARANTEED. Hero MotoCorp Ltd. RESERVES THE RIGHT TO MAKE
CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR
INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO
REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING
PRIOR WRITTEN PERMISSION FROM HeroMotoCorpLtd.

RIDING 24
PARKING / ANTI-THEFT TIPS 26
BRAKING 25
PRODUCT SPECIFICATION 2
SAFE RIDING TIPS 4
TIPS FOR HEALTHY ENVIRONMENT 6
DESCRIPTION 7
• INSTRUMENTS & INDICATORS 10
MOTORCYCLE IDENTIFICATION 1
• IGNITION SWITCH 12
• FUEL GAUGE 13
PARTS FUNCTION 10
ACCESSORIES & MODIFICATION 5
• REALTIME MILEAGE INDICATOR (RTMI) 13
• LEFT HANDLEBAR CONTROLS 14
• HELMET HANGER 16
TYRES 20
ENGINE OIL 18
ENGINE OIL TOP UP PROCESS 18
ENGINE OIL REPLACEMENT PROCESS 19
• FUEL TANK 17
• SEAT LOCK 16
• RIGHT HANDLEBAR CONTROLS 15
• STEERING LOCK 16
PRE-RIDE INSPECTION 22
STARTING THE ENGINE 23
• HEADLAMP ADJUSTMENT 49
• WASHING THE MOTORCYCLE 53
UTILITY BOX / TOOL KIT 27
• SAFETY PRECAUTION 29
• OIL SCREEN FILTER/CENTRIFUGAL FILTER 32
• THROTTLE OPERATION 36
• VALVE CLEARANCE 36
• CLUTCH 38
• REAR BRAKE 45
• BATTERY 46
• FRONT WHEEL REMOVAL 50
• REAR WHEEL REMOVAL 52
• MAINTENANCE SCHEDULE 30
• DRIVE CHAIN 40
• SPARK PLUG 33
• FRONT BRAKE 42
FIRST AID KIT 28
MAINTENANCE 28
• AIR CLEANER 34
• STOP LAMP SWITCH 48
• SUSPENSION 49
BASIC TROUBLESHOOTING 55
ROAD SIGNS 59
HERO GENUINE PARTS
• CATALYTIC CONVERTER 53
• AIR SUCTION VALVE 54
WARRANTY DETAILS

Model VIN Engine
Glamour Programmed FI
(Electric Start/Disc/Cast Wheel)
AP
EL
MBLXXXXAPYZXYYYYY
MBL
Manufacturer
Code
XXXXAP
Vehicle
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
XXXXEL
Engine
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
XXXXELYZXYYYYY
MBLXXXXAPYZXYYYYY
XXXXELY
ZXYYYYY
Model Code.:
MOTORCYCLE IDENTIFICATION
Vehicle Identification Number (VIN)
VIN
VIN

129 kg
12 litres (minimum)
2005 mm
1070 mm
1500 + 100 r/min
In:0.05 mm Ex:0.05 mm
0.95 litre at disassembly
0.75 litre at draining
Saddle Height 790 mm
157 ml
kW
124.8 cc
ITEM SPECIFICATIONS
PRODUCT SPECIFICATION
Maximum Power
Maximum Torque 10.35 N-m @ 4000 r/min
(cold condition)

20A, 15A, 10A
Electric Start
(Amber bulb) with clear lens -MFR*
140 W @ 5000 r/min
Headlamp (High/Low)
Tail/Stop Lamp
Turn signal Lamp
Meter Illumination
Neutral Indicator
Turn Signal Indicator
Position Lamp
Hi Beam Indicator
Programmed-FI Malfunction Indicator Lamp
3.350 (67/20)
3.071 (43/14)
2.769 (36/13)
1.500 (30/20)
1.095 (23/21)
0.913 (21/23)
ITEM SPECIFICATIONS
Telescopic Hydraulic Shock Absorber
Rectangular Swingarm with 5 step
Adjustable Hydraulic Shock Absorber
Front Suspension
Rear Suspension
Front
Rear
12 V 21/5 W - MFR*
LED
LED
12V 5.0W
LED
CHASSIS AND SUSPENSION
POWER TRANSMISSION
ELECTRICAL
LED
12V 1.12W
Dia 240 mm (Optional)
**MF Battery, MF-4:12V 3 Ah
**MF stands for Maintenance Free
*MFR Stands for Multi-Focal Reflector

3. While riding, sit in a comfortable posi-
tion with your legs close to fuel tank.
10. Take care of loose / hanging clothes
while solo / pillion riding.
1. Always conduct simple pre-ride
inspection (ref. page no 22).
11. Get your motorcycle serviced regularly
by the Authorised Hero MotoCorp
Workshop.
2. Always wear a helmet (ISI marked)
with chinstrap securely fastened and
insist on a helmet for your pillion rider.
5. For stopping motorcycle, use both
brakes simultaneously, keeping throttle
in the close position.
7. During night time, dip headlamps of
your motorcycle for oncoming traffic,
or when following another vehicle.
8. Give way to others on the road and sig-
nal before you make a turn.
Do's:
9. To make yourself more visible, wear
bright reflective clothing that fits well.
4. Ride defensively and at a steady speed
(between 40-50 km/hr).
6. Respect road signs and obey traffic
rules for your own safety and that of
others on the road (ref. page no. 59-60).
motorcycle.
SAFE RIDING TIPS
4. Never touch any part of the hot exhaust
system like muffler.

Modifying your motorcycle or using non-
Hero MotoCorp accessories can make
your motorcycle unsafe. Before you
consider making any modifications or
adding an accessory, be sure to read the
following information.
Follow all instructions in this owner's
manual regarding accessories and
modifications.
Improper accessories or modifications
can cause a crash in which you can be
seriously hurt or killed.
• Make sure that the accessory does not
obscure any lamps, reduce ground
clearance, limit suspension travel or
steering travel, affect your riding
position or interfere with operating any
controls.
• Be sure electrical equipment does not
exceed the motorcycle's electrical
system capacity (page-3). A blown
fuse can cause a loss of lights.
Modifications
We strongly advise you not to remove
any original equipment or modify your
motorcycle in any way that would
change its design or operation. Such
changes could seriously impair your
motorcycle's handling, stability and
braking, making it unsafe to ride.
• Do not pull a trailer or sidecar with
your motorcycle. This motorcycle was
not designed for these attachments,
and their use can seriously impair your
motorcycle's handling.
Removing or modifying your lamps,
mufflers, emission control system or
other equipment can also make your
motorcycle illegal.
Accessories
ACCESSORIES & MODIFICATIONS

Regular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp
workshop, as per the service schedule, for an optimum performance and keep the
emission level under check.
Genuine Engine Oil: Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine oil
recommended by Hero MotoCorp and make sure you change it every 6000 kms.
(with top up every 3000 kilometres) to keep the engine fit and environment healthy.
The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.
Genuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or
incompatible spares and accessories can upset or deteriorate your motorcycle’s
running condition.
Noise Pollution : Noise beyond a certain decibel is pollution. Whether it is from
horns or defective mufflers, excessive noise will cause headaches and discomfort.
Emission Pollution : Get emission of your motorcycle checked by Authorised
agencies atleast once every 3 months or as notified by the government from time to
time.
Fuel Saving & Reduce Pollution : Switch "OFF" the engine while waiting at traffic
signal points to save fuel and reduce pollution, if the waiting period is long.
6
Healthy Engine: The engine is the lifeline of every vehicle. To keep it healthy, it
should be tuned regularly, which will also help reduce pollution and improve vehicle
performance & fuel efficiency.
TIPS FOR HEALTHY ENVIRONMENT

(8) Neutral indicator
(9) Turn signal indicator
(1) High beam indicator
PARTS LOCATION
(2) Horn switch
(4) Headlamp switch
Indicator Lamp
(6) Pass lamp switch
(7) Headlamp dimmer switch
(3) Turn signal switch
(5) Rear view mirror
(10) Programmed FI Malfunction (20) Leg guard
(19) Fuel tank cap
(13) Tripmeter knob
(15) Front brake lever
(16) Throttle grip
(17) Electric starter switch
(11) Speedometer
(12) LCD panel
(14) Master cylinder
(18) Ignition switch with steering lock
DESCRIPTION
*Accessories and features shown may not be part of standard fitment.
5
15
12 14
2
3
4
6810 11 13
1
16
17
18
19
20
79

12 4 578 9 11
Fuel injector
(13) Rear reflex reflector
(14) Tail / Stop lamp
(15) Rear grip
(17) Front reflex reflector
(12) Rear turn signal lamp
(16) Clutch lever
17
Starter motor
10
15
13
LEFT SIDE VIEW
6
*Accessories and features shown may not be part of standard fitment.
3
12
14
16

14
RIGHT SIDE VIEW
(3) Kick starter pedal
(5) Oil level window
(1) Pillion foot rest
(4) Rider foot rest
(2) Battery compartment
(Inside) (8) Throttle body (Inside)
(10) Utility box
(9) Air suction valve
(6) Brake pedal
(7) Oil filler cap
(11) Caliper assembly
(12) Front brake disc
(13) Front turn signal lamp
(16) Exhaust muffler
(15) Visor
(14) Headlamp
13
15
*Accessories and features shown may not be part of standard fitment.
346710 11
598
212 1
16

2 Hi beam indicator Light glows when headlamp is in Hi beam.
Sl. No. Description Function
Button when pressed switches display between
1 Mode / reset button tripmeter and odometer. When tripmeter is
selected & button is long pressed it resets the
tripmeter to zero.
When the ignition switch is turned "ON" the
3 Programmed-FI
Programmed-FI Malfunction Indicator Lamp
glows for few seconds and then should go "OFF".
It indicates that Programmed FI system is OK.
If it "flashes", or remains "ON" there is an
abnormality in the Programmed FI, it is recommended
to reduce the speed and drive to the Authorised
Hero MotoCorp workshop for check-up.
headlamp.
58
6
2
4
1
7
9
10
PARTS FUNCTIONS
INSTRUMENTS AND INDICATORS
Malfunction Indicator Lamp
3

Sl. No. Description Function
8 Digital fuel gauge Indicates approximate fuel available.
9 Odometer Shows accumulated distance traveled.
10 Tripmeter Shows the distance traveled during a trip.
4 Neutral indicator Light glows when vehicle is in neutral.
Indicates the turn signal lamp operation to
6 Turn signal indicator the rider.
It indicates the current mileage of the
7 Real Time Mileage Indicator
5 Speedometer Indicates driving speed.
motorcycle (in km / litre). The indication
(RTMI) will change after every 10 seconds
depending upon the driving condition.
(page-13).

illuminates for few seconds.
The engine can be started. Turn signal
lamps, Horn, Tail / Stop lamp and Pass
lamp can be operated. Fuel gauge
indicates fuel level. Programmed FI
Malfunction Indicator Lamp
functional.
Engine cannot be started and
no electrical system will be
Key can be removed.
“ON”
“OFF”
“LOCK” Steering can be locked.
1
2
3
“OFF” Position /
Lock Open
“LOCK” Position
“ON” Position
IGNITION SWITCH

13
(1) Fuel gauge (2) Segments
FUEL GAUGE
The fuel gauge (1) is liquid crystal display
type. The approximate amount of fuel
quantity available in the fuel tank is
indicated by the number of segments in
the display. if all the segments (2) are
displayed it means fuel quantity in the
fuel tank is 12 litres.
If only one segment (3) is displayed and blinks,
this indicates that the fuel quantity is low and the
fuel tank should be refilled as soon as possible.
3
(3) Segment
12
Real Time Mileage Indicator (RTMI)
The Real Time Mileage Indicator (1) shows the
current mileage of the motorcycle in km / litre and
is refreshed after every 10 seconds.
When the ignition switch is turned ON, the Real
Time Mileage Indicator will temporarily show
the digit " " which indicates that all the
digital LCD segments are working. The display
range is from (km/litre).
1
(1) Real time mileage indicator
The RTMI shows a minimum value of
km/litre and maximum value of
km/litre. During coasting with throttle
fully closed, the fuel consumption
The fuel consumption shall be displayed
when the speed of the vehicle is 5 + 2
km/hr. If the speed is less then 5 + 2 km/hr
"_ _,_" shall be displayed.

2
3
1. Pass lamp switch
2. Headlamp switch
Position lamp
Tail / Stop lamp
Fuel indicator display
Meter illumination
Headlamp “ON”
marked by white dot.
LEFT HANDLEBAR CONTROLS
14
is very minimal and hence the display can
go up to km /litre.
ODOMETER
The Odometer (4) shows accumulated
distance traveled.
The Tripmeter / Odometer can be selected
by pressing the MODE / RESET button
alternately.
TRIPMETER
The Tripmeter (2) shows distance traveled
per trip. The Tripmeter can be reset to zero
by pressing the MODE / RESET button (3)
for more than 2 seconds.
NOTE :
(2) Tripmeter (3) MODE/RESET button
(4) Odometer
24
3
16

1
(1) Starter switch
6. Clutch switch
be started by electric start switch until the
1. Starter switch
the vehicle is in neutral. If the vehicle
Shift the turn signal switch sideways for
right / left indications and leave it to come
back to its normal position on its own.
5
4
3. Dimmer switch
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently
push the knob inside.
4. Turn signal lamp switch
15
5.
RIGHT HANDLEBAR CONTROLS

Steering lock is with Ignition switch, put
the ignition key (2) to “OFF” position &
turn the handle bar towards left or right &
push the key downwards & turn towards
“LOCK” position.
After locking take out the ignition key.
STEERING LOCK
(2) Ignition key
2
2
Location : On the rear left side of the seat,
below rear cowl.
SEAT LOCK
16
Operation : Insert the key (1) and turn it
clockwise. Pull the knob (2) downward to
release the seat. To install, engage the lug
on the underside of the seat with the frame
and press on the top rear side of the seat
until the lock clicks.
HELMET HANGER
The helmet can be hung and locked on the
helmet hanger (3) provided with the seat
lock by rotating the key.
(1) Key (2) Knob (3) Helmet hanger
3
1
2
Never hold starter switch continuously for
more than 5 seconds as continuous
cranking of engine will drain the battery.

(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
17
Fuel tank capacity is 12 litres (minimum).
2. Do not overfill the tank. There should
be no fuel (4) in filler neck (5).
3. To lock - Position the cap back on the
opening with the arrow mark "D" on the
cap facing towards the front of the
motorcycle then press gently. The key
springs back to the normal position and
cap gets locked.
1. To unlock fuel tank cap (1) - Lift the
key hole cover (2), insert ignition key
(3) turn it clockwise and remove the
cap.
Do not park the motorcycle under direct
sunlight as it causes evaporation of petrol
due to heat and deterioration of paint gloss
due to ultra violet rays.
4
(4) Fuel
(5) Filler neck
5
3
2
1
