HERON dipperLog SMART User manual

www.heroninstruments.com
Made in Canada
HERON INSTRUMENTS INC.
447 Moxley Road, Dundas, ON L9H 5 2 CANADA
1-800-331-2032 or 905-628-4999
[email protected]
Please visit our website www.heroninstruments.com
for more information on the complete Heron product line.
HERON ALSO MANUFACTURES:
• Water Level Meters
• Data Loggers
• Interface Meters
• Conductivity Meters
• Temperature Meters
• Well Casing Indicators
• Well Depth Indicators
• Tag Lines
• Downhole Inspection Cameras
dipperLog SMART
Remote Monitoring System
Quick Start Guide
Oper ting nd M inten nce Instructions Inside
SPIDERMESH
Connect the Gateway
to a power outlet
SpiderMesh Cooperative
Mesh Network
Sensor/Probe
tt ch to
Node
Sensor/Probe
tt ch to
Node
Gateway GATEWAYGATEWAY
Sensor/Probe
tt ch to
Node
Sensor/Probe
tt ch to
Node
Sensor/Probe
tt ch to
Node
ptional
Web App
Cloud
Connect to the internet to
enable remote monitoring
(optional)
Android device
Figure 1: Typical System Deployment
P ge 1

Prep ring the dipperLog SMART System
The dipperLog SMART is a turnkey monitoring system for viewing and recording
the remote data on any computer, tablet or smartphone from anywhere.
In the starter kit, you will nd:
1. A Sensor, either water depth & temperature or water detection connected via
a downhole cable.
2. A Node dedicated to each sensor.
3. A G tew y to collect the data.
4. An Android T blet with the dipperLog SMART App already installed. In most
cases, the following steps can be skipped if the tablet has been previously
congured.
Inst ll tion Wiz rd
Starting with a fresh install of the dipperLog SMART App (not n upd te nor
precongured t blet), the Installation Wizard will automatically launch when the
App starts. You can skip the Wizard anytime, except at the end, when the nish
button has already been pressed. This step will utom tic lly be skipped if your
t blet w s precongured.
If you skip the Wizard, it will automatically re-launch at the next App restart, and
will continue to do so as long as there is no G tew y registered in the App. nce
a master component is registered in the database (a G tew y), then the Wizard
can only be launched manually through the CFG tab, under Installation Wizard.
Note that you will need to be connected to an internet network for the Wizard to
congure and download your maps properly.
Inst ll tion Wiz rd - Step 1 - N me Device
Name your device (your Android device) so that you can recognize it easily in the
future when you have more Android devices.
Inst ll tion Wiz rd - Step 2 - Enter Your Address
Enter your address (the location of the system installation). For Canadian systems,
the 3 rst digits of the postal code, and for American systems it could be a zip
code. Then tap on Se rch Address. The address found will be used as the center
location of the maps that will be downloaded. It is important to enter the correct
location, or the maps downloaded won’t be relevant (only maps surrounding your
area will be saved to your device).
Inst ll tion Wiz rd - Step 3 - Remote Use
Next, you’ll be asked whether you wish to use the system locally only or locally and
remotely (i.e. use the system outside of the network, to view your system at home,
at work or anywhere in the world). If you select Yes, then the Wizard will guide
you through some extra steps to congure the remote access.
Inst ll tion Wiz rd - Step 4- Congure Google Account
For remote use, the Wizard will prompt you to congure a Google Account (either
choose an existing one or create a new one). Most of our services use Google
services (such as Google Drive) to store your private data.
Unboxing
Step 1: Connect the G tew y to a power outlet and turn it on by pressing the
ON/OFF button. Look at the L D ashing. The G tew y is ready
once it starts blinking at a regular pace. The dipperLog SMART System
is sending/receiving data when the L D blinks.
Step 2: pen your tablet. Look for the dipperLog SMART App icon
either on the main screen or by clicking on Applications. pen the
dipperLog SMART App.
Step 3: After the main splash screen, you will either enter into the App or be
presented with an installation Wizard. If you are not comfortable setting
up the system manually, then follow through the steps of the Wizard to get
your system operational.
dipperLog SMART Remote Monitoring System Quick St rt Guide
Inst ll tion Wiz rd - Step 5- Congure Al rms
Next, you can customize the basic alarm settings. You can disable/enable:
- Sound alarms on errors and warnings (you will be able to set the error
limits on each sensor later on)
- Turn on Text-to-Speech to get warnings and errors even when not
looking at the system
Inst ll tion Wiz rd - Step 6 - Congure Units
Next, you can customize the units that will be used throughout the App. You can
choose either Metric or Imperi l units or tap on Customize Units to choose the
right unit for each of your measurements.
Metric units: distance in meters, height in cm, temperature in °C, positive
pressure in bar, negative pressure or vacuum in inches Hg, volume in L, ow in
gpm (UK gallons)
Imperi l units: distance in feet, height in inches, temperature in °F, positive
pressure in psi, negative pressure or vacuum in inches Hg, volume in gal (US),
ow in gpm (US gallons)
Inst ll tion Wiz rd - Step 7 - Choose Applic tion
Next, you will be prompted to select the main use of the dipperLog SMART system.
Choose general application if you are unsure.
Inst ll tion Wiz rd - Step 8 - Re der or Writer
Then, you will be asked to choose how the App will gather data from the
dipperLog SMART system:
1) by pairing with a G tew y (choose this if this is your rst installation)
2) if you answered yes at Step #3 (you are going to use the system remotely),
by reading data from the cloud
Inst ll tion Wiz rd - Step 9 - Inst ll G tew y
Now it’s time to install the device that you have chosen in Step #8. Tap on scan if
applicable to scan the barcode of your G tew y. Then, name your gateway
device. The next two steps will congure the G tew y settings (if applicable)
depending on the conguration of your network size and estimated coverage.
Inst ll tion Wiz rd - Step 10 - Dene System
Enter the distance of the farthest Node from the G tew y (from your main
location). In other words, what will be the radius of your dipperLog SMART
network if the center is at the G tew y.
Inst ll tion Wiz rd - Step 11 - Congure Perform nce
Choose how you would like to optimize the system:
1) B tttery S ver (low data-rate). You should choose this option if you do not
currently need very high data rate to save your battery life. When saving
battery life, the system will respond slower than with the high performance
option. You will still get frequent readings, but not once every second.
2) High perform nce (high data-rate). You can choose this option if you are
currently monitoring a critical operation. The system will respond very fast and
consume more battery life.
You can choose to run on the B ttery S ver mode all the time. You should still have
plenty of data. nce the Wizard is over, you can still change these options
manually without having to re-run the Wizard. To do so, go to the Node tab in the
dipperLog SMART App. Tap on your activated G tew y. Change the duty cycle
from 5% (battery saving mode) to any higher value (e.g. 10%, 15%, 20%...).
Inst ll tion Wiz rd - Step 12 - Choose Theme
Choose the look of your App. For the best experience, select Modern theme.
Inst ll tion Wiz rd - Fin l Step - Finish
You can now commit your preferences and click on Finish, or you can cancel by
pressing Skip (no changes will be made). Wait while your preferences are applied.
The Wizard will also take care of downloading the satellite map for you. nce
completed, the App will restart and you should be ready to start adding sensors to
your network.
P ge 2

Inst lling Nodes in the Field
Step 1: Turn on the Node by pressing the Power Button. The Network LED
indicator will start blinking. The rst sequence of blinks represents the
Ch nnel that the Node is currently set on (e.g. 3 blinks = Channel # 3).
After the startup sequence, the Power LED light will start blinking at the
same rate as your G tew y once it is connected (after a few seconds to a
few minutes). The Network LED will blink 3 times every 8 seconds while it
is searching for the network (It is not connected yet!)
Step 2: Install the Nodes starting from the nearest ones (from the G tew y). Go to
the exact location where the Node will be installed with your tablet.
Step 3: If the LED on the Power Button of the Node is still blinking steadily, then
you can install your dipperLog SMART Node at that location (the blinking
LED indicates a connection to the network). If the Network LED is blinking,
then you are out of the network. Install other Nodes or a Repe ter
between. Since the Nodes are relaying messages to the G tew y,
installing other Nodes rst might increase the network’s coverage.
In the dipperLog SMART App (on the t blet):
1. Go to the Nodes t b, swipe left to right or right to left to view the Node
list (G tew y,Repe ter,Depth & Temper ture, etc.) If your tablet was
precongured, then all unused Node types might be hidden. You can unhide
them by going to the CFG. tab, tap on Select Active Nodes and check all
Node types that you wish to show.
2. Tap on the Menu Button of the Android device and tap on Add Node.
The Menu Button varies depending on the Android device and can be
toggled by clicking or long clicking any of the following buttons (or any
other)
dipperLog SMART Remote Monitoring System Quick St rt Guide
3. Tap on Add New Node (see picture on below)
4. In the Menu, click on the Sc n B rcode button
5. Scan the barcode on the Node, turning on the ashlight if needed
6. Tap the N me eld and name the Node. Tap the Ok button.
7. The Node has now been installed and the sensor's icon should appear in the
sensors list (Nodes tab) and on the M p tab as well.
8. Repeat steps 1-7 for all Nodes to be added to the network, always using
the same Android device (tablet) to add/remove Nodes.
9. You will start getting your readings once you return to your G tew y (until
the tablet can communicate with the G tew y via a Bluetooth connection)
Your system should now be up and running. If the Node’s page headers (including
the G tew y header) are greyed out then your tablet has not been paired with the
G tew y. To pair, click and hold on the G tew y’s name. In the menu, scroll down
and tap on Activate. The App will restart, this time with a Bluetooth connection with
the G tew y. After a few seconds, the sensors lists will change color and you
will start receiving data. If the G tew y stays red, make sure the Bluetooth is
activated on the Android device and that it is in Bluetooth range of the G tew y.
See Figure 3 to Ensure Correct Setup
B rcode
Power LED
Network LED
Network Button
Power Button
Figure 2: Node Buttons & Features
Figure 3: (a) G tew y is not connected to the
T blet and Nodes lists are greyed out
Figure 3: (b) G tew y is connected to the tablet
and Nodes lists are coloured
Data is stored locally in the Android smartphone/tablet. You can view the logged
history by tapping on the Node(s) of interest and click on the gr ph button.
If you have enabled remote use in the Installation Wizard, then you should see a
Google Drive Downloading message appear at the bottom of the screen from time
to time. nce the message change to Google Drive K, then your remote access is
ready to be viewed online. pen a Chrome browser on any computer/
tablet/smartphone that has access to the internet. Then go to:
https://dipperlogsm rt.com/Web24_gener l/#/home
Click on the user icon and log into the same Google Account as congured on the
dipperLog SMART System. In the menu, click on My Nodes -List by Type to view
your system.
P ge 3
