Operating instructions
Angle safety valve
Type 06810/06815/06820/06850/06855

Operating instructions
2
Phone [phone]
READ CAREFULLY BEFORE USE! RETAIN FOR FUTURE REFERENCE!
© 2018 HEROSE GMBH
ARMATUREN UND METALLE
Elly-Heuss-Knapp-Straße 12
23843 Bad Oldesloe
Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Web: www.herose.com
1st issue 08/2018
The transmission or duplication of this document and the reuse or communication of its
content are forbidden unless expressly permitted. Any violations shall result in liability for
damages. All rights in the event of patent, utility model or registered design are
reserved.

Operating instructions
herose.com
3
Table of contents
1About these instructions................................................................................................ 4
2Safety ........................................................................................................................... 4
3Transport and storage................................................................................................... 7
4Description of the safety valve ...................................................................................... 7
5Assembly .................................................................................................................... 10
6Operation.................................................................................................................... 11
7Maintenance ............................................................................................................... 12
8Disassembly and disposal........................................................................................... 14

Operating instructions
4
Phone [phone]
1 About these instructions
1.1 Principles
The operating instructions are part of the safety valve named on the front page.
1.2 Applicable documents
Document
Contents
Catalogue page
Description of the safety valve
Refer to the manufacturer's documentation for accessories.
1.3 Hazard levels
The warning notes are marked and classified according to the following hazard levels:
Symbol
Explanation
DANGER
Identifies a hazard with a high risk level that will result in
death or serious injury.
WARNING
Identifies a hazard with a moderate risk level that will result
in death or serious injury.
CAUTION
Identifies a hazard with a low risk level that will result in a
minor or moderate injury.
NOTICE
Identifies a risk to property. Damage to property may occur if
this note is ignored.
2 Safety
2.1 Intended use
The safety valve protects the tank and pipeline systems against impermissible overpressure. The
permissible operating conditions are specified in these operating instructions.
The safety valve is suitable for the media listed in these operating instructions, see section 4.5 "Media".
Operating conditions and applications deviating from these require the approval of the manufacturer.
Only media may be employed to which the materials used for the valve body and seals are resistant.
Contaminated media or usage outside of the pressure and temperature specifications can lead to damage
to the valve body and seals.
Avoidance of foreseeable incorrect use
Never exceed the permissible usage limits specified in the data sheet or in the documentation
with regard to pressure, temperature, etc.
Follow all safety instructions and operating procedures in these operating instructions.
Warranty claims against HEROSE GMBH will be rejected if the HEROSE seal is broken by
unauthorised companies.
2.2 Meaning of the operating instructions
The operating instructions are to be read and followed by the responsible technical personnel before
installation and start-up. As part of the valve the operating instructions must be available close to it.
People could be seriously injured or killed if the operating instructions are not followed.
Read and observe the operating instructions before using the safety valve.
Retain the operating instructions and make sure they are available.
Pass on the operating instructions to subsequent users.

Operating instructions
herose.com
5
2.3 Requirements for persons who work with the safety valve
Persons could be seriously injured or killed if the safety valve is used improperly. In order to avoid
accidents, all persons who work with the safety valve must meet the following minimum requirements.
They must be physically able to control the safety valve.
They are able to safely carry out the work with the safety valve within the scope of these operating
instructions.
They understand how the safety valve works within the scope of their work and can recognise and
avoid the hazards associated with the work.
They have understood the operating instructions and are able to implement the information of the
operating instructions accordingly.
2.4 Personal protective equipment
Missing or unsuitable personal protective equipment increases the risk of damage to health and injuries to
people.
The following protective equipment is to be provided and worn during work:
Protective clothing
Safety shoes
Set out and use additional protective equipment depending on the utilisation and the media:
Safety gloves
Eye protection
Ear protection
Wear the specified personal protective equipment for all work on the safety valve.
2.5 Additional equipment and spare parts
Additional equipment and spare parts not conforming to the manufacturer's requirements can negatively
affect the operational safety of the safety valve and cause accidents.
In order to ensure operational safety, use original parts or parts that conform to the
manufacturer's requirements. If in doubt, have these confirmed by the dealer or manufacturer.
2.6 Adhere to the technical thresholds
If the technical thresholds for the safety valve are not adhered to, the safety valve may sustain damage,
accidents may be caused and people may be seriously injured or killed. Adhere to the thresholds.
See chapter 4 "Description of the safety valve".
2.7 Safety instructions
DANGER
Hazardous medium.
Escaping operating medium can lead to poisoning, burns and caustic burns!
Wear the prescribed protective equipment.
Provide suitable collecting containers.
Stand to the side of or behind the valve during lifting (manual actuation for test purposes).
The outlet must be free.
Flammable media and dusts
Risk of sustaining burns!
Avoid potential sources of ignition in the immediate vicinity of the safety valve.
Attach warning signs.
Risk of injury due to pressure.
Injury due to the valve being flung away!
Depressurise and empty all supply pipes before dismounting the valve.
Make sure that the system is depressurised.
Secure against being pressurised again.
Do not bend over the valve when dismounting.

Operating instructions
6
Phone [phone]
WARNING
Harmful and/or hot/cold conveyed media, lubricants and fuels
Hazardous for persons and the environment!
Collect and dispose of rinsing medium and any residual media.
Wear protective clothing and a protective mask.
Observe legal regulations regarding the disposal of harmful media.
CAUTION
Cold/hot pipelines and/or safety valves.
Risk of injury due to thermal influences!
Insulate the valves.
Attach warning signs.
Medium escaping at high speed and high/low temperature.
Risk of injury!
Wear the prescribed protective equipment
Secure the discharge area
NOTICE
Impermissible stresses arising from operating conditions and extensions / added structures.
Safety valve body leaking or broken!
Provide suitable support.
Additional loads, such as traffic, wind or earthquakes, are not explicitly taken into account by
default and require separate dimensioning.
Condensation in air conditioning, cooling and refrigeration plants.
Icing!
Blocking of the actuation mechanism!
Damage due to corrosion!
Insulate the safety valve diffusion-tight
Improper installation.
Damage to the safety valve!
Remove cover caps before installation.
Clean the sealing surfaces.
Protect the body against impacts.
Painting of safety valves and pipelines.
Impairment of the function of the safety valve / loss of information!
Protect plastic parts and type plates from being painted over.
Protect inlet and outlet when applying paint.
Exceeding the maximum permissible operating conditions.
Damage to the safety valve!
The maximum permissible operating pressure of the safety valve must not be exceeded, and the
minimum and maximum permissible operating temperatures must not be undershot or exceeded.

Operating instructions
herose.com
7
3 Transport and storage
3.1 Inspection of condition on delivery
Inspect the safety valve for damage upon receipt.
In case of transport damage, determine and document the precise extent of the damage, and
report it immediately to the supplying dealer/carrier and the insurer.
3.2 Transportation
Transport the safety valve in the packaging supplied.
The safety valve is delivered in a ready-to-operate state with the connections protected by caps.
Protect the safety valve against shocks, impacts, vibrations and dirt.
Adhere to a transport temperature range of -20 °C to +65 °C.
3.3 Storage
Store the safety valve in a clean and dry place.
Make use of a desiccant or heating in damp storerooms to prevent the formation of
condensation.
Adhere to a storage temperature range of -20 °C to +65 °C.
4 Description of the safety valve
See catalogue page
4.1 Structure
Design
Directly acting angle safety valve, spring-loaded
4.2 Marking
The safety valve is equipped with a marking for identification.
Layout of the type plate
Explanation
Type
06810/ 06815/ 06820/ 06850/ 06855
TAG-no.
Specified by the customer
Ser.-no
Serial number
Date
MM.YY, month and year of manufacture
TÜV SV
Component identification number
S/G
Coefficient of discharge for vapours (S) and gases (G)
L
Coefficient of discharge for liquids (L)
p0
Opening pressure
d0
Narrowest flow diameter in mm
A0
Narrowest flow cross-section in mm²
cap
Capacity of the valve
Lift
Valve lift
Temp
Temperature range min/max
pset
Setting pressure
O2
Mark indicating suitability for use with oxygen
0045
CE-mark, ID of notified body
herose.com Type: 06810 TAG-no.: O2
Ser.-no: 00000002 Date: 11.13 TüV SV
12-1130
S/G 0,50 cap.: 627 m³/h po:10 % d0:10mm
L 0,50 cap.: 9377 kg/h Lift: 3mm A0: 78,5mm²
Temp.: -270°C to 400°C pset:
20,00 bar
0045 EN ISO 4126-1

Operating instructions
8
Phone [phone]
4.3 Mode of operation
Safety valves protect tanks and pipeline systems against impermissible overpressure. Safety valves
represent the last line of safety for a tank or pipeline system. They should be capable of preventing
impermissible overpressure when all other upstream regulating, control and monitoring devices have
failed. In order to ensure this operability, safety valves require special attention during their assembly and
maintenance.
A safety valve is a piece of equipment with a safety function for protecting pressure equipment when the
permissible limits are exceeded and is thus subject to Directive 2014/68/EU (Pressure equipment
directive) of the European Parliament and of the Council, article 2, section 4.
4.4 Operating data
Type
d0
[mm]
Pressure
range**
[bar]
Max. back
pressure
[%]
Temperature
[°C]
Medium
0681x
6
30 to 550
10
-270 to +400
See section
4.5 "Media"
10
0.5 to 180
15
06820
6
30 to 550
10
0685x
10
0.5 to 250
15
14
0.2 to 200
18
0.5 to 110
**When the valve disc is implemented with a sealing plate, the sealing plate material (soft
material seal) must be considered in relation to the pressure and temperature (see details on
the technical data sheet). Further details are to be taken from the VdTÜV bulletin.
4.5 Media
Gases, cryogenic liquefied gases and their gas mixtures, such as:
Name
Argon,
Nitrous oxide,
Ethane,
Ethylene,
Helium,
Carbon dioxide,
Krypton,
LNG,
LPG,
Air,
Methane,
Neon,
Oxygen,
Nitrogen,
Trifluoromethane,
Hydrogen,
Xenon,

Operating instructions
herose.com
9
4.6 Materials
Part
no.
Name
Material
1
Cap, lifting cap
1.4408; 1.4404
2
Spindle
1.4404
3
Spring cover
1.4408; 1.4404
4
Spring
1.4571
5
Body
1.4408; 1.4404
6
Closing body
1.4571;NBR;FKM;VESPEL
7
Seat insert
1.4571
4.7 Scope of delivery
Safety valve
Operating instructions
4.8 Dimensions and weights
See catalogue page
4.9 Lifetime
The user is obligated to use Herose products only for their intended purpose.
In this case, a technical service life may be assumed in accordance with the underlying product standards
(e.g. EN1626 for shut-off valves and EN ISO 4126-1 for safety valves).
The technical service life can be restarted several times through the exchange of wearing parts within the
context of the maintenance intervals, and lifetimes of more than 10 years can be achieved.
If products are stored for a period exceeding 3 years, then the plastic components and elastomer sealing
elements fitted to the product should be replaced as a precautionary measure before installation and use.
1
2
3
4
5
6
7

Operating instructions
10
Phone [phone]
5 Assembly
5.1 Installation position
Vertical
From 20 to 300 bar in the horizontal installation position, with the outlet facing downwards.
5.2 Notes regarding the installation
Use suitable tools.
Open-ended spanners
Torque wrench
Clean tools before the installation
Open the packaging only directly before the installation. Freedom from oil and grease for oxygen
(O2)
Safety valves for oxygen are permanently marked with "O2".
Only install the safety valve if the maximum operating pressure and usage conditions correspond
to the marking on the safety valve. Take note of the p-t curve of the valve on the catalogue page
and the resulting areas of use.
Remove protective caps or covers before installing.
Inspect the safety valve for dirt and damage. DO NOT install damaged or dirty safety valves.
Remove any dirt and residues from the pipeline in order to avoid leaks.
Use the entire usable thread length for mounting; at least four thread pitches.
Avoid damaging the connections.
The sealing surfaces must remain clean and intact.
Seal the safety valve using suitable seals.
No sealant (sealing tape, liquid sealing tape) may enter the safety valve.
Respect the suitability for use with O2.
Connect pipelines in a force-free and torque-free manner.
Stress-free installation.
In order to ensure trouble-free operation, no impermissible static, thermal or dynamic stresses
may be transmitted to the safety valve. Observe reactive forces.
The safety valve is supported by the pipeline system.
The safety valve must be protected against dirt and damage during construction work.
Check leak-tightness after completion of mounting.
Tightening torques
The tightening torques specified by the manufacturer are maximum permissible values at room
temperature and with uniform thread mating. The real torque to be used depends on the screw-in
conditions in the plant and must be specified by the plant operating company.
Thread
1/2"
3/4"
1"
1 1/4"
1 1/2"
2"
Inlet
MA [Nm] –max. perm. tightening torque
G
120
230
440
1300
1700
-
R / NPT
150
270
500
800
1000
-
Outlet
MA [Nm] –max. perm. tightening torque
G
70
110
220
340
430
640
R / NPT
180
280
530
850
1100
1700

Operating instructions
herose.com
11
6 Operation
The maximum permissible pressure loss in the supply pipes to the safety valves may not exceed the
3% pressure difference between the response pressure and external back pressure on the safety
valve.
Vibrations are to be avoided.
6.1 Liftability (manual actuation for testing)
Liftable safety valves are equipped with an appropriate device above the spring cover.
Make liftable safety valves open at ≥85 % of the set pressure without aids.
Proceed as follows during the initial start-up, after breaks in operation and for checking the
function:
The valve is ready for operation.
1. Pull the lifting lever away from the spring cover until
blow-off of the operating medium is clearly audible.
2. Release the lifting lever again.

Operating instructions
12
Phone [phone]
7 Maintenance
7.1 Safety during cleaning
Take note of the specifications in the safety data sheet and the general occupational health and
safety rules if degreasers are used for process-related reasons for the cleaning of bearing parts,
fittings and other precision parts.
7.2 Maintenance
The maintenance intervals must be defined by the user according to the operating conditions.
The recommendations for the functional checking of the safety valves are to be taken from section 7.2.1
"Recommended inspection and maintenance intervals" in these operating instructions.
7.2.1 Recommended inspection and maintenance intervals
Inspection
During
commissio
ning
annuall
y
2 years
5 years
10 years
Correspondence to
design drawing,
specifications,
type approval,
marking,
X
-
-
-
-
Suitability
(medium, size, temperature,
pressure, setting)
X
-
-
-
-
Visual inspection
of the valve for damage
of the marking for
legibility
X
X
X
X
X
Correspondence of the
technical data for the valve to
the documentation
X
X
X
X
X
Leak-tightness
Fittings
of the valve seat
X
X
X
X
X
If existent, actuation of the
lifting
X
X
X
X
X
Static pressure test with clean
water or another suitable
liquid
-
-
-
-
X
Visual examination of the
plant components for cracks,
inadmissible changes in
shape or leaks
-
-
-
-
X

Operating instructions
herose.com
13
7.3 Fault table
Fault
Cause
Remedial action
Safety valve does
not respond
Covers have not been
removed
Remove covers
Setting pressure too high
Replace the safety valve
Back pressure not taken into
account
Replace the safety valve
Not liftable
Pressure below 85% of the
set pressure
Lifting in the range ≥85 % of the set
pressure without aids
Leak in the seat
Foreign bodies between cone
and seat, contaminated
medium
Remove foreign bodies by briefly
lifting / flush the system or replace
the safety valve
Seat damaged
Replace the safety valve
Cone seal damaged
Replace the safety valve
Safety valve has fluttered
See "Fluttering"
Damage to the
inlet/outlet
Transport damage
Replace the safety valve
Wrong connecting thread /
tightening torque too high
Replace the safety valve
impermissible forces such as
bending or torsional forces
are being transmitted.
Install stress-free
Pressure surges
Safety valve not mounted at
the highest point
Install the safety valve at the
highest point
water not drained correctly or
at all
Attach water drain according to
regulations
Constantly
blowing off
Spring corroded by
impermissible medium and
broken
Replace the safety valve
Cone seal damaged
Replace the safety valve
Fluttering
Pressure loss in the supply
line >3%
Reduce resistance through chamfer
or radius in the connecting socket;
choose a larger one if necessary
Seals for inlet and outlet
connector too small or not
installed centrally
Change conditions
Safety valves are too
powerful
choose smaller safety valves
Blow-off pipe too long or
diameter too small
Use a larger nominal diameter or a
back-pressure-compensating
stainless steel bellows. The max.
height is to be specified by the
manufacturer.
Inlet or outlet connector too
small
Dimensions must be larger than the
nominal inlet or outlet diameter
Back pressure higher than
10% or 15% respectively
Use back-pressure-compensating
stainless steel bellows. The max.
height is to be specified by the
manufacturer.
Inadequate
performance
Safety valves dimensioned
incorrectly for the plant
conditions
Re-dimension and replace the
safety valve
Safety valves not being used
in accordance with the
applicable regulations
Change conditions

Operating instructions
14
Phone [phone]
7.4 Repairs
Repairs to the safety valves may be carried out only by HEROSE or by specialist workshops authorised
by HEROSE and monitored by the regulatory authorities, using only original spare parts.
7.5 Returns / complaints
Use the Service form in case of returns/complaints.
Contact in case of service:
Herose.com › Start › Service › Product service › Complaints
E-mail: [email protected]
Fax: [phone]
8 Disassembly and disposal
8.1 Notes regarding the disassembly
Take note of all national and local safety requirements.
The pipeline system must be depressurised.
The medium and the safety valve must be at ambient temperature.
Aerate / flush the pipeline in the case of corrosive and aggressive media.
8.2 Disposal
1. Dismantle the safety valve.
Collect greases and lubricating fluids during dismantling.
2. Separate the valve materials:
Metal
Plastic
Electronic scrap
Greases and lubricating fluids
3. Carry out a sorted disposal of the materials.
