Hexagone Quick VAC Classic User manual

Tél.[phone] www.myhexagone.com 2
Dear Customer,
Congratulations on your purchase of a HEXAGONE robotic pool cleaner we trust you will enjoy the benefits of
your new state of the art robotic cleaner.
The cleaner range has been designed, manufactured and checked with the upmost care so that you will be
completely satisfied with it.
Please take the time to read this Operation Manual before you use your new robotic pool cleaner.
This manual contains all the necessary information required to ensure the optimum and safe operation of your
cleaner.
For any other additional information, contact your dealer (as shown below) in relation to the utilization and
maintenance of your cleaner.
Their service technicians are available for any questions, support or training necessary to ensure the correct
operation of your robot.
Yoann Chouraqui
Directeur Général Hexagone
L'équipe HEXAGONE
Contact
Mail address :
HEXAGONE
1-5 rue Michel Carré
95104 –Argenteuil
Tél. [phone]
Fax. [phone]
Web site:
www.myhexagone.com
e-mail address’s:
Service After Sales: [email protected]
Customer Service : [email protected]
Commercial Service: [email protected]
General: [email protected]

Tél.[phone] www.myhexagone.com 3
Safety
• Keep the robot out of the reach of children
• Place the trolley so that the cleaner can reach the furthest corner of the pool.
• Never let anybody enter the swimming pool during cleaning
• Never put the trolley into the water, Only the robot has to go into the water
• Avoid working under direct sunlight; place the electric box out of direct sunlight.
• To avoid any electrical risk, never open the box yourself. Ask for a qualified person.
• Never pull on the cable.
• Cleaner for industrial purpose only and to be operated by qualified personal
• Operators to keep hands away from pump turbine while cleaner is connected
• When lifting the robot out of the pool, use proper lifting techniques to avoid back injury.
Destruction –Environmental protection
Respectful of directive DEEE - 2002/96/CE, worn electronic and electric products have to be disposed of correctly,
by recycling or any other way of disposal. To dispose of this product you have to follow local conditions or contact
your supplier who will inform you of the correct procedure.

Tél.[phone] www.myhexagone.com 4
Index
1. How to set up your cleaner ?
A –Unpacking
B –Battery connection
2. How to use your Quick Vac ?
A –Pool entry
B –Start up
D –Pool exit
3. Cleaning and maintenance
A –Cleaning of filter
B –Cleaning of the Quick Vac
C –Care maintenance
D –Charging the battery
4. Usage advice
5. Warrantee conditions
6. Exploded view and spare parts list

Tél.[phone] www.myhexagone.com 5
1. How to set up your cleaner ?
A –Unpacking
Unpack the unit by taking the necessary precautions. Do not use sharp tools (cutter, knife ...)
Check all items for damage from delivery. If damage is caused from the delivery please make a note on the delivery slip.
Only the recipient can file a claim with the carrier, you have 48 hours to do so by registered letter with acknowledgment of
receipt. Also please notify us as soon as possible of the damage.
If your device is not in perfect condition, or if it does not work, notify your dealer immediately and do not try to operate
without advice from a qualified or approved representative.
We recommend keeping the packaging and the original materials, they will be used for further transportation.
The Packaging must contain:
• The Quick Vac, its cable and filter
• The transport trolley (Follow instructions enclosed for assembly)
• 1 wallet with instruction booklet and screws for trolley assembly
Depending on your buying option you will have:
No power supply
oOne battery box
Battery power supply
oOne battery box
oOne battery
oOne charger for batterye
Sector power supply
oSpecial cupboard
B –Battery connection
Install lugs on the battery terminals. Take care of polarity
- lug + must be installed on the + terminal of the battery and connected to the red wire
- pod - must be installed on the terminal - battery and connected to the black wire
!!! CAUTION !!!
Serious damage can be caused to the device if it is run out of the water,
resulting in immediate void of the warrantee.

Tél.[phone] www.myhexagone.com 6
2. How to use your Quick Vac ?
A –Pool entry
• The trolley and the Battery box should be placed so that the robot can reach all corners of the pool;
• Be sure to place the entire cable in the pool, removing any cable loops before entering the unit in water.
• Install a telescopic pole (adapted to the dimensions of the pool) on the bracket at the rear of the vacuum, then clip into
place (you hear a "click" indicating that the handle is in place). This will allow you to guide the QUIK VAC during cleaning
operations.
• Immerse the unit in water, ensuring to position the vacuum on wheels.
CAUTION : Never start the QUICK VAC out of water, this could damage the pump and void any warrantee
B –Start up
Connect the plug to the power box, the pump starts turning immediatly. You can start to clean the pool.
C –Pool exit
Once the pool is clean at your convenience please follow the following steps:
• Bring back to you by pulling the telescopic handle
• Unplug and wait a few minutes so that the check valve closes and the dirt collected remains trapped.
• Grasp the pole and pull the vacuum cleaner to drain water, once to the surface grasp the side handle to remove the
QUICK VAC from the water.
• Position the Quick Vac on the cart, proceed with cleaning the filter (see next paragraph),
• Store the cable by winding it around the arms provided on the trolley. It is advisable to wrap the cable near the top of the
trolley allowing any loops to be removed easily.
!!! CAUTION !!!
Never pull the Quick Vac out of water by the cable.

Tél.[phone] www.myhexagone.com 7
3. Cleaning and maintenance
A - Cleaning of filter
IMPORTANT : The filter bag must be cleaned after each use.
Remove the filter from the Quick Vac.
Put the bag upside down to empty theany largest debris
Wash the filter under a tap or use a hose to spray.
Put the filter back on the Quick Vac for storage
Ecological Idea:
Prefer cleaning in a bucket of water, 15 or 20L of water should be enough.
Note: We recommend changing the filter bag regularly for the assurance of optimum cleaning.
IMPORTANT: Never operate the robot if the filter is damaged or the elastic has relaxed.
B - Cleaning of the Quick Vac
The submersible part should be cleaned with clean water and you should check and possibly remove debris caught in the
propeller.
No mechanical parts require any external lubrication or maintenance.
C - Care maintenance
IMPORTANT: All the cleaning and inspection must be carried out with the cable unplugged.
To ensure the efficiency of your QUICK VAC, it is important to check the below every week:
The state of the turbine, check there is no debries in the propeller, you can remove turbine by unscrewing its
locating block. Be careful not to lose the turbine pin.
Check filter and elastic retainer inside the filter.
Inspect the swivel wheels, make sure that nothing prevents their movement.
Finally, check the general appearance of the vacuum cleaner, the pressure of the tires of the trolley, the state of
the filter.
Check the status of the sealing flap.
Check levels of distilled water in the compartments of the battery, Charge or replace as needed.
D –Charging the battery
The battery that we advise is a battery 12 VDC 32A. It allows you 3 hours of battery life. Charge as soon as you notice a
decline in power.
To increase the battery life we recommend you do not let it fully discharge and ensure full charge each time.
IMPORTANT: Do not exceed 6 amp charger. Charge slow and fully and the battery will last longer.
!!! CAUTION !!!
The battery contains sulfuric acid which can cause severe burns.
Avoid contact with eyes or skin.
The battery can release emissions which can be dangerous. Take care to charge the battery
in a ventilated room free from flame.
4. Usage advice
Your safety :

Tél.[phone] www.myhexagone.com 8
Your vacuum cleaner has been manufactured in accordance with the highest standards. To use your equipment safely,
observe the following:
Keep the power supply unit far from the pool so as to prevent any falls.
In order to avoid any risk of electric shock, never open the electronic control box. Call a qualified technician.
Never attempt to repair the power cable. Contact the seller for replacement parts to avoid danger.
Caution :
Use your vacuum as often as possible: you will enjoy a pool which is always clean and there will be less debris in
your filter each time.
Never put the cleaner in water with a temperature below 10 ° C or above 35 ° C.
Never use the vacuum cleaner in water with a salinity of ≥ 4 mg / l, or water with sulfur content.
Store the cleaner in a well ventilated room free from frost, chemicals and acids.

Tél.[phone] www.myhexagone.com 9
5 –Your warrantee
These conditions correspond to the French laws in force at the date of printing.
Manufacturers Conditions
A - Conditions
We guarantee that all materials are technically sound and free of defects of materials and manufacture and
that they are consistent with the state of the art and techniques at the time of marketing. Subsequent
technological modifications applied to our products due to technological progress cannot give rise to any
intervention on our part.
The warranty is limited to the repair or replacement of the equipment if a compliance defect is recognised.
The choice of the solution is at our discretion given that any application of the warranty could not exceed the
resulting direct prejudice suffered and cannot lead to unreasonable costs to the dealer or the manufacturer.
The warranty is cancelled as of right if the equipment has been worked upon by a third party who does not
belong to our workshop or by a repairer not certified by us or if modifications have been applied without our
written consent. The warranty is also cancelled as of right if the operation and maintenance does not comply
with the operation manual supplied with the equipment at purchase time.
All legal warranties as described in section 1641 of the Civil Code are applicable. Any text that could become
Law after the printing of the present guarantee and whose terms would be in the order of public interest would
automatically apply even if they are different from the present conditions.
The following are excluded from the warranty:
The replacement of components liable to wear and tear such as Tracks, Brushes, Belts, Filter Bags.
Electrical faults caused by storm or bad electrical connections.
Damage due to impact.
Any breakdown related or non-related to replacement with non-genuine parts.
Problems arising as a result of non-compliance to the instructions of the operation manual.
Under no circumstances can the repair or replacement done under guarantee result in the extension or
renewal of the duration of the guarantee of the equipment.
B –Purpose Of The Warranty
The warranty period is limited by 2 years or 1200 hours of work (first period achieved stop the warranty. To
ensure good working conditions we advice you to ask for an overhaul every 1000 hours for the pump and
every 2000 hours for the driving motors.Every pump without any overhaul after 1000 hours of work will not be
covered by the warranty anymore by he manufacturer.
During the warranty period defined above, any component that is recognized to be faulty will be repaired or
replaced by a new component or one that is in good operating condition.
The transport and labor costs will be the responsibility of the user. In the case of a return to our workshop, the
two-way transport costs will be the responsibility of the user and the labor costs will be the responsibility of the
manufacturer. The immobilization and lost operation time of the equipment due to repairs cannot give rise to
any benefit. In any case, the legal warranty of the seller continues to apply under section 4 of Decree n° 78-
464 of the 24th of March 1978.
C –Transport Damage
The equipment is transported at the risk of the consignee. The latter is responsible for verifying that the
equipment is in perfect condition before accepting delivery. We cannot be held responsible in this matter.
D - Compliance
This equipment has been designed and manufactured according to the following standards:
• NF C15-100 - Very low power supply for security
• NF EN 50 081-1 and NF EN50 082-1st June 1992 Electromagnetic compatibility –Generic standard for
emission / immunity - Part I : residential, commercial and light industry
• NF EN 50 082-1st June 1992
Additional information relative to CE certification: the swimming pool cleaning Robot is certified CE
according to the following guidelines:
• C.E.M. 89/336/CEE and 92/31/CEE
• Low voltage 73/23/CEE with which the equipment is compliant.

Tél.[phone] www.myhexagone.com 10
6 –Exploded view and spare parts list
ITEM
REFERENCE
DESIGNATION
Qty
1
ZPVJD002
Pump/debris sealing flap
1
2
ZPV005-D
Cable
1
3
ZPVBB001
Float
6
4
ZPVQS002
Telescopic fixing point
1
5
ZPVQS001
Mount for Telescopic fixing point
1
6
ZPV026-D
360° multi direction wheels
4
7
ZPV011-D
Cable Plug
1
8
ZPVQP001
Side Handle
1
-
ZPV020-D-2100
Filter standard
1
-
ZPV022-D-2100
Filter Large
1
-
ZPV019-D-2100
Filter super fin
1
-
ZPVPB001
Turbine
1
-
ZPV010-D
Battery Case female socket
1
