Hi Sharp HS-ML3700 User manual

Thank you for purchasing our product.
Please read this User’s Manual before
using the product. Change without Notice
37-INCH TFT-LCD MONITOR
INSTRUCTION MANUAL

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION:
CAUTION
Explanation of Graphical Symbols
2
Warning
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.

IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and usage instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Clean only with a dry cloth.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury, and serious
damage to the unit. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination to overturn.
9. VENTILATION
Slots and openings at the rear cabinet and bottom are provided for ventilation, these are to ensure reliable operation of the unit,
and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by
placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat
source. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.
10. POWER SOURCE
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of
power supply to your home, consult your appliance dealer or local power company.
11. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
12. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line
surges.
13. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or
where it can fall onto or against such power lines or circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits, as contact with them might be fatal.
14. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
15. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could
result in fire or electric shock. Never spill or spray any type of liquid into the unit.
16. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
17. CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure
to do so may cause a product damage. Read the owner's manual of the other equipment carefully and follow the instructions
when making any connections.
18. LCD
Do not press on or jolt the LCD panel. Doing so may cause the LCD panel glass to break and injury may occur. Should the LCD
panel be broken and liquid leaks out, do not inhale or swallow it. Doing so may cause poisoning. If you have got it into your
mouth, wash it out and consult your doctor. If your hands or clothes have touched it, wipe them with alcohol and a cleaning cloth
and then wash them well.
3
Important Information

Federal Communications Commission (FCC) Statement
This Equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
zYou are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
4
Safety Precautions
This device complies with Part 15 FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including interference that may
cause undesired operation

Table of contents
zWarning……….………………………………………………………………….. 2
zImportant Information…………………………………………………………… 3
zSafety Precautions……….……………………………………………………. 4
zTable Of Contents……………………………………………………………….. 5
zFeatures……….…….…………………………………………………………… 6
zOperating Instructions-Controls……………………………………………….. 7
zTop Side…………………………………………………………………………… 8
zSide Connections…..….………………………………………………………… 9
zRemote Control………………………………………………………………….. 10
zOSD Architecture………………………………………………………………… 12
A. General Setup………………………………………………………………. 12
B. Video Setup…………………………………………………………………. 13
C. VGA Setup..………………………………………………………………… 14
D. Audio Setup..……………………………………………………………….. 15
E. PIP Setup..………………………………………………………………...... 16
zLCD Monitor Mounting guide..……….………………………………………… 17
A. Wall Mount…………………………………………………………………... 17
B. VESA Bracket………………………………………………………………. 17
zSpecification……………………………………………………………………… 18
zAppendixes ……………………………………………………………………… 19
A. Trouble Shooting.………………………………………………………….. 19
B. Package List.………………………………………………………………. 19
zDimension……………………………………………………………………….. 20
5

z37-inch LCD monitor with multiple inputs (Composite video, Y/C (S-Video) (SVHS) and
D-sub computer)
zHigh brightness of 500 cd/㎡
zHigh contrast of 1500 :1
zWide viewing angle of 160 degrees, both vertically and horizontally
zFast LCD response time of 6.5ms, allowing excellent rendering of motion
zLatching power supply automatically restores power after interruption or remote switching
zControl button lock-out using the OSD, to minimize tampering in public view applications
zRemote control for 37-inch LCD, adding flexibility for Public View applications
z37-inch LCD include an anti-scratch, anti-reflective shield, which is ideal for public areas
zSimple OSD Menu User Interface
zVideo input supports both NTSC / PAL standards
zUser selectable 6500°K / 9300°K color temperature settings
zAuto termination (75 Ohms)
zPole / Wall mountable using VESA standard ( 100mm X 100mm ) bracket on the 37-inch
LCD
6
Features

Operating Instructions-Control
Front Side
1 2
1. Monitor power ON / OFF indicator.
When OFF, monitor is in standby status.
Green Light – Power On
Red Light – Power Off
2. Receiver
Remote control IR sensor.
7

Top Side
8
Operating Instructions-Control
1. EXT- 1
Support Card Reader for advertising purpose.
2. EXT - 2
Support second Card Reader for advertising
purpose.
3. Power
Turn ON / OFF monitor. When OFF, monitor is in
standby status.
4. Adjust - UP
Increase value or turn ON/OFF function.
5. Adjust - DOWN
Decrease value or turn ON/OFF function.
6. Enter
To enter the sub-menu function when selected.
7. Menu
OSD menu and ON/OFF selection.
8. Source
Video input selection for AV1, AV2, S-Video, EXT1,
EXT2 or VGA.

A. SIDE PANEL CONTROL
9
Side Connections
1, 3 AUDIO-2 IN (L, R)
Stereo Audio Signal Input, this input is for AV2 or
AUX
2, 4 AUDIO-1 IN (L, R)
Stereo Audio Signal Input, this input is for AV1,
S-Video or PC IN
5 S-Video IN
Y/C separated signal input
6 AUX OUT
Video looping output for AUX 1
7 AUX IN
Composite signal Input for AUX 1
8 VIDEO 2 OUT
Video looping output for VIDEO 2
9 VIDEO 2 IN
Composite signal Input for VIDEO 2
10 VIDEO 1 OUT
Video looping output for VIDEO 1
11 VIDEO 1 IN
Composite signal Input for VIDEO 1
12 DC Output
DC 12V power output at 500mA (Max)
13 PC VGA IN
14 AC POWER CORD

Key Function
10
Remote Control
POWER: Turn ON / OFF monitor. In the
OFF mode, the monitor will be in
standby status.
PIP / POP SWAP: PIP/POP display switch
PIP/ ZOOM: Zoom Screen
PIP/POP SOURCE:Select PIP/POP display
MUTE: To disable audio.
: Decrease audio volume.
: Increase audio volume.
DISPLAY: Displays video source title.
AUDIO: PIP/POP Main/Sub Audio switch.
VGA: Select PC monitor mode.
EXT 1: Select EXT 1 display.
EXT 2: Select EXT 2 display.
AV 1: Select display to Video1.
AV 2: Select display to Video2
AUX: Select display to AUX.
S-VIDEO: Select S-Video.
MENU: OSD menu ON / OFF and selection.
◄: Decrease value or turn ON / OFF
Function.
▲:Increase value on OSD menu.
►: Increase value or turn ON / OFF
function.
▼:Decrease value on OSD menu.
The button to confirm selections.

MULTIMEDIA PLAYER
EFFECT: The button to change transition effects.
SETUP: The button to enter the main menu.
SLIDE SHOW: The button to start the slide show.
SLIDE TIME: The button to change dwell time between slides.
◄Left: The button to select a different sub menu
►Right: The button to select a different sub menu
▲Up: The button to select a different folder
▼Down: The button to select a different folder
◄◄ Reverse: The button to rewind MP3 or movies.
►► Forward: The button to forward MP3 or movies.
■Stop: The button to stop playing.
Play / Pause: Press 1 time will play picture SLIDE, press 2 times will pause
picture and music.
Repeat: The button to repeat MP3 or movies
11
Remote Control

A. General Setup
AutoSourceDetect
OSD Language
Power ON Control
Key Lock
Power Memorize
Channel Display
CCDMode
Default
0
None
Off
On
On
ON
OFF
NO
Auto Source Detect : The monitor will auto detect the video source when powered ON.
OSD Language : Multi-Language selection in English, French and Spanish.
Power ON Control : This function is to assign a specific video signal when power ON.
Key Lock : The Key-Lock function is provided to prevent tempering. Press
ENTER and MENU to unlock.
Power Memorize : This function enables the monitor to memorize the previous power
status before power break.
Channel Display : his function is to allow the channel title to be displayed on the
monitor.
CCD Mode: If video signal source directly comes from CCD camera, using CCD
Mode is suggested to obtain better picture performance.
Default : Return to factory default value.
12
OSD Architecture

B. Video Function
9300
Brightness : Adjusts the overall picture black levels.
Tip: Use the Brightness to make details in the dark areas of the
picture to be just visible, and Contrast to “brighten” the picture
without causing noises and foreheads to turn white.
Contrast : Permits adjustment of contrast between light and dark areas of the
picture. Adjusts the picture white levels.
Color : Adds color to the black and white picture content (of a color
signal), and is usually set for viewer’s preference in color saturation.
TINT : Adjusts all the hues on the screen, but is most noticeable to the eye
in reds and yellows, and is also usually set for pleasing face tones.
Sharpness : Sets the desired sharpness enhancement to the picture.
Color Temperature : Selects color temperature of either 6500°K or 9300°K.
Scan Mode : Selection of picture size in UNDER, FULL, OVER and WIDE scan.
4:3
H-position : Allows adjustment for horizontal position.
V-position : Allows adjustment for vertical position.
AGC Control : This function provides a small scale of backlight enhancement to
compensate for insufficient luminance.
DEFAULT : Sets monitor to the original factory settings.
13

C. VGA Setup (Note: VGA Setup is only available in VGA mode when a VGA signal is
provided)
Auto
Brightness
Contrast
Color Temperature
H-Position
V-Position
Clock
Phase
Default
No
50
60
9300
50
23
50
45
No
Auto : Auto detects screen detail data such as clock and phase.
Brightness : Adjusts the overall picture shade and brightness.
Tip: Use the Brightness to make details in the dark areas of the
picture to be just visible, and Contrast to “brighten” the picture
without causing noises and foreheads to turn white.
Contrast : Permits adjustment of contrast between light and dark areas of the
picture. Adjusts the level of white areas.
Color Temperature : Selects color temperature of either 6500°K or 9300°K.
H-position : Allows adjustment for horizontal position.
V-position : Allows adjustment for vertical position.
Clock : Is used to adjust best picture quality. It adjusts the number of pixel
clock cycles across one line time. Therefore it can affect the picture
position and size. Note: improper adjustment will cause image
failure.
Phase : Is used to adjust best picture quality. It adjusts the sampling phase
across one pixel time. When the phase is not adjusted properly, the
picture will be unclear. Therefore this value should be carefully
adjusted. Note: improper adjustment will cause image failure.
Default : Sets monitor to the original factory settings.
14

D. Audio Setup
Volume : Controls built-in speaker’s output volume.
Note: Volume control can also be adjusted by hot key.
+
Treble : Audio high frequency adjustment.
Bass : Audio low frequency adjustment.
Balance : Controls built-in speakers LEFT / RIGHT volume balance.
Mute : To disable the audio function. To restore, press MUTE again.
Default : Sets AUDIO settings to the original factory settings.
15

E. PIP Setup
Multi-mode
PIP/POP Source
-Wi ndow Size
-H-Position
-V-Position
SWAP
Switching
Switch Time
Audio Source
PIP
PIP
PIP
Off
1/4
0
100
Off
10~100
No.1
5+
Multi-Mode: Selection of PIP
PIP/POP Source : Select PIP/POP display
PIP Window Size : The selection of PIP window size in 1/4, 1/3,1/2 and side by side.
PIP H-Position : Control the PIP window position horizontal position.
PIP V-Position : Control the PIP window position vertical position.
Swap: Main/Sub screen exchange
Switching : Enables PIP source switching.
Switching Time : Controls PIP source switching time.
Audio Source: PIP/POP Main/Sub. Audio switch
16

A. Wall Mountable
Using the 326 mm pre-cut keyholes.
B. VESA bracket
Using VESA standard Pole/wall mount design and the 100mm hole pattern on the back panel
to install the LCD monitor to the wall.
17
LCD monitor Mounting Guide
Note : It’s highly suggested to use
provided accessories to mount
the LCD onto a cement wall to
ensure safety.

LCD Panel 37 inch” TFT, TN Mode
Display Mode 3D De-interlace
Input Filter 3D Comb filter
Resolution 1366 x 768
Brightness 500 cd/m2
Contrast ratio 1500:1
Response Time 6.5ms typ.
L/R
View Angle U/D
85(left), 85(right) CR=5
85(up), 85(down) CR=5
Input Signal
BNCx3 in
BNC x 3 out (Auto Termination)
D-Sub 15pin
Y/C x1 in
Audio In/Out RCA(R/L) x 2 set
Operating Controls OSD
Power Supply AC 96~256V 50/60Hz
Power Consumption 165 W
Dimension 908(H) x 570(V) x 124.8(D)mm
Weight 23.2kg
Operating Temperature -10~60℃
Humidity 20%~80%
18
Specifications

A. TROUBLE SHOOTING
Problem:
1.No power
2.No video or audio
3.Bad video or audio
4.Image not stable
5.Ab-normal line
6.Ghost image
7.Desired video disappears
B Package List
A. 37”LCDMonitor x1
B.PowerCord x1
C. User Manual x 1
D. Accessory Kit x 1
E. Remotecontrol x1
19
Appendixes
CHECK:
Power-cord connected? Power ON?
Change to right input channel?
Check signal cable?
Any interrupt from other devices?
Adjust video control on OSD?
Adjust video source?

20
Dimension
