HighPoint RR3740 User manual

1
RR3740/3720/2840/840
PCI-Express 3.0 x8 RAID Controller
RR3740/2840/840
RR3720
Quick Installation Guide
v1.02

2
RR3740/3720/2840/840 Kit Contents
•RAID Controller Card
•Low Profile Bracket
•Quick Installation Guide
Operating System
•Windows 11,10, 8, 7 / Server 2022, 2019, 2016, 2012R2, 2008 /
Microsoft Hyper-V
•RHEL/Ubuntu/Debian/Fedora/Proxmox (Linux kernel 3.10 and
later)
•Arch Linux (Kernel 5.17.5 and above)
•macOS 10.9 ~ macOS 13.x

3
Required Accessories
Certified cables is available directly from HighPoint and our authorized
resellers. For more information, please contact our Sales Department
([e-mail]).
1. In order to use SATA drives with the RR3740/3720/2840/840 R
AID controller, you will need at least one 8643-4SATA-1M ca
ble. Each cable can support four SATA hard drives or SSD’s
via an SFF-8643 port.
2. In order to use SAS/SATA drives with the RR3740/3720/2840
RAID controller, you will need at least one 8643-4SAS-1M
cable. Each cable can support up to four SAS/SATA hard
drives or SSD’s via an SFF-8643 port.

4
RR3740/2840/840 Hardware
Front View
RR3720 Hardware
Front View
Channels 5-8
Channels 1-4
Channels 13-16
Channels 9-12
Channels 1-4
Channels 5-8

5
RR3740/3720/2840/840 Hardware Installation
Note: Make sure the system is powered-off before installing the RAID
Controller.
1. Connect the RR3740/3720/2840/840 into the PCIe 3.0/ 4.0 x8 or x16
slot of the motherboard;
2. How to connect disks to the RR3740/3720/2840/840 using the 8643-
4 S ATA -1M cable.
SATA Power Connector
SATA Drivers

6
3. How to connect disks to the RR3740/3720/2840 using the 8643-
4SAS-1M cable.
Each cable can support up to four SAS/SATA hard drives or
SSDs via an SFF-8643 port.
SATA/SAS Drivers
SAS Power Connector

7
Optional Certified Cable Accessories
Device Cables
8643-4SAS-1M
1M SFF-8643 SAS to 4x
SFF-8482 SAS cable
Length: 1M
8643-4SATA-1M SFF-8643 SAS to 4x SATA
cable, with Power Connector
Length: 1M

8
Resources
A variety of manuals, guides and FAQ’s are available for RocketRAID
3700/2800/800 series RAID controllers. In addition, we recommend
visiting the Software Downloads webpage for the latest drivers,
management interfaces, and installation guides.
For Software Downloads, Documentation and more information
about this product, please visit the following website:
RR3700:
https://www.highpoint-tech.com/rr3700-overview
RR800:
https://www.highpoint-tech.com/rr800-overview
RR2800:
https://www.highpoint-tech.com/rr2800-overview
Certified Accessories:
https://www.highpoint-tech.com/rr-accessories
FAQ & Troubleshooting:
FAQ - HighPoint Technologies, Inc. (helpjuice.com)

9
Customer Support
If you encounter any problems while utilizing the RAID controllers, or
have any questions about HighPoint Technologies, Inc. products &
solutions, feel free to contact our Customer Support Department.
Web Support:
https://www.highpoint-tech.com/support-and-services
HighPoint Technologies, Inc. websites:
http://www.highpoint-tech.com
© Copyright 2022 HighPoint Technologies, Inc. All rights reserved.
