HIK VISION DS-2CC592 P(N)-FB User manual

Hikvision Technical Manual
DS-2CC592 P(N)-FB Analog Camera
Vandal Proof Color Dome Camera
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[email protected]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1.Key Features
zCompact Structure Design
z1/3 inch SONY CCD
zDay / Night with Auto Switch
zLow Illumination: 0.1Lux @ F1.2
zAuto White Balance, Auto Gain Control, Electronic Shutter Control and Backlight
Compensation
zDigital Signal Processing
zInternal Synchronization
zAdvanced Engineering Design, High Reliability
zImpact Protection: IEC60068-275 test, Eh, 50J; EN50102, exceeding IK10

Hikvision Technical Manual
2.Specifications
Parameter Model DS-2CC592P (N)-FB
Image Sensor 1/3 inch SONY Super HAD CCD
Signal System PAL/NTSC
Effective Pixels PAL: 752 (H) × 582 (V)
NTSC: 768 (H) × 494 (V)
Min. Illumination 0.1Lux @ F1.2
Electronic Shutter Speed 1/50 (60)s to 1/100,000s
Lens 3.5 ~ 8mm (4 ~ 9mm option)
Day & Night Electronic
Horizontal Resolution (TVL) 540 TVL
Synchronization Internal synchronization
Video Output 1Vp-p Composite Output (75Ω/BNC)
S/N Ratio More than 48dB
BLC ON
Impact Protection IEC60068-275 test, Eh, 50J; EN50102, exceeding IK10.
Power Supply 12VDC, ±10%
Working Temperature -10℃~ 60℃(14°F ~ 140°F)
Power Consumption 2W MAX
Dimension (mm) φ140 × 92
Weight 660g
©2006 – 2010 by HIKVISION. All rights reserved.
5

Hikvision Technical Manual
3.Dimension
©2006 – 2010 by HIKVISION. All rights reserved.
6
