HIK VISION DS-K4T100 User manual

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
1 of 10
DS-K4T100 Electric Lock Connect to DS-K2600&DS-
K2800 serires Access Controller
Preparation
Connecting electric lock to access controller is mainly applied to open the door for exiting. For electric
lock and access controller in this document, please check the table below:
Magnetic Lock
Access Controller
DS-K4T100
DS-K2601, DS-K2602, DS-K2604
DS-K2801, DS-K2802, DS-K2804
Note
This document is simply used to guide users how to wire correctly and ensure access controllers can
control locks.
The access controller model in this document is DS-K2604 & DS-K2804.
Part 1 is mainly for electric lock wiring, and Part 2 and Part 3 are mainly for the situation that users could
get the door status on iVMS-4200 Client.
Notice
1. Please cut off power supply before wiring;
2. Please check interfaces of electric lock in following picture;
3. Correspondingly, there are lock and door magnetic interfaces in DS-K2800 & DS-K2600 series
access controllers, as pictures show:
Note: means lock interface; means door magnetic interface;
Access Controller
Interface
DS-K2801
Color
Description
Red
12V
Black
GND
Green
COM
Yellow
NC
Blue
NO

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
2 of 10
DS-K2802
DS-K2804
DS-K2601
DS-K2602
DS-K2604

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
3 of 10
Part 1: Lock+ & Lock- Wiring
DS-K4T100 & DS-K2804
Please connect as the following picture:
DS-K4T100 & DS-K2604
Please connect as the following picture:
2 * DS-K4T100 & DS-K2804
Please connect as the following picture:
2 * DS-K4T100 & DS-K2604
Please connect as the following picture:
NC
C
O
M
NO
S
G
V-
V+
+
-
NC
C
O
M
NO
S
G
+
-

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
4 of 10
Part 2: Lock+/Lock- & NC/COM Wiring
Step 1:
DS-K4T100 & DS-K2804
Please connect as the following picture:
2 * DS-K4T100 & DS-K2804
Please connect as the following picture:
DS-K4T100 & DS-K2604
Please connect as the following picture:
NC
C
O
M
NO
S
G
+
-
NC
C
O
M
NO
S
G
NO
NC
G
B
S
COM
+
-
NC
V+
COM
V-
NO
COM
V+
V-
NO
NC

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
5 of 10
2 * DS-K4T100 & DS-K2604
Please connect as the following picture:
Step 2:
Add access controller to iVMS-4200 Client;
Step 3:
Click Tool Device Arming Control, check your access controller arming status;
The icon means device was armed by iVMS-4200 Client;
Step 4:
Enter Access Control Advanced Function Access Control Parameters interface, set Door
Magnetic Sensor as Remian Closed, and it should be consistent with the wiring of Door Magnetic
Singnal Output;
NC
V+
COM
V-
NO
COM
V+
V-
NO
NC
Lock1+
Lock1-
Door
Magnetic1
GND

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
6 of 10
Step 5:
Enter Status Monitor Door Status interface, open the door, check door status on iVMS-4200 Client
and the magnetic lock LED status;
Door Status
Alarm Event
Part 3: Lock+/Lock- & NO/COM Wiring
Step 1:
DS-K4T100 & DS-K2804
Please connect as the following picture:
NC
C
O
M
NO
S
G
+
-

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
7 of 10
2 * DS-K4T100 & DS-K2804
Please connect as the following picture:
DS-K4T100 & DS-K2604
Please connect as the following picture:
2 * DS-K4T100 & DS-K2604
Please connect as the following picture:
NC
C
O
M
NO
S
G
NO
NC
G
B
S
COM
+
-
NC
V+
COM
V-
NO
COM
V+
V-
NO
NC
Lock1+
Lock1-
Door
Magnetic1
GND
NC
V
+
COM
V-
NO
COM
V
+
V-
NO
NC
z

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
8 of 10
Step 2:
Add access controller to iVMS-4200 Client;
Step 3:
Click Tool Device Arming Control, check your access controller arming status;
The icon means device was armed by iVMS-4200 Client;
Step 4:
Enter Access Control Advanced Function Access Control Parameters interface, set Door
Magnetic Sensor as Remian Open, and it should be consistent with the wiring of Door Magnetic
Singnal Output;
Step 5:
Enter Status Monitor Door Status interface, open the door, check door status on iVMS-4200 Client
and the magnetic lock LED status;
Door Status

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
9 of 10
Alarm Event
NOTE: Abnomal in Magnetic lock LED status part could be displaied in following scenario, open door
timeout, abnomally open door(by force), as well as not standard installation cuasing armature plate and
lock body contact are not fully fitted.

Title:
DS-K4T100 Electric Lock Connect to
DS-K2600&DS-K2800 serires Access
Controller
Version:
v1.0
Date:
3/19/2018
Product:
Access Control Device
Page:
10 of 10
First Choice for Security Professionals
HIKVISION Technical Support
