DS-7300HFI-ST Series DVR
Technical Manual

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Notices
The information in this documentation is subject to change without notice and does
not represent any commitment on behalf of HIKVISION. HIKVISION disclaims any
liability whatsoever for incorrect data that may appear in this documentation. The
product(s) described in this documentation are furnished subject to a license and
may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2011 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for
the purposes for which it is supplied. It may not be reproduced in whole or in
part, in any form, or by any means or be used for any other purpose without prior
written consent of HIKVISION and then only on the condition that this notice is
included in any such reproduction. No information as to the contents or subject
matter of this documentation, or any part thereof, or arising directly or indirectly
therefrom, shall be given orally or in writing or shall be communicated in any
manner whatsoever to any third party being an individual, firm, or company or any
employee thereof without the prior written consent of HIKVISION. Use of this
product is subject to acceptance of the HIKVISION agreement required to use this
product. HIKVISION reserves the right to make changes to its products as
circumstances may warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Main Features
Each channel supports encoding at up to 4CIF resolution real time.
Simultaneous HDMI, VGA and CVBS outputs.
HDMI output and VGA output at up to 1920×1080P resolution.
Quick setting menu is provided for live view.
Support eSATA disk for recording or backup.
HDD quota management; different capacity can be assigned to
different channel.
Holiday recording schedule configuration.
Searching record files and captured pictures by events (alarm
input/motion detection).
Motion analysis for the selected area in the video.
Up to 16-ch synchronous playback.
Support dual stream.
Captured pictures can be sent to the FTP and the FTP can be
upgraded remotely.

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Functions & Performances
Compression
PAL/NTSC adaptive video inputs.
H.264 video compression with high reliability and superior definition.
Each channel supports encoding at up to 4CIF resolution real time.
Each channel supports dual stream.
Independent configuration for each channel, including resolution, frame
rate, bit rate, image quality, etc.
Quality of the imported and exported record is configurable.
Each channel supports two kinds of compression parameters, the normal
continuous and event, which can be configured locally.
Encoding for both audio/video composite stream and video stream; audio
and video synchronization during composite stream encoding.
Watermark technology.
Local Monitoring
Simultaneous HDMI, VGA and CVBS outputs.
HDMI output and VGA output at up to 1920×1080P resolution.
1/4/6/8/9/16-division live view is supported, and the display sequence of
screens is adjustable.
Live view screen can be switched in group, and manual switch and
automatic cycle review is also provided, the interval of automatic cycle
can be adjusted.
Quick setting menu is provided for live view.
The selected live view channel can be shielded.
Motion detection, tamper-proof, video exception alert and video loss alert
functions.
Privacy mask.
Several PTZ protocols supported; PTZ preset, patrol and pattern.
Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
Up to 4 SATA hard disks, 8 network disks (8 NAS disks, or 7 NAS disks+1
IP SAN disk) and 1 eSATA disk can be connected, each disk with a
maximum of 4TB storage capacity.
Support eSATA disk for recording or backup.
HDD group management.
Support HDD standby function.
HDD property: redundancy, read-only, read/write (R/W).
HDD quota management; different capacity can be assigned to different
channel.

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Recording, Capture and Playback
Holiday recording schedule configuration.
Cycle and non-cycle recording mode.
Normal and event video encoding parameters.
Multiple recording types: manual, normal, alarm, motion, motion | alarm,
motion & alarm.
8 recording periods with separated recording types configurable.
Pre-record and post-record for alarm, motion detection for recording, and
pre-record time for schedule and manual recording.
Searching record files and captured pictures by events (alarm
input/motion detection).
Customizing tags, searching and playing back by tags.
Locking and unlocking record files.
Local redundant recording and capture.
Searching and playing back record files by channel number, recording
type, start time, end time, etc.
Motion analysis for the selected area in the video.
Zooming in when playback.
Supports pause, play fast, play slow, skip forward, and skip backward
when playback, locating by dragging the mouse.
Up to 16-ch synchronous playback.
Manual capture, continuous capture of video images and playback of
captured pictures.
Backup
Export video data by USB, SATA or eSATA device.
Export video clips when playback.
Management and maintenance of backup devices.
Alarm and Exception
Configurable arming time of alarm input/output.
Alarm for video loss, motion detection, tampering, abnormal signal,
different input and output video standard, illegal login, network
disconnected, IP confliction, abnormal record/capture, HDD error, and
HDD full, etc.
Alarm triggers full screen monitoring, audio alarm, notifying surveillance
center, sending email and alarm output and upload captured pictures to
FTP.
Automatic restore when system is abnormal.
Other Local Functions
Users can operate by front panel, mouse, remote control, and control
keyboard.
Three-level user management; admin user is allowed to create many
operating accounts and define their operating permission, which includes

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
the limit to access any channel.
Operation, alarm and exception logs recording and searching.
Manually triggering and clearing alarms.
Import and export of device configuration information.
Network Functions
1 self-adaptive 10M/100M network interfaces.
IPv6 is supported.
TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS,
and iSCSI are supported.
TCP, UDP and RTP for unicast.
Remote search, playback, download, locking and unlocking the record
files, and downloading files broken transfer resume.
Remote parameters setup; remote import/export of device parameters.
Remote viewing of the device status, system logs and alarm status.
Remote keyboard operation.
Remote locking and unlocking of control panel and mouse.
Remote HDD formatting and program upgrading.
Remote system restart and shutdown.
RS-232, RS-485 transparent channel transmission.
Alarm and exception information can be sent to the remote host
Remotely start/stop recording.
Remotely start/stop alarm output.
Captured pictures can be sent to the FTP and the FTP can be upgraded
remotely.
Remote PTZ control.
Remote JPEG capture.
Two-way voice talk and voice broadcasting.
Embedded WEB server.
Development Scalability
SDK for Windows and Linux system.
Source code of application software for demo.
Development support and training for application system.

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Panels & Interfaces
Front Panel
①Power Button
②IR Receiver
③USB Interface
④DVD-ROM
⑤Status Indicator(Power, Ready, Status, Alarm, HDD, Tx/Rx)
⑥Compound Buttons
⑦DIRECTION/ENTER Buttons
⑧JOG SHUTTLE Control

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Rear Panel
Note: The DS-7308HFI-ST provides 8 BNC video input connectors on the rear panel.
①MAIN VIDEO OUT, SPOT VIDEO OUT
②VIDEO IN
③AUDIO IN
④LINE IN
⑤CVBS AUDIO OUT, VGA AUDIO OUT
⑥LOOP OUT (Optional)
⑦RS-232 Interface
⑧VGA
⑨HDMI
⑩USB Interface
⑪LAN Interface
⑫RS-485 Serial Interface, Keyboard Interface, ALARM IN, ALARM OUT
⑬eSATA Interface
⑭GROUND
⑮100~240VAC Power Input
⑯Power Switch

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Specifications
Model
DS-7304HFI-ST
DS-7308HFI-ST
DS-7316HFI-ST
Video/
Audio
input
Video
compression
H.264
Analog video
input
4-ch, BNC (1.0
Vp-p, 75Ω),
PAL/NTSC
adaptive
8-ch, BNC (1.0
Vp-p, 75Ω),
PAL/NTSC
adaptive
16-ch, BNC (1.0
Vp-p, 75Ω),
PAL/NTSC
adaptive
Audio
compression
G.711
Audio input
4-ch, RCA (2.0 Vp-p, 1 kΩ)
Voice talk
input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video/Au
dio output
HDMI output
(with
HDMI/VGA
audio
output)
1-ch, resolution:
1080P: 1920 × 1080 /60 Hz; UXGA: 1600 × 1200 /60 Hz;
SXGA: 1280 × 1024 /60 Hz; 720P: 1280 × 720 /60 Hz;
XGA: 1024 × 768 /60 Hz.
VGA output
(with VGA
audio
output)
1-ch, resolution:
1080P: 1920×1080 /60 Hz; UXGA: 1600 × 1200 /60Hz;
SXGA: 1280 × 1024 /60 Hz; 720P: 1280 × 720 /60 Hz;
XGA: 1024 × 768 /60 Hz.
CVBS output
2-ch (1 Main Video Out+1 Spot Video Out),
BNC (1.0 Vp-p, 75Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop
out
(optional)
4-ch
8-ch
16-ch
Encoding
resolution
4CIF /2CIF /CIF /QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit
rate
32 Kbps ~ 2048 Kbps, or user defined (Max. 3072 Kbps)
Audio output
2-ch, RCA (Linear, 600Ω)
Audio bit
rate
64 Kbps
Dual stream
Support,
Sub stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Video / Video &
Audio
Channel 1-4:
Video/Video &
Audio;
Channel 5-8:
Video
Channel 1-4:
Video/Video &
Audio;
Channel 5-16: Video
Playback
resolution
4CIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch
8-ch
16-ch

Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Hard disk
SATA
4 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External
interface
Network
interface
1 RJ45 10M / 100M adaptive Ethernet
Serial
interface
1 RS-232 interface (for parameters configuration,
maintenance, transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
USB
interface
3, USB2.0
Alarm in
8
8
16
Alarm out
4
Others
Power
supply
100 ~ 240 VAC, 5 A, 50~60 Hz
Consumption
≤ 30 W (without
hard disk or
DVD-R/W)
≤ 35 W (without
hard disk or
DVD-R/W)
≤ 40 W (without
hard disk or
DVD-R/W)
Working
temperature
-10 ºC ~ + 55 ºC
Working
humidity
10% ~ 90%
Chassis
19-ich rack-mounted 1.5 U chassis
Dimensions
(W × D × H)
440 × 390 × 70 mm
Weight
≤ 8 Kg (without hard disk or DVD-R/W)
