HIK VISION DS-8100HMI-B Series User manual

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 1 -
DS-8100HMI-B Embedded Mobile Net DVR
User Manual
(V1.0)

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 2 -
Statement
Please kindly note and understand that there may be misprints and technically inaccurate description. The contents of
this manual are subject to change without notice from time to time accompanying with the release of new version.
The listed products or programs will be improved or renewed whenever necessary.
Tips for users:
· Please install the DVR in well-ventilated places;
· Please make sure the DVR work in the allowed range of temperature
and humidity;
· The dust board will cause a short circuit after damping; Please dedust
regularly for the board, connector, chassis fan etc with brush.
· Please select the hard driver manufacturers recommended HDDs
which can meet the demand of DVR—long time, reading and writing
large amount of data.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 3 -
1Production Description ......................................................................................................................................................................................... 6
1.1 Overview..................................................................................................................................................................................................... 6
1.2 Key Functions ............................................................................................................................................................................................. 6
2Installation help .................................................................................................................................................................................................... 9
2.1 Check device and accessories..................................................................................................................................................................... 9
2.2 SATA Installation.........................................................................................................................................................................................9
2.3 SIM/UIM card installation ........................................................................................................................................................................11
2.4 Rear Panel Interface Description..............................................................................................................................................................12
2.5 KEY Ignition Switch Connection................................................................................................................................................................13
2.6 Alarm Output Connection Guide.............................................................................................................................................................. 16
3Operation Guide .................................................................................................................................................................................................17
3.1 Front Panel Description............................................................................................................................................................................17
3.2 IR Control.................................................................................................................................................................................................. 18
3.3 Menu Description.....................................................................................................................................................................................20
3.3.1 Menu items ....................................................................................................................................................................................20
3.3.2 Menu Operations ...........................................................................................................................................................................21
3.4 Input Method ...........................................................................................................................................................................................23
4Basic Operation Guide ........................................................................................................................................................................................24
4.1 Power On ..................................................................................................................................................................................................24
4.2 Preview ..................................................................................................................................................................................................... 25
4.3 User name and password......................................................................................................................................................................... 25
4.4 PTZ Control ...............................................................................................................................................................................................27
4.5 Manual Record .........................................................................................................................................................................................27
4.6 Playback.................................................................................................................................................................................................... 28
4.7 Backup Recorded Files.............................................................................................................................................................................. 29

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 4 -
5Parameters Setup Guide..................................................................................................................................................................................... 32
5.1 Basic Setting .............................................................................................................................................................................................32
5.1.1 Administrator and Password .........................................................................................................................................................32
5.1.2 Add and Delete User ......................................................................................................................................................................33
5.1.3 Unit Name and Device ID............................................................................................................................................................... 34
5.2 Local Preview Setup .................................................................................................................................................................................35
5.2.1 Video output standard................................................................................................................................................................... 35
5.2.2 Screen Saver Setup ........................................................................................................................................................................ 35
5.2.3 OSD Setup ......................................................................................................................................................................................35
5.2.4 Video Parameters Setup ................................................................................................................................................................36
5.2.5 Mask Area Setup ............................................................................................................................................................................36
5.2.6 Preview Properties.........................................................................................................................................................................37
5.3 Alarm setup ..............................................................................................................................................................................................38
5.3.1 External Alarm Input and Relay Output......................................................................................................................................... 38
5.3.2 Motion Detection Alarm ................................................................................................................................................................ 40
5.3.3 Video Loss Alarm............................................................................................................................................................................42
5.3.4 View Tampering Alarm .................................................................................................................................................................. 42
5.4 Recording Setup ....................................................................................................................................................................................... 42
5.4.1 Recording parameters description ................................................................................................................................................ 43
5.4.2 Pre-Record Time and Post-Record Time........................................................................................................................................ 43
5.4.3 Record Schedule Setup ..................................................................................................................................................................43
5.5 Network Parameters ................................................................................................................................................................................44
5.6 PTZ ............................................................................................................................................................................................................45
5.7 Exceptions.................................................................................................................................................................................................47
5.8 Mobile Setup ............................................................................................................................................................................................48
5.8.1 Boot & Halt Setup ..........................................................................................................................................................................48

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 5 -
5.8.2 GPS Setup....................................................................................................................................................................................... 49
5.8.3 Server Login Setup .........................................................................................................................................................................50
6Utilities ................................................................................................................................................................................................................51
6.1 Save Parameters....................................................................................................................................................................................... 51
6.2 Restore Parameters.................................................................................................................................................................................. 51
6.3 Upgrade ....................................................................................................................................................................................................52
6.4 Hard Disk Management............................................................................................................................................................................ 52
6.5 Clear Alarm Out ........................................................................................................................................................................................53
6.6 Reboot ......................................................................................................................................................................................................53
6.7 Power Off..................................................................................................................................................................................................53
6.8 View Log ...................................................................................................................................................................................................53
6.9 System Information..................................................................................................................................................................................54
Appendix A HDD Capacity Calculation.......................................................................................................................................................................55
Appendix B ETHERNET Connect Cable Made Method...............................................................................................................................................57
Appendix C Specifications..........................................................................................................................................................................................58
Appendix D FAQ .........................................................................................................................................................................................................60

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 6 -
1Production Description
1.1 Overview
Embedded digital net recorder DS-8100HM-B, which is an excellent product designed for vehicle surveillance. It combines the latest technology from fields of
IT, mechanism and electronics, such as, video and audio compression & decompression, recording of high capacity hard disk, hard disk vibration- proof and bracing
technology, TCP/IP, GPS, wireless, etc.
DS-8100HM-B is an integration of DVR and DVS, can either work alone or in groups basing on internet.
In addition, built-in application code in FLASH definitely makes it more stable.
Key features:
Support SATA;
Adopt patented army technology of high shock tolerance for hard disk;
Support ignition power on;
Support shutdown delay and auto power on/off;
Support GPS and automatic time sync;
Specific platform for vehicle remote monitoring;
Support variety of wireless networks video transmission.
1.2 Key Functions
Compression technology
· 4-ch PAL/NTSC Vin, H.264 based. Choice of changeable bit rate and frame rate, configurable video quality and data rate;
· Each channel supports 4CIF (6fps), DCIF (12fps), 2CIF (15fps), CIF (full frame) and QCIF (full frame) encoding;

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 7 -
· 1-ch AIN, 16kps OggVorbis standard real-time compression;
· Choice of synchronously mixed video & audio and single video;
· Support dual-stream, local storage and wireless network transmission can be set separately;
· Support video parameters dynamic setting;
· Support OSD and LOGO.
Feature of local process
Video recording
· Variety of recording models: Schedule recording, manual recording, alarm recording, etc;
· Support 1 or 2 SATA, adopt patented army technology of high shock tolerance for hard disk;
· HD format FAT32;
· Management locking ensures the security of key information;
· Pre-allocation and low-seeking technology ensure recorded data be effectively scanned;
· SMART;
· Choice of recording modes cycle and non-cycle;
·Support USB 2.0, recordings backup to flash disk, USB HD, USB CD/DVDRW.
Preview and playback
· Portion (or whole) video mask;
· Portion (or whole) video mask alarm;
· Choice of playback modes fast forward, fast backward and single frame; Search by recording type and time;
· Indication of recording and alarm status.
Alarm
· Support speed limit alarm;
· 4-ch input alarm, 2-ch output alarm;
· Choice of alarm types motion detected, mask, video loss and sensor input;
· Alarm schedule setup;
· A series of exception alarm, such as HD error and video format conflict.
Security
· Customizing authority for operators by the administrator. Support multi-administrators, more flexible security management;
· Channel based authority;
· A supper user with user name admin, password 12345.
Network

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 8 -
· TCP/IP based;
· Wireless comfortable compression technology;
· Software for alarms e.g. switch triggered, abnormity and GPS;
· Screen capture at client software;
· Track tracing and video playback at client side;
· PPP enabled;
· Log system.
Client developing
· SDK provided;
· DEMOs with source code provided.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 9 -
2Installation help
2.1 Check device and accessories
Please check carefully according to the list inside once you get it.
2.2 SATA Installation
Note: Please make sure the operation is under power off.
DS-8100HM-B Installation Steps
1. Please prepare all the tools and
materials: 2.5 inch SATA HD,
anti-static gloves, HDD-Lock key,
cross screwdriver, HD screws
2. Firstly, open the HD-Lock with
the key, and loosen the screw
alone the anti-clockwise. Then
pull out the HD box with uniform
force.
3. Remove the 6 screws used for
fixing the HD bracket on the right
and left sides.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 10 -
4. Upward Push out the HD
bracket on the side of baffle with
appropriate force.
5. Please wear antistatic gloves.
Carefully put in the first HD on the
bracket (PCB face down), aim at
the HD interface and insert it
tightly.
6. Put in the second HD on the
bracket (PCB face down), aim at
the HD interface and insert it
tightly.
7. Restore the HD bracket
position, aim at the holes and
tighten the screws.
8. Install the HD screws, and
fasten the HDs (4 screws per HD)
9. After the HD installation, push
in the HD box and screw up. Don’t
forget to lock the HD-Lock.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 11 -
Note:
1. Tips for HD purchase: please choose recommended high-quality HD from creditable provider, that should be comfortable for longtime and frequent read
& write;
2. HD should be formatted after the installation, or there may be HD error with alarm. Format method please refer to section 6.4 ;
3. With the default configuration, the corresponding recording times for different Volume are:
HD volume (Unit:
GB)
Recording time(Bit
Rate: 512Kbps Unit:
Hour )
Recording time(Bit
Rate: 1Mbps Unit:
Hour )
Recording time(Bit
Rate: 1.5Mbps
Unit: Hour )
160 720 360 240
250 1136 568 378
320 1456 728 485
500 2274 1137 758
750 3400 1700 1133
Declaration: Recording time may be not so precise, it is just for reference, and we will not take the responsibility for this.
2.3 SIM/UIM card installation

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 12 -
2.4 Rear Panel Interface Description
DS-8100HM-B rear panel is shown as below: (Note: the descriptions are subject to the physical product)
Fig 2.1 DS-8104HMI-B rear panel
1. Reverse the device, loosen
the screws of the wireless
network module board on the
right corner
2. Carefully overturn the board
with wireless module, use your
finger press the yellow
handspike softly (as shown).
The slot will pop-up.
3. Unplug the pop-up slot, insert
the SIM/UIM card, and please
note the card missing angle
should fit the slot.
4. Insert the SIM/UIM card back
to the module, and fasten the
screws on the board.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 13 -
2.5 KEY Ignition Switch Connection
Note:
1. Please connect the KEY interface of DVR to the Vehicle Ignition Switch (for time-delay shutdown function) or batteries (for auto on-off function), or
else the device can not start up.
No
. Interface Physical Name Description
1 DC IN Power Input Connect the power input (Note: If the vehicle battery connected, please access
a fuse in the battery anode).
2 KEY Ignition Switch Connect to ignition switch or battery (Please refer to 2.4)
3 KB Wire Remote
Control Interface Connect to wire remote control.
4 DC OUT Power Output Power output 12VDC/5VDC for cameras ,etc.
5 RS-485 PTZ Interface Connect to PTZ or G-mouse.
6 ALARM IN Alarm Input Connect to alarm input (4-ch switch signal input, please refer to 2.5).
7 (ALARM)
OUT Alarm Output Connect to alarm output (1-ch switch signal output, please refer to 2.5).
8 LAN LAN Interface Connect to ETHERNET devices, e.g. ETHERNET exchanger, HUB, etc. Cable made
method please refer to Appendix 2;
9 AUDIO
IN,OUT
Audio Input/
Output AUDIO IN connects to microphone; AUDIO OUT connects to speaker.
10 VIDEO
OUT Video Output Connect to monitor, the upper one is main output for local preview and menu display, the other one is aux output for local preview.
11 VIDEO IN Video Input Connect to Camera, BNC interface.
12 USB USB Interface Connect to USB devices, e.g. FLASH disk, USB HD
13 AN1,An2 Antenna Interface Connect to main and aux antennas of wireless network

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 14 -
2. Please make sure that the positive pole of DVR power line connects the positive pole of vehicle batteries with the fuse.
1. Key interface connected to the vehicle ignition switch for DVR function of vehicle ignition startup and time-delay shutdown. There
are two kinds of vehicle ignition switch:
(1)Positive pole ignition switch:
Ignition switch are connected to the positive pole of DC+12/24V of vehicle batteries.
Vehicle Batteries
+12/24V GND
Device
Ignition Switch
Fig 2.2
(2)Negative pole ignition switch:
Ignition switch are connected to the GND of vehicle batteries.
Vehicle Batteries
+12/24V GND
Device
Ignition Switch
Fig 2.3
Please make sure that the connection is correct, and detailed descriptions are as below:
Note: Please contact the vehicle battery manufacture for the information on the voltage polarity.
(1) Connection of Positive Pole Switch (Fig 2.4):

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 15 -
Connect the “DC IN +” of DVR to the positive pole of vehicle batteries;
Connect the “KEY +” of DVR to the vehicle ignition switch;
Connect the “GND” and “KEY -” of DVR to the negative pole of vehicle batteries.
(2) Connection of Negative Pole Switch (Fig 2.5):
Connect the “DC IN +” and “KEY +” of DVR to the positive pole of vehicle batteries;
Connect the “KEY -” of DVR to the vehicle ignition switch;
Connect the “GND” of DVR to the negative pole of vehicle batteries.
After KEY connected to the switch, when switch on, the DVR will start up with the vehicle; when switch off, the DVR will shut down within the preset
delay time. More information on the time-delay shutdown function can be found in section 5.8.1
2. Key interface connected to the vehicle batteries for the DVR auto on-off function:
Please refer to the section 5.8.1 for details.
Vehicle Batteries
GND
KEY +
+12/24V
KEY -
Ignition
Switch
DC IN + DC IN -
Fig 2.4
Vehicle Batteries
GND
KEY +
+12/24V
KEY -
Ignition
Switch
DC IN + DC IN -
Fig 2.5
Vehicle Batteries
GND
KEY +
+12/24V
KEY -
DC IN + DC IN -
Fig 2.6

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 16 -
2.6 Alarm Output Connection Guide
Typical Sample
+
-
(n)B DC
(n)A
JJ1
DC LoadAlarm Out
(n)B AC
(n)A
JJ1
Relay
AC Load
Alarm Out
JQC-3FG
Relay
12V DC
GND Output
Power
Supply
Live
Wire
Zero
Line
～220V AC
(n)B
(n)A
On-Off
Output
Mobile DVR
(10A 250VAC)
Please kindly pay attention to different connection for JJ1. While connecting to DC load, the 2 connection mode for JJ1 are both ok, yet it is suggested to use it
under 12V,1A. While connecting to AC load, then JJ1 must be open (unplug the short-circuit port on main board). For safety consideration, it is recommended
to use external relays while connecting to AC load (As the right side figure shows).There are 4 short-circuit port on main board that refers to each alarm output
channels JJ1, JJ2, JJ3, JJ4, which are all in short-circuit mode by default, and must be unplugged while connecting to AC load.
Warnings! Short-circuit port must be unplugged on connect to AC load, and users should also use external relays to avoid device damage and shock hazard!
Connection Description
Detailed steps are as below:
1. Pull out the green plug in the device;
2. Loosen the screws in the plug with mini cross screw, insert the signal wire into the corresponding pinholes;
3. Then insert the green plug into the corresponding socket.

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 17 -
3Operation Guide
3.1 Front Panel Description
DS-8100HM-B Front Panel Description (The descriptions are subject to the physical product.)
LED Indicator Description:
IR: IR Control receiver, please make sure the lamp is unblocked by any object.
Power: Power indicator, red means the device is standby, green means the DVR starts up normally.
Ready: Status indicator, green means the device is in normal working status, can be controlled by remote control.
Record: Recording indicator, green means recording now.
Network: Network indicator, green means the device connect to network, blinks orange means network transmitting.
Alarm: Alarm indicator, red means there are warning messages.
Fig.3.1 DS-8100HM-B

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 18 -
Other interfaces description:
DS-8100HM-B
HD Socket:On the front panel(HDD-LOCK),insert and pull HD bracket from here. Each side of the HD bracket has a bolt for manual fastening the HD
bracket;
HDD-LOCK:”HDD-LOCK”, when the groove of the lock core is upward means the HD is locked, if the groove is leftward means the HD bracket is opened
Note: When insert HDDs, firstly, please fasten the bolts, then lock the HDD-LOCK, otherwise the HDDs will not work.
3.2 IR Control
No. Name Description
1 POWER Reserved
2 DEV Reserved
3 Numeric
Keys
Input number, upper and lower case, symbol, and
Chinese character.
4 EDIT
1. Enter the edit state, and then delete the
character in the front of the cursor;
2. Switch between and × in the status box
5 A
1. Switch between input methods (Number,
English, Chinese, Symbol);
2. Display or hide the channel status in the preview
interface.
6 REC Manual Recording;
7 PLAY Playback;
8 INFO Reserved
9 VOIP Reserved
10 MENU Switch from preview interface to menu interface.
Fig.3.2

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 19 -
11 PREV Multi-screen switch;
12
Direction
Keys
Up [], Down [], Left [], Right []:
1. In menu mode, moving the activity frame by
press [] & [], and selecting the data items by
press [] & [];
2. PTZ Position Control;
3. Playback fast, slow, forward and rewind.
ENTER 1. Confirm when in menu mode;
2. Switch between and × in the status box ;
3. Pause when playback
13 PTZ Enter PTZ Control mode
14 ESC Cancel and return to previous menu
15 Reserved
16 F1 Reserved
17 Lens
Control Adjust Iris, focus and zoom.
18 F2 Reserved

User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0)
- 20 -
3.3 Menu Description
3.3.1 Menu items
Item Option Item Option Item Option
Display
Unit Name
Device ID
Require Password
Screen Saver
Video Standard
Enable Scaler
Menu Transparency
DST
Date & Time
Select Camera
Name & Position
Brightness, Contrast, Hue,
Saturation
OSD & Position
Privacy Mask
View Tampering
Signal Loss
Motion Detection
Copy to Camera
Recording
If HD full Overwrite /Stop Recording
Stream Type, Resolution, Bit Rate Type, Max Bit Rate,
Image Quality, Frame Rate
Enable Recording
Pre-Recording Time & Post-Recording Time
Copy to Camera
Network
Basic network parameters, e.g. IP, Mac…
Multi-cast IP
Http Port
DNS IP
Remote Host & Port
Download Server
PPPoE
Alarms
Alarm In & Type
Alarm Handling
Copy to Alarm In
Alarm Out & Time
Alarm Out Schedule
Copy to Alarm Out
Exceptions
Exception Type
Handle Method: Audible Warning, Upload to Center,
Trigger Alarm Out
PTZ
Camera
Baud Rate, Data Bits, Stop Bits, Parity,
Flow Control, Protocol
PTZ Address
Preset, Sequence, Cruise
RS232 Reserved Preview
Preview Mode
Switch Time
Audio Preview
Display Delay
Layout
