HIK VISION Door Station User manual

Module Door Staon
Quick Start Guide

Legal Informaon
Quick Start Guide
©2019 Hangzhou Hikvision Digital Technology Co., Ltd.
About this Manual
This Manual is subject to domesc and internaonal copyright protecon.
Hangzhou Hikvision Digital Technology Co., Ltd. ("Hikvision") reserves all
rights to this manual. This manual cannot be reproduced, changed,
translated, or distributed, parally or wholly, by any means, without the
prior wrien permission of Hikvision.
Please use this user manual under the guidance of professionals.
Trademarks
and other Hikvision marks are the property of
Hikvision and are registered trademarks or the subject of applicaons for
the same by Hikvision and/or its aliates. Other trademarks menoned in
this manual are the properes of their respecve owners. No right of license
is given to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION
MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL. HIKVISION DOES
NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING
THE USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR
RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF THIS
MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE WHOLLY AT YOUR
OWN RISK AND RESPONSIBILITY.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT
Module Door Staon Quick Start Guide
i

TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT
LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO
ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION
SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH
ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Module Door Staon Quick Start Guide
ii

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note Provides addional informaon to emphasize or
supplement important points of the main text.
Module Door Staon Quick Start Guide
iii

Contents
1 Appearance ................................................................................................ 1
2 Terminal and Wiring ................................................................................... 5
2.1 Terminal Descripon ......................................................................................... 5
2.2 Door Lock Wiring ............................................................................................... 7
2.3 Door Magnec Wiring ....................................................................................... 7
2.4 Exit Buon Wiring ............................................................................................. 8
3 Installaon ................................................................................................ 10
3.1 Congure Sub Module Address ....................................................................... 10
3.2 Two-Module Installaon ................................................................................. 11
3.2.1 Two-Module Surface Mounng .............................................................. 11
3.2.2 Two-Module Flush Mounng ................................................................. 16
3.3 Three-Module Installaon .............................................................................. 20
3.3.1 Three-Module Surface Installaon ......................................................... 20
3.3.2 Three-Module Flush Mounng ............................................................... 26
3.4 More-Than-Three Module Installaon ............................................................ 30
3.4.1 More-Than-Three Module Surface Mounng ........................................ 30
3.4.2 More-Than-Three Module Flush Mounng ............................................ 36
4 Remote Operaon .................................................................................... 44
4.1 Acvate Device ................................................................................................ 44
4.2 Edit Network Parameters ................................................................................ 45
4.3 Add Device ...................................................................................................... 46
4.4 Call Resident .................................................................................................... 47
Module Door Staon Quick Start Guide
iv

4.4.1 Dial via Main Unit ................................................................................... 47
4.4.2 Dial via Nametag Module ....................................................................... 48
Module Door Staon Quick Start Guide
v

1 Appearance
Main Unit
Figure 1-1 Main Unit Appearance
Table 1-1 Appearance Descripon
No. Descripon
1 Microphone
2 Low Illuminaon IR Supplement Light
3 Built-in Camera
4 Loudspeaker
5 Call Buon
6 Nametag
7 TAMPER
8 Network Interface
9Module-Connecng Interface (output)
10 Terminals
Module Door Staon Quick Start Guide
1

Note
•Nametag area supports insert customized name card. The suggested
card size is: 58 (L) x 11.7(W) mm.
•The module connecng interface is used to connect other funcon
module, such as nametag module, keypad module, card reader module,
etc. All these modules are known as sub module.
Nametag Module
Figure 1-2 Nametag Module Appearance
Table 1-2 Appearance Descripon
No. Descripon
1 Call Buon
2 Nametag
3Module-Connecng Interface (output)
4Module-Connecng Interface (input)
5 Debug Port
Module Door Staon Quick Start Guide
2

Keypad Module
Figure 1-3 Keypad Module Appearance
Table 1-3 Appearance Descripon
No. Descripon
1Buon
2Module-Connecng Interface (output)
3Module-Connecng Interface (input)
4 Debug Port
Card Reader Module
Figure 1-4 Card Reader Module
Module Door Staon Quick Start Guide
3

Table 1-4 Appearance Descripon
No. Descripon
1 Card Reading Area
2Module-connecng Interface (output)
3Module-connecng Interface(input)
4 Debug Port
Module Door Staon Quick Start Guide
4

2 Terminal and Wiring
2.1 Terminal Descripon
Main Unit Terminals
Figure 2-1 Main Unit Terminals
Table 2-1 Descripons of Terminals and Interfaces
No. Interface Descripon
A1 NC1 Door Lock Relay Output (NC)
A2 NO1 Door Lock Relay Output (NO)
A3 COM Common Interface
A4 NC2 Door Lock Relay Output (NC)
A5 NO2 Door Lock Relay Output (NO)
A6 GND Grounding
A7 12 VDC Power Supply Output
A8 GND Grounding
B1 AIN2 For the access of Door Magnec 2
B2 AIN1 For the access of Door Magnec 1
B3 AIN3 For the access of Exit Buon 1
Module Door Staon Quick Start Guide
5

No. Interface Descripon
B4 AIN4 For the access of Exit Buon 2
B5 485- Module-connecng Interface
B6 485+
B7 12 V OUT
B8 GND
C LAN PoE Network Interface(Supports IEEE
802.3af/at-Compliant Devices)
Sub Module Terminal
Figure 2-2 Sub Module Terminal
Table 2-2 Descripon
No. Interface Descripon
A1 485- Module-Connecng Interface (Input)
A2 485+
A3 12V IN
A4 GND
B1 485- Module-Connecng Interface (Output)
B2 485+
Module Door Staon Quick Start Guide
6

No. Interface Descripon
B3 12V OUT
B4 GND
2.2 Door Lock Wiring
Figure 2-3 Door Lock Wiring
Note
•Terminal NC1/COM is set as default for accessing magnec lock/electric bolt;
terminal NO2/COM is set as default for accessing electric strike.
•Lock should be powered by itself. Max. voltage and current for relay is 30V and
1A.
2.3 Door Magnec Wiring
Module Door Staon Quick Start Guide
7

Figure 2-4 Door Magnec Wiring
Note
AIN1 and AIN2 are defaulted to connect door magnec. Door magnec connected to
AIN1 detects status of the lock that connected to NC1/NO1; Door magnec
connected to AIN2 detects the status of the lock connected to NC2/NO2.
2.4 Exit Buon Wiring
Figure 2-5 Exit Buon Wiring
Module Door Staon Quick Start Guide
8

Note
AIN3 and AIN4 are set as default for connecng exit buon. Exit buon connected to
AIN3 opens the lock connected to NC1/NO1; Exit buon connected to AIN4 controls
the lock that connected to NC2/NO2.
Module Door Staon Quick Start Guide
9

3 Installaon
Note
•Make sure the device in the package is in good condion and all the assembly
parts are included.
•Sub module must work along with the main unit.
•Set the sub module address before start the installaon steps.
•Make sure the place for surface mounng is at.
•Make sure all the related equipment is power-o during the installaon.
•Tools that you need to prepare for installaon:
Drill (ø6), cross screwdriver (PH1*150 mm), and gradienter.
3.1 Congure Sub Module Address
You need to set the sub module address via DIP before installaon.
Steps
1. Remove the rubber cover on the sub module rear panel to expose the DIP
switch.
Figure 3-1 DIP Switch
2. Set the sub module address according to the DIP rules, and install the rubber
cover back.
Module Door Staon Quick Start Guide
10

Note
•Digit 1, 2, 3, 4 are used to coding the sub module address; Digit 5, 6, 7 are
reserved; Digit 8 is a resistance (120Ω) is you set it as on.
•Valid sub module address range is 1 to 8. The No. should be unique for sub
modules that connected to the same main unit.
The sub module address and corresponding switch status as below.
Table 3-1 Descripon
Sub
Module
Address
12345678
Digit 1 ON OFF ON OFF ON OFF ON OFF
Digit 2 OFF ON ON OFF OFF ON ON OFF
Digit 3 OFF OFF OFF ON ON ON ON OFF
Digit 4 OFF OFF OFF OFF OFF OFF OFF ON
3.2 Two-Module Installaon
3.2.1 Two-Module Surface Mounng
Module Door Staon Quick Start Guide
11

Before You Start
Figure 3-2 Mounng Frame
Note
•The dimension of two-module mounng frame is: 219(W)×107 (H)×32.7(D) mm.
•The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1. Paste the installaon Scker 1 onto the wall. Make sure the scker is placed
leveled via measuring with the gradienter.
2. Chisel 4 holes with drill align to the screw holes on the scker. The suggested size
of hole is 6 (diameter) × 25 (depth) mm. The suggested length of cables le
outside is 270 mm.
Module Door Staon Quick Start Guide
12

Figure 3-3 Chisel Screw Holes
3. Remove the scker and insert the expansion sleeves into the screw holes.
4. Fix the mounng frame onto the wall with 4 expansion bolts.
Figure 3-4 Fix the Mounng Frame
5. Thread the module-connecng line across the thread hole of the frame. Pass the
main unit connecng lines across the thread hole to the upper grid.
Module Door Staon Quick Start Guide
13

Figure 3-5 Placement of Lines
6. Connect the cables.
1) Connect the cables and module-connecng line to the corresponding
interfaces of the main unit, then place the main unit into the upper grid.
2) Connect the other end of the module-connecng line to the input interface
of the sub module.
3) Organize the line with cable e in the package. The suggested line
connecon picture as below.
Module Door Staon Quick Start Guide
