HIK VISION DS-3WF01C-2N User manual

User Manual of DS-3WF01C-2N
DS-3WF01C-2N
User Manual

User Manual of DS-3WF01C-2N
User Manual
COPYRIGHT ©2016 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of
Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be
“Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced,
changed, translated, or distributed, partially or wholly, by any means, without the prior written
permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties,
guarantees or representations, express or implied, regarding to the Manual.
About this Manual
This Manual is applicable to DS-3WF01C-2N device.
The Manual includes instructions for using and managing the product. Pictures, charts, images and all
other information hereinafter are for description and explanation only. The information contained in
the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find
the latest version in the company website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various
jurisdictions. Other trademarks and logos mentioned below are the properties of their respective
owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-
INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS,
EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT
YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH
ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

User Manual of DS-3WF01C-2N
Regulatory Information
FCC Information
Attention that changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC compliance: This product has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This product
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
product does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and
comply therefore with the applicable harmonized European standards listed under the EMC
Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU,the RE
Directive 2014/53/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for
specific battery information. The battery is marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body

User Manual of DS-3WF01C-2N

User Manual of DS-3WF01C-2N
5
Table of Contents
Chapter 1 Product Overview..................................................................................6
1.1 Product Advantages ..........................................................................................................6
1.2 Electrical Specifications....................................................................................................7
1.3 Features.............................................................................................................................8
1.4 Using Example..................................................................................................................9
1.5 Hardware Overview..........................................................................................................9
1.6 LED Description .............................................................................................................10
Chapter 2 Installation...............................................................................................11
2.1 Connections and installation ...........................................................................................11
2.2 Restore to Factory Settings .............................................................................................12
2.3 Default Values.................................................................................................................13
Chapter 3 Quick Configuration............................................................................14
3.1 Log in..............................................................................................................................14
3.2 Wizard.............................................................................................................................16
Chapter 4 Status......................................................................................................19
Chapter 5 System....................................................................................................21
5.1 System.............................................................................................................................21
5.2 Administration ................................................................................................................24
5.3 LED Configuration .........................................................................................................25
5.4 Backup / Upgrade ...........................................................................................................26
5.5 Reboot.............................................................................................................................27
Chapter 6 Services ..................................................................................................28
6.1 CAPWAP ........................................................................................................................28
6.2 SNMP .............................................................................................................................29
Chapter 7 Network.................................................................................................33
7.1 Interfaces.........................................................................................................................33
7.1.1 Common Configuration ..................................................................................33
7.1.2 DHCP Server.....................................................................................................36
7.1.3 Add New Interface...........................................................................................37
7.1.4 Router Mode .....................................................................................................39
7.2 Wifi .................................................................................................................................42
7.2.1 Device Configuration.......................................................................................42
7.2.2 Interface Configuration ...................................................................................50
7.3 Firewall ...........................................................................................................................52
7.4 VLAN .............................................................................................................................54
7.5 Ping Watchdog................................................................................................................57
Chapter 8 Logout....................................................................................................59
Chapter 9 FAQ ........................................................................................................59

User Manual of DS-3WF01C-2N
6
Chapter 1 Product Overview
1.1 Product Advantages
DS-3WF01C-2N is specially designed for elevator wireless video transmission and
customized products; compared with the traditional elevator video transmission
products, it has the following advantages:
1. Good anti - jamming ability
Super low frequency power supply interference, electrical spark interference, inverter
motor interference, control signal interference etc. that below tens of kilohertz are
found in the elevator environment, the use of WIFI high-frequency transmission, can
effectively avoid the interference of elevator environment. At the same time the device
supports extended frequency, can avoid the same frequency interference in the
traditional WIFI.
2. Short construction period
In the absence of a large amount of wiring work, so greatly shorten the construction
period, save a lot of human resources.
3. Embedded XTrans technology
DS-3WF01C-2N devices is embedded with XTrans technology, including TDMA,
20M/40MHz bandwidth, intelligent rate control, Auto ACK Time-out adjust. It makes the
device have longer transmission distance, higher throughput and better point-to-multi-
point performance.
4. Embedded hardware watchdog
DS-3WF01C-2N is embedded with hardware watchdog, which is used to monitor the
working status of the device. Once the system is not working properly, the device can be
rebooted to guarantee the stability of the system.
5. More Non-standard channels availability
Currently most of the WIFI devices are working at standard 802.11 2.4GHz frequency.
However, standard 802.11 2.4GHz only provide limited channels, and there is serious
interference if there are a lot of 2.4GHz WIFI devices nearby. DS-3WF01C-2N support
more channels near 2.4GHz band, and spread the band to non-standard frequency part.
The advantage of working at the non-standard band is to avoid the interference in the
standard channels, and the wireless throughput can be improved.

User Manual of DS-3WF01C-2N
7
Note: Please confirm whether those non-standard channels are permitted locally before
using them.
1.2 Electrical Specifications
DS-3WF01C-2N electrical specifications as shown below:
Table 1-1 Electrical Specifications
Items
Specifications
Wireless
Standard
IEEE802.11 b/g/n（2T2R 300Mbps）
Operation
Frequency
2412～2472 MHz(More Non-standard channels is
availability,2312MHz-2732MHz)
Antenna
Internal, 6dBi, H: 65° V: 60°
Max Output power
27dBm
Receive Sensitivity
-72dBm@65Mbps，-97dBm@1Mbps
Operation
Frequency
11n：300Mbps(HT40)，130(HT20)
11g：54Mbps
Hardware
Power supply
I/P:12V 1A/PoE48V,0.1A
Interface
3×10/100M Base-TX (Cat. 5/5E，RJ-45) ports
Operation
Temperature
-30℃～+65℃
Storage
Temperature
-40℃～+85℃
Operation
Humidity
5%～95%RH
Dimensions:
150*150*31.6mm
Software
Application
scenarios
Elevator Car / Elevator Room
Encryption
WPA-PSK/WPA2-PSK
Network
Router/Bridge
Security
MAC filter, SSID hidden
Network Protocol
TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP

User Manual of DS-3WF01C-2N
8
TDMA
Supported (Avoid 802.11 hidden-node problems, and
improve the point-to-multi-point performance)
Auto ACK timing
Adjust
Supported
Management and
Logs
NTP, SNMP, Syslog, Telnet, AC
Web based
Configuration
Supported
Firmware Update
Supported
Bandwidth
supported
20M/40MHz
1.3 Features
High performance 802.11n 2×2 MIMO chip
It supports four operating modes: Access Point, Client, Access Point (WDS), Client
(WDS)
Integrated XTrans technology, including TDMA, intelligent rate control, Auto ACK
Time-out adjust
TDMA solves the problems of hidden-node problem in the 802.11 network, thus
having better long-distance and PTMP performance
Support point-to-point, point-to-multipoint connection
Unique antenna, RF amplifier, and low noise receiver to ensure long-distance video
transmission
Web based working scenario selection makes the installation and setting much
easier
Multi-network interface design, more conducive to the expansion of a variety of
applications
Web-based configuration, easy to use

User Manual of DS-3WF01C-2N
9
High temperature flame retardant housing ensure stable operation in harsh
environments
1.4 Using Example
DS-3WF01C-2N products can be used inside the elevator shaft to survey the video
transmission, while the use of multiple network interfaces equipped with elevator
advertising machine to real-time updates. Backhaul data networks can rely on existing
properties or assembling outdoor wireless device.
Figure 1-1 DS-3WF01C-2N Using Example
1.5 Hardware Overview
Hardware information of DS-3WF01C-2N is described in the following Table:
Table 1-2 Hardware Information
Hardware Specifications

User Manual of DS-3WF01C-2N
10
CPU/Baseband Radio
Atheros QCA9531
Memory
64MB DRAM, 8MB Flash
Physical Interface
3×10/100M Base-TX (Cat. 5/5E, RJ-45) Ports
LED
LAN, WLAN, 3×Link Quality
1.6 LED Description
DS-3WF01C-2N use LED to reflect the current status of working and quality of the
connection. LED is mainly divided into two parts, status of the device and the quality of
the connection. As shown on the picture, the first left LED indicator for the LAN, the
second from the left for the WLAN indicator light, the middle three signal strength
indicator, as specified in the following Table:
Figure 1-2 LED
Table 1-3 LED Information
LED
Color
Status
LAN
Yellow
The light indicates there is an external
device connects to the LAN port which is the
LAN1 port of DS-3WF01C-2N.
WLAN
Green
The light indicates that the wireless DS-
3WF01C-2N is enabled.
Blinking means enabled wireless devices,

User Manual of DS-3WF01C-2N
11
and is sending the wireless data.
Signal Level
Red
The light indicates the signal level
Green, yellow and red lights on, indicates
the wireless signal level is high
Yellow and red lights on, indicating signal
level is medium
Only red light on, indicating that the signal
is weak or no signal
Yellow
Green
Chapter 2 Installation
2.1 Connections and installation
The installation of DS-3WF01C-2N as shown in the following figure:
Figure 2-1 Connections

User Manual of DS-3WF01C-2N
12
1. DS-3WF01C-2N Device
2. I/P: 12V 1A power adaptor (Model: DSA-12G-12FEU 120120; Brand: DVE)
3. Mount Bracket
4. Three LAN port on the device can be connected to the camera
There are two devices within a package: DS-3WF01C-2N (T) and DS-3WF01C-2N (R), two
I/P: 12V 1A power adaptors. The DS-3WF01C-2N (T) should be mounted on top of the
elevator car; it’s normally linked up with network cameras and other network
advertising screens equipment through the network cable. DS-3WF01C-2N (R) should be
installed in the elevator room, for receiving the network signal. The two devices can be
fixed by each hoop.
You can use I/P: 12V 1A power supply for the device. The LAN port of the device can be
used for connecting cameras.
2.2 Restore to Factory Settings
In some cases, users can restore the device to factory settings. Push the reset button for
5~10 seconds and wait for 2~3 minutes. The device will restore to factory settings.
Figure 2-2 Reset

User Manual of DS-3WF01C-2N
13
2.3 Default Values
There are two DS-3WF01C-2N devices: DS-3WF01C-2N (T) and DS-3WF01C-2N (R), a
twin pack. They can be used directly without debugging after installation, the main
parameters of the default factory settings as shown below. If you want to change the
default values and other parameters, please read the manual in the following sections.
Table 2-1 Main parameters at the factory settings
Items
Elevator Car / DS-3WF01C-
2N(T)
Elevator Room / DS-3WF01C-
2N(R)
Wireless
mode
Access Point
Client
IP address
192.168.1.35
192.168.1.36
User name
root
root
Password
admin
admin
SSID
Wireless-Bridge
Wireless-Bridge
Hidden SSID
Enable
N/A
Channel
6(2.437 GHz)
Auto
Encryption
WPA2-PSK Key:
1234567890abc
WPA2-PSK Key:
1234567890abc
Network
mode
Bridge
Bridge

User Manual of DS-3WF01C-2N
14
Chapter 3 Quick Configuration
3.1 Log in
To log in the DS-3WF01C-2N device, you need to configure the TCP/IP of your computer
first as the following steps:
1. Right click Local Area Connection icon of your computer and click properties, then
click Continue, the Local Area Connection Properties dialog box appears as shown
below:
Figure 3-1 Local Area Connection Properties
2. Select Internet Protocol (TCP/IP) and click Properties button, and the following
dialog box appears:

User Manual of DS-3WF01C-2N
15
Figure 3-2 IP Settings
3. As shown in the figure above, IP address should be set to 192.168.1.*, but cannot
be the same as DS-3WF01C-2N, here * can be a number between 1-255 (but not 36
or 35) since the DS-3WF01C-2N (T) default IP address is 192.168.1.35, and the DS-
3WF01C-2N(R) default IP address is 192.168.1.36.
4. Input the default IP 192.168.1.36 or 192.168.1.35 into the address bar of your web
browser, click Enter.
5. Input the user name and password (default is root/admin), the you can log in to the
web configuration menu of the DS-3WF01C-2N device

User Manual of DS-3WF01C-2N
16
Figure 3-3 DS-3WF01C-2N Login Page
3.2 Wizard
Users can quickly configure DS-3WF01C-2N according to the following steps through the
wizard in this chapter.
1. The first page shown after log in is the Status page, which indicates the working
status, current setting, software version and other information of the DS-3WF01C-
2N device. User can switch to other pages by clicking the main menus.

User Manual of DS-3WF01C-2N
17
Figure 3-4 Status–DS-3WF01C-2N (T)
2. Click Wizard. The page goes to Wizard page as shown below, and this page helps to
set the basic network parameters. The default mode is Bridge mode, and the
default LAN IP address of DS-3WF01C-2N (T) is 192.168.1.35, the default LAN IP
address of DS-3WF01C-2N(R) is 192.168.1.36. If the user wants to configure the
device to Router mode, please refer to chapter 7.
Note: If there are several DS-3WF01C-2N devices connected in the Point-to-Point or
Point-to-Multi-Point topologies, they must be configured to different IP address to avoid
conflicts.

User Manual of DS-3WF01C-2N
18
Figure 3-5Wizard –DS-3WF01C-2N (T)
Elevator Car: (AP mode), in this scenario mode, DS-3WF01C-2N will be set to AP mode;
it can be connected to a client device. When you close the TDMA function, your phone
or laptop can connect to the DS-3WF01C-2N. If you need other wireless configurations
in detail, please refer to chapter 7.
Figure 3-6 Wizard –DS-3WF01C-2N (R)
Elevator Room: In this scenario mode, DS-3WF01C-2N will be set to client mode; it can
be connected to an access point device.
Notes: The default SSID of DS-3WF01C-2N (T) and DS-3WF01C-2N (R) is Wireless-Bridge,
and they can be directly interconnected and transmit audio and video or data, if there
are other DS-3WF01C-2N equipment within 500 meters, you should change SSID to
different one in order to avoid connection confusion, please refer to chapter 7 to see
how to modify the SSID.

User Manual of DS-3WF01C-2N
19
3、Click Save & Apply button, the device will reboot and apply your configuration.
Figure 3-7 Complete wizard settings
Chapter 4 Status
The status page is the first page after logging in, the page displays the current
configuration and working status of the device. It is the first item in the menu bar, as
shown in figure:

User Manual of DS-3WF01C-2N
20
