HIKOKI CF 18DSL User manual

CF 18DSL •CF 18DSAL
CF18DSL CF18DSAL
Handling instructions
0000BookCF18DSL.indb10000BookCF18DSL.indb1 2017/12/0510:26:322017/12/0510:26:32

2
power source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and safer
at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power toolʼs operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery pack
may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the offposition before connecting to
0000BookCF18DSL.indb20000BookCF18DSL.indb2 2017/12/0510:26:322017/12/0510:26:32

3
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS STEEL REBAR CUTTER
SAFETY WARNINGS
WARNING
1. Do not undertake tasks that go beyond the cutting
capabilities of this tool as listed in the specifications
column. Also, do not cut hard materials whose tensile
strength exceeds 490 N/mm2. Doing so could result in
injury from flying fragments.
Rebar
490N/mm2
2. Make sure to use the product with the anti-scattering
guard attached at all times. Never use the tool with the
guard removed.
Anti-scatter guard
3. Always wear a helmet, safety boots and other protective
equipment when working.
4. Hydraulic oil is flammable and the following precautions
should be taken to avoid fire.
○Do not remove the pump cases oil plug during operation
or when the tool is warm.
○Replenish hydraulic oil after the tool has sufficiently
cooled.
○When replenishing hydraulic oil, choose a location
where there are no combustibles in the vicinity and
avoid any spilling. Should the oil be spilled, make sure to
thoroughly wipe it up.
○Do not smoke when replenishing hydraulic oil or while
operating the tool.
○Do not operate the tool near the location where hydraulic
oil was replenished.
5. When cutting rebar, make sure that the rebar is deeply
sandwiched between the cutting block. If not placed
deep enough, the cutter block may be damaged or
fragments may fly, resulting in accident or injury.
Rebar Cutter block
6. Never set the rebar in a slant where it sticks out above
the anti-scatter guard.
Rebar
Cutter block
Anti-scatter
guard
7. When operating the switch, never place your fingers
near the cutter block. Doing so can result in injury.
8. Do not cut rebar down to a length that is any shorter than
30 cm. Also, do not cut 2 or more rebars at one time.
Doing so can result in flying fragments that may result in
accident or injury.
Rebar Rebar
Cutter
block
30cm
9. Do not use a damaged cutter block. Replace it with a
new one as a damaged cutter block will not only cause
damage to the tool, but accidents as well. If deformed,
the cutter block can be used by changing the direction in
which it is attached.
Cutter block
Cutter block
blade
0000BookCF18DSL.indb30000BookCF18DSL.indb3 2017/12/0510:26:322017/12/0510:26:32

4
Cutter block deformation
10. Prior to use, conduct a trial run. If during the trial run or
while using the tool, there are any indications of trouble,
abnormal sounds or abnormal vibrations, immediately
switch offthe tool , discontinue use and arrange for
inspection or repairs with a HiKOKI Authorized Service
Center. Continued use may result in injury.
11. If you accidentally drop or bump the tool, check it for
damage, cracks or deformities. If there are any, they may
result in injury.
CAUTION
1. Before operation, inspect the cutter block and housing
for loose bolts, hydraulic oil volume etc. Also, make sure
to remove any attached tools such as a wrench.
2. Make sure to remove the battery when inspecting,
cleaning or exchanging the cutter block. Accidentally
switching the tool on may result in injury.
3. Make sure there is nobody below when working in high
locations. Dropping the tool or other materials could
result in accident or injury.
4. Only use genuine hydraulic oil. The genuine oil must
be the equivalent of international ISO auxiliary viscosity
grade 46 (VG46).
5. If hydraulic oil comes into contact with eyes, do not rub.
Wash immediately and thoroughly with clean running
water and contact a physician for treatment. Left
untreated, the oil may lead to eye damage.
6. If hydraulic oil comes into contact with skin, wash
immediately and thoroughly with clean water and soap.
Failure to do so may lead to skin inflammation.
7. If hydraulic oil is accidentally swallowed, do not attempt
to vomit. Immediately contact a physician for treatment.
8. When hydraulic oil is not in use, make sure the lid of the
container is secure and store it in a dark place away from
direct sunlight and out of the reach of children.
9. Do not place the hydraulic oil container near a
combustion source such as heat, flame or sparks. Doing
so may result in explosion.
10. Make sure the battery is securely attached. If not
securely attached, the battery could come loose and
cause injury.
11. Do not throw away battery with regular trash or dispose
in fire.
12. Store the battery in a location out of the reach of children.
13. Use the battery correctly in accordance with its
specifications.
ADDITIONAL SAFETY WARNINGS
1. If the switch does not return to its original position,
immediately discontinue use and arrange for repairs with
the HiKOKI Authorized Service Center.
2. Do not strike or apply strong impact to the switch panel.
Doing so can lead to damage.
3. While operating the tool:
○Make sure the rebar does not slant diagonally.
Rebar
○Keep the switch on until the piston reaches the tip.
○When switched on, the piston will not move forward until
it has completely returned. This is to ensure that the
next oil pressure is not applied while the hydraulic valve
inside the tool remains open.
4. Replace the blade at an early stage. Using a chipped
or deformed blade could result in injury from flying
fragments.
5. Use the provided hex. bar wrench (4 mm) when installing
or removing the cutter block. Using a tool other than the
one provided may result in too much or not enough
tightening that can lead to injury.
6. When replenishing hydraulic oil:
○Always make sure it is done when the temperature of
both the tool and the hydraulic oil is cool. Removing the
oil plug while the tool is hot can result in the oil inside the
tool to spray out and cause accident or injury.
○Try to avoid inserting air when injecting the oil.
Pump case Hydraulic oil
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such a case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes of
overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
0000BookCF18DSL.indb40000BookCF18DSL.indb4 2017/12/0510:26:342017/12/0510:26:34

5
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○During work make sure that swarf and dust do not fall on
the battery.
○Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
○Do not store an unused battery in a location exposed to
swarf and dust.
○Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately stop
further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove it
from the equipment or battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the first time, do not use and return it to your
supplier or vendor.
WARNING
If a conductive foreign matter enters in the terminal of lithium
ion battery, the battery may be shorted, causing fire. When
storing the lithium ion battery, obey surely the rules of
following contents.
○Do not place conductive debris, nail and wires such as
iron wire and copper wire in the storage case.
○To prevent shorting from occurring, load the battery in
the tool or insert securely the battery cover for storing
until the ventilator is not seen.
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe the
following precautions.
WARNING
Notify the transporting company that a package contains a
lithium-ion battery, inform the company of its power output
and follow the instructions of the transportation company
when arranging transport.
●Lithium-ion batteries that exceed a power output of
100Wh is considered Dangerous Goods and will require
special application procedures.
●For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Power Output
2 to 3 digit number
NAMES OF PARTS (Fig. 1 – Fig. 11)
1Anti-scatter guard
2Housing
3Piston
4Release valve
5Pump case
6Brush cap
7Cutter block
8Side handle
9Motor
0Nameplate
!Oil plug
@Adjustment bolt
#Switch
$Battery
%Switch panel
^Remaining battery indicator switch
&Remaining battery indicator lamp
*Light switch: Cannot be used with this tool.
(Rebar
)Cutter block blade
qCutter block deformation
wCutter block fragment
eOpen ended wrench
rHydraulic oil
tHex. bar wrench (5mm)
yHex. bar wrench (4mm)
uHex. Socket bolt
iLatch
0000BookCF18DSL.indb50000BookCF18DSL.indb5 2017/12/0510:26:342017/12/0510:26:34

6
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
CF18DSL / CF18DSAL
: Cordless Steel Rebar Cutter
Read all safety warnings and all instructions.
Always wear eye protection.
Wear head protection
No open flame; Fire, open ignition source and
smoking prohibited
Keep your hands away
Keep your face away
Direct current
V Rated voltage
D max The maximum diameter that can be cut
Disconnect the battery
Light switch: Cannot be used with this tool
Switching ON
Operates the same on either side
Remaining battery indicator switch
The battery remaining power is nearly empty.
Recharge the battery soonest possible
The battery remaining power is a half.
The battery remaining power is enough.
Bites into rebar
Prohibited action
Warning
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 8.
Standard accessories are subject to change without notice.
APPLICATIONS
Cutting rebar to be used for reinforcing concrete
SPECIFICATIONS
Model CF18DSL CF18DSAL
Voltage 18 V
Cutting capacity Up to 16 mm
diameter
Up to 20 mm
diameter
Cutting speed 4 sec. 6.5 sec.
Max. Rebar
hardness Tensile strength 490 N/mm2
Head angle of
rotation 345° 360°
Dimensions
(L×W×H)
370 × 90 × 306 mm
(without side handle)
413 × 103 × 316 mm
(without side handle)
Weight 6.6 kg (BSL1850) 9.4 kg (BSL1850)
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
CHARGING
For rechargable batteries, please charge in according to
the handing instruction of the charger which you are using.
(Fig.3)
REGARDING ENVIRONMENT AND
CONDITIONS OF USE
This tool operates on oil pressure.
When used during the winter season or in cold conditions
the hydraulic oil’s viscosity will excessively rise to dull the
tool’s operation.
In such cases, run the tool through a warm-up operation
prior to use.
How to run a warm-up operation
Without setting up a rebar, switch on the tool and let it
continuously run for 30 to 60 seconds.
WARNING
Do not place your hands in the vicinity of the piston
during warm-up operation.
Depending on the environment and conditions of use, the
hydraulics may heat up (over 50°C). This can lower the
viscosity of the hydraulic oil and reduce its cutting power.
If this occurs, allow the tool to cool down and then resume
operation.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery 2 9
Charging 3 9
Switch operation 4 10
Regarding the switch panel
(Remaining battery indicator) 510
Regarding the rotation mechanism of
the tool head 610
Cutting 7 11
If the tool bites into a rebar 8 12
Changing the cutter block* 9 12
0000BookCF18DSL.indb60000BookCF18DSL.indb6 2017/12/0510:26:342017/12/0510:26:34

7
How to replenish the hydraulic oil 10 13
Check and replacing the carbon brush 11 14
Selecting accessories ―15
*Changing the cutter block
With repeated rebar cutting, the cutter block will sustain
damage such as blade wear, deformation or chipping.
When a worn, deformed or chipped cutter block is
used, the piston may not return due to the rebar not
being fully cut and remaining sandwiched by the cutter
block. Furthermore, this could lead to tool malfunction or
damage to the cutter block.
●1000 cuts per single blade location
The life (number of cuts) of a single location on the
blade is approximately 1000.
●4 blade locations on a single cutter block
There are 4 blade locations on the cutter block which
can be used by re-attaching and changing the facing
of the block 4 times.
●Change the cutter block as early as possible
Change the facing of the cutter block or exchange it if
the blade is chipped or deformed.
Blade
Deformation/
Chipping
MAINTENANCE AND INSPECTION
1. Maintenance after use
After using the tool, put on a pair of leather gloves and
clean offthe metal particles and other waste matter
around the piston.
NOTE
Metal particle buildup can cause the piston to seize up.
WARNING
Do not blow away the waste matter with an airgun or
similar tool.
Sharp-edged fragments can cause injury when scattered
in the air.
2. Check the cutter block
Periodically check the blade for chipping or deformation.
WARNING
Replace the blade at an early stage. Using a chipped
or deformed blade could result in injury from flying
fragments.
3. Check hydraulic oil volume
Over 70% of reduced cutting power is the result of
insufficient hydraulic oil volume. Before using the tool,
always check the hydraulic oil volume.
4. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
5. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
6. Inspecting the carbon brushes (Fig. 11)
The motor employs carbon brushes which are
consumable parts. Since and excessively worn carbon
brush with new ones when it becomes worn to or near
the “wear limit” ⓐ. In addition, always keep carbon
brushes clean and ensure that they slide freely whithin
the brush holders.
NOTE
When replacing the carbon brush with a new one, be
sure to use the HiKOKI Carbon Brush Code No. 999100.
7. Replacing carbon brushes (Fig. 11)
Take out the carbon brush by first removing the brush
cap and then hooking the protrusion of the carbon brush
with a flat head screw driver, etc.
When installing the carbon brush, choose the direction
so that the nail ⓑof the carbon brush agrees with the
contact portion ⓒoutside the brush tube. Then push it in
with a finger. Lastly, install the brush cap.
CAUTION
Be absolutely sure to insert the nail of the carbon brush
into the contact portion outside the brush tube. (You can
insert whichever one of the two nails provided).
Caution must be exercised since any error in this
operation can result in the deformed nail of the carbon
brush and may cause motor trouble at an early stage.
8. Cleaning on the outside
When the power tool is stained, wipe with a soft dry cloth
or a cloth moistened with soapy water. Do not use chloric
solvents, gasoline or paint thinner, for they melt plastics.
9. Storage
Storing in a place below 40°C and out of the reach of
children.
NOTE
Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
significantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, significantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries dead
and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
Important notice on the batteries for the HiKOKI
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the battery is disassembled and modified (such as
disassembly and replacement of cells or other internal
parts).
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
0000BookCF18DSL.indb70000BookCF18DSL.indb7 2017/12/0510:26:352017/12/0510:26:35

8
4 mm 5 mm
CF18DSL
(NK) 11–111
CF18DSAL
(NK) –11111
0000BookCF18DSL.indb80000BookCF18DSL.indb8 2017/12/0510:26:352017/12/0510:26:35

9
1
〈CF18DSL〉
〈CF18DSAL〉
9
9
#
#
&
6
6
0
0
$
$
3
3
4
4
8
8
7
7
@
@
!
!
%
^
5
5
1
1
2
2
23
1
2
$ $
i12
0000BookCF18DSL.indb90000BookCF18DSL.indb9 2017/12/0510:26:352017/12/0510:26:35

10
4
Ϩ

# #
5
&^*
6
〈CF18DSL〉
345°
360°
〈CF18DSAL〉
0000BookCF18DSL.indb100000BookCF18DSL.indb10 2017/12/0510:26:362017/12/0510:26:36

11
7
2
〈CF18DSL〉
345°
360°
〈CF18DSAL〉
30 cm 30 cm
(((
(
(
77
7
$
(@
7
7
(
7
(
##
0000BookCF18DSL.indb110000BookCF18DSL.indb11 2017/12/0510:26:362017/12/0510:26:36

12
8
〈CF18DSL〉
60°
60°
〈CF18DSL〉
〈CF18DSAL〉〈CF18DSAL〉
(
4 4
4 4
9
7
u
uu
uu
u
y
7
7
133
y
)
q
q
q
w
0000BookCF18DSL.indb120000BookCF18DSL.indb12 2017/12/0510:26:362017/12/0510:26:36

13
10

Ϩ
Ϩ
D max
×2
〈CF18DSL〉〈CF18DSL〉
〈CF18DSAL〉〈CF18DSAL〉
#
(
$
!!
!!
t
e
t
e
r5
# # $
(
$
0000BookCF18DSL.indb130000BookCF18DSL.indb13 2017/12/0510:26:362017/12/0510:26:36

14
11
ⓒ
ⓐ
ⓑ
6
6
3 mm
9.5 mm
0000BookCF18DSL.indb140000BookCF18DSL.indb14 2017/12/0510:26:372017/12/0510:26:37

15
UC18YFSL (14.4V – 18V) 329897
18V (Li-ion)
944458 944459
931161 306254 306295 999100
338710
0000BookCF18DSL.indb150000BookCF18DSL.indb15 2017/12/0510:26:372017/12/0510:26:37

806
Code No. C99715011 G
Printed in China
Shinagawa Intercity Tower A, 15-1, Konan 2-chome,
Minato-ku, Tokyo, Japan
0000BookCF18DSL.indb160000BookCF18DSL.indb16 2017/12/0510:26:372017/12/0510:26:37
