RASOR FP862MT Mounting instructions

PNEUMATIC SCISSORS
USE MANUAL
FP862
MT
FP862
MT

2
EN
THE COMPANY
ACKNOWLEDGMENT
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by the two promoting partners
Spinelli and Ciminaghi. For more than sixty years it has been producing automatic cutting
systems, cutting units for textile applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Rasor®can rely on the professional continuity of three generations,
thanks to the precious support of the promoting partner, to his passion, dedication and
great experience of seventy years.
The main characteristic of Rasor®is that each working phase, starting from the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor®has always considered as essential
since the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended to use only original spare parts and to contact the head
office for any maintenance work.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of pneumatic scissors FP862MT and must be
carefully read before using it since it gives important indications with regards
to its safe installation, use and maintenance. Keep it with care.
Before using pneumatic scissors FP862MT, read carefully the following general
safety rules.
• PACKAGING.
After taking off the packaging make sure that the machine is intact. In case
of doubt do not use it and contact an authorized service centre. Do not leave
pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within the
reach of children or disabled persons since they are potential sources of danger.
•AVOIDDANGEROUSENVIRONMENTS.
•KEEPCHILDRENAWAY.
Unauthorized persons, in particular children, must be kept away from the
working area.
• KEEP THE WORKING AREA ALWAYS IN ORDER.
The workplace must always be kept in order and well lightened.
•ALWAYS USE PNEUMATIC SCISSORS FP862MT PROPERLY.
Use the scissors only to carry out the works they have been designed for; do
not use them improperly.
•OBSERVETHEUSEOFTHETOOLS.
Do not cut excessively thick materials and always check blade conditions.
•AVOID ACCIDENTAL STARTINGS.
Before connecting pneumatic scissors FP862MT, make sure that everything
is installed properly.
• CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves approved by Rasor®during
use and maintenance operations (according to UNI EN 388:2004 standard).
•SPAREPARTS.
During maintenance and replacement operations use only original spare parts.
Blade maintenance must be only performed by Rasor®technicians.
• INSTALLATION.
Any installation that is not in conformity with these specifications could jeopardize
your safety and cancels the warranty.

4
EN
The original configuration of the pneumatic scissors must not be changed at all.
On receiving the machine make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the scissors have not been damaged during transport.
Customer Care Technical Service
WARNING
Informative letter
WARNING
The installer and the maintenance man must know the content of this manual. Although
the main features of the machine described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the machine or to meet manufacturing
or commercial requirements at any time and without being obliged to update this
manual immediately.
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONALCOPYRIGHTCONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without
the prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor® Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of
explosions and at high risk of fire.
In case of damage or malfunction, pneumatic scissors FP862MT must not be used until the
Customer Care Technical Service has repaired them.
For any information, please contact
RASOR®ELETTROMECCANICAS.r.l.
ViaV. Caldesi, 6; 20161,MILANO (MI) - ITALY
Phone: [phone];Fax: [phone]
e-mail: [e-mail]
web: www.rasor-cutters.com

EN
5
2. TRANSPORT AND PACKING
2
2
3. PLATE DATA
1
Serial number
Year of production
Model
Motor data READ THE INSTRUCTION MANUAL
USE METAL GLOVES
USE GOGGLES
SHEARING RIS
DO NOT REMOVE THE SAFETY
DEVICES
3
The pneumatic scissors are delivered in a cardboard box, inside which there are various
optionals. The code of the ordered product and its serial number are indicated outside the
package (see picture 1). The following accessories are contained in a bag inside the package:
1) Octagonal blade (8 sides);
2) Butterfly key for blade nut disassembly;
3) Drift for blade disassembly.
The manufacturer's identification and 2006/42/EC STANDARD conformity plate (see picture
below) is located on the front part of the pneumatic scissors.
The plate must not be removed at all, even if the machine is resold. Always refer to the serial
number (written on the plate itself) when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the scissors feeding cable;
such warnings must be strictly followed by everyone dealing with the machine. The company
is not to be held responsible for damage to property or accidents to people which might
occur if the above-mentioned warnings are not observed. In such a case, the operator is the
only person responsible.
MT
1
FP862MT MT
1400

6
EN
4. PRODUCT DESCRIPTION
2
1
3
13
15
5
9
78
10
14
6
11
12 4
The fixture described in this manual is a pneumatic scissor model FP862MT which has been
designed to cut composite materials such as Kevlar, fiberglass or carbon fibre. It is extremely
versatile, light and precise in the cutting operation, suitable also for very difficult cuttings.
One special feature of pneumatic scissors FP862MT is their ability to sharpen the blade in
each moment without disassembling it by means of a grinding wheel mounted on the
scissors head. After carrying out this operation, it is possible to start cutting again. The
pneumatic scissors are provided with a threaded connection to the pneumatic circuits. The
turbine, perfectly balanced, with a high number of revolutions and totally free of maintenance,
reduces the vibrations and the noise to the minimum.
The pneumatic scissors can be used also outdoor and to cut damp or wet materials and
therefore particularly recommended in tannery, dyeworks, etc.
The pneumatic scissors FP862MT are extremely light (they weight only 1 Kg) and handy
and allow carrying out quick and precise cuts, even with curve profiles. The use of compressed
air as source of energy allows working continuously without problems of heating or
motor overload. The mechanical parts are made up of steel and high resistant bronze and
require a lubrication after many working hours.
11/4" gas connection for the air
connector 9 Sharpening button
2Safet device to enable the control
lever 10 Front guard of the blade (movable)
3 Control lever 11 Rear guard of the blade (fixed)
4 Supporting foot 12 Motor support
5 Polygonal blade 13 Silencer
6 Greaser 14 Reference drift
7 Pneumatic motor 15 Counterblade
8Sharpener
Device components

EN
7
7. FIELD OF APPLICATION
6. NOISE LEVEL
5. TECHNICAL FEATURES
The technical data are only indicative and they can be changed without notice.
8sidebladeØ86mm,inH.S.S.steel
5sidebladeØ86mm,inH.S.S.steel
8 side blade Ø 86 mm, in H.S.S. steel treated
with titanium
8 side blade Ø 86 mm, in H.S.S. steel covered
with Teflon
5 side blade Ø 86 mm, in H.S.S. steel covered
with Teflon
8sidebladeØ86mm,inintegralhardmetal
(Widia)
Features of the available blades
86THSS
86THSSTN
86TMD
86PHSSTN
86THSSTF
86PHSS
The maximum acoustic pressure level emitted by pneumatic scissors FP862MT is about 60 dB
(A).
Noise tests have been carried out in compliance with Standard ISO 11202. The device noise
levels, measured at different distances (without any sound wave filtering system), vary in
the extent of few db (A). The noise level has beeen detected with the silencer supplied
with the fixture assembled on the exhaust. The silencer must never be removed.
NOTE
It is advisable for pneumatic scissors FP862MT owners to verify the compliance with the
standard concerning safety of workers: refer to the Local Law. The use of ear
protecting devicesiscompulsory.
Pneumatic scissors FP862MT have been designed, manufactured and assembled to cut every
kind of fabrics or materials, with the exception of metal, plastic or wood, by means of rotary
pentagonal or octagonal blades.
This equipment must not work:
-inareaspronetoexplosions;
- in presence of fine dust or corrosive gases;
- to cut plastic, metal and wooden materials.
It is forbidden to use pneumatic scissors FP862MT for purposes different from the
above-mentioned ones.
86 mm with hard-metal counterblade
1400 rev./min
about 20 mm
400 W with max. pressure
max. 6 bar
1100 g
2000 g
9 litres/sec.
LUX 200
< 2,5 m/s2
0 ~ 55°C
10 ~ 95% without condensate
Cutting working depth
Power
Weight
Pneumatic scissors FP862MT features
Blade diameter
Blade speed
Working pressure
Temperature
Humidity
Weight with package
Air consumption
Minimum light for working operations
Vibrations at the start up

8
EN
8. USE WARNINGS
We recommend following the indications below in order to always work in safety conditions.
All the operations must be carried out complying strictly with the safety rules of the
country where the machine is to be installed.
It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the pneumatic scissors.
The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules and
regulations in force, as well as the special provisions in force in sport and public installations
the Customer declares to know after receiving all the relative necessary information.
The pneumatic scissors work also without their safety protective device and
when the protection guard is lifted. This protective device must NEVER be
removed.
Always check the resistance of the material to be cut and the kind of blade which is being
used.
The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
Only one operator must use the pneumatic scissors always standing behind the guide
handle. Do not make any adjustment while the blade is working.
Always pay attention to the position of the air pipe to prevent it from being cut or
damaged by the blade.
It is allowed to assemble pneumatic scissors FP862MT on machines O.E.M. on condition
that their original structure is not modified. Otherwise, the intervention must be certified
by Rasor®.
The pneumatic scissors FP862MT are equipped with double safety push button with a
lever and a ratchet on the handle: the ratchet prevents the start push button from being
enabled accidentally, the lever operates the scissors. Never remove the ratchet.

EN
9
9. RESIDUAL RISKS
10. USE
4
3
56
B
A
Thecuttingbladecanworkevenwhentheprotectivedeviceisdisassembled.
Even though the pneumatic scissors are safe, operators must pay attention to preserve their
and other people’s safety.
To use the pneumatic scissors manually, proceed as follows:
1) Lay the material to be cut on the table;
2) Connect the air hose to the quick connection “A” (not supplied) (see picture 3);
3) Adjust the pressure gauge (optional) on 6 bar;
4) Put the material on the cutting foot (see picture 4);
5) Push the starting lever after moving the safety device (see picture 5);
6) Push the pneumatic scissors in the desired direction, being careful to keep the material
in front of them as stretched as possible and preventing it from curling in the front
part of the scissors.
NOTE
The thrust on the pneumatic scissors must be as uniform as possible. To carry out linear cuts
with precision (and to follow predetermined paths), we also recommend using the arrow
pointonthefrontprotection(seepoint“B”infigure6).

10
EN
12. BLADE SHARPENING
11. AIR PRESSURE GAUGE (OPTIONAL)
8
1
2
7
5
1
2
3
4
6
7
8
The sharpener button can be used only if the
transparent guard is completely lowered.
WARNING
13. LUBRICATION
The blade must never be dirty with grease or oil.
9
WARNING A
The pneumatic scissors must be necessarily fed with
lubricated air with a pressure of maximum 6 bar.
Rasor®offers, as optional, a reduction unit filter with
a pressure gauge already calibrated with the quantity
of oil to be delivered as optional.
The unit shown also in picture 7 is made up of:
1 - pressure reducer;
2 - valve to drain the condensate;
3 - drip-feed oiler unit;
4-oiltank;
5 - pressure gauge;
6-condensatetank;
7 - pipe fitting to connect the quick connection to
the network;
8 - pipe fitting to connect the quick connection to the scissor.
For the use and maintenance read the instruction sheet supplied with the filter.
After using the machine for some hours without
interruption, or if the machine cutting capacity
is reduced, it is necessary to sharpen the blade.
To carry out this operation, start the blade and
press sharpener “2” on the blade itself (by means
of push button “1”, as shown in picture 8) for 3-
4 seconds. Repeat this operation 2-3 times.
Every 3-4 working hours, it is necessary to lubricate the
gear pair. In order to carry out this operation, remove
protective plug “A” located on the head of the pneumatic
scissors and fill it with the grease supplied. Screw plug
“A” again a few turns. Screw plug “A” a few turns every
2-3 working hours (see picture 9).
