HiLook IPC-D720H-Z User manual

1
Network Dome Camera
Quick Start Guide

Network Dome Camera·Quick Start Guide
2
Quick Start Guide
COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This manual is applicable to Network Dome Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective
owners.

Network Dome Camera·Quick Start Guide
3
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE
LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

Network Dome Camera·Quick Start Guide
4
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions

Network Dome Camera·Quick Start Guide
5
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info

Network Dome Camera·Quick Start Guide
6
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.

Network Dome Camera·Quick Start Guide
7
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.

Network Dome Camera·Quick Start Guide
8
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -30°C to +60°C, or -40°C to +60°C if the
camera model has an “H” in its suffix), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Dome Camera·Quick Start Guide
9
Table of Contents
1 Appearance ..............................................................................10
2 Installation ...............................................................................12
2.1 Memory Card Installation .................................................13
2.2 Camera Mounting..............................................................14
2.2.1 Ceiling Mounting....................................................14
2.2.2 Wall Mounting........................................................17
2.3 Image and Focus Adjusting ...............................................19
2.3.1 Angle Adjustment...................................................19
2.3.2 Zoom and Focus Adjustment.................................20
2.4 Installation of Network Cable Waterproof Jacket
(Optional) .......................................................................................22
3 Set the Network Camera over the LAN.......................................25
3.1 Wiring.................................................................................25
3.2 Activate the Camera ..........................................................26
3.2.1 Activation via Web Browser ..................................26
3.2.2 Activation via SADP Software................................28
3.3 Modify the IP Address.......................................................29
4 Access via Web Browser............................................................33
5 Operate via Hik-Connect App ....................................................35
5.1 Enable Hik-Connect Service on Camera...........................35
5.1.1 Enable Hik-Connect Service via SADP Software...35
5.1.2 Enable Hik-Connect Service via Web Browser .....36
5.2 Hik-Connect Setup.............................................................38
5.3 Add Camera to Hik-Connect .............................................38
5.4 Initialize the Memory Card ...............................................40

Network Dome Camera·Quick Start Guide
10
1Appearance
26
4
3
7
8
5
9
1
10
Figure 1-1 Overview of Camera

Network Dome Camera·Quick Start Guide
11
Description
No.
Description
1
Bottom Base
2
Panning Adjusting Bracket
3
Safety Rope
4
Bubble
5
Network Interface
6
Tilting Adjusting Bracket
7
Lens
8
IR LED
9
Black Enclosure
10
Power Interface

Network Dome Camera·Quick Start Guide
12
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12 VDC or PoE (802.3af). Make
sure your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the mount.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.

Network Dome Camera·Quick Start Guide
13
2.1 Memory Card Installation
Steps:
1. Loosen the screws to remove the bubble.
Figure 2-1 Remove the Bubble
2. Insert the memory card into the slot.
Figure 2-2 Remove the Bubble
3. (Optional) To unmount the memory card, push to eject it.

Network Dome Camera·Quick Start Guide
14
2.2 Camera Mounting
2.2.1 Ceiling Mounting
Steps:
1. Loosen the screws to remove the bubble.
Remove the Bubble
2. Paste the drill template to the place where you want to install the
camera.
3. Drill screw holes and cable hole (optional) in the ceiling according
to the drill template.

Network Dome Camera·Quick Start Guide
15
130
130
The Drill Template
Note:
If you need to route cables through the ceiling, dill a cable hole
according to the drill template. Skip this step if you want to route
the cables on the surface of the ceiling.
4. Route the cables of the camera.
5. Align the holes and secure the camera with the screws.

Network Dome Camera·Quick Start Guide
16
Secure the Camera
Note:
●The supplied screw package contains self-tapping screws,
and expansion bolts.
●For cement ceiling, use expansion bolts to secure the
camera. For wooden ceiling, use self-tapping screws
6. Connect the corresponding cables, such as power cord and
network cable.
7. Power on the camera, and set the network configuration (for
details, refer to 3 Set the Network Camera over the LAN and 4
Access via Web Browser) to check whether the image is gotten
from the optimum angle. If not, adjust the surveillance angle (for
details, refer to 2.3.1 Angle Adjustment).
8. Install the bubble back to the camera and secure it with screws.

Network Dome Camera·Quick Start Guide
17
Secure Black Liner and Bubble
2.2.2 Wall Mounting
The wall mounting bracket is not supplied in the package and should
be purchased separately.
Steps:
1. Loosen the screws to remove the bubble.
Figure 2-7 Remove the Bubble

Network Dome Camera·Quick Start Guide
18
2. Install the bracket to the wall with screws.
Figure 2-8 Install the Bracket
3. Install the cap to the bracket.
Cap
Figure 2-9 Install the Cap to the Bracket
4. Install the camera to the bracket with screws.

Network Dome Camera·Quick Start Guide
19
Figure 2-10 Install the Camera to the Bracket
5. Install the bubble to the camera with the screws.
Figure 2-11 Install the Bubble to the Camera
2.3 Image and Focus Adjusting
2.3.1 Angle Adjustment
Steps:

Network Dome Camera·Quick Start Guide
20
1. Loosen the pan adjusting screw to adjust the pan angle from 0° to
355° and tilt angle from 0° to 75°.
2. Fasten the adjusting screw.
Pan: 0° to 355°
Tilt: 0°to 75°
Angle Adjustment
2.3.2 Zoom and Focus Adjustment
Manually Adjustment
Certain camera models of this series have the lens that zoom and
focus levels must be manually adjusted via zoom/focus lever and you
can use zoom lever and focus lever to adjust the lens.
Steps:
1. Loosen the zoom lever and move the lever between T (Tele) and
W (Wide) to obtain the appropriate angle of view.
