Original operating instructions
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal
injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious
injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to
slight personal injury or damage to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household
waste

2 English 2160456 *2160456*
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions
The numbering reflects the sequence of operations shown in the
illustrations and may deviate from the steps described in the text
Item reference numbers are used in the overview illustrations and
refer to the numbers used in the product overview section
This symbol is intended to draw special attention to certain points
when handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols can be used on the product:
The power tool supports near-field communication (NFC) technol-
ogy, which is compatible with iOS and Android platforms.
Hilti Li-ion battery type series used. Observe the information given in
the section headed Intended use.
Li-ion battery
Never use the battery as a striking tool.
Do not drop the battery. Never use a battery that has suffered an
impact or is damaged in any other way.
1.3.2 Symbols
The following symbols are used:
Read the operating instructions before use.
Instructions for use and other useful information
Rated speed under no load
Revolutions per minute
Direct current (DC)
Diameter
1.3.3 Illustrations
The illustrations in these operating instructions are intended to convey a
basic understanding and may differ from the actual version of the product:
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions.

*2160456* 2160456 English 3
The numbering in the illustrations reflects the order of the work steps
in the illustration and may deviate from the numbering of work steps
in the text.
Item reference numbers are used in the overview illustration. In the
product overview section, the numbers shown in the legend relate to
these item reference numbers.
1.4 Product information
Hilti products are designed for professional use and may be operated, ser-
viced and maintained only by trained, authorized personnel. This personnel
must be informed of any particular hazards that may be encountered. The
product and its ancillary equipment may present hazards when used incor-
rectly by untrained personnel or when used not as directed.
▶Make a note of the designation and serial number printed on the identifi-
cation plate in the following table.
▶Always quote this information when you contact a Hilti representative or
Hilti Service regarding questions about the product:
Product information → page 3
Product information
Drill SF BT 22A
Generation: 01
Serial no.:
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
▶Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.

4 English 2160456 *2160456*
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
▶Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
▶Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
▶When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
▶If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
▶Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position
before connecting to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your finger on the switch
or energising power tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.

*2160456* 2160456 English 5
▶If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
▶Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
▶Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
▶Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery tool use and care
▶Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
▶Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
▶When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.
▶Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.

6 English 2160456 *2160456*
Service
▶Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
2.2 Drill safety warnings
▶Use auxiliary handle(s), if supplied with the tool. Loss of control can
cause personal injury.
▶Hold power tool by insulated gripping surfaces, when performing an
operation where the cutting accessory may contact hidden wiring.
Cutting accessory contacting a "live" wire may make exposed metal parts
of the power tool "live" and could give the operator an electric shock.
2.3 Additional safety instructions
Personal safety
▶Use the tool only when it is in technically faultless condition.
▶Never tamper with or modify the tool in any way.
▶Always hold the tool with the hand on the grip provided. Keep the grip
clean and dry.
▶Avoid touching rotating parts – risk of injury!
▶Wear suitable protective glasses, a hard hat, ear protection, protective
gloves and light respiratory protection while using the power tool.
▶Wear protective gloves also when changing the accessory tool. Touching
the accessory tool presents a risk of injury (cuts or burns).
▶Wear eye protection. Flying fragments present a risk of injury to the body
and eyes.
▶Take breaks between working and do physical exercises to improve the
blood circulation in your fingers. Exposure to vibration during long periods
of work can lead to disorders of the blood vessels and nervous system in
the fingers, hands and wrists.
▶Use a dust removal system and suitable vacuum cleaner whenever
possible. Dust from materials, such as paint containing lead, some
kinds of wood, concrete / masonry / stone containing silica, and minerals
as well as metal, may be injurious to health.
▶Keep the power tool out of reach of children. The power tool is not
intended for use by inexperienced persons who have received no special
training.
▶Observe the national health and safety requirements.
Careful handling and use of batteries
▶Do not use the battery as a power source for other unspecified appliances.
▶Observe the special guidelines applicable to the transport, storage and
use of lithium-ion batteries.
▶Do not expose batteries to high temperatures, direct sunlight or fire.

*2160456* 2160456 English 7
▶Do not disassemble, squash or incinerate batteries and do not subject
them to temperatures over 80°C (176°F).
▶Do not attempt to charge or continue to use damaged batteries.
▶If the battery is too hot to touch it may be defective. In this case, place
the power tool in a non-flammable location, well away from flammable
materials, where it can be kept under observation and allowed to cool
down. Contact Hilti Service after the battery has cooled down.
3 Description
3.1 Overview of the product 1
@Keyless chuck
;Motor cooling air intake
=Grip
%Switch safety lock
&Control switch (with electronic
speed control)
(Belt hook
)Battery
+Air exit
§Battery release button
/Battery display
3.2 Intended use
The product described is a hand-held cordless drill designed for drilling blind
holes in steel using Hilti TXBT… stepped drill bits which is a prerequisite
for driving Hilti XBT threaded studs.
• Use only Hilti lithiumion batteries of the B 22 series with this product.
• Use only Hilti-approved battery chargers to charge these batteries. More
information is available from your Hilti Store or from www.hilti.group
3.3 Switch-on interlock release button 2
The tool is equipped with a switch safety lock that can be used to lock the
control switch, thereby preventing inadvertent starting.
Switch positions
• If the switch safety lock is positioned longitudinally, i.e. in line with the
working direction of the drill, the control switch is locked (the safety lock
is active).
• If the switch safety lock is pointing to the left relative to the working
direction of the drill, the control switch is free to operate (the safety lock
is deactivated).
3.4 Overload and overheating protection
The power tool is equipped with an electronic system to protect against
overloading and overheating. The power tool switches itself off automatically
in the event of overloading or overheating. After releasing the control switch,
the power tool may not restart immediately when the switch is pressed again
(while the power tool is cooling down).

8 English 2160456 *2160456*
Activation of the automatic cut-out is indicated by all 4 LEDs on the
battery display blinking.
3.5 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are
indicated by the display on the Liion battery. The charge status of the Liion
battery is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. Charge status: 75 % to 100 %
3 LEDs light. Charge status: 50 % to 75 %
2 LEDs light. Charge status: 25 % to 50 %
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks, the power tool is
ready for use.
Charge status: < 10 %
1 LED blinks, the power tool is not
ready for use.
The battery has overheated or is
completely discharged.
4 LEDs blink, the power tool is not
ready for use.
The power tool is overloaded or has
overheated.
Battery charge status cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given
in the Troubleshooting section.
3.6 Items supplied
Electric drill, operating instructions.
Other system products approved for use with this product can be found at
your local Hilti Store or at: www.hilti.group
4 Technical data
Rated voltage 21.6 V
Weight including battery B22⁄8.0 5.7 lb
(2.6 kg)
Torque ≤ 7 ftlbf
(≤ 9 Nm)
Keyless chuck clamping range 3/64 in … 25/64 in

*2160456* 2160456 English 9
5 Operation
5.1 Inserting the battery 3
CAUTION
Risk of injury. The drill may start inadvertently.
▶Before fitting the battery, check that the drill is switched off and that the
switch safety lock is activated.
CAUTION
Electrical hazard. Dirty contacts may cause a short circuit.
▶Before inserting the battery, check to ensure that the battery terminals
and the contacts on the drill are free from foreign objects.
CAUTION
Risk of injury. If the battery is not fitted correctly it may drop out and fall.
▶Check that the battery is securely seated in the drill so that it cannot drop
out and fall, thereby presenting a hazard to other persons.
▶Push the battery into the drill from the rear until it is heard to engage with
a click.
5.2 Removing the battery 4
▶Remove the battery.
5.3 Fitting the belt hook (optional) 5
WARNING
Risk of injury! Hazard presented by a falling power tool.
▶A falling power tool may present a risk of injury to yourself and others.
Check that the belt hook is fitted securely before beginning work.
The belt hook allows the drill to be attached to a belt worn by the
operator. The belt hook can be fitted to allow attachment on the left or
right side of the body.
▶Fit the belt hook on the appropriate side of the drill.
5.4 Fitting or removing accessory tools 6
CAUTION
Risk of injury. The drill may start inadvertently.
▶Make sure that the safety lock has been activated or that the battery has
been removed from the drill.
1. Open the keyless chuck.

10 English 2160456 *2160456*
2. Check that the connection end of the accessory tool is clean and then
insert it in the keyless chuck or, respectively, pull the accessory tool out
of the keyless chuck.
3. Retighten the keyless chuck.
5.5 Switching on
▶Press the control switch.
The running speed can be controlled smoothly right up to maximum
speed by varying how far the control switch is pressed in.
5.6 Switching off
▶Release the control switch.
6 Care and maintenance
WARNING
Electrical hazards. Improper repairs to electrical parts may lead to serious
injuries.
▶Electrical parts may be repaired only by trained electrical specialists.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Center or online at: www.hilti.com
▶Keep the tool, especially its grip surfaces, clean and free from oil and
grease.
▶Do not use cleaning agents containing silicone.
▶Never operate the power tool when the ventilation slots are blocked.
Clean the air vents carefully using a dry brush. Do not permit foreign
objects to enter the interior of the tool.
▶Clean the outside of the tool at regular intervals with a slightly damp cloth.
Do not use a spray, steam pressure cleaning equipment or running water
for cleaning. This may negatively affect the electrical safety of the power
tool.
7 Transport and storage
WARNING
Fire hazard. Risk of short circuiting.
▶Never store or transport Liion batteries in loose, bulk form.
▶Remove the battery before transporting or storing the drill.
▶Observe the nationally and internationally applicable transport regulations
when shipping batteries by road, rail, sea or air.

*2160456* 2160456 English 11
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
Trouble or fault Possible cause Action to be taken
The battery doesn’t
engage with an audi-
ble double click.
The retaining lugs on the
battery are dirty.
▶Clean the retaining
lugs and push the
battery in until it
engages. Contact
Hilti Service if the
problem persists.
The control switch
can’t be pressed, i.e.
the switch is locked.
The safety lock is en-
gaged.
▶Push the switch safety
lock to the side (to the
left as seen from the
working direction).
The power tool
doesn’t run.
The battery is not fully
inserted.
▶Push the battery in
until it engages with
an audible click.
The tool doesn’t
work and one LED
blinks.
Low battery. ▶Change the battery
and charge the empty
battery.
The tool cuts out
while operating, the
4 LEDs on the bat-
tery display blink.
The overload cut-out
has been activated.
▶Release the control
switch and then press
it again.
The overheating cut-out
has been activated.
▶Allow the power tool
to cool down. Clean
the air vents.
The battery runs
down more quickly
than usual.
Very low ambient tem-
perature.
▶Allow the battery to
warm up slowly to
room temperature.
The tool or battery
gets very hot.
The tool is overloaded
(application limits ex-
ceeded).
▶Pay attention to the
power and perfor-
mance rating of the
product before using
it, i.e check its suit-
ability for the job on
hand. See “Technical
data” section.
9 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about
the warranty conditions.

12 Français 2160456 *2160456*
Mode d'emploi original
1 Indications relatives à la documentation
1.1 À propos de cette documentation
• Lire intégralement la présente documentation avant la mise en service.
C'est la condition préalablement requise pour assurer la sécurité du travail
et un maniement sans perturbations.
• Bien respecter les consignes de sécurité et les avertissements de la
présente documentation ainsi que celles figurant sur le produit.
• Toujours conserver le mode d'emploi à proximité du produit et uniquement
le transmettre à des tiers avec ce mode d'emploi.
1.2 Explication des symboles
1.2.1 Avertissements
Les avertissements attirent l'attention sur des dangers liés à l'utilisation du
produit. Les termes de signalisation suivants sont utilisés :
DANGER
DANGER !
▶Pour un danger imminent qui peut entraîner de graves blessures corpo-
relles ou la mort.
AVERTISSEMENT
AVERTISSEMENT !
▶Pour un danger potentiel qui peut entraîner de graves blessures corpo-
relles ou la mort.
ATTENTION
ATTENTION !
▶Pour attirer l'attention sur une situation pouvant présenter des dangers
entraînant des blessures corporelles légères ou des dégâts matériels.
1.2.2 Symboles dans la documentation
Les symboles suivants sont utilisés dans la présente documentation :
Lire le mode d'emploi avant d'utiliser l'appareil
Pour des conseils d'utilisation et autres informations utiles
Maniement des matériaux recyclables
Ne pas jeter les appareils électriques et les accus dans les ordures
ménagères

*2160456* 2160456 Français 13
1.2.3 Symboles dans les illustrations
Les symboles suivants sont utilisés dans les illustrations :
Ces chiffres renvoient à l'illustration correspondante au début du
présent mode d'emploi
La numérotation détermine la séquence des étapes de travail dans
l'image et peut se différencier de celles des étapes de travail dans le
texte
Les numéros de position sont utilisés dans l'illustration Vue d’en-
semble et renvoient aux numéros des légendes dans la section Vue
d'ensemble du produit
Ce signe doit inviter à manier le produit en faisant particulièrement
attention.
1.3 Symboles spécifiques au produit
1.3.1 Symboles sur le produit
Les symboles suivants peuvent être utilisés sur le produit :
L'appareil prend en charge la technologie NFC qui est compatible
avec les plates-formes iOS et Android.
Série de type d'accu Li-Ion Hilti utilisée. Observer les instructions au
chapitre Utilisation conforme à l'usage prévu.
Accu lithium-ions
Ne jamais utiliser l'accu comme outil de percussion.
Ne pas laisser tomber l'accu. Ne pas utiliser d'accu ayant subi un
choc ou d'autres dommages.
1.3.2 Symboles
Les symboles suivants sont utilisés :
Lire le mode d'emploi avant d'utiliser l'appareil
Pour des conseils d'utilisation et autres informations utiles
Vitesse nominale à vide
Tours par minute
Courant continu
Diamètre
1.3.3 Illustrations
Les illustrations dans le présent mode d'emploi servent à faciliter la com-
préhension essentielle et peuvent différer de la version effective :

14 Français 2160456 *2160456*
Ces chiffres renvoient à l'illustration correspondante au début du
présent mode d'emploi.
La numérotation des illustrations détermine la séquence des étapes
de travail dans l'image et peut se différencier de la numérotation des
étapes de travail dans le texte.
Les numéros de position sont repris dans la vue d'ensemble relative
à l'illustration. Dans la section Vue d’ensemble des produits, les
numéros des légendes renvoient à ces numéros de position.
1.4 Informations produit
Les produits Hilti sont conçus pour les utilisateurs professionnels et ne
doivent être utilisés, entretenus et réparés que par un personnel agréé et
formé à cet effet. Ce personnel doit être au courant des dangers inhérents
à l'utilisation de l'appareil. Le produit et ses accessoires peuvent s'avérer
dangereux s'ils sont utilisés de manière incorrecte par un personnel non
qualifié ou de manière non conforme à l'usage prévu.
▶Reporter la désignation et le numéro de série qui se trouvent sur la plaque
signalétique dans le tableau suivant.
▶Toujours fournir ces informations en cas de questions relatives au produit
pour communiquer avec notre représentant ou point de service :
Caractéristiques produit → Page 14
Caractéristiques produit
Perceuse SF BT 22A
Génération : 01
N° de série :
2 Sécurité
2.1 Indications générales de sécurité pour les outils électriques
AVERTISSEMENT Lire et comprendre toutes les consignes de sécu-
rité et instructions. Tout manquement à l'observation des consignes de
sécurité et instructions risque de provoquer une électrocution, un incendie
et/ou de graves blessures.
Les consignes de sécurité et instructions doivent être intégralement
conservées pour les utilisations futures.
La notion d'« outil électroportatif » mentionnée dans les consignes de
sécurité se rapporte à des outils électriques raccordés au secteur (avec
câble de raccordement) et à des outils électriques sur accu (sans câble de
raccordement).
Sécurité sur le lieu de travail
▶Conserver la zone de travail propre et bien éclairée. Un lieu de travail
en désordre ou mal éclairé augmente le risque d'accidents.
