HIMS T70ET User manual

HIMS International Blaze ET –User Manual
1
Blaze ET
User Manual
(Model: T70ET)
ENGLISH MANUAL
for Software Version 1.0
(February, 2015)
When there are any manual updates,
the readme files or appendices
will be added to the manual CD
and website.
HIMS International Corporation
174, Gajeong-ro, Yuseong-gu, Daejeon, Korea 305-350
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.himsintl.com

HIMS International Blaze ET –User Manual
2
Congratulations on the purchase of your Blaze ET! The Blaze ET is capable of scanning
printed material and reading DAISY content as well as many standard functions of
portable mainstream media devices, –but with a tactile interface utilizing a full numeric
keypad and a few other intuitively placed buttons rather than using a touch screen!
Before using the Blaze ET, you should read the entire manual to familiarize yourself
with the functions of the Blaze ET. The Blaze ET contains many programs with a variety
of functions, thus, reading the entire manual will allow you to operate the Blaze ET to its
fullest potential.
If you are unable to find a solution to a problem within the manual, or if you need
assistance with the Blaze ET, please email us at [email protected]. You may also
visit us on the web at www.himsintl.com; or, you can call us at [phone].
Copyright 2015. All RIGHTS reserved, HIMS.
This User Manual is protected by copyright belonging to HIMS, with all rights reserved.
The User Manual may not be copied in whole or part, without consent from HIMS.

HIMS International Blaze ET –User Manual
3
Safety Precautions
For your safety and protection of the Blaze ET, please read and abide by the following
safety precautions.
1. The input voltage of the AC adapter is 100V - 240V, and the output is DC 5V / 2A.
2. When the Blaze ET is shipped, the battery may be packaged separate from the unit
to avoid damage. When you use the Blaze ET for the first time, you may need to
open the package, remove the battery, and insert it into the battery slot at the rear
panel of the unit. (See section 1, introduction, for more details on inserting the
battery.) It is possible that the dealer or distributor from whom you purchased the
Blaze ET has already done this for you. The battery may not be fully charged when it
is shipped. Before you use the Blaze ET, you should ensure the battery is fully
charged.
3. When you use the Blaze ET with the battery for the first time, the battery status may
not be displayed accurately. To avoid this, leave the Blaze ET connected to the AC
adapter for about three hours with the unit turned on. If you want to use the Blaze ET
immediately, you may use it while it is charging.
4. If you want or need to remove the battery from the unit, power the unit off, and then
remove the battery. If the unit is connected to AC power, before re-inserting the
battery in to the unit, make certain that the power is off.
There is a risk of explosion if battery is replaced by an incorrect type. Please make
certain to use only battery packs produced specifically for the Blaze ET by HIMS.
Please dispose of used batteries according to the instructions.

HIMS International Blaze ET –User Manual
4
5. When you are using the Blaze ET on battery power, the status of the remaining
battery power is announced when the battery charge is low. When the battery’s
charge falls below 10 percent, connect the AC adapter to the unit for recharging. If
the remaining battery charge drops to three percent, and the unit is not connected to
the AC adapter, the Blaze ET shuts down one minute after the announcement of the
battery’s status. The amount of battery life per charge varies depending on the
options you have set and the number and type of tasks you are running.
6. Your Blaze ET needs to be handled with care. The Blaze ET is a very delicate
machine. Please handle the unit in a proper, careful manner. The Blaze ET is very
sensitive to dust. Make sure to keep the Blaze ET away from dusty environments.
7. Do not use the Blaze ET in a moisture-rich environment such as a bathroom or
shower. This is to prevent damage caused by moisture getting into the device. Do
not touch the AC adapter with wet hands.
8. Do not leave your Blaze ET in closed or high temperature environments such as
inside a car on a hot summer day, as the battery attached to the Blaze ET may be
damaged or catch fire. Please do not let your Blaze ET remain in such environments
for long periods of time.
9. To prevent possible damage to your hearing, do not listen to audio at high volume
levels for long periods.
10. Do not take apart the Blaze ET yourself. Do not have anyone else who is not
authorized by HIMS take apart the Blaze ET. If an unqualified person disassembles
the unit, serious damage may occur to the Blaze ET. If an unauthorized person
disassembles the Blaze ET, the unit is excluded from any free maintenance, and the
warranty becomes void. If any liquid or external force damages the unit, it may also
be excluded from free maintenance, even if the damage occurs during the warranty
period.

HIMS International Blaze ET –User Manual
5
11. Thank you for using the Blaze ET. We value any comments or suggestions you have
for our product. If you have any complaints or suggestions, please provide us with
your comments on our website. We will improve our product based on your
comments and suggestions.
12. This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

HIMS International Blaze ET –User Manual
6
Caution Statement for Modifications
CAUTION: Any Changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment.
Mobile Device RF Exposure Statement
RF Exposure - This device is only authorized for use in a mobile application. At least 20
cm of separation distance between the transmitting antenna device and the user's body
must be maintained at all times.
Model Name: T70ET
Manufacturer Name: HIMS
International Corporation
S/N:
This device complies with part
15 of the FCC Rules.
Operation is subject to the
following two conditions:
1) This device may not cause
harmful interference, and
2) This device must accept any
interference received,
including interference that
may cause undesired
operation.

HIMS International Blaze ET –User Manual
7
Table of contents
1. Introduction.........................................................................................16
1.1 Main Features.....................................................................................................16
1.2 What's in the Box?.............................................................................................17
1.3 Hardware Specifications. ..................................................................................18
1.4 Physical Orientation to the Blaze ET................................................................19
1.4.1 The Top Face. ..............................................................................................20
1.4.2 The Left Edge...............................................................................................21
1.4.3 The Right Edge............................................................................................22
1.4.4 The Top Edge...............................................................................................22
1.4.5 The Bottom Edge.........................................................................................22
1.4.6 The Back Face. ............................................................................................23
2. Getting Started....................................................................................24
2.1 Inserting and Removing the Battery.................................................................24
2.2 Charging.............................................................................................................24
2.3 Powering On/Off.................................................................................................25
2.4 Inserting and Removing the SD CARD.............................................................25
2.5 Connecting to a computer.................................................................................26
2.5.1 Connecting to a PC. ....................................................................................26
2.5.2 Connecting to a Mac. ..................................................................................27
2.6 Folders used in the Blaze ET. ...........................................................................28
3. Basic Functions..................................................................................29

HIMS International Blaze ET –User Manual
8
3.1 The Home Menu. ................................................................................................29
3.2 Adjusting Volume and other properties...........................................................30
3.3 Checking Date and Time. .................................................................................30
3.4 Checking Status.................................................................................................31
3.5 Locking the Keys. ..............................................................................................31
3.6 Stopping Speech................................................................................................31
3.7 Quick Launch commands .................................................................................31
3.8 Menus, Dialogs and Edit Boxes........................................................................32
3.8.1 Using Menus................................................................................................32
3.8.2 Using a dialog box.......................................................................................33
3.8.3 Using an Edit box........................................................................................33
3.9 Using Help Mode................................................................................................35
4. File Manager........................................................................................36
4.1 Executing and exiting the File Manager...........................................................36
4.2 Exploring, selecting and opening content.......................................................36
4.2.2 File Manager Commands............................................................................37
4.2.3 General Navigation......................................................................................38
4.2.4 Reviewing information................................................................................38
4.2.5 Selecting multiple items. ............................................................................39
4.2.6 Opening Content. ........................................................................................40
4.3 Managing Files and Folders..............................................................................40
4.3.1 Copy .............................................................................................................40
4.3.2 Cut/Move ......................................................................................................41

HIMS International Blaze ET –User Manual
9
4.3.3 Delete............................................................................................................42
4.3.4 Renaming a file or folder. ...........................................................................42
4.3.5 Creating a folder..........................................................................................43
4.3.6 Compressing files. ......................................................................................43
4.3.7 Unzipping files.............................................................................................44
5. Using the Media Player.......................................................................45
5.1 Supported Media Formats.................................................................................45
5.2 Playing Audio Files............................................................................................45
5.3 Play and Pause...................................................................................................46
5.4 Getting playback information. ..........................................................................46
5.5 Moving by Track.................................................................................................46
5.6 Moving by Time..................................................................................................46
5.7 Changing Navigation units................................................................................47
5.8 moving to specific locations.............................................................................47
5.8.1 Move to a specified time.............................................................................47
5.8.2 Moving by percentage.................................................................................48
5.8.3 Moving to a specified track. .......................................................................48
5.9 Media Playback settings....................................................................................48
5.9.1 Adjusting Volume, speed, and Equalizer. ................................................49
5.9.2 Shuffle play on/off.......................................................................................49
5.9.3 Setting repeat Play......................................................................................49
5.9.4 Equalizer Settings. ......................................................................................50
5.9.5 Setting Media preferences..........................................................................50

HIMS International Blaze ET –User Manual
10
5.10 Marks.................................................................................................................51
5.10.1 Inserting a Book mark...............................................................................51
5.10.2 Inserting a Voice Mark. .............................................................................52
5.10.3 Inserting a Highlight Mark. .......................................................................52
5.10.4 Moving to a Mark.......................................................................................53
5.10.5 Deleting a Mark..........................................................................................53
5.11 Using the Explorer...........................................................................................54
5.11.1 General Navigation....................................................................................54
5.11.2 moving to specific items...........................................................................55
5.11.3 Moving between the file and folder list....................................................55
5.11.4 review information for files and folders. .................................................55
6. Book Reader........................................................................................56
6.1 Supported File Types.........................................................................................56
6.2 Selecting and playing content. .........................................................................57
6.3 Navigation...........................................................................................................58
6.4 Quick Movement. ...............................................................................................59
6.5 Moving to specific locations.............................................................................59
6.5.1 Moving to a specified time..........................................................................60
6.5.2 Moving by percentage.................................................................................60
6.5.3 Moving to a specified heading. ..................................................................60
6.5.4 Moving to a specified page.........................................................................60
6.5.5 Additional movement functions.................................................................61
6.5.6 Searching for a specific word. ...................................................................61

HIMS International Blaze ET –User Manual
11
6.6 Reviewing information for the current book or file.........................................61
6.7 Marks...................................................................................................................62
6.7.1 Inserting a Book mark.................................................................................63
6.7.2 Inserting a Voice Mark. ...............................................................................63
6.7.3 Inserting a Highlight Mark. .........................................................................63
6.7.4 Moving to a Mark.........................................................................................64
6.7.5 Deleting a Mark............................................................................................64
6.8 Adjusting Volume and Speed. ..........................................................................65
6.9 Switching Daisy Modes.....................................................................................65
6.10 Using The Explorer..........................................................................................66
6.10.1 Entering and Exiting the Explorer...........................................................66
6.10.2 General Navigation....................................................................................66
6.10.3 Moving to specific items...........................................................................66
6.10.4 Moving between the file and folder list....................................................66
6.10.5 Reviewing information for files and folders............................................67
6.11 DAISY and document settings........................................................................67
7. FM Radio..............................................................................................69
7.1 Playing the Radio...............................................................................................69
7.2 Adjusting Radio Volume....................................................................................69
7.3 Navigating Frequencies.....................................................................................70
7.4 Selecting and Moving to Channels...................................................................70
7.5 Using the Internal Speaker................................................................................71
7.6 Recording a Radio Broadcast...........................................................................71

HIMS International Blaze ET –User Manual
12
8. Recording............................................................................................73
8.1 Making a Recording...........................................................................................73
8.2 Listening to a Recorded File.............................................................................73
8.3 Searching for and Deleting Recorded Files.....................................................74
8.4 Setting Recording Options................................................................................74
8.5 Making DAISY recordings. ................................................................................76
9. OCR......................................................................................................77
9.1 Opening and Closing OCR................................................................................77
9.2 Taking a Picture. ................................................................................................77
9.3 Taking continuous pictures. .............................................................................78
9.4 Reading the OCR Result....................................................................................79
9.5 Importing Image Files........................................................................................80
9.5.1 Opening a Captured File.............................................................................80
9.5.2 Opening an External Image File.................................................................81
9.6 Setting OCR Options. ........................................................................................81
9.6.1 Turning Flash On/Off...................................................................................81
9.6.2 Selecting Image Recognition File handling. .............................................81
9.6.3 Deleting All Recognized Text Files............................................................82
10. Web Radio.........................................................................................83
10.1 Executing and exiting Web Radio...................................................................83
10.2 Moving by channel...........................................................................................84
10.3 Searching for Web Radio Channels. ..............................................................84
11. Podcasts............................................................................................86

HIMS International Blaze ET –User Manual
13
11.1 Subscribing to Podcasts.................................................................................86
11.2 Executing and Exiting Podcasts.....................................................................87
11.3 Navigating Feeds and Podcasts.....................................................................87
11.4 Deleting Content. .............................................................................................88
12. Library Services................................................................................89
12.1 Logging In.........................................................................................................89
12.2 Navigating content...........................................................................................89
12.3 Downloading and Playing content..................................................................90
12.4 Returning content to the Online DAISY Bookshelf.......................................91
13. Utilities...............................................................................................92
13.1 Color Reader ....................................................................................................92
13.1.1 opening the color reader ..........................................................................93
13.1.2 using the Color reader..............................................................................93
13.2 Memo.................................................................................................................93
13.2.1 opening the Memo program. ....................................................................93
13.2.2 Adding a memo..........................................................................................94
13.2.3 The Memo list.............................................................................................94
13.2.4 Searching for memos................................................................................95
13.2.5 Deleting memos.........................................................................................95
13.3 Calculator .........................................................................................................96
13.3.1 opening the Calculator..............................................................................96
13.3.2 performing calculations............................................................................96
13.3.3 Using help Mode........................................................................................97

HIMS International Blaze ET –User Manual
14
13.4 The Alarm. ........................................................................................................97
13.4.1 Setting an alarm.........................................................................................97
13.4.2 Deleting an alarm.......................................................................................98
13.5 Setting the Sleep Timer...................................................................................98
13.6 Initializing options............................................................................................98
13.7 Formatting drives.............................................................................................99
13.8 Upgrading Blaze ET firmware. ........................................................................99
13.8.1 Online Upgrade..........................................................................................99
13.8.2 Offline Upgrade........................................................................................100
14. The options menu...........................................................................101
14.1 Global Settings...............................................................................................101
14.2 Guide Voice Settings.....................................................................................102
14.3 Sound Settings...............................................................................................103
14.4 Set Date and Time..........................................................................................103
14.4.1 Manually setting the Date and Time.......................................................104
14.4.2 Synchronizing with a Time Server.........................................................104
14.5 Bluetooth Settings.........................................................................................105
14.5.1 Turning Bluetooth On/Off. ......................................................................105
14.5.2 Connecting a Bluetooth Headset or Speaker........................................105
14.5.3 Disconnecting a Bluetooth Headset or Speaker...................................106
14.6 Using Wireless LAN.......................................................................................106
14.6.1 Checking the Status of Wireless LAN....................................................107
14.6.2 Turning Wireless On/Off. ........................................................................107

HIMS International Blaze ET –User Manual
15
14.6.3 Connecting to a Wireless Network.........................................................108
14.6.4 Deleting a Wireless Profile. ....................................................................108
14.7 checking System Status................................................................................109
15. Appendices: ....................................................................................110
15.1. Appendix 1: The premium Accessory Pack................................................110
15.1.1 Assembling the OCR stand. ...................................................................110
15.1.2 The OCR remote......................................................................................112
15.1.3 The Cradle................................................................................................112
15.2. Appendix 2: Using Blaze ET with Windows Media Player and Windows XP.
.................................................................................................................................113

HIMS International Blaze ET –User Manual
16
1. Introduction.
Thank you for purchasing the Blaze ET OCR multi-player. The Blaze ET is a digital audio
player and portable OCR device manufactured by HIMS International Corporation. It is a
small, lightweight portable device which can play digital books, music files, document
files, DAISY content, FM radio, and can scan and recognize printed text and text image
files with the built-in 5 megapixel camera and OCR software. With the built-in Wi-Fi users
can also utilize Online DAISY, Web Radio and subscribe to and download podcasts.
Blaze ET also includes convenient features like a calculator, memo application and and
an alarm clock.
Though the Blaze ET is a powerful device with advanced features, it remains easy to use,
even for the non-technical person, with many functions available with the press of a single
button.
1.1 Main Features.
This section introduces the key features of the Blaze ET and briefly outlines the main
functions.
1) Use the Media player to play a variety of multimedia file formats including music,
audio books, podcasts, and your own recordings. The Media Player features
navigation by several movement units including tracks and time elements,
adjustment of playback speed and preamp, Equalizer settings, and more. In
addition, by connecting an external CD-ROM drive with an Audio CD inserted, you
can use Blaze ET to play commercial CD's.
2) Use the Book Reader to easily read Daisy books and various document file types.
Navigate by pages, paragraphs, sentences, lines, and other text units. Adjust
reading speed, volume, and pitch, reading of DAISY audio and more. In addition,
by connecting an external CD-ROM, you can also use Blaze ET to read DAISY
books produced on CD.
3) Listen to the FM radio, auto scan for channels, store presets, and record for later
listening.

HIMS International Blaze ET –User Manual
17
4) Use Blaze ET's built-in camera to capture images of printed textbooks, brochures,
or restaurant menus and recognize them using the OCR program. You can also
import images from other sources and recognize them as well.
5) Record via an internal / external microphone, using an Apple-compatible headset
microphone or line-in recording source. Record using mp3 or wave file formats
and adjust a variety of options, such as microphone sensitivity and recording
quality.
6) Listen to media or document playback via a Bluetooth headset connection for
wireless audio listening.
7) Use the Built-in Wi-Fi and included Podcast application to subscribe to and
download podcasts for listening on the go.
8) Use the Web radio application to stream music, news and other audio content
from around the world.
9) Use the Blaze ET as your talking clock even when the power is off, just press the
power button to check the current date and time. Blaze ET also contains an alarm
and sleep timer.
10)Copy, move, delete, rename, compress, and extract files with the built-in File
Manager. Easily navigate files and folders; select files or folders and automatically
launch playback in the associated program.
11)Stay organized with the Memo and Calculator functions. Easily keep track of
phone numbers or other short notes with the Memo function. Perform quick
calculations on the go with the accessible calculator.
1.2 What's in the Box?
Your Blaze ET packing box should contain the following items:
Blaze ET
Rechargeable Battery Pack
Carrying pouch
AC adapter
USB Cable for connecting to PC

HIMS International Blaze ET –User Manual
18
USB Gender adapter
Earbuds
Documentation CD
Getting Started Guide
Optional Accessory Pack:
OCR stand
OCR Remote
Cradle
Spare Battery Pack
Spare AC adapter
1.3 Hardware Specifications.
User memory (internal memory): 12GB
Micro USB OTG port
SD card slot
FM radio
Bluetooth 3.0 (Bluetooth stereo headset support)
Wi-Fi (802.11B/G/N, 2.4GHz)
5-megapixel camera
Headphone jack (3.5 mm, apple compatible headsets can be connected.
Stereo microphone jack (3.5 mm, supports line-in input)
Built-in stereo speakers
Built-in mono microphone
Replaceable battery (Lithium Polymer, 11.5 hours of continuous music playback
when fully charged.

HIMS International Blaze ET –User Manual
19
1.4 Physical Orientation to the Blaze ET.
The Blaze ET is a small, rectangular unit, similar in size and shape to a smart phone. It
weighs just 118g, is 59.3mm wide, 116.86mm long and 16.44mm thick.
Place the Blaze in your hand or on a desk or table top in front of you so that the keypad is
facing up and the long rectangular slot on the side of the unit is facing left.
<The Top
Face>
POWER On/Off
Button
INFO Button
NAVIGATION
Pad
CANCEL Button
NUMBER Pad
HOME Button
OCR Button
REVIEW Button
MENU Button

HIMS International Blaze ET –User Manual
20
1.4.1 The Top Face.
The top face of the unit contains the main keypad. At the top center is a slightly recessed
square depression. This is the Power On-Off button. To the left and right of the Power
button are the stereo speakers.
Below the Power button is a row of 3 buttons. From left to right, they are the Info button,
the Home button and the OCR button. The Info button announces Time and date, Power,
Wi-Fi and Bleutooth status. The Home button brings up the main “Home” menu from
anywhere on the unit. The OCR button launches the OCR program, press it again to
capture the image under the camera.
Below the program buttons is a circular navigation pad containing 5 keys: the Left, Right,
Up and Down arrows, and a small round button in the center which is the OK button.
Below the navigation pad is another row of 3 buttons: from left to right, these are Cancel,
Menu and review. The Cancel
button is used to exit a program, menu or dialog. The Menu button opens the specific
menu for the currently running program. The Review button repeats the currently-focused
text, or announces the title of the item currently being played, etc.
Below these keys is a standard 12 key telephone-style keypad. The keypad is used to
enter text, and to perform specific functions in each program on the unit.
On the very bottom of the front face are 2 LED's showing power and charging status, and
the internal microphone.
