INSTRUCTION MANUAL
Welcome to
the Pureit family
WITH A NEW
WATER DRINKING
EXPERIENCE

KNOW YOUR PUREIT ULTIMA
MINERAL RO+UV+MF PURIFIER
1
01. Digital display panel
02. Soft-touch button
03. Water dispensing outlet
04. Light assisted water dispensing
05. Pre-sediment filter
06. Inlet water tube
07. Reject water tube
08. Cleaning solution dispenser
5
6
8
1
4
3
7
2
Ultima

~Depends on your water quality. ^Pure refers to TDS range of water. *You can see the quality of water through the
Purity Indicator only when water is being purified or the purifier is in use. **Under test condition, Input TDS – 750
ppm, Turbidity – <1 NTU, Input Pressure – 10 psi, Input Hardness – 300 ppm, Temp. – Room temp. ***Assumption:
5 member family needing 20 litres of water every day (4 litres per person per day). ##Pureit Ultima Mineral
RO+UV+MF has highest purification rate across filters life when compared to leading RO brands (Kent Grand+ and
Aquaguard Enhance RO+UV) - Under test condition, Input TDS – 1500 ppm, Turbidity – <1 NTU, Input Pressure –
10 psi, Input Hardness – 700 ppm, Temp. – Room temp.
UNIQUE FEATURES OF PUREIT ULTIMA
MINERAL RO+UV+MF PURIFIER
2
1. Pre-Sediment Filter (SF)
Removes fine and coarse particulate
impurities/dirt and improves life of
the Carbon Filter.
2. Pre-RO Carbon Filter
Removes chlorine and organic
impurities such as harmful
pesticides. It also absorbs bad taste
and odor-causing organic
compounds from water.
3. Mesh Filter
Filters water further to ensure removal
of finer particulate impurities.
4. RO Membrane
Removes dissolved salts, hardness,
pesticides and heavy metals like
arsenic, lead and mercury. It also
removes microbial contaminants like
bacteria, virus, protozoa and cysts.
PUREIT ULTIMA MINERAL RO+UV+MF
PURIFIER’S ADVANCED PURIFICATION
PROCESS
This is a graphic
representation of filters
DIGITAL PURITY INDICATOR
Senses water quality upto 5000 times a second~to show* how pure^ your
water is.
100% RO PURIFIED WATER
All water passes through RO ensuring no mixing of purified and impure water.
Only RO can remove harmful chemicals like Lead, Mercury, etc.
HIGH WATER SAVING UP TO 45%**
Saving significant water when ordinary ROs save only 25%.
ADVANCED 7 STAGE PURIFICATION PROCESS
WITH RO+UV+MF
Every drop of water you drink is sweet and always safe.
7
LARGE STORAGE CAPACITY OF 10 LITRES
You will never run out of purified water.
10
DOUBLE PURITY LOCK: ADVANCE ALERT WARNS YOU
BEFORE FILTER EXPIRY AND AUTO SHUT OFF STOPS
WATER IF FILTER IS NOT CHANGED.
100% guarantee of safe and sweet water.
INCLUDES MINERAL CARTRIDGE
Enriches water by adding essential minerals like Calcium and Magnesium.
HI-SPEED PURIFICATION OF UP TO 28 LITRES/HOUR**
(HIGHEST AMONG LEADING ROS##)
Purifies water required for the entire day in less than 1 hour***.
24 L/HR
1. Pre-Sediment Filter (SF)
This is a graphic
representation of filters
1
2
3
4
5
6
7
5. UV Chamber
Acts as an additional stage of
purification to further inactivate
bacteria, virus and parasites to
deliver safe water.
6. Post RO Carbon Filter
This level of purification acts as a
polisher and enhances the taste of
purified water.
7. Micro Filtration (MF) Membrane
Micro Filtration (MF) Membrane is
added Post-RO and UV, which
ensures that the water is purified
thrice!

INSTALLING YOUR PUREIT ULTIMA
MINERAL RO+UV+MF PURIFIER
CLEANING & MAINTENANCE
TAKING CARE OF YOUR PUREIT ULTIMA
MINERAL RO+UV+MF PURIFIER
1. Use only the plug provided with the purifier.
2. The purifier should not be connected to any hot water tap. Do not run hot water
over 45°C through the purifier.
3. Water from waste water tube is not suitable for drinking. You can use that water
for gardening or to clean floors.
4. Store water only in the purifier and don’t use other bottles and containers. If you
do so, water may get contaminated.
1. The purifier should be installed by a trained Pureit technician.
2. It can be wall-mounted or used as a table top purifier.
3. The purifier should be placed in area which is free of ants/insects/other pests.
4. The purifier should be placed close to the plumbed inlet connection
(not more than 2 metres).
5. Do not install the purifier above any electric socket.
6. Avoid sharp bends to the pipes of the product.
7. Do not use an extension cord.
8. Make sure you test the input water TDS (Total dissolved salts) before installing
the purifier. The maximum input TDS should not exceed 2000 PPM.
Dispenser
1. Do not use detergents, soap or wet cloth to clean the external parts. Use dry and
soft cloth to clean the front cover. It is recommended to use a 3M mop cloth for this.
2. Clean the dispenser by using disinfectants like bleach/hypochlorite (50 PPM
available chlorine). Discard 2 litres of water after cleaning the dispenser.
3. Do not use any cleaning solution to clean the Digital Display Panel. Damages
ensuing thereof are not covered under warranty.
Storage Tank
1. Discard the water in the storage tank once in 15 days.
2. Drain the water in the storage tank if purifier is not used for 2 days.
3. Clean the storage tank once a month with disinfectant solution. To purchase this
solution, call us at 1860-210-1000 now.
4. How to clean the tank: Open the cleaning solution dispenser and put 1 ml of the
disinfectant solution (10–15 drops) into the storage tank. (Ensure the tank is full).
Drain the entire tank after 10 minutes.
5. No foreign material (like dust/ants/insects/other pests) should enter the storage
tank. The filtered water in the storage tank may deteriorate in the process.
6. The point-of-use reverse osmosis drinking water treatment systems addressed by
NSF-58 standard are designed to be used for the reduction of specific substances
that may be present in drinking water supplies (public or private) which are
considered to be microbiologically safe and are of known quality.
7. The output water may continue to have flora which are harmless and pose no
health hazard to normal healthy adults and children.
3
Disposal Guidelines (Electrical): To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate electrical items in this product such as power supply adaptor, control circuits,
LED panel, and wiring from other types of waste and recycle them responsibly to promote sustainable use of
material resources. Contact either the retailer where you purchased this product, or local government office for
details of where and how these items can be taken for environmentally safe recycling.

KEEP YOURSELF SAFE
CLEANING AND MAINTENANCE
1. Do not open the purifier for cleaning or for any replacements. This can be done
only by a qualified company personnel or an authorized agent.
2. Do not plug or unplug the power cord with wet hands to avoid any untoward
accident due to electrical shock or fire.
3. Do not splash the filtration system with water while cleaning.
4. Do not put heavy or sharp objects on the purifier.
5. Never put the cord near stoves or heaters.
6. If the power cord is damaged, the power adapter must be replaced and not used
7. Always switch-off the “Ball Valve” and electrical power in case you notice any
leakage from the purifier or you are out of home for more than 2 days.
8. Ensure input pressure is more than 10 PSI and less than 30 PSI ***
9. In case UV lamp breaks, carefully sweep all the fragments, wipe the area with a
wet towel, and dispose all the fragments including the used towel in a sealed
plastic bag. Open windows to allow room to ventilate. Do not use vacuum
cleaner. Hand over the bag to the service technician for proper disposal of the
same when he visits to replace UV lamp.
10.In case of any smoke or burning smell, switch-off power, remove the plug
immediately and call us at 1860-210-1000.
Sediment Filter
STEP 1 :
Close the ball valve
before opening ESF
housing for cleaning
STEP 5 :
Clean the Sediment Filter
under jet of water,
rub by hand / tap gently
to clean
STEP 6 :
After cleaning the Filter,
put it back in the housing
and then put the grey
coloured Carbon Sleeve
back into the housing
STEP 8 :
Connect the water
inlet tube to the housing
STEP 2 :
Remove the water
inlet tube which is
attached to the housing
STEP 3 :
Rotate the housing
clock-wise and remove it
completely from the cap
STEP 4 :
Take out the grey
coloured Carbon Sleeve
and the Sediment Filter
from the housing
STEP 7 :
Insert the housing inside
the cap and rotate it
anticlockwise to engage
the threads Ensure the
housing is tightened till
it’s original marking
4
ATTENTION
• Close the ball valve before opening SF housing for cleaning.
• Please do not use any abrasive / pointed tool to clean the Sediment
Filter as it may damage the Sediment Filter.
• In case you observe the rubber ring is dirty, clean the rubber ring &
fix it on the housing again properly.
• Clean the inner portion of the housing as well.
• If required, a Spanner for opening ESF housing can be bought from
Pureit service technician.

TECHNICAL SPECIFICATIONS
5
Pureit Ultima Mineral RO+UV+MF
Height ~485 mm
Width ~360 mm
Depth ~311 mm
Weight of Pureit Ultima Mineral RO+UV+MF ~9.5 kg
Flow rate* Approximately 28 litres per hour
Storage tank capacity 10 litres**
7 -Stage Purifying Technology
Membrane type
Pump type Diaphragm pump, 24V dc
Thin-film composite spiral wound
% Recovery* Typically 45%
TDS reduction*** 90% (min)
Inlet Water Temperature 10°C to 40°C
Input water pH range 6.5-8.5
Rated Power 60 Watts
Pressure rating 10-30 PSI****
Rated Voltage 100-240V AC 50/60 Hz (Device can withstand voltage
fluctuation from 100 to 300 V AC.)
Material of construction for plastic parts Food safe, non-toxic, engineering grade plastics
Length of Power Cord 1.5 metres
Total Dissolved Solids in input water Upto 2000 mg/lit##
Total hardness of input water 500 mg/lit (max.)
Iron in input water 0.3 mg/lit (max.)###
Turbidity of input water 1NTU (max.)
PP Melt Blown Pre-Sediment Filter, Pre-RO Carbon Filter,
Mesh Filter, Reverse Osmosis Membrane, UV Chamber,
Post-RO Carbon Filter and Micro Filter
Germkill Kit™
Germkill Kit - 1
Pre-Sediment Filter – 1 Number
Material of construction Food safe, non-toxic, engineering-grade plastics
Germkill Kit - 2
Mesh Filter – 1 Number
Pre-RO Carbon Filter – 1 Number
Pre-Sediment Filter – 1 Number Pre-RO Carbon Filter – 1 Number
RO Membrane – 1 Number TDS Mondulator – 1 Number
Post-RO Carbon Filter – 1 Number MF Membrane – 1 Number
Germkill performance standard
Meets stringent international criteria for
microbiologically safe drinking water – e.g.,
Environmental Protection Agency (EPA), USA
* Permeate flow rate and recovery are based on standard test conditions and may vary depending on input water quality, TDS,
pressure and life of Filter elements.
** 10 litres of storage only with running water. Or else 9.2 litres of water dispensing.
*** Input water quality and TDS content are important determinants of output water quality.
**** If input pressure exceeds 30 PSI, please install a company provided pressure reducing valve at an additional cost. If the pressure is
lesser than 5 PSI then you need to buy ‘Pressure enhancing pump’ at an additional cost. Device should not be installed in a house
where input pressure is greater than 60 psi.
# Technical specifications are subject to change or improvement without prior notice.
## In case the TDS is >1000 ppm, a company provided anti-scalant is recommended to be installed, this has to be
purchased at extra cost.
### If the iron content in the input water is more ,it is recommended to install a company provided iron filter.
UNDERSTANDING THE DIGITAL DISPLAY PANEL
Indicator Indicator Status Frequency of Indication Indication
Tank Full
No light N/A Tank is not full
Blue N/A Tank is full
TANK
FULL
Purity Indicator
Blue bars on the left and
right of the Digital Panel
When there is input water
in the purifier
Shows the indicative range of TDS in the input and
output water respectively. The level of these bars will
change depending on the input water
~Purity refers to the TDS range of water. TDS (Total Dissolved Solids) indications are measured on the basis of conductivity of
output water and this conductivity depends on 1) mobility of ions 2) valency of ions 3) concentration of ions and 4) the
temperature of water. The display of TDS values is an indicative range and not an absolute value. Purity Indicator will only function
when there is input water in the purifier. In case there is no input water in the purifier, then the Digital Display Panel will show an
error and there will be one band lit on either side of the panel. This is a default state indication and does not reflect the Purity
Level of water. You can see the quality of water through the Purity Indicator only when water is being purified or the purifer is in
use. Quality here refers to the TDS range of water.
#After every 300 hours of pump running time or 360 days of clock time, whichever is earlier, the respective Germkill Kit needs to
be changed.
Every 300 hours of pump running time typically gives 4000 litres of purified water under test conditions of 10 PSI input pressure,
750 ppm TDS and 25°C temperature. Any variations from the test conditions will lead to variations in the ltered life. While the
Germkill Kits and the Sediment Filter have a fixed replacement schedule, you might be required to clean/change the SF in the
interim depending on the quality of your input water.
Pureit Ultima Mineral RO+UV+MF has been designed in such a way that during the first time startup of the device, the “Tank Full”
indicator will blink for 15 minutes (maximum) and then normalise for usage.
Germkill KitTM 1
Life Indicator
Germkill KitTM 2
Life Indicator
Extremely low
Very low
Low
Moderate
High
Very high
Low
Moderate
Moderate
High
Very high
Extremely high
TDS range
represented
TDS range
represented
Purity~Indicator Purity~Indicator
TDS IN
TDS OUT
TANK
FULL
GKK 1
GKK 2
SF
SF
Blue N/A Pre-Sediment Filter is safe to use
SF (Central bar of the
GKK-1 / inner circle)
This indicates that the life of the Pre-Sediment Filter will
end soon.Please get your Pre-Sediment Filter cleaned/
replaced*. If the sediment filter is not cleaned/replaced
is time,it may affect the performance of the purifier
Central bar of the GKK-1 circle (inner
circle) will blink Blue and the Call
Centre number (1860-210-1000) will
be displayed on the panel
177-180 days of clock time or 147-150
hours of pump running time,whichever
is earlier after device installation or
GKK-2 replacement.
Blue N/A Pre-Sediment Filter is safe to use
SF (Central bar of the
GKK-2 / outer circle)
This indicates that the life of the Pre-Sediment Filter will
end soon.Please contact the Pureit helpline and get your
Pre-Sediment Filter replaced* If the sediment filter is not
replaced in time, it may affect the performance of the purifier
Central bar of the GKK-1 circle
(inner circle) will blink Blue and the
Call Centre number (1860-210-1000)
will be displayed on the panel
525-540 days of clock time or 450 hours
of pump running time, whichever is
earlier after GKK-1 replacement
Blue N/A Gkk-1 is safe to use
GKK-1
GKK-1 life will end soon. Please contact the Pureit
helpline to replace your GKK-1
Last bar of the GKK-1 circle (inner
circle) blinks, ‘CHANGE GKK’ blink
at the centre of the panel and the
call centre number ‘1860-210-1000’
illuminated at the bottom of the panel
After every 345 days of clock time or
285 hours of pump running time,
whichever is earlier, post-device
installation or GKK-2 replacement
GKK-1 life is completed and must be replaced. At this
point, Auto Shut Off shuts the water flow ensuring you
don’t drink unsafe water even by accident
Last bar of the GKK-1 circle (inner
circle) blinks, ‘CHANGE GKK’ static
at the centre of the panel and the
call centre number ‘1860-210-1000’
illuminated at the bottom of the panel
After every 360 days of clock time or
300 hours#of pump running time,
whichever is earlier, post-device
installation or GKK-2 replacement
Not visible N/A Purifier is safe to use
Guided
Alert System
Indicates where the fault is in the purifier. At this point,
Auto Shut Off shuts the water flow ensuring you don’t
drink unsafe water even by accident. Please contact
the Pureit helpline to repair the fault.
Red band illuminated In case of a specific electrical fault
Blue N/A GKK-2 is safe to use
GKK-2
GKK-2 life will end soon. Please contact the Pureit
helpline to replace your GKK-2
Last bar of the GKK-2 circle (outer
circle) blinks, ‘CHANGE GKK’ blink
at the centre of the panel and the
call centre number ‘1860-210-1000’
illuminated at the bottom of the panel
After every 705 days of clock time or
585 hours of pump running time,
whichever is earlier, after device
installation or previous GKK-2
replacement
GKK-2 life is completed and must be replaced. At this
point, Auto Shut Off shuts the water flow ensuring you
don’t drink unsafe water even by accident
Last bar of the GKK-2 circle (outer
circle) blinks, ‘CHANGE GKK’ static
at the centre of the panel and the
call centre number ‘1860-210-1000’
illuminated at the bottom of the panel
After every 720 days of clock time or
600 hours of pump running time,
whichever is earlier, after device
installation or previous GKK-2
replacement

FAQ S
Pureit Helpline
1860-210-1000
www.pureitwater.com
What is the storage capacity of Pureit Ultima
Mineral RO+UV+MF?
Pureit Ultima Mineral RO+UV+MF has a
storage tank capacity of 10 litres with running
input water. With no continuous input water, the
average dispense capacity is 9.2 litres. The
process of filling the storage tank is fully
automatic and when you take water out of the
tank, the purification process automatically
starts and refills the storage tank.
How much time it takes to purify water in
Ultima Mineral RO+UV+MF?
Ultima Mineral RO+UV+MF can purify water
upto 28 litres per hour. However, the time taken
to purify depends on the life of the Filters, the
input water pressure, TDS and other impurities
present in water.
How will I get new Consumables/Membranes
replaced?
You need to call the Pureit Helpline and order
for a Germkill Kit. Our technician will visit your
place and replace the Germkill Ki at a nominal
cost.
What should I do if there is no water being
dispensed from the tap?
In case you cannot dispense water from the
tap, then you need to first check whether the
power supply is on. If it is on, then check if
there are any fault indicators illuminated, or
“CHANGE GKK” and the Call Centre Number is
illuminated on the Digital Display Panel. Call
the Pureit helpline and get either the fault
resolved or Germkill Kit replaced.
If none of these lights are illuminated on the
Digital Display Panel, then check if the Ball
Valve is closed. If none of these cases are true,
then please call Pureit Helpline for assistance.
Can I use any type of water to purify through
my Pureit Ultima Mineral RO+UV+MF?
Pureit Ultima Mineral RO+UV+MF will purify
“potable” water for removal of hardness and
other impurities to give you safe drinking water.
If the input water has impurities normally not
present in drinking water (high iron/ turbidity/
microbial contamination etc.) or water is from
unknown source (river/lake/pond /borewell etc.)
then suitable pre-treatments may be required.
The Advance Alert System did not give me a
warning before the purifier stopped working.
Why is it so?
There may be several reasons for this:
While the Germkill Kits and the Pre-Sediment
Filter have fixed replacement schedules,
depending on your input water quality the
Pre-Sediment Filter might need a replacement
or cleaning even before the purifier gives you
an alert. In such cases, please contact Pureit
helpline on 1860-210-1000 and get the
Pre-Sediment Filter cleaned or replaced. The
purifier will communicate the alert only if the
purifier is in a switched on condition during the
scheduled alert time. Post the completion of the
scheduled alert time, Auto Shut off of water will
be activated automatically for GKK, even if the
purifier is in a switched off condition.
Does Pureit Ultima Mineral RO+UV+MF remove
arsenic, flouride and nitrates?
Like ions, the RO technology can also remove
arsenic, flouride and nitrates
Can I use the reject water? What can I do with
the Reject Water?
It can be used for gardening or cleaning floors,
but is not fit for consumption.
What should I do if any part of the purifier is
broken?
Please call the Pureit Helpline. We will guide
you on the repairs required. You would need to
buy the replacement parts at an additional cost.
What should I do if there is a leakage from the
purifier?
Turn off the Ball Valve and switch off the power,
if you find any failure. Check for any visually
improper fitments and then call our Pureit
Helpline at 1860-210-1000 and register a
service request.
How long the stored water in Pureit Ultima
Mineral RO+UV+MF can be used for drinking?
You can use stored water for 2 days. If it is not
used for more than 2 days we advice you to
discard that water, refill and then consume.
How do I know when I have to change my
Germkill Kit?
Pureit Ultima Mineral RO+UV+MF has a Digital
Display System that will flash a message
“Change GKK” to prompt you to call the call
centre to get the respective GKK changed,
whenever the life of the Germkill Kit is about to
get over. (Please refer to the "Understanding
The Digital Display Panel" section of this user
manual, for further details).
Can the Pre-Sediment Filter or the other filter
parts choke before the Advance Alert?
While the Germkill Kits and the Pre-Sediment
Filter have a fixed replacement schedule, you
might be required to change the filters in the
interim depending on the quality of your input
water.
Should the tap flow rate be very less or if it is
taking too long for the tank to fill, then please
contact the Pureit helpline at 1860-210-1000 to
change the membranes. These extra visits will
be chargeable as per T&C.
Will I be able to dispense water from the
purifier in case the red band of “Guided Alert
System” gets illuminated OR the water is Auto
Shut-Off?
In case any red band of "Guided Alert System"
illuminates, the purification process will stop,
until the fault is fixed. But, you will be able to
dispense out the water available in the storage
tank by pressing the Soft-Touch button. Once
pressed, the button will operate and dispense
for 2 minutes or till the water is available in the
tank or whichever is earlier.
For how long can I continuously dispense
water?
Once pressed, Soft-Touch button dispenses
water for 5 minutes and it automatically stops
dispensing after that. In case you need more
water, you need to press the button again. You
can stop the flow of water in between by
pressing the Soft-Touch button again.
Will the Guided Alert System indicate any
leakage complaints?
No. It only indicates key electrical faults.
What should I do if the water from the purifier
tastes unusual or the purification is taking
more time?
Please call the Pureit helpline at
1860-210-1000. Our technician will visit you
and help you resolve all the issues.
Why is the output water blue in colour?
The blue colour in the output water is because
of the lighting system built in the purifier.
What are the ideal usage conditions for an RO
technology based water purifier?
The point-of-use reverse osmosis drinking
water treatment systems addressed by NSF-58
standard are designed to be used for the
reduction of specific substances that may be
present in drinking water supplies (public or
private) which are considered to be microbio-
logically safe and are of known quality.
What do I do if a Guided Alert System band is
illuminated?
In case of any electrical fault, a segment of the
red band will illuminate to indicate where the
fault is. If it is illuminated, please call the Pureit
Helpline at 1860-210-1000 for assistance.

To know more
Contact Pureit helpline number
1860 210 1000
Or Visit: www.pureitwater.com
