HIRED-HAND Econo-Flow User manual

INSTALLATION
1. Fan may be securely mounted upright in wall, suspended
from ceiling, or hinged from wall or post.
In Wall: Refer to Framing Diagram on reverse side.
Suspended: Install 3/8" bolts with nuts, or 3/8" eye
screws in ceiling at desired mounting location. Hang fan
with chain and S-hooks or with winch, pulleys, and cable.
2. Fan is provided with wire guards for your protection.
National safety codes require that guards be installed
if fan is installed within 7 feet of floor or in reach of
personnel or livestock.
FAILURE TO GUARD MOVING PARTS MAY RESULT
IN SERIOUS INJURY OR DEATH.
3. Unit is now ready for operation.
IMPORTANT: INSPECT FAN FOR ANY OBJECT THAT
MAY OBSTRUCT BLADE ROTATION.
Disconnect power source before installing
or servicing fan. Failure to disconnect power
source can result in property damage, serious
injury, or death.
CAUTION
1. Inspect fan for damage in transit. Check for loose,
missing, or damaged parts..
BEFORE INSTALLING FAN
MAINTENANCE
1. Read WARNING statements before proceeding.
2. Blades, motor and wire guards should be
cleaned periodically to decrease vibration and
ensure maximum fan life. DO NOT SPRAY
MOTOR WITH WATER OR CLEANING
FLUIDS - remove dirt with a dry brush or
compressed air.
3. Fan performance may be greatly reduced by
damaged or dirty shutter. Clean and inspect
shutter periodically to ensure maximum fan
performance.
WARRANTY
Your Econo Flow fan has been manufactured with the
finest materials and components available and is backed
by a one year warranty against electrical and mechanical
defects in material and workmanship. If this fan fails to
operate during this period, return it prepaid to place of
purchase for repair or replacement without charge at the
manufacturer's option.
Damage by accident or abuse is not covered by this
warranty.
This warranty gives you specific legal rights and you may
have other rights that vary from state to state.
WARNING
HAZARDOUS ROTATING FAN BLADE
!
Do not operate fan until you are completely
familiar with its operation. READ ALL
INSTRUCTIONS PRIOR TO INSTALLATION.
VOLTAGE 240VAC - 50Hz - Single Phase
CURRENT 4.4 Amps (Maximum)
(See Reverse Side for Parts List)
THIS FAN MAY START AT ANY TIME
!
WARNING
Hired-Hand, Inc.
1733 Co Rd 68
Bremen, AL 35033
ph: 205-287-1000
fax: [phone]
Main Office:
410 Lawler Ave.
Iowa Falls, IA
50126
ph: 515-648-4213
fax: [phone]
Midwest Plant:
EF-36P Belt Drive 1 Hp 50Hz 1 Phase Manual 4801-0261
When this fan is used in a life support ventilation system
where failure could result in loss or injury, the user should
provide adequate backup ventilation or accept the risk of
such loss or injury.
WARNING !

FRAMING DIAGRAMPARTS LIST
EXPLODED ASSEMBLY DRAWING
EF-36P Belt Drive 1Hp 50Hz 1Phase Manual 4801-0261
Replacement Parts
Part No. Description
1016-0101 BEARING flange mount 1" w/collar
1022-2633 BELT A-48
1022-2998 BELT power twist
0404-2932 GALVANIZED_STEEL bracket bent hanging
0404-2946 GALVANIZED_STEEL bracket flat hanging
0404-2913 GALVANIZED_STEEL gusset cabinet corner
1019-2417 KEY Shear 1/4"X1/4"X1" steel
3017-1233 MOTOR 1725 RPM 1Hp 230V
6403-2420 PROPELLER GS EF-36-B 4 blade
1011-2413 SHEAVE AK-104X1" with 2 set screws
1011-2641 SHEAVE AK-46X5/8
1024-2650 SPRING formed compression 3/8"IDX2-1/2"X.11
0411-2110 STEEL shaft 1"X7-5/8"
0011-0118 WIRE_GUARD 1X2 41.75X41.75X15g
